UTAH SCIENTIFIC BPS-2020 Instruction Manual

BPS-2020 / Bypass Switcher
System Overview and Operations

ii BPS-2020
BPS-2020/Bypass Switcher Operations Guide
•Document Number:82102-0022
•Document Version: 2.0.1
•Date: February 23, 2012
• Printed in U.S.A.
Copyrights and Trademarks
© 2012 Utah Scientific, Inc., All rights reserved. Any use or reproduction of this guide’s contents
without the prior written consent of Utah Scientific, Inc. is strictly prohibited.
•BPS-2020 is a trademark of Utah Scientific, Inc.
•Windows references (all versions) are registered trademarks of Microsoft Corporation.
•All other product names and any registered or unregistered trademarks mentioned in this guide are
used for identification purposes only and remain the exclusive property of their respective owners.
Notice
Information contained in this guide is subject to change without notice or obligation. While every effort
has been made to ensure that the information is accurate as of the publication date, Utah Scientific, Inc.
assumes no liability for errors or omissions. In addition, Utah Scientific, Inc. assumes no responsibility
for damages resulting from the use of this guide.
FCC Compliance (USA) and Digital Equipment Compliance (Canada)
This equipment has been tested and found to comply with the limits for a Class A, digital device,
pursuant to Part 15, Subpart B of the FCC Rules and the Canadian EMC Requirement (ICES-003).
These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case, the user will be required to correct the interference at
their own expense. Shielded cables must be used to ensure compliance with the FCC Class A limits.

Setup and Operations Guide
Declaration of Conformity
Utah Scientific, Inc.
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
We declare our sole responsibility that the Utah-400 Digital Routing Switcher is in conformance with
the following standards:
Emission
•EN55022:1994+A1&A2
Immunity
•EN55024:1998
•EN61000-3-2
•EN61000-3-3
Safety
•IEC 60950-1:2001 /EN 60950-1:2001
Following the provisions of the Directive(s) of the Council of the European Union:
•EMC Directive 89/336/EED
•Low Voltage Electrical Directive 72/23/EEC
Utah Scientific, Inc. hereby declares that the product specified above conforms to the above Directive(s)
and Standard(s).

iv BPS-2020
Important Safeguards and Notices
This section provides important safety guidelines for the Operator and Service Personnel. Specific
warnings and cautions are found throughout the guide where they apply, but may not appear here. Please
read and follow the important safety information, specifically those instructions related to risk of fire,
electric shock, or injury to persons.
Safety Symbols
•Hazardous Voltage symbol
•Caution symbol. The product is marked with this symbol when it is necessary to
refer to the manual to prevent damage to the product.
Warnings
Please observe the following important warnings:
•Any instructions in this guide that require opening the chassis, changing a
power supply, or removing a board, should be performed by qualified personnel
only. To reduce the risk of electric shock, do not perform any service unless you
are qualified to do so.
•Heed all warnings on the unit and in the operating instructions.
•Do not use this product in or near water. Disconnect AC power before installing
any options or servicing the unit unless instructed to do so by this manual.
•This product is grounded through the power cord ground conductor. To avoid
electric shock, plug the power cord into a properly wired receptacle before con-
necting the product inputs or outputs.
•Route power cords and other cables so they won’t be damaged.
•The AC receptacle (socket) should be located near the equipment and be easily
accessible.
•Disconnect power before cleaning. Do not use any liquid or aerosol cleaner -
use only a damp cloth.

Setup and Operations Guide v
•Dangerous voltages exist at several points in this product. To avoid personal
injury, do not touch exposed conductors and components while power is on. Do
not insert anything into either of the systems two-power supply cavities with
power connected.
•Do not wear hand jewelry or watches when troubleshooting high current cir-
cuits, such as power supplies. During installation, do not use the door handles
or front panels to lift the equipment as they may open abruptly and injure you.
•To avoid fire hazard when replacing fuses, use only the specified correct type,
voltage and current rating as referenced in the appropriate parts list for this
product. Always refer fuse replacement to qualified service personnel.
•Have qualified personnel perform safety checks after any service.
Cautions
Please observe the following important cautions:
•When installing this equipment do not install power cords to building surfaces.
To prevent damage when replacing fuses, locate and correct the problem that
caused the fuse to blow, before reconnecting power.
•Use only specified replacement parts
Notices
Please observe the following important notes:
• When the adjacent symbol is indicated on the chassis, please refer to the man-
ual for additional information.
• For the HD-2020 Chassis and Master Control Panel, refer to “Connecting and
Disconnecting Power” - Chapter 2 (Hardware Installation).

vi BPS-2020
Company Information
Utah Scientific, Incorporated
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
•Telephone: [phone]
•FAX: [phone]
•Technical Services (voice): [phone]
•Technical Services (FAX): [phone]
•E-Mail -General Information: [email protected]
•E-Mail -Technical Services: [email protected]
•World Wide Web: http://www.utahscientific.com
•After Hours Emergency: [phone]. Follow the menu instructions for Emergency Service.

