USBDÜSEN NOZZCAM User manual

Im Eisenhütle 4 | D-74626 Bretzfeld | Phone [phone] | www.usbduesen.de
Operating instructions
NOZZCAM™

2
USB Düsen GmbH
Im Eisenhütle 4
D-74626 Bretzfeld
Phone: [phone]
E-mail: [email protected]
Web: www.usbduesen.de
Contact

3
Table of contents
1. General 4 - 6
1.1 Information regarding these instructions 4
1.2 Explanation of symbols 4 - 5
1.3 Copyright protection 6
1.4 Warranty terms 6
1.5 Customer service 6
2. Safety 7 - 14
2.1 Intended use 7
2.2 Responsibility of the user 8
2.3 Personnel requirements 9
2.4 Personal protective equipment 10
2.5 Basic hazards 10
2.5.1 General hazards at the workplace 11 - 12
2.5.2 Electrical hazards 12 - 13
2.5.3 Mechanical hazards 13 - 14
3.Technical data 15 - 17
3.1 General Information 15 - 16
3.2 Connection values 16
3.3 Power ratings 16
3.4 Operating conditions 17
3.5 Name plate 17
4. Overview 18 - 23
4.1 Scope of delivery 18
4.2 Optional accessories 19
4.3 Control elements 20 - 21
4.4 Connection points 22
4.5 Interfaces 23
5. Unpacking,
transporting and storing 24 - 26
5.1 Symbols on the packaging 24
5.2 Unpacking and checking the delivery 24 - 25
5.3 Transporting and storing the unit 26
6. NOZZCAM™ / Bending 27
function
7. Operation 28 - 42
7.1 Switching on the unit 29 - 33
7.2 Switching off the unit 34 - 35
7.3 Operating the digital video recorder 36
7.3.1 Starting the recording 36
7.3.2 Ending the recording 36
7.3.3 Viewing the last video recorded 36
7.3.4 Returning to the live image 36
7.3.5 Deleting videos 36
7.4 Advancing the camera 37 - 40
7.5 Controlling the light 41
7.6 Resetting the electronic
meter measurement 42
8. Cleaning,
care and maintenance 43 - 46
8.1 Safety instructions for maintenance 43
8.2 Maintenance schedule 43
8.3 Cleaning the unit,accessories
and camera head 44
8.4 Servicing the unit,
accessories and camera head 45
8.4.1 Servicing the camera head 46
9.Troubleshooting 47
10. Disposal 48 - 49
11. Index 50 - 51

4
General
1 General
1.1 Information about this manual
This manual provides information on safe and efficient handling of the unit.This manual is part of the
unit and must remain in the immediate vicinity of the unit and accessible to personnel at all times.
The personnel must have read this manual carefully and understood it before beginning any work.
Complying with all safety and handling instructions in this manual is a basic prerequisite for safe work.
Local accident prevention regulations and general safety guidelines for the field of application of the unit
also apply.
The figures in this manual are intended to assist in basic understanding; the design of the actual unit
may differ somewhat.
1.2 Explanation of symbols
Safety instructions The safety instructions in this manual are identified by symbols.
The safety instructions are preceded by signal words that express the severity of
the hazard.
To prevent accidents,personal injuries and property damage,always heed the
safety instructions and work cautiously.
DANGER!
This combination of symbol and signal word identifies an
imminently dangerous situation that will result in severe or fatal
injury if it is not avoided.
WARNING!
This combination of symbol and signal word identifies a
potentially dangerous situation that can result in severe or fatal
injury if it is not avoided.
CAUTION!
This combination of symbol and signal word identifies a
potentially dangerous situation that can result in minor or slight
injury if it is not avoided.

