UTAH SCIENTIFIC UTAH-100/UDS XY-Panel Setup guide

UTAH-100/UDS XY-Panel
Setup and Operation Guide

ii
UTAH 100/UDS XY Control Panel
• Document Number: 82102-0084
• Document Version: 1.0
• Date: January 28, 2015
• Printed in U.S.A.
Copyrights and Trademarks
© 2015 Utah Scientific, Inc., All rights reserved. Any use or reproduction of this guide’s
contents without the prior written consent of Utah Scientific, Inc. is strictly prohibited.
•UTAH 100 is a trademarks of Utah Scientific, Inc.
•Windows, Windows 2000 and Windows NT and XP are registered trademarks of
Microsoft Corporation.
•All other product names and any registered or unregistered trademarks mentioned in
this guide are used for identification purposes only and remain the exclusive property
of their respective owners.
Notice
Information contained in this guide is subject to change without notice or obligation.
While every effort has been made to ensure that the information is accurate as of the
publication date, Utah Scientific, Inc. assumes no liability for errors or omissions. In
addition, Utah Scientific, Inc. assumes no responsibility for damages resulting from the
use of this guide.
FCC Compliance (USA) and Digital Equipment Com-
pliance (Canada)
This equipment has been tested and found to comply with the limits for a Class A, digital
device, pursuant to Part 15, Subpart B of the FCC Rules and the Canadian EMC
Requirement (ICES-003). These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case, the user will be required to correct the
interference at their own expense. Shielded cables must be used to ensure compliance with
the FCC Class A limits.

iii
Section 1
Declaration of Conformity
Utah Scientific, Inc.
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
We declare our sole responsibility that the UTAH-100/UDS Digital Routing Switcher is in
conformance with the following standards:
Emission
•EN55022:1994+A1&A2
Immunity
•EN55024:1998
•EN61000-3-2
•EN61000-3-3
Safety
•IEC 60950-1:2001 /EN 60950-1:2001
Following the provisions of the Directive(s) of the Council of the European Union:
•EMC Directive 89/336/EED
•Low Voltage Electrical Directive 72/23/EEC
Utah Scientific, Inc. hereby declares that the product specified above conforms to the above
Directive(s) and Standard(s).

iv
Important Safeguards and Notices
This section provides important safety guidelines for the Operator and Service Personnel.
Specific warnings and cautions are found throughout the guide where they apply, but may
not appear here. Please read and follow the important safety information, specifically
those instructions related to risk of fire, electric shock, or injury to persons.
Safety Symbols
•Hazardous Voltage symbol
•Caution symbol. The product is marked with this symbol when
it is necessary to refer to the manual to prevent damage to the
product.
Warnings
Please observe the following important warnings:
•Any instructions in this guide that require opening the chassis,
changing a power supply, or removing a board, should be per-
formed by qualified personnel only. To reduce the risk of elec-
tric shock, do not perform any service unless you are qualified
to do so.
•Heed all warnings on the unit and in the operating instructions.
•Do not use this product in or near water. Disconnect AC power
before installing any options or servicing the unit unless
instructed to do so by this manual.
•This product is grounded through the power cord ground con-
ductor. To avoid electric shock, plug the power cord into a
properly wired receptacle before connecting the product inputs
or outputs.
•Route power cords and other cables so they won’t be damaged.
•The AC receptacle (socket) should be located near the equip-
ment and be easily accessible.
•Disconnect power before cleaning. Do not use any liquid or
aerosol cleaner - use only a damp cloth.

v
Section 1
•Dangerous voltages exist at several points in this product. To avoid
personal injury, do not touch exposed conductors and components
while power is on. Do not insert anything into either of the systems
two-power supply cavities with power connected.
•Do not wear hand jewelry or watches when troubleshooting high
current circuits, such as power supplies. During installation, do not
use the door handles or front panels to lift the equipment as they
may open abruptly and injure you.
•To avoid fire hazard when replacing fuses, use only the specified
correct type, voltage and current rating as referenced in the appro-
priate parts list for this product. Always refer fuse replacement to
qualified service personnel.
•Have qualified personnel perform safety checks after any service.
Cautions
Please observe the following important cautions:
•When installing this equipment do not install power cords to build-
ing surfaces. To prevent damage when replacing fuses, locate and cor-
rect the problem that caused the fuse to blow, before reconnecting
power.
•Use only specified replacement parts

vi
Company Information
Utah Scientific, Incorporated
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
•Telephone: [phone]
•FAX: [phone]
•Technical Services (voice): [phone]
•Technical Services (FAX): [phone]
•E-Mail -General Information: [email protected]
•E-Mail -Technical Services: [e-mail]
•World Wide Web: http://www.utahscientific.com
•After Hours Emergency: [phone]. Follow the menu instructions for Emer-
gency Service.

