UTAH SCIENTIFIC MC-2020 Manual instruction

MC-2020
System Setup and Operations

ii MC-40/400 Operations Guide
The MC-2020 Operators' Manual
•Document Number: 82102-0020
•Document Version: 2.5
•Date: June 7, 2011
• Printed in U.S.A.
Copyrights and Trademarks
© 2011 Utah Scientific, Inc., All rights reserved. Any use or reproduction of this guide’s contents with-
out the prior written consent of Utah Scientific, Inc. is strictly prohibited.
•MC-2020 and MCP-2020 are trademarks of Utah Scientific, Inc.
•All other product names and any registered or unregistered trademarks mentioned in this guide are
used for identification purposes only and remain the exclusive property of their respective owners.
Notice
Information contained in this guide is subject to change without notice or obligation. While every effort
has been made to ensure that the information is accurate as of the publication date, Utah Scientific, Inc.
assumes no liability for errors or omissions. In addition, Utah Scientific, Inc. assumes no responsibility
for damages resulting from the use of this guide.
FCC Compliance (USA) and Digital Equipment Compliance (Canada)
This equipment has been tested and found to comply with the limits for a Class A, digital device,
pursuant to Part 15, Subpart B of the FCC Rules and the Canadian EMC Requirement (ICES-003).
These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case, the user will be required to correct the interference at
their own expense. Shielded cables must be used to ensure compliance with the FCC Class A limits.

Setup and Operations Guide
Declaration of Conformity
Utah Scientific, Inc.
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
We declare our sole responsibility that the Utah-400 Digital Routing Switcher is in conformance with
the following standards:
Emission
•EN55022:1994+A1&A2
Immunity
•EN55024:1998
•EN61000-3-2
•EN61000-3-3
Safety
•IEC 60950-1:2001 /EN 60950-1:2001
Following the provisions of the Directive(s) of the Council of the European Union:
•EMC Directive 89/336/EED
•Low Voltage Electrical Directive 72/23/EEC
Utah Scientific, Inc. hereby declares that the product specified above conforms to the above Directive(s)
and Standard(s).

iv MC-40/400 Operations Guide
Important Safeguards and Notices
This section provides important safety guidelines for the Operator and Service Personnel. Specific
warnings and cautions are found throughout the guide where they apply, but may not appear here. Please
read and follow the important safety information, specifically those instructions related to risk of fire,
electric shock, or injury to persons.
Safety Symbols
•Hazardous Voltage symbol
•Caution symbol. The product is marked with this symbol when it is necessary to
refer to the manual to prevent damage to the product.
Warnings
Please observe the following important warnings:
•Any instructions in this guide that require opening the chassis, changing a
power supply, or removing a board, should be performed by qualified personnel
only. To reduce the risk of electric shock, do not perform any service unless you
are qualified to do so.
•Heed all warnings on the unit and in the operating instructions.
•Do not use this product in or near water. Disconnect AC power before installing
any options or servicing the unit unless instructed to do so by this manual.
•This product is grounded through the power cord ground conductor. To avoid
electric shock, plug the power cord into a properly wired receptacle before con-
necting the product inputs or outputs.
•Route power cords and other cables so they won’t be damaged.
•The AC receptacle (socket) should be located near the equipment and be easily
accessible.
•Disconnect power before cleaning. Do not use any liquid or aerosol cleaner -
use only a damp cloth.

Setup and Operations Guide v
•Dangerous voltages exist at several points in this product. To avoid personal
injury, do not touch exposed conductors and components while power is on. Do
not insert anything into either of the systems two-power supply cavities with
power connected.
•Do not wear hand jewelry or watches when troubleshooting high current cir-
cuits, such as power supplies. During installation, do not use the door handles
or front panels to lift the equipment as they may open abruptly and injure you.
•To avoid fire hazard when replacing fuses, use only the specified correct type,
voltage and current rating as referenced in the appropriate parts list for this
product. Always refer fuse replacement to qualified service personnel.
•Have qualified personnel perform safety checks after any service.
Cautions
Please observe the following important cautions:
•When installing this equipment do not install power cords to building surfaces.
To prevent damage when replacing fuses, locate and correct the problem that
caused the fuse to blow, before reconnecting power.
•Use only specified replacement parts
Notices
Please observe the following important notes:
• When the adjacent symbol is indicated on the chassis, please refer to the man-
ual for additional information.
• For the HD-2020 Chassis and Master Control Panel, refer to “Connecting and
Disconnecting Power” - Chapter 2 (Hardware Installation).