5
General
ATTENTION!
This combination of symbol and signal word identifies a
potentially dangerous situation that can cause property damage
and damage to the environment if it is not avoided.
The symbol identifies useful tips and recommendations as well
as information for efficient and trouble-free operation.
Tips and recommendations
To bring attention to specific hazards,the following symbols are used
in safety instructions:
Special safety instructions
DANGER!
This combination of simple and signal word identifies
electrical hazards.Failure to heed the safety
instructions poses the risk of severe or fatal injuries.
Signs used in this manual The following signs are used in this manual to identify handling
instructions,describe results,lists,cross-references and other elements:
Sign Explanation
Identifies step-by-step handling instructions.
Identifies a condition or automatic consequence resulting
from performing a step.
Identifies cross references to sections in this manual and to
related documents.
Identifies lists and entries in lists without a specific order.
Identifies designations of pushbuttons, on-screen buttons and
other control elements.
[Taste]

6
General
1.3 Copyright protection
This manual is copyrighted and intended solely for internal purposes.
Providing this manual to third parties,reproduction in any manner or form,including excerpts,as
well as use and/or conveyance of its contents except for internal purposes are not allowed without
written approval.
The user shall be held liable for damages arising from contravention.
The right to make further claims is reserved.
1.4 Warranty terms
The warranty terms are contained in the General
Terms and Conditions of Business of the manufacturer.
1.5
For technical information, contact USBDÜSEN GmbH. For contact data,see p. 2.
Please also note that our employees are always interested in receiving new information and hearing
about your experience with our products that can contribute to improving these products.
Customer service

7
Claims of any kind resulting from misuse will not be honored.
Safety
2 Safety
This section provides an overview of all important safety aspects for optimal protection of personnel as
well as safe and trouble-free operation.
Failure to follow the handling instructions and heed the safety information in this manual can result in
serious hazards.
2.1 Intended use
The unit has been designed and built solely for the intended use described here.
The color,pipe and sewer inspection camera serves strictly for visual inspection of wastewater sewer
lines,wastewater tanks, heating and cooling channels,ventilation shafts,electrical installation shafts,
chimneys,wells,wastewater drop pipes and in-ground wastewater lines when used with accessories
provided by the manufacturer in areas that do not contain potentially explosive atmospheres.
Complying with all information in this manual is also considered an aspect of the intended use.
Every use beyond or differing from the intended use constitutes misuse.
Misuse WARNING!
Danger resulting from misuse!
Misuse of the color, pipe and sewer inspection camera
can result in hazardous situations.
- Never use the unit in pipe runs with non-return flaps.
- Never use the unit in areas with potentially explosive atmospheres.
- Never operate the unit in close proximity to combustible liquids
and/or gases.
- Never use the unit with accessories from anyone but the manufacturer.
- Never use the unit without a PE protective conductor.
- Never expose the unit to precipitation.
- Never operate the unit outdoors or under similar conditions without
a 30-mA residual-current-operated device at the power source.
- Never operate the unit in a moist environment and/or place it in
water or other liquids.
- Never connect the unit to a receptacle without a protective ground
contact.

8
Safety
2.2 Responsibility of the operator
Operator The operator is the entity or person who operates the unit for commercial or business
purposes themselves or provides it to a third party for use/application and during
the operation of which bears the statutory product responsibility for protection of the
user, personnel or third party.
Obligations of
the operator
The unit is used for commercial purposes.
The operator of the unit is thus subject to the statutory obligations for safety in the
workplace.
In addition to observance of the safety information in this manual,compliance with
the applicable safety,accident prevention and environmental protection regulations
for the field of application of the unit is required.
The following applies in particular:
The operator must become familiar with applicable workplace safety regulations
and identify through a risk assessment the additional hazards that arise because
of the special work conditions at the place of use of the unit.They must be
incorporated in the form of operating instructions for use of the unit.
During the entire service life of the unit,the operator must review whether
the operating instructions prepared comply with all current regulations and,if
necessary,update the operating instructions.
The operator must regulate and specify clearly the responsibilities for
installation,operation,troubleshooting,maintenance and cleaning.
The operator must ensure that all employees who handle the unit have read and
understood this manual.In addition, the operator must train the personnel at
regular intervals and inform them of the hazards.
The operator must provide the personnel with the required protective equipment
and mandate that the required protective equipment be worn.
In addition,it is the responsibility of the operator to ensure that the unit is always in
technically perfect condition.
Accordingly, the following applies:
The operator must ensure that the maintenance intervals described in this
manual are observed.
The operator must have all safety devices checked regularly for proper operation
and completeness.