vii
Section 1
Warranty Policies
Hardware Warranty
Utah Scientific, Inc. warrants to the original purchaser that the Utah Scientific
hardware is free from defects in materials and workmanship and will perform
substantially in accordance with the accompanying written materials under normal
use and service for a period of two (2), five (5), or ten (10) years from the date of
shipment. Any implied warranties on hardware are limited to the above three
warranty periods (depending on purchase). Some states/jurisdictions do not allow
limitations on duration of an implied warranty, so the above limitation may not apply
to certain specific purchasers.
Software Warranty
Utah Scientific warrants that the software will perform substantially in accordance
with the accompanying written materials for a period of one (1) year from the date of
shipment.
Customer Remedies
For the first one (1) year after purchase of the software and the first two (2), five (5),
or ten (10) years after the date of purchase of the hardware, Utah Scientific’s and its
suppliers’ entire liability and purchaser’s exclusive remedy shall be, at Utah
Scientific’s option, either:
• Return of the price paid, or
• Repair or replacement of the software or hardware that does
not meet the above warranties and is returned to Utah Scientific
under the returned materials authorization (RMA) process with
freight and forwarding charges paid.
After the initial warranty periods, purchaser’s exclusive remedy is the repair or
replacement of the hardware upon payment of a fixed fee to cover handling and
service costs based on Utah Scientific’s then-current price schedule. The above
warranties are void if failure of the software or hardware has resulted from an
accident, abuse, or misapplication. Any replacement software or hardware will be
warranted for the remainder of the original warranty period or thirty (30) days,
whichever is longer.

viii
No other warranties. To the maximum extent permitted by applicable law, Utah
Scientific and its suppliers disclaim all other warranties, either express or
implied, including, but not limited to implied warranties of merchantability and
fitness for a particular purpose, with regard to the software, the accompanying
written materials, and any accompanying hardware. This limited warranty gives
the purchaser specific legal rights. These rights may vary in certain
states/jurisdictions.
No liability for consequential damages. To the maximum extent permitted by
applicable law, in no event shall Utah Scientific or its suppliers be liable for any
damages whatsoever (including without limitation, damages for loss of business
profits, business interruption, loss of business information, or any other
pecuniary loss) arising out of the use of or inability to use Utah Scientific
products, even if Utah Scientific has been advised of the possibility of such
damages. Because some states/jurisdictions do not allow the exclusion or
limitation of liability for consequential or incidental damages, the above
limitation may not apply in those circumstances.

Table of Contents 1
Table of Contents
Section 1
Panel Operation
Introduction ........................................................................... ......................... 1-1
System Setup Requirements ................................................ ......................... 1-1
The UTAH-100/UDS XY Panel ............................................. ......................... 1-2
Home ........................................................................................................ 1-2
Options ..................................................................................................... 1-2
Source Track Button .................................................................1-3
Auto Source Preset ..................................................................1-3
Auto Destination Select ............................................................1-3
Knob Clockwise ........................................................................1-4
Knob Take ................................................................................1-4
Network Setup .......................................................................................... 1-4
Network Summary .................................................................................... 1-6
Panel Info ................................................................................................. 1-7
Additional Notes - Review ........................................................1-7
Operation / Making a Take .......................................................1-8
Panel Operation .................................................................... ......................... 1-10
The Link Light ...........................................................................1-11
Panel Buttons ........................................................................................... 1-12
Source and Destination ............................................................1-12
Lock ..........................................................................................1-12
Browser Operation ................................................................ ......................... 1-13
General Overview ..................................................................................... 1-13
Radio Buttons ...........................................................................1-13
System ..................................................................................................... 1-13
Source Categories .................................................................................... 1-14
Destination Categories button .................................................................. 1-15
Encoding ............................................................................... ......................... 1-16
Enabling Function Parameters ................................................................. 1-16
Save and Program ................................................................................... 1-17

2 UTAH-100/UDS Setup & Operations Guide

Section 1 1-1
Introduction
Section 1
Section 1
Panel Operation
Introduction
This guide covers the setup and operational detail of the UTAH-100/UDS XY panel,
including fixed panel operation and the accompanying browser utility.
System Setup Requirements
• Windows™ operating system 7
• Java 7.07™ or newer
• Internet Explorer™, Firefox™, or Chrome™
• Ethernet connection
All UDS devices - PC, Router, and Panel - connect over Ethernet on a house network, or
within a stand-alone (direct) mode. The system will provide default IP address during
setup, or you can use unique IP addresses if required within your operation.

1-2 System Setup
Panel Operation
The UTAH-100/UDS XY Panel
Home
Press the Home button to take the panel to the main menu selection (below).
Figure 1-1. Home button and screen display
Using the scroll wheel, rotate to Options and press the wheel to select.
Options
There are five options available for modification from this screen; Source Track Button,
Auto Source Preset, Auto Destination Select, Knob clockwise or counter-clockwise
control, and Knob Take (on or off). Highlight the option to select, then press the knob to
make a change, or press the Enable/Disable button to the right to make a change. Note:
You must press the Save button to complete the change.
Figure 1-2. XY Panel Options

