UTAH SCIENTIFIC Utah-400 2 Series Manual instruction

The Utah-400 Series 2
XL, 528, 288, 144 and 72 Systems
Setup and Operations Guide

ii The Utah-400
The Utah-400 Series 2 - Setup and Operations Guide
• Document Number: 82101-0077
• Document Version: 2.5.4
• Date: September 14, 2016
• Printed in U.S.A.
Copyrights and Trademarks
© 2016 Utah Scientific, Inc., All rights reserved. Any use or reproduction of this guide’s contents
without the prior written consent of Utah Scientific, Inc. is strictly prohibited.
• Utah-400 is a trademark of Utah Scientific, Inc.
• Windows references (all versions) are registered trademarks of Microsoft Corporation.
• All other product names and any registered or unregistered trademarks mentioned in this guide are
used for identification purposes only and remain the exclusive property of their respective owners.
Notice
Information contained in this guide is subject to change without notice or obligation. While every effort
has been made to ensure that the information is accurate as of the publication date, Utah Scientific, Inc.
assumes no liability for errors or omissions. In addition, Utah Scientific, Inc. assumes no responsibility
for damages resulting from the use of this guide.
FCC Compliance (USA) and Digital Equipment Compliance (Canada)
This equipment has been tested and found to comply with the limits for a Class A, digital device,
pursuant to Part 15, Subpart B of the FCC Rules and the Canadian EMC Requirement (ICES-003).
These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case, the user will be required to correct the interference at
their own expense. Shielded cables must be used to ensure compliance with the FCC Class A limits.

UTAH-400 Series 2 iii
Declaration of Conformity
Utah Scientific, Inc.
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
We declare our sole responsibility that the Utah-400 Digital Routing Switcher is in conformance with
the following standards:
Emission
• EN55022:1994+A1&A2
Immunity
• EN55024:1998
• EN61000-3-2
• EN61000-3-3
Safety
• IEC 60950-1:2001 /EN 60950-1:2001
Following the provisions of the Directive(s) of the Council of the European Union:
• EMC Directive 89/336/EED
• Low Voltage Electrical Directive 72/23/EEC
Utah Scientific, Inc. hereby declares that the product specified above conforms to the above Directive(s)
and Standard(s).

iv The Utah-400
Important Safeguards and Notices
This section provides important safety guidelines for the Operator and Service Personnel. Specific
warnings and cautions are found throughout the guide where they apply, but may not appear here. Please
read and follow the important safety information, specifically those instructions related to risk of fire,
electric shock, or injury to persons.
Safety Symbols
• Hazardous Voltage symbol
• Caution symbol. The product is marked with this symbol when it is necessary to
refer to the manual to prevent damage to the product.
Warnings
Please observe the following important warnings:
• Any instructions in this guide that require opening the chassis, changing a
power supply, or removing a board, should be performed by qualified personnel
only. To reduce the risk of electric shock, do not perform any service unless you
are qualified to do so.
• Heed all warnings on the unit and in the operating instructions.
• Do not use this product in or near water. Disconnect AC power before installing
any options or servicing the unit unless instructed to do so by this manual.
• This product is grounded through the power cord ground conductor. To avoid
electric shock, plug the power cord into a properly wired receptacle before con-
necting the product inputs or outputs.
• Route power cords and other cables so they won’t be damaged.
• The AC receptacle (socket) should be located near the equipment and be easily
accessible.
• Disconnect power before cleaning. Do not use any liquid or aerosol cleaner -
use only a damp cloth.

UTAH-400 Series 2 v
• Dangerous voltages exist at several points in this product. To avoid personal
injury, do not touch exposed conductors and components while power is on. Do
not insert anything into either of the systems two-power supply cavities with
power connected.
• Do not wear hand jewelry or watches when troubleshooting high current cir-
cuits, such as power supplies. During installation, do not use the door handles
or front panels to lift the equipment as they may open abruptly and injure you.
• To avoid fire hazard when replacing fuses, use only the specified correct type,
voltage and current rating as referenced in the appropriate parts list for this
product. Always refer fuse replacement to qualified service personnel.
• Have qualified personnel perform safety checks after any service.
Cautions
Please observe the following important cautions:
• When installing this equipment do not install power cords to building surfaces.
To prevent damage when replacing fuses, locate and correct the problem that
caused the fuse to blow, before reconnecting power.
• Use only specified replacement parts
Notices
Please observe the following important notes:
• When the adjacent symbol is indicated on the chassis, please refer to the man-
ual for additional information.
• For the HD-2020 Chassis and Master Control Panel, refer to “Connecting and
Disconnecting Power” - Chapter 2 (Hardware Installation).