9
Safety
2.3 Personnel requirements
WARNING!
Risk of injury in case of inadequate qualifications of personnel!
If unqualified personnel carry out work on the unit or linger in
the danger zone of the unit,there is a risk of severe injury and
significant property damage.
- Allow only qualified personnel to work on the unit.
- Keep unqualified personnel away from danger zones.
These operating instructions list the qualifications required by personnel for the
various activities:
Electrical technician/electrician
On the basis of their technical training, knowledge and experience as well as
familiarity with applicable standards and regulations,electrical technicians/
electricians have the ability to perform work on electrical systems independently and
avoid possible hazards.
The electrical technician/electrician has been specially trained for their work
environment and knows the relevant standards and regulations.
The electrical technician/electrician must comply with the applicable regulations
regarding accident prevention.
Technical personnel
On the basis of their technical training, knowledge and experience as well as
familiarity with applicable standards and regulations,technical personnel has the
ability to perform the assigned work independently and avoid possible hazards.
Manufacturer
Certain work may only be performed by our technical personnel.Other personnel is
not authorized to perform this work.To have the necessary work performed,contact
our service department (address on p.2).
Only individuals who can be expected to perform their work professionally are
acceptable as personnel.Individuals whose ability to respond is compromised,
e.g.by drugs,alcohol or medications,are not acceptable.
Comply with applicable age- and profession-specific regulations when selecting
personnel for the worksite.

10
Safety
2.4 Personal protective equipment
Personal protective equipment protects the personnel from dangers that can adversely affect their
health and safety when working.
Personnel must wear personal protective equipment when carrying out various tasks on and with
the unit.This equipment is pointed out separately in the individual sections of this manual.
The personal protective equipment is explained in the following:
Before beginning the respective task,always put on the personal protective equipment
required in the various sections of this manual.
Follow the instructions regarding personal protective equipment posted in the work area.
Description of personal protective equipment
Chemical-resistant protective gloves
Chemical-resistant protective gloves are used to protect the hands from
exposure to aggressive chemicals.
Protective goggles
Safety goggles are used to protect the eyes from flying objects and
sprayed liquids.
2.5 Basic hazards
The following section lists residual risks that may be posed by the unit and which have been
identified through a risk assessment.
To reduce health hazards and avoid dangerous situations,observe the safety instructions
presented here as well as the safety instructions in additional sections of these operating
instructions.

11
Safety
2.5.1 General hazards at the workplace
Open access to pipe WARNING!
Risk of falling into open access to pipe!
When introducing the camera,it is necessary to open
the access to the pipe.If the work area around the open
access to the pipe is not blocked and/or insufficiently
marked,this can result in a life-threatening fall into the
open access to the pipe.
Severe to fatal injuries can be the consequence.
- Block off the work area around the open access to
the pipe and mark it visually (e.g.with signal tape,
flexible barriers and/or pylons).
- Make sure that no unauthorized individuals can enter
the work area and danger zone.
- Properly close access to the pipe once all work has
been completed.
Microbiological pollution WARNING!
Risk of illness from exposure to microbiologically
contaminated deposits!
During work in sewers,the unit,accessories,personal
protective equipment and/or cleaning utensils come
into contact with microbiologically contaminated
deposits that can cause extremely severe to fatal
illnesses.
- Make sure that no unauthorized individuals can enter
the work area and danger zone.
- Always wear chemical-resistant protective gloves.
- Do not eat,drink and/or smoke while working.
- Thoroughly clean the unit,the accessories and the
personal protective equipment after each use.
- Clean and/or properly dispose of cleaning utensils
that are no longer needed in an environmentally
responsible manner.