Setup and Operations Guide
Warranty Policies
Hardware Warranty
Utah Scientific, Inc. warrants to the original purchaser that the Utah Scientific hardware is free
from defects in materials and workmanship and will perform substantially in accordance with
the accompanying written materials under normal use and service for a period of ten (10) years
from the date of shipment. Any implied warranties on hardware are limited to ten (10) years.
Some states/jurisdictions do not allow limitations on duration of an implied warranty, so the
above limitation may not apply to certain specific purchasers.
Software Warranty
Utah Scientific warrants that the software will perform substantially in accordance with the
accompanying written materials for a period of one (1) year from the date of shipment.
Customer Remedies
For the first one (1) year after purchase of the software and the first ten (10) years after the date
of purchase of the hardware, Utah Scientific’s and its suppliers’ entire liability and purchaser’s
exclusive remedy shall be, at Utah Scientific’s option, either:
• Return of the price paid, or
• Repair or replacement of the software or hardware that does not meet the above warranties
and is returned to Utah Scientific under the returned materials authorization (RMA)
process with freight and forwarding charges paid.
After the initial warranty periods, purchaser’s exclusive remedy is the repair or replacement of
the hardware upon payment of a fixed fee to cover handling and service costs based on Utah
Scientific’s then-current price schedule. The above warranties are void if failure of the
software or hardware has resulted from an accident, abuse, or misapplication. Any replacement
software or hardware will be warranted for the remainder of the original warranty period or
thirty (30) days, whichever is longer.

viii BPS-2020
No other warranties. To the maximum extent permitted by applicable law, Utah Scientific and
its suppliers disclaim all other warranties, either express or implied, including, but not limited
to implied warranties of merchantability and fitness for a particular purpose, with regard to the
software, the accompanying written materials, and any accompanying hardware. This limited
warranty gives the purchaser specific legal rights. These rights may vary in certain states/
jurisdictions.
No liability for consequential damages. To the maximum extent permitted by applicable law,
in no event shall Utah Scientific or its suppliers be liable for any damages whatsoever
(including without limitation, damages for loss of business profits, business interruption, loss
of business information, or any other pecuniary loss) arising out of the use of or inability to use
Utah Scientific products, even if Utah Scientific has been advised of the possibility of such
damages. Because some states/jurisdictions do not allow the exclusion or limitation of liability
for consequential or incidental damages, the above limitation may not apply in those
circumstances.

TOC- BPS-2020 TOC-i
Contents
BPS-2020 / Bypass Switcher
Table of Contents
1 - BPS-2020 (Bypass Switcher)
Receiving the System - Unpacking ...................................................1-1
General Overview ............................................................................. 1-2
How the System is Used ............................................................1-2
System Layout ............................................................................ 1-2
Control Panel Variations .............................................................1-2
Video Card Variations ................................................................1-3
Audio Card Options ....................................................................1-3
System Installation ............................................................................ 1-4
Rack Mounting ...........................................................................1-4
Control Interconnections ............................................................1-4
Multichannel Connections ..........................................................1-5
Video Connections .....................................................................1-6
Operation of the BPS-CP-16 ......................................................1-7
Rear Panel Audio Connections ..................................................1-7
Card Installation ................................................................................ 1-8
PCB Mounted Controls and Indicators ..............................................1-9
Power Supplies ..........................................................................1-9
Crosspoint/Control Card (121188-1, -2) .....................................1-10
Crosspoint/Control Card - continued ....................................1-13
BPS-2020 Video DA Card ..........................................................1-14
BPS-2020 Video 8x1 Input Card ................................................1-14
BPS-2020 AES Crosspoint .........................................................1-14
BPS-2020 Analog Audio Crosspoint ..........................................1-14
BPS-2020 Deluxe Audio Crosspoint (121178-1/2) .....................1-15
BPS-2020 Clean Quiet Module ..................................................1-16
2 - Operation
Initial System Power up ....................................................................2-1
Control Panel Usage ..................................................................2-2
Indications ............................................................................2-2
Control Options ..........................................................................2-2
Initial System Configuration ..............................................................2-3
Other operational Scenarios .............................................................2-5