vi MC-40/400 Operations Guide
Company Information
Utah Scientific, Incorporated
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
•Telephone: [phone]
•FAX: [phone]
•Technical Services (voice): [phone]
•Technical Services (FAX): [phone]
•E-Mail -General Information: [email protected]
•E-Mail -Technical Services: [email protected]
•World Wide Web: http://www.utahscientific.com
•After Hours Emergency: [phone]. Follow the menu instructions for Emergency Service.

Setup and Operations Guide
Warranty Policies
Hardware Warranty
Utah Scientific, Inc. warrants to the original purchaser that the Utah Scientific hardware is free
from defects in materials and workmanship and will perform substantially in accordance with
the accompanying written materials under normal use and service for a period of ten (10) years
from the date of shipment. Any implied warranties on hardware are limited to ten (10) years.
Some states/jurisdictions do not allow limitations on duration of an implied warranty, so the
above limitation may not apply to certain specific purchasers.
Software Warranty
Utah Scientific warrants that the software will perform substantially in accordance with the
accompanying written materials for a period of one (1) year from the date of shipment.
Customer Remedies
For the first one (1) year after purchase of the software and the first ten (10) years after the date
of purchase of the hardware, Utah Scientific’s and its suppliers’ entire liability and purchaser’s
exclusive remedy shall be, at Utah Scientific’s option, either:
• Return of the price paid, or
• Repair or replacement of the software or hardware that does not meet the above warranties
and is returned to Utah Scientific under the returned materials authorization (RMA)
process with freight and forwarding charges paid.
After the initial warranty periods, purchaser’s exclusive remedy is the repair or replacement of
the hardware upon payment of a fixed fee to cover handling and service costs based on Utah
Scientific’s then-current price schedule. The above warranties are void if failure of the
software or hardware has resulted from an accident, abuse, or misapplication. Any replacement
software or hardware will be warranted for the remainder of the original warranty period or
thirty (30) days, whichever is longer.

viii MC-40/400 Operations Guide
No other warranties. To the maximum extent permitted by applicable law, Utah Scientific and
its suppliers disclaim all other warranties, either express or implied, including, but not limited
to implied warranties of merchantability and fitness for a particular purpose, with regard to the
software, the accompanying written materials, and any accompanying hardware. This limited
warranty gives the purchaser specific legal rights. These rights may vary in certain states/
jurisdictions.
No liability for consequential damages. To the maximum extent permitted by applicable law,
in no event shall Utah Scientific or its suppliers be liable for any damages whatsoever
(including without limitation, damages for loss of business profits, business interruption, loss
of business information, or any other pecuniary loss) arising out of the use of or inability to use
Utah Scientific products, even if Utah Scientific has been advised of the possibility of such
damages. Because some states/jurisdictions do not allow the exclusion or limitation of liability
for consequential or incidental damages, the above limitation may not apply in those
circumstances.