12
Safety
Dirt and objects
lying around CAUTION!
Risk of injury from dirt and objects lying around!
Dirt and objects lying around present slipping and tripping
hazards.A fall can result in injuries.
- Always keep the work area clean.
- Remove no longer needed objects from the work area,
especially from the floor.
- Always ensure adequate lighting at work area.
- Always comply with official regulations for working in
shafts/sewers.You are obliged to carry a gas warning
device when entering a shaft and an air supply system
for a sewer.
2.5.2 Electrical hazards
Electricity DANGER!
Life-threatening electrical hazard!
Contact with live components presents an immediate life-
threatening hazard from electrocution.Damaged insulation
or individual components can be life- threatening.
- During all work on the electrical connection and on
electrical cables,switch off the unit and ensure that no
voltage is present.
- Allow only electrical technicians/electricians to work on
electrical equipment.
- Connect the unit only to a receptacle with a VDE
protective contact.
- In the event of damage to the power cable,immediately
disconnect power by pulling the power plug out of the
receptacle and initiate repairs.
- Use only tested, undamaged power cables.
- Always grasp the power plug when pulling,never the
power cable.
- Keep the cable length in mind;consider use of a strain relief.
- Keep moisture away from live components.
Exposure to moisture could result in short-circuits.
- Never operate the unit in a moist environment and/or
place it in water or other liquids.
- Never operate the unit outdoors or under similar
conditions without a 30-mA residual-current-operated
device at the power source.
- Never bypass fuses or disable them.
When replacing fuses,always use the correct amperage rating.
- Pull the power plug when performing all maintenance work.
- If the insulation is damaged,immediately disconnect the
power source and initiate repairs.

13
Safety
Rechargeable batteries (1)
(1) optional accessory
WARNING!
Risk of injury from incorrect handling of rechargeable
batteries!
Rechargeable batteries that are handled improperly
may explode or leak harmful fluid.The liquid can
cause chemical burns on the skins,severe poisoning if
swallowed and blindness if it comes into contact with
the eyes.
- Use only an appropriate charger to charge such batteries.
Always place the batteries in the charger with the poles
(+/-) in the correct orientation.If the battery does not fit
properly, never use force when attempting to insert it.
- Never short-circuit the contacts (plus and minus poles)
of the battery.
- Never expose the battery to wetness or moisture
(rain,salt water, liquids).
A moist or wet battery must not be used or charged
under any circumstances.
- Never use, charge or store the battery in areas where
a potentially explosive atmosphere exists or where high
temperatures can occur.
2.5.3 Mechanical hazards
Crushing hazard when using the advancing reel
WARNING!
Risk of fingers being crushed in the cable guide!
There is a risk of fingers being crushed in the cable
guide on the advancing reel when retracting and
extending the pushing cable.The result may be broken
bones and bruised fingers.
- Retract and extend the advancing cable slowly.
- Always wear protective gloves.
- Keep fingers away from the cable guide when retracting
and extending the cable.
- When retracting and extending the pushing cable,
always hold the advancing reel securely by the handle.

14
Safety
Rotating advancing reel WARNING!
Risk of injury during use with rotating
advancing reel!
The advancing reel rotates while the pushing cable
is advanced and retracted. Reaching into the rotating
advancing reel can cause severe injuries.
- Always wear protective gloves.
- When retracting and extending the pushing cable,always
hold the advancing reel securely by the handle.
- Retract and extend the advancing cable slowly.
- Always use the quick-clamp lever to stop/brake the
rotating advancing reel. Never reach directly into the
advancing reel with your hands.
ATTENTION!
Improper use in pipe runs with non-return flaps!
Non-return flaps in pipe runs automatically drop closed
after the camera head has been inserted, preventing
retraction of the camera head.This results in blockage
of the pipe,time-consuming and expensive repair work
on the pipe,including severe damage and possibly even
destruction of the unit.
- Never use the unit in pipe runs with non-return flaps.
- As soon as a non-return flap is recognized on the display of
the LCD monitor,interrupt the visual inspection immediately
and retract the camera head from the pipe run.
Use in pipe runs with
non-return flaps
Broken glass on
camera objective ATTENTION!
Risk of glass breakage from objects in the object
being inspected!
If the camera head encounters an obstruction during the
visual inspection,this can result in serious damage and/or
breakage of the protective glass on the camera objective.
- Move the camera head slowly and cautiously through the
object being inspected.
- As soon as an obstruction is recognized on the display
of the LCD monitor,interrupt the visual inspection and
remove the obstruction from the object being inspected so
that the camera’s advance can proceed without difficulty.