TOC-ii BPS-2020 / Bypass Switcher
Forcing the bypass relay ........................................................... 2-5
Changing the reference standard .............................................. 2-5
Rear Panel Description .................................................................... 2-6
Control Connectors .................................................................... 2-6
3 - Specifications
Overview .......................................................................................... 3-1
Power Supplies ................................................................................ 3-4
Appendix A - Rear Panel Pinout Detail
Serial Port .................................................................................. A-1
RS-232 Mode ...................................................................... A-1
RS-422 Mode ...................................................................... A-1
Tally Output ............................................................................... A-2
Audio Connections .................................................................... A-3
Audio Input/Output Connectors ........................................... A-3
Output Connectors Pinout ................................................... A-4
Appendix B - BPS-2020 Break Out Addendum
In This Addendum ..................................................................... B-1
Using the UTAH-200 Breakout Panel on the BPS-2020 ........... B-2
Appendix C Debug Port C-1
Description ....................................................................................... C-1
Connector ......................................................................................... C-1
Terminal Emulation Settings ............................................................ C-2
Verifying Communication ................................................................. C-2
Appendix D - Firmware Update Procedure
Description ....................................................................................... D-1
Procedure ......................................................................................... D-1

Chapter 1 1-1
Receiving the System - Unpacking
Section1
1
BPS-2020 (Bypass Switcher)
Receiving the System - Unpacking
The BPS-2020 consists of a 2 rack unit electronics frame and one or more
control panels. Power cards are provided for each device.
The 1 rack unit control panel can exist as the following versions; the BPS-8
(eight button control panel), the BPS-16 (multi-channel control panel), or the
BPS-16S (16 source control panel). See your sales order for details.
Receiving the System - Unpacking ........................... 1-1
General Overview ..................................................... 1-2
System Installation .................................................... 1-4
Card Installation ........................................................ 1-8
PCB Mounted Controls and Indicators ...................... 1-9

1-2BPS-2020
BPS-2020 (Bypass Switcher)
General Overview
How the System is Used
The BPS-2020 is intended to be downstream of all processing equipment
in a standard TV station environment. The Audio/Video output would
directly feed the transmission system of a station. The system can also be
used in any other AV switching application.
System Layout
The BPS-2020’s electronic components are housed in a 2RU rack mount
frame, while the control panel is contained in a remote 1 RU frame. The
electronics frame contains redundant power supplies.
The video section contains two slots; one for a crosspoint and another for
a video DA card, which provides looping input, or a video input card in 16
input systems.
The audio section contains two slots for 8x2 crosspoint cards. These
cards can exist as analog audio, standard digital audio, or deluxe digital
audio.
The BPS supports only balanced audio. A UDA-200 must be used to
convert to Unbalanced audio if the installation requires it.
Control Panel Variations
Stand Alone – 8 Standard Veetronix switches that represent one of the 8
inputs, or 16 switches for the 16 input systems.
Multichannel – 16 Veetronix switches in two banks of 8, with one bank
representing a channel select, and the other bank selecting one of the
eight inputs on that particular channel.
The control panel communicates with the electronics frame via RS-485.

Chapter 1 1-3
General Overview
Section1
Video Card Variations
There are two different video crosspoint cards. This card is the heart of the
system from a control standpoint, and orchestrates all system activities. The
121188-2 card is an 8 input crosspoint, while the 121188-1 is a 16 input
crosspoint.
The other video cards are the 8 circuit DA (121182-1), which can only be used
in conjunction with the 8 input crosspoint card, and the 121186-1 input card,
which contains the additional 8 input circuits for the 121188-1 16 input
system.
One other optional module, the 121169-1 Clean/Quiet submodule, can be
installed on either one of the crosspoint cards. This module provides
error-free switching of un-timed sources to provide the cleanest possible
video output.
Audio Card Options
There are 3 audio cards available. The analog audio card (121183-1) is a
stereo 8x1 device. Up to two can be installed for a dual stereo system. The
standard digital audio card (121184-1) is also an 8x1, dual stream device.
Two can be installed for a quad stream system.
The Deluxe Digital Audio card (121178-1) provides a V-Fade transition and
can be used as either a Quad 8x1 with two cards or as a dual 16x1.

1-4BPS-2020
BPS-2020 (Bypass Switcher)
System Installation
Rack Mounting
The 2 Rack Unit electronics frame should be installed near the master
control switcher in the main audio/video path of the system. The 1 Rack
Unit control panel should be installed in the Master Control room where it
is easily accessible to the operator.
Control Interconnections
Figure 1-1. Lower right chassis quadrant
This section of the BPS rear panel contains the control interconnections
for the system. The necessary connection between the control panel and
the electronics frame is a single CAT-5 cable between the panel port and
the RJ-45 connector on the back of the panel. Other control connections
include RS-232/422, tally and GPI’s.
See section 2 for pinout and other details of these control connectors.
SERIAL
LOOP OUT
COM
GPI
RESET
PAN EL
BPS-NET
12345678TALLY
C R S C