Section 1 1-3
The UTAH-100/UDS XY Panel
Section 1
Source Track Button
Source Tracking allows automatic Takes when enabled. The current Tracking status will
display at the location illustrated below. When enabled, takes will occur immediately
whenever a new Source is highlighted by scrolling. Takes are simultaneous, without any
Preset or separate ‘Take’ activation.
Figure 1-3. Track button - enabled
Use the Track button to toggle tracking on or off.
Note that while in Tracking mode, the last Preset remains listed (bottom left within the
display), allowing for an immediate return to the last preset by pressing the Take button.
Disabling Source tracking will turn the “track” item off and the Sources will then work in a
Preset/Take mode only. In this mode you will scroll to the desired Source and the “Take”
button (lower right physical button on the panel will start blinking, and when pressed, the
switch will occur.)
Note: When disabled, the preset window will always contain the Source you will be taking
next, which will remove the ability to revert back to the previous Source.
Auto Source Preset
When enabled, individual selections are automatically preset by scrolling the knob in the
Source Selection menu. If disabled, Source Preset selections are activated by pressing
the scroll button only.
Auto Destination Select
When enabled, each destination scrolled to (in the Destination menu) will update the
source for that particular destination. If disabled, the scroll knob must be pressed to obtain
the destination’s current status.

1-4 System Setup
Panel Operation
Knob Clockwise
Knob Clockwise changes the direction the highlightor (on the LCD screen) scrolls when the
scroll knob is rotated.
Knob Take
Knob Take allows the user to press the knob (or the Take) button to send a take. If disabled,
the user must press the Take button to make the actual take.
Network Setup
The first step in UDS XY panel operation is establishing a good network connection. From
the main menu, use the scroll knob to select Network Setup, then push the knob to activate
network configuration.
Figure 1-4. Network menu selection and screen

Section 1 1-5
The UTAH-100/UDS XY Panel
Section 1
The Network Setup screen allows modification to Local Gateway, Mask and Router IP;
modified by pressing the corresponding button on the panel.
Figure 1-5. Toggle button
The options are cycled through with each button press. The router IP is the actual router
device this panel communicates with, and its corresponding port must match the XY panel;
5001 in nearly all cases.
The octets for IP address, Gateway, and Mask are selected by pressing the lower right and
left buttons.
Figure 1-6. Octet toggle control
You can also use the scroll wheel to move up or down numerically. Jump through larger
number sequences with faster scroll wheel moves.
In most circumstances the Router Port should be left at 5001.

1-6 System Setup
Panel Operation
The system will prompt the user to Save or discard changes (Yes or No) before leaving
the screen. Note the asterisk on the Save button, indicating pending changes.
Figure 1-7. Save button - asterisk indicating change
Important note: The chassis must be reset at the back of the unit (reset button) following
any address change.
Network Summary
Select Network Summary from the main menu.
Figure 1-8. Network Summary

Section 1 1-7
The UTAH-100/UDS XY Panel
Section 1
Edit activates the Network Setup area (described previously). The remainder of the screen
contains IP, Gateway, Mask, and Port address detail for both the XY panel and router.
Figure 1-9. Existing panel and router address detail
Panel Info
This is a summary of software, boot loader, and firmware versions for the XY panel.
Figure 1-10. Panel Info screen
Additional Notes - Review
Sources and Destinations are divided into the needed categories for the specified panel
through the web GUI. It is also important to note that Categories cannot be ‘set up’ through
the chassis.

1-8 System Setup
Panel Operation
Operation / Making a Take
Select a Destination Category by pressing the Home button twice, then make sure Dest
Category is indicated in the upper right portion of the screen.
Figure 1-11.
Press the Home button again if you do not get the above result.
The Dest Category should be highlighted in the upper right portion of the screen.
Now select the Destination category by scrolling up and down the categories in the middle
of the screen display (using the scroll wheel).
Push the scroll wheel when the category selection is made, use the scroll wheel to select
the actual destination.
Note: The Source will automatically be displayed when Auto DST Select is
enabled -- as each new destination is scrolled to. If Auto DST Select
is disabled, the scroll knob must be pressed to see the source on the
destination.
The selection is again made from the list in the middle of the screen.
• Preset the Selection
• Make the Take (Take button)
Note: When the Preset is different from the Source status, both the Preset
(on the screen) and the Take button will flash.
After the destination is selected, press the Source Category button. Scroll the knob to
select the desired source category and press the knob, then scroll the knob to select the
desired source.

Section 1 1-9
The UTAH-100/UDS XY Panel
Section 1
The preset will flash to indicate a take is pending. Press the Take button to
make the Source/Destination connection.
Note: If the Auto Source Preset is enabled, the source will be
auto preset. Otherwise you must press the knob to
preset, then press the Take button.
Shortcut
Push the Destination button (upper left button on the chassis) to
quickly reveal a display of the Destinatio n’s location within its
associated category.
Cycle through multiple categories (if they have been assigned) by
repeatedly pushing the above Destination button.

1-10 System Setup
Panel Operation
Panel Operation
Press the Home/Menu button until the Home Page appears.
Figure 1-12. Home Page
The currently selected Destination, Source, and Preset will appear on the left side of the
display. Categories are indicated on the right side of the display, and the contents of the
currently highlighted category are displayed in the middle of the screen.
Typically a Destination is selected first. To make a change, press the black panel button
associated with Destination Category, use the scroll wheel to make a new category selection
in the middle (such as monitors), then press the knob to reveal the contents of that particular
category.
Figure 1-13.