vi The Utah-400
Company Information
Utah Scientific, Incorporated
4750 Wiley Post Way, Suite 150
Salt Lake City, Utah 84116-2878 U.S.A.
• Telephone: [phone]
• FAX: [phone]
• Technical Services (voice): [phone]
• Technical Services (FAX): [phone]
• E-Mail -General Information: [e-mail]
• E-Mail -Technical Services: serv[email protected]
• World Wide Web: http://www.utahscientific.com
• After Hours Emergency: [phone]. Follow the menu instructions for Emergency Service.

UTAH-400 Series 2 vii
Warranty Policies
Hardware Warranty
Utah Scientific, Inc. warrants to the original purchaser that the Utah Scientific hardware is free
from defects in materials and workmanship and will perform substantially in accordance with
the accompanying written materials under normal use and service for a period of ten (10) years
from the date of shipment. Any implied warranties on hardware are limited to ten (10) years.
Some states/jurisdictions do not allow limitations on duration of an implied warranty, so the
above limitation may not apply to certain specific purchasers.
Software Warranty
Utah Scientific warrants that the software will perform substantially in accordance with the
accompanying written materials for a period of one (1) year from the date of shipment.
Customer Remedies
For the first one (1) year after purchase of the software and the first ten (10) years after the date
of purchase of the hardware, Utah Scientific’s and its suppliers’ entire liability and purchaser’s
exclusive remedy shall be, at Utah Scientific’s option, either:
• Return of the price paid, or
• Repair or replacement of the software or hardware that does not meet the above warranties
and is returned to Utah Scientific under the returned materials authorization (RMA)
process with freight and forwarding charges paid.
After the initial warranty periods, purchaser’s exclusive remedy is the repair or replacement of
the hardware upon payment of a fixed fee to cover handling and service costs based on Utah
Scientific’s then-current price schedule. The above warranties are void if failure of the
software or hardware has resulted from an accident, abuse, or misapplication. Any replacement
software or hardware will be warranted for the remainder of the original warranty period or
thirty (30) days, whichever is longer.
No other warranties. To the maximum extent permitted by applicable law, Utah Scientific and
its suppliers disclaim all other warranties, either express or implied, including, but not limited
to implied warranties of merchantability and fitness for a particular purpose, with regard to the
software, the accompanying written materials, and any accompanying hardware. This limited
warranty gives the purchaser specific legal rights. These rights may vary in certain states/
jurisdictions.
No liability for consequential damages. To the maximum extent permitted by applicable law,
in no event shall Utah Scientific or its suppliers be liable for any damages whatsoever
(including without limitation, damages for loss of business profits, business interruption, loss
of business information, or any other pecuniary loss) arising out of the use of or inability to use

viii The Utah-400
Utah Scientific products, even if Utah Scientific has been advised of the possibility of such
damages. Because some states/jurisdictions do not allow the exclusion or limitation of liability
for consequential or incidental damages, the above limitation may not apply in those
circumstances.

Table of Contents i
Table of Contents
Table of Contents
CHAPTER 1
Introduction
Conventions 1-3
Abbreviations 1-4
Terms 1-5
Routing Switcher Basics 1-6
Switching Matrix 1-7
Signal Levels 1-8
The Utah-400 Routing Matrix 1-9
Component Locations 1-12
XL Configuration 1-12
528 Configuration 1-14
288 Configuration 1-16
144 Configuration 1-18
72x72 Configuration 1-19
UT-400 Embedded Signal Processing Functionality 1-20
TDM Enabled IO Cards 1-22
Supported Signal Types 1-22
Delay Considerations 1-22
Shuffling versus Routing 1-23
CHAPTER 2 Hardware Installation
In This Chapter 2-1
Unpacking and Inspection 2-2
528 Systems 2-2
XL Systems Carton Handling and Chassis Management 2-4
Transferring an XL system between Equipment Racks 2-11
Installing Physical Equipment - 528 and XL Systems 2-16
Mounting Equipment in Rack Frames - 528 Systems 2-17
Installing the Utah-400 Digital Routing Switcher 2-17
Installing the MX-Bus Cables 2-21
Interconnecting the SC-4 and Utah-400 Frames 2-22
Connecting the AES Reference Signal 2-24
Determining and Setting Router Signal Levels 2-25