Chapter 1 1-5
System Installation
Section1
Multichannel Connections
Multi-channel BPS-2020 systems can operate as single units, as a networked
system, or both. To operate as a multi-channel system, a BPS-CP-16 is
required.
Figure 1-2. Basic Multi-Channel connection
The interconnect between the CP-16 and the bypass switchers is done with
standard CAT5 cable. The CP-16 is at one physical end of the bus and is
terminated internally. The cable then loops through the BPS-2020 chassis on
the two “BPS-NET” RJ-45 connectors. The open connector on the last
BPS-2020 should be terminated with USI part number 65324-04.
Note that each BPS-2020 must be addressed with a dipswitch on the video
crosspoint card.
BPS #1 BPS #2 BPS #3 BPS #8
BPS 4 - 7
BPS CP 16
Terminator
(Part # 65324-04)

1-6BPS-2020
BPS-2020 (Bypass Switcher)
Video Connections
Figure 1-3. 8-Input systems
Standard video ports include 8 inputs and 1 dual output connection. Optionally, a
DA card can be purchased that provides an active loop output for each input.
Figure 1-4. 16-Input systems
16-Input systems contain updated legends to describe the different BNC
functions. This system requires a 16x1 crosspoint card as well as an 8x input card
to be installed in the lower video slot.
VIDEO
INPUT
IN1 IN2 IN 3 IN4 IN 5 IN6 IN7 IN 8
LOOP OUT
(INVERTED)
OUT
VIDEO
INPUT
1
OUT 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
OUT

Chapter 1 1-7
System Installation
Section1
Operation of the BPS-CP-16
Operation is very straight forward. The left bank of 8 buttons selects the
BPS-2020 chassis you wish to control. When a channel is selected, the right
bank of buttons will show its current status. A cycling lamp pattern will indicate
that the designated address is not communicating.
Rear Panel Audio Connections
Figure 1-5. Left side of rear panel
Audio connections are contained within the 26 pin high density D connector.
The audio can be analog, digital, or not installed depending on what was
purchased. See the ‘Card Installation’ section on page (1-6) to determine
which cards are installed in your system. Section 2 contains pinout
information for the ‘D’ connectors.
CH 1-2
CH 5-6
CH 1-2
CH 5-6
AUDIO
CH 7-8
CH 7-8
CH 3-4
CH 3-4
IN
OUT

1-8BPS-2020
BPS-2020 (Bypass Switcher)
Card Installation
The BPS -2020 has two power supply slots and four slots for plug-in
cards. The following list shows which cards can be placed in which slots
1. Power Supplies – USI PN 140080-02.
2. Slot 1 – Either the 121188-2 8x1 crosspoint or the 121188-1
16x1 crosspoint can be installed in this slot.
3. Slot 2 – Either the 121182-1 video DA or the 121186-1 8x1
input card can be installed here. The 121182-1 should only
be used with the 121188-2 8x1 crosspoint, and the 121186-1
should only be used with the 121188-1 16 Input crosspoint.
4. Slots 3, 4 – either the BPS-2020 Digital Audio (121184-1)
crosspoint, the BPS-2020 Analog Audio Crosspoint
(121183-1), or the Deluxe Audio crosspoint can be placed
here.
Figure 1-6. Card Installation
Power Supply
Slot 1
Slot 2 Slots 3 and 4
Power Supply

Chapter 1 1-9
PCB Mounted Controls and Indicators
Section1
PCB Mounted Controls and Indicators
Power Supplies
• The power supplies are calibrated at the factory. No field
adjustment is necessary.
• The supplies have Red LED’s that indicate failure of the 5V, 3.3V,
+-12V, integral fan and overtemperature. They also have a
bi-color LED that is green when all other failure leds are off, and
red when one or more of the other alarms trip.
Figure 1-7. Power Supply (card) and front LEDs

1-10 BPS-2020
BPS-2020 (Bypass Switcher)
Crosspoint/Control Card (121188-1, -2)
BPS-2020 Video Crosspoint/Control Card. This card is the heart of the BPS-2020 system, as it
consolidates all control functions as well as the video switching. There are numerous controls
on it.
Indicators:
Figure 1-8. Card Indications
P1 Diagnostic Port
Switch 1 Dipswitch
Switch 2 Reset
DS8 Reset LED (Red)
ON
DS-10
Clean/Quiet
Module Active
(Green)
Reference OK
(Green)
DS-7 VCO Lock
(Green)
DS-6 Power OK
(Green)
DS-5
SMPTE Alarm
(Red)
DS-9
XPT0-3
Switch Status
DS1-4