Table of Contents
The MC-2020 Operators' Manual
CHAPTER 1 Quick Start
System Parts Listing ............................................................................... 1-2
Connections ............................................................................................ 1-2
Ethernet Hub .................................................................................... 1-3
Initial Activation and Confirmation ........................................................... 1-3
Default IP Configuration ................................................................... 1-3
System Set-up - Visual Guide ................................................................. 1-4
CHAPTER 2 System Introduction
In This Chapter ....................................................................................... 2-1
Conventions ............................................................................................ 2-2
Abbreviations .......................................................................................... 2-3
Terms ...................................................................................................... 2-5
Introducing the MC-2020 Digital Master Control Processor .................... 2-7
System Configurations ............................................................................ 2-9
Sample Configurations ..................................................................... 2-9
CHAPTER 3 Hardware Installation
In This Chapter ....................................................................................... 3-1
The MC-2020 Backplane ........................................................................ 3-2
AC Power Connections ........................................................................... 3-3
Video Input Connections ......................................................................... 3-4
Video Inputs ...................................................................................... 3-4
Input Definitions ................................................................................ 3-5
Video Sources: ................................................................................. 3-5
Program, Preset and Preview In: ...................................................... 3-5
Key and Fill Inputs: ........................................................................... 3-5

Video Reference: ..............................................................................3-6
Video Output Connections .......................................................................3-7
Program Out: ....................................................................................3-7
Monitor Out: ......................................................................................3-7
Auxiliary Video Out: ..........................................................................3-7
Audio Connections ..................................................................................3-8
AES Reference Input ........................................................................3-8
Audio Monitoring ...............................................................................3-9
Control / Network Connections ................................................................3-10
Port Functions ...................................................................................3-11
Control Ethernet Port: ...................................................................3-11
LAN Ethernet Port: ........................................................................3-11
UNET Port: ....................................................................................3-11
TIMECODE INPUT PORTS ..............................................................3-11
SERIAL PORTS 1 - 4 ........................................................................3-12
ALARM PORT ...................................................................................3-12
CANBUS PORT ................................................................................3-12
RELAYS / OPTOS: Ports A and B ....................................................3-12
Relay Optos Specification ...........................................................................3-13
GPIOs .........................................................................................................3-14
HD/SD System Connections ...................................................................3-15
CHAPTER 4 MC-2020 System Components
In This Chapter ........................................................................................4-1
The Control Processor Board -- MC-2020 ...............................................4-2
Video Reference Card ......................................................................4-4
The Main Processor Structure ..........................................................4-5
Communication Ports ........................................................................4-5
Alarm Circuitry ..................................................................................4-6
Information Display LED Indicators ...................................................4-6
LED Locations on the Control Processor Board ...............................4-7
LED Definitions (additional) ..............................................................4-8
Reference Lock .............................................................................4-8
Power ............................................................................................4-8
JTAG Programming ......................................................................4-8
Dipswitch Functions ..........................................................................4-8
Board Resident Relay Functions ......................................................4-8

SMPTE Alarm Function .................................................................... 4-9
The Video Output Board ......................................................................... 4-10
Voltage and Power Indicators ........................................................... 4-10
Video Input Board ................................................................................... 4-11
Voltage and Power Indicators ........................................................... 4-12
APPENDIX A Troubleshooting
In This Appendix ..................................................................................... A-1
Subsystem Level Troubleshooting .......................................................... A-2
Main Troubleshooting Chart .................................................................... A-2
Video Subsystem Troubleshooting Table ............................................... A-4
Power Subsystem Troubleshooting Table .............................................. A-5
Power Supply Alarms ....................................................................... A-5
Control Subsystem Troubleshooting Table ............................................. A-6
System Controller Alarms ................................................................. A-7
Control Panel Troubleshooting ............................................................... A-8
APPENDIX B Hardware Specifics
Alarm Port - SMPTE ............................................................................... B-2
AES INPUT: Program and Preset .......................................................... B-3
AES IN -- Preview and EXT 1 ................................................................. B-5
AES IN: EXT 2 and EXT 3 ...................................................................... B-7
AES Out: AUX/Spare .............................................................................. B-9
AES Out: Program/Monitor ..................................................................... B-11
Ethernet Ports A and B ........................................................................... B-13
Canbus Port ............................................................................................ B-15
Relays/Optos A (Ports 1-10) ................................................................... B-16
Relay/Optos B (ports 11 - 21) .................................................................. B-18
Serial Ports 1 - 4 ..................................................................................... B-20
Timer 1 and Timer 2 Port ........................................................................ B-21
Time Code IN and AES Reference Port ................................................. B-22
U-Net Connector ..................................................................................... B-23