ii UTAH-400 Series 2 Operations Guide
Offset Switch 2-27
Serial Port 2-28
Ethernet Port 2-29
GPIO Port 2-30
Installing the Video/Unbalanced Digital Audio Input & Output 2-31
Installing the Analog Audio Input and Output Cables 2-33
Connecting and Disconnecting Power 2-34
DC Connectivity 2-36
Pre Power-Up Checks 2-37
UTAH-400 Series 2 - 72x72 AV Router 2-40
Overview 2-40
Rear Panel Interconnect 2-41
Hardware Checkout 2-42
CHAPTER 3
Configuration and Operation
In This Chapter 3-1
Utah 400 SC-4 Control 3-2
Chassis Types 3-4
72x72 Front and Rear Views 3-4
System Control Functionality 5
144 Front and Rear Views 3-6
288 Front and Rear Views 3-7
528 Module Array 3-8
Operation 3-10
Alarm Indication 3-10
Ethernet and RS-232 Connection 3-11
Crosspoint Cards Maintenance 3-11
Input and Output Card Removal and Replacement 3-12
Crosspoint Card Removal and Replacement 3-12
Air Dam Removal and Maintenance 3-13
Fan Service 3-14
Power Supply 3-15
CHAPTER 4 Utah-400 Components
In This Chapter 4-1

Table of Contents iii
Table of Contents
Video Input 4-3
Multi-rate 4-3
Video Output Boards 4-5
Multi-rate 4-5
Multirate Fiber Input Card - 121234-1 4-7
Multirate Differential Pair Output Card – 121235-1 4-9
Fiber Interface - (Optional) 4-11
Specification Detail 4-12
Frame Controller 4-13
Overview 4-13
Monitor Matrix Module 4-15
Overview 4-15
Circuit Description 4-15
Controls and Indicators 4-16
Indicators. 4-16
Video Crosspoint Board 4-17
Overview 4-17
Circuit Description 4-18
Controls and Indicators 4-18
Crosspoint LEDs (Active) 19
UT400 288x288 Crosspoint Card – 121248-1 4-20
General 4-20
Circuit Description 4-20
Controls and Indicators 4-21
UT400 144x144 Crosspoint Card – 121242-1 4-23
General 4-23
Circuit Description 4-23
Controls and Indicators 4-24
UT400 Series 2 Dis-Embedding SDI Fiber Input Card – PN 121406-1 4-26
General 4-26
Circuit Description 4-27
Power Supplies 4-27
Controls And Indicators 4-27
Specifications 4-28
Rear Panel Connections 4-29
UT400 Series 2 Dis-Embedding SDI Input Card – PN 121292-1 4-30
General 4-30
Circuit Description 4-31

iv UTAH-400 Series 2 Operations Guide
Power Supplies 4-31
Controls And Indicators 4-32
Specifications 4-32
Rear Panel Connections 4-33
UT400 Series 2 Embedding SDI Output Card – 121293-1/2 4-34
General 4-34
Circuit Description 4-35
Control 4-35
Power Supplies 4-36
Controls And Indicators 4-36
Specifications 4-37
Rear Panel Connections 4-38
UT400 Series 2 Embedding SDI Fiber Output Card – 121405-1 4-39
General 4-39
Circuit Description 4-40
Control 4-40
Power Supplies 4-41
Controls And Indicators 4-41
Specifications 4-42
Rear Panel Connections 4-43
UT400 Series 2 Triple Port MADI IO Card – 121320-1/2 4-44
General 4-44
Circuit Description 4-44
Controls And Indicators 4-45
Specifications 4-47
Rear Panel Connections 4-47
Serial Diagnostic Port Commands 4-48
UT400 Series 2 12 Port TDM Crosspoint Submodule – 121295-1 4-49
General 4-49
Circuit Description 4-49
UT400 Series 2 528 Frame TDM Crosspoint Carrier – 121323-1 4-51
General 4-51
Circuit Description 4-51
Controls And Indicators 4-52
UT4-528 Standard Digital Audio Input with TDM Board – 121288-1 4-53
General 4-53
Circuit Description 4-53
Controls and Indicators 4-54
Serial Diagnostic Port Commands 4-55
Rear Panel Connections 4-56