15
Technical data
3 Technical data NOZZCAM™
3.1 General information
Color camera Item Value Unit
Weight
Ø NOZZCAM™
Camera housing material
0.5
43
Stainless steel
kg
mm
Dual-power lighting - 10 Ultra-white light LED
- 5 SMD-LED
Automatic white balance
Light sensitivity approx.0.01 Lux
Objective:Wide angle 87° with nano coating
2 x front jet nozzles,2 x steering nozzles 45 °,5 x rear nozzle inserts
Color camera chip CCD Sony - 480 TV lines
- Resolution:752 x 582 pixels
Drum Item Value Unit
Weight (with camera)
Ø inside
Low-temperature resistance
Height
Depth (with LCD monitor)
Length
Ø outside
Wall thickness
High-temperature resistance
Width
9.5
5
100
34
31
26
60
6
1
-20
kg
°C
°C
m
mm
mm
mm
cm
cm
cm
Manual hand brake
6-pole slip ring
Pushing cable plastic sheath material:
Polypropylene and polyethylene

16
Technical data
Screen aspect ratio
Video output
Screen resolution
Video input
4:3
16/0.5
960x234
1
Pixels
Ω/W
Vp-p
Aluminum glare shield
Aluminum housing
Electronic meter inset in image with zeroing
Color system:NTSC/PAL
Contrast ratio:350 CD/m2:350:1
Color:TFT-LCD (AU)
Backlighting:Cathode filament
3.2
3.3
Connection values
Performance values
Control box
LCD monitor
Item Value Unit
Voltage
Frequency
Power consumption
230/12 (1)
50
80 - 300
Hz
V
W
(1) Battery mode
Item
Item
Value
Value
Unit
Unit
Voltage
Frequency
Power consumption
Max.water tightness
Max.operating pressure of the
high-pressure pump
12
50
7
5
200
Hz
V
W
bar
bar
Item Value Unit
Screen diagonal 8 (20.32) Inch (cm)
TFF monitor

17
Technical data
3.4
3.5
Operating conditions
Name plate
Item
Item
Value
Value
Unit
Unit
Temperature range
Relative humidity, maximum
Maximum continuous operating time
Pause before next use
0 to +40
8.3
80
5
°C
%
h
min
Duration
The name plate is located inside the housing on the
electric motor and contains the following information:
Manufacturer’s address
Machine designation+ number
Shaft revolutions per minute
CE mark
Power rating
IP protection rating
Fusing
Voltage and frequency
Duty cycle

18
Overview
4 Overview
4.1 Scope of delivery - NOZZCAM™
Fig.1:Overview
NOZZCAM™ Cleaning and camera unit with
dual-power lighting
( section 7.4“Advancing the camera”
on p. 37)
Handle ( section 7.4“Advancing the
camera”on p.37)
Cable drum ( section 7.4“Advancing the
camera”on p.37)
230-V power cable ( section 7.1
“Switching on the unit”on p.29)
8”LCD monitor with color display and glare
shield Control box with rechargeable battery
( section 4.3“Control elements”on p.20 ff.)
Membrane keypad
1
2
3
4
5
6
7
2
3
1
6
7
5
4

19
Overview
4.2 Optionally available accessories
Membrane keypad for DVR
Designation
Designation
Ordering number
Membrane keypad for DVR
12-V battery pack
D.1000-Fl
R.1000 rechargeable battery
Fig.2:Membrane keypad
12-V battery pack
Lithium ion rechargeable battery DC 12V
6800 mAh.Battery life approx. 2 1/2 hours.
Fig.3:12-V battery pack
Ordering number

20
Overview
4.3 Control elements
Control box front panel
Control box back panel
Item
number
Item
number
Designation
Designation
Function
Function
1
1
2
[Light controller]
( section 7.5
“Controlling the
light”on p.41)
Button
[Zeroing]
( section 7.7
“Resetting the
electronic meter
measurement”
on p. 42)
Regulating the LED for the
dual-power lighting The light
controller on the control
box provides fully automatic
white balance up to approx.
4 cm before the obstruction
Pressing the button [zeroing]
resets the electronic meter
measurement for the number
of meters already traveled by
the camera head to zero
Fig.4:Control box,front of control box
On/off switch
[Power supply]
( section 7.1
“Switching on the
unit”on p.29)
Safely switches
power for the unit on
and off
(1) only functions if optional“Cable position system”
accessory is ordered.
Fig.5:Control elements
Control box back panel
1
1
2