U-NET Cabling ........................................................................................B-24
APPENDIX C The MC-2020 Breakout Panel
Panel’s Purpose ......................................................................................C-1
Cabling ....................................................................................................C-2
Physical Layout .......................................................................................C-3
Inner Panel Connectivity ...................................................................C-3
Breakout Rear Panel .........................................................................C-3
Balanced and Unbalanced ......................................................................C-4
Audio Output .....................................................................................C-4
Audio Input ........................................................................................C-4
AES Reference .................................................................................C-5
Relay Optos, Time Code, and Alarm ................................................C-5
Hardware .................................................................................................C-6
Ongoing Usage and Maintenance ...........................................................C-7
APPENDIX D MC-2020 Logo Generation Program Installation
Installation of the MicrosoftTM .net Framework .......................................D-2
Installing the 2020 Logo Conversion Application .....................................D-3
Creating a USI Format Logo File .............................................................D-3
What is ‘Background On’ ? ............................................................D-5
Creaging PNG Files Prior to Conversion .................................................D-6
Converting PNG Files Using LogoGen ....................................................D-6
Burning Logos to the MC .........................................................................D-11
Logo Operation from the Panel ...............................................................D-12
From the MCP-2020 (Used with MC4000, MC2020, MC400 and MC40) D-12
From the MCP-400 (Used with MC400 and MC40 only) ..................D-12
APPENDIX E A Discussion About Timing
TIMING SOURCES INTO THE MC-2020 ................................................E-1
HOW TO USE THE TIMING UTILITY ...............................................E-2
Connecting Via Serial .......................................................................E-3
Connecting Via Telnet .......................................................................E-3

Using LCD on MCP-2020 Panel ....................................................... E-4
Adjusting Timing ............................................................................... E-4
Timing for Systems Using SqueezeMAX ................................................ E-5
SD SqueezeMAX Timing Upstream ................................................. E-5
SD SqueezeMAX Timing Downstream ............................................. E-5
HD SqueezeMAX Downstream ........................................................ E-5
APPENDIX F The MC-2020 EAS Upgrade
MC-2020 EAS Upgrade .......................................................................... F-1
MACRO SETUP for TFT and DASDEC Models .............................. F-5
Macro Setup for Sage Models ......................................................... F-6
GPI (Sage setup only) ...................................................................... F-7
AES Input Port (for TFT, Sage and Dasdec TFT) ............................. F-7
AES Audio Only Buttons (for TFT, Sage and Dasdec TFT) .............. F-8
Manual Configuration ....................................................................... F-8
Wiring diagram from Utah MC-2020 to Sage ................................... F-11
Sample TFT Macro ........................................................................... F-12
Sample SAGE Macro and GPI Section Config ................................. F-13
Sample EAS Auto Action .................................................................. F-14
Sample Serial Port Setup for MC2020 Interface to TFT or Sage ..... F-15
Sample EAS Display Configuration for TFT ..................................... F-16
Sample EAS Display Configuration for Sage ................................... F-18
EAS_NOTIFY,YES ,1 ,2 ,1 ,WHITE_100 ,TIMEKEY_BG ,YES ..... F-19

MC and MCP-2020 1-1
CHAPTER 1 Quick Start
This Chapter contains the following:
System Parts Listing ......................................................1-2
Connections .................................................................. 1-2
Ethernet Hub ...........................................................1-3
Initial Activation and Confirmation .................................1-3
Default IP Configuration ..........................................1-3
System Set-up - Visual Guide .......................................1-4

Quick Start
1-2 Quick Start
System Parts Listing
The system components you have received (or will already have) may include the following:
•Utah 200 or 400 Router
•Control Card, housed within the SC-3 or SC-4 system (external). The system is also com-
patible with the SC-200.
• [White] Terminator box or UNET “Y” splitter cable. This device is placed between the SC-
4 (or SC-3)and the MC-2020.
• MC-2020 mainframe (processor)
• MCP-2020 panel
• Controller Terminators for the Router and SC-3 or SC-4
•Ethernet Hub
• System Installation CD (with NFS Server license)
• CAT 5 to 9-pin serial adapter for diagnostic port
• MC-2020 Breakout Panel (optional)
Connections
The MC-2020 mainframe and SC-3 or SC-4 are connected via UNET cabling. The UNET cable
is attached to its corresponding port on the back of the SC-3/4 controller (see the next illustra-
tion). Since UNET must be terminated, the cable is passed through a termination box or “Y”
cable prior to being connected to the MC-2020. Termination is necessary since there is no
loop through capability.