Table of Contents v
Table of Contents
121245-1 Rear Panel Layout (BNC) 4-58
Specifications 4-58
UT4-528 Standard Digital Audio Output with TDM Board – 121289-1 4-59
General 4-59
Circuit Description 4-59
Controls and Indicators 4-60
Specifications 4-64
Serial Diagnostic Port Commands 4-65
UT4-528 Digital Audio Digital to Analog (DAC) Output with TDM Board
– 121326-1 4-66
General 4-66
Circuit Description 4-66
Controls and Indicators 4-67
Specifications 4-69
Rear Panel Connections 4-70
Serial Diagnostic Port Commands 4-71
UT4-528 Digital Audio Analog to Digital (ADC) Input with TDM Board
– 121325-1 4-72
General 4-72
Circuit Description 4-72
Controls and Indicators 4-73
Specifications 4-74
Rear Panel Connections 4-75
Serial Diagnostic Port Commands 4-75
72x72 AV Router Components 4-76
Crosspoint Card - 121337-1 4-76
UT400 72x72 Audio Crosspoint Card – 121338-1 4-78
121332-1 SDI Module 4-80
UT400 Series 2 Advanced Input Card – 121395-1 4-82
Circuit Description 4-83
Controls And Indicators 4-84
Operational Modes 4-86
Serial Diagnostic Port Commands 4-86
Specifications 4-87
UT400 Series 2 Advanced Output Card – 121396-1 4-88
Power Supplies 4-94
UT400 Series 2 MOHO Video + MADI Output Card 4-95
General 4-95
Circuit Description 4-96

vi UTAH-400 Series 2 Operations Guide
Controls And Indicators 4-97
Specifications 4-98
Rear Panel Connections 4-99
Serial Diagnostic Port Commands 4-99
UT400 Series 2 MIHI Video + MADI Input Card 4-101
General 4-101
Circuit Description 4-101
Controls And Indicators 4-102
Specifications 4-103
Rear Panel Connections 4-103
Serial Diagnostic Port Commands 4-104
UT400 Series 2 SMPTE 2022 Receiver (121400-1) 4-106
General 4-106
Circuit Description 4-106
Controls and Indicators 4-108
Rear Panel Connections 4-109
Terminal Interface 4-110
Local Monitoring Processor Menu 4-111
UT400 Series 2 SMPTE 2022 Transmitter (121401-1) 4-116
General 4-116
Circuit Description 4-116
Controls and Indicators 4-117
Rear Panel Connections 4-118
Terminal Interface 4-119
Local Monitoring Processor Menu – 4-120
K70 Network Processor Menu – 4-120
SMPTE 2022 Processor Menu – 4-120
Specifications 4-124
Rear Panel Considerations 4-125
MX Bus 4-125
Dip Switches 4-125
Video Ref A, Video Ref B 4-125
AES Ref 4-125
Power supplies 4-126
External Power Supply 4-126
Router Power supplies 4-127
LED Indications 4-128
4-129

Table of Contents vii
Table of Contents
CHAPTER 5 Troubleshooting
In This Chapter 5-1
Subsystem Level Troubleshooting 5-2
Main Troubleshooting Chart 5-2
Video Subsystem Troubleshooting Table 5-4
Audio Subsystem Troubleshooting Table 5-5
Power Subsystem Troubleshooting Table 5-6
Power Supply Alarms 5-6
Control Subsystem Troubleshooting Table 5-7
System Controller Alarms 5-8
Control Panel Troubleshooting 5-9
UNET Panels 5-9
Ethernet Panels 5-9
APPENDIX A Specifications
In this Appendix A-1
Power A-2
Input Power and DC Power Specifications A-2
Digital Video A-3
Digital Audio Specifications A-4
Reference A-5
Reference Specifications A-5
Control A-6
Control Specifications A-6
Alarms A-6
Alarm Specifications A-6
Physical A-7
Physical Specifications A-7
Regulatory A-8
Regulatory Specifications A-8
Connector Suppliers and USI Part Numbers A-9
Connector Suppliers A-9