MC/P-2020 System 1-3
Initial Activation and Confirmation
Ethernet Hub
The Ethernet hub is designed to accommodate a stand-alone operation when a house net-
work is not available. The following devices connect to this central hub:
• SC-3 or SC-4
• MCP-2020
• MC-2020
• Computer control (optional, for RMS and Telnet operations)
(see figure 1-1)
Initial Activation and Confirmation
Once all connections have been made and the system is powered up, the system will scan the
network and locate the processor assigned to Channel 1, then make the necessary connec-
tions via the UNET cabling.
The MCP-2020 will complete its brief test cycle and allow you to complete takes from the
panel.
The system uses an SD video signal for reference input and timing control (on HD systems
use an HD video signal). This can consist of house black or color bars. Though the default
system configuration is for one channel, the panel has the ability to control a minimum of eight
different channels.
Channels not located will display as ‘pending’.
Default IP Configuration
The single-channel default (factory set) IP configuration is as follows:
Multiple chassis configurations will affect these addresses. Please contact customer service
for more detail.
MC-2020 192.168.5.7
MCP-2020 192.168.5.11

Quick Start
1-4 Quick Start
System Set-up - Visual Guide
FIGURE 1-1. MC/P-2020 Basic Setup
Ethernet Hub
MC-2020
MCP-2020
MC-2020 Breakout Panel
(Optional)
Configurator Computer
(U-CON)
SC-3 or 4 Controller
UTAH 300/400
Router
UNET cable
MX-Bus
Ethernet
Ethernet
Ethernet
Ethernet
Termination
Termination
White Terminator box
or "Y" type cable

MC-2020 2-1
CHAPTER 2 System Introduction
In This Chapter
This chapter provides an overview for the operating terms and configuration
within the Utah Scientific MC-2020 Digital Master Control Processor. The
following topics are covered:
Conventions ......................................................................... 2-2
Abbreviations ........................................................................ 2-3
Terms ................................................................................... 2-5
Introducing the MC-2020 Digital Master Control Processor .2-7
System Configurations ......................................................... 2-9
Sample Configurations ................................................... 2-9

System Introduction
2-2 Introduction
Conventions
The following conventions are used throughout this guide:
•Buttons, knobs, and connectors will be indicated by bold, upper case text in Arial Black font.
For example:
• Press the PST button CGPGM to…
•Upper and lower case Helvetica font will indicate displays and software instructions. For
example:
• The display above PVW keys one through four should indicate **** CAM1 PGM and
00251.
PST
CGPGM
**** CAM1 PGM 00251

MC-2020 System 2-3
Abbreviations
Abbreviations
The following abbreviations may be used in this guide: See Appendix A for an additional Glos-
sary of Terms and further definitions.
TABLE 1. Common Abbreviations and Mnemonics
Abbreviation Description
ATR Audio Tape Recorder
AES Audio Engineering Society
CPU Central Processing Unit
DTR Digital Tape Recorder
EBU European Broadcast Union
ENET Ethernet
HDTV High Definition Television
I/O Input / Output
IP Internet Protocol
JPEG Joint Photographic Experts Group
M-JPEG Motion – JPEG
MPEG Motion Picture Experts Group
MX-Bus Utah Router Control Comm. Bus
RMS Router Management System
RU Rack Unit
SDI Serial Digital Interface
U-Net Utah Control Panel Comm. Network
UTP Unshielded Twisted Pair
VTR Video Tape Recorder