viii UTAH-400 Series 2 Operations Guide
APPENDIX B The Debug Port
Diagnostic Port Usage B-1
Physical Connections B-1
Baud Rate and terminal Settings B-1
Terminal Settings B-2
Recommended Terminal Emulation Program B-2
System Diagnostics – Frame Controller Module B-2
121222-1 Crosspoint card Diagnostic Interface B-7
121323-1 TDM Audio Crosspoint Carrier for 528 Systems Diagnostic
Interface B-10
121248-1 Crosspoint card Diagnostic Interface B-12
1242-1 Crosspoint Card Diagnostic Information B-15
SDI IO Card Diagnostic Information B-16
AES IO Card Diagnostic Information B-18
121320-1/2 Triple MADI IO card Diagnostic Information B-19
Embedding SDI Output Card (121293-1/2) Diagnostic Information B-20
Dis Embedding SDI Input Card (121292-1) Diagnostic Information B-21
121337-1 72x72 Crosspoint card Diagnostic Interface B-22
121338-1 72x72 Audio Crosspoint card Diagnostic Interface B-23
APPENDIX C The UT4-528 Digital Audio Breakout Panel
Scope C-2
The AES Breakout Panel Kit C-2
Description of the AES Breakout Panel C-3
Analog Rear Panels Connected to Breakout Panel C-4
AES Balanced Rear Panels Connected to Breakout Panel C-5
Connection Examples 6
Installation of the AES Breakout Panel C-7
Label Instructions for the Utah-400 Breakout Panel C-9
Scope C-9
Application C-9

Utah-400 Series 2 1-1
CHAPTER 1 Introduction
In This Guide
This guide provides instruction for the installation, configuration, and
operation the Utah Scientific, Utah-400 528 and XL Router Systems. These
routers contain redundant crosspoints with 44 to 88 slots for both the input
and output and cards, and stand 20 and 40 rack units in height.
The following chapters and appendices are included:
• Chapter 1
"Introduction" summarizes the guide, describes basic router operation and
describes the hardware and software components of the Utah-400 Digital
Routing Switcher.
• Chapter 2
"Hardware Installation" provides instructions for installing the Utah-400
Digital Routing Switcher in your facility.
• Chapter 3
"Configuration and Operation" provides specific information regarding the
configurations of this unit, and necessary equipment handling (operation).
• Chapter 4
"Utah-400 Router Components" provides basic information about the Input,
Output, Crosspoint, Interface board and Power Supplies. Included is gen-
eral information about LED indicators and alarms present on each board
type.

Introduction
1-2 Introduction
• Chapter 5
"Troubleshooting" looks at some of the common hardware and software problems, diagnostics
and solutions available to the user on site. Included in this section is information on the various
avenues to contact Utah Scientific Technical Services and tips on discussing equipment prob-
lems.
• Appendix A
"Specifications" lists all system specifications, including Audio, Video, physical, power, and
regulatory.
• Appendix B
“The Debug Port” contains information regarding the current Utah 400 firmware, along with
setup and use of the system Debug Cable.
• Appendix C
“The Utah 400 Digital Audio Breakout Panel” applies to the installation and operation of the
AES Digital Audio Break Out Panel, a component designed to simplify the installation of the
Utah-400 Balanced Digital Audio Routing System.

Utah 400 Series 2 1-3
Conventions
Conventions
The following conventions are used throughout this guide:
• Connectors and terminators will be indicated by bold, upper case text in Arial Black font.
For example:
• Connect the MX-Bus to J-1
• Operator Actions will be indicated in Helvetica Bold where a board is inserted, removed
and/or an action is required in the Troubleshooting or configuration sections of this manual.
There will usually be a graphic to accompany the instruction(s). For example:
• Insert the expansion Input board in slot 6.
• Switch the suspected bad input to a known good input to verify output "X".
• The use of bullets indicates a random order of operation or to draw the readers attention to
specific items.
1. The use of numbers in specific operations or lists indicates a "recommended order of
operation" to perform specific tasks. Bulleted items may be below numbered items to
highlight tasks or indicate the operation(s) may be performed at random.

Introduction
1-4 Introduction
Abbreviations
The following abbreviations may be used in this guide: See Appendix A for an additional
Glossary of Terms and further definitions.
TABLE 1. Common Abbreviations and Mnemonics
Abbreviation Description
ATR Audio Tape Recorder
AES Audio Engineering Society
CPU Central Processing Unit
DTR Digital Tape Recorder
EBU European Broadcast Union
ENET Ethernet
HDTV High Definition Television
I/O Input / Output
IP Internet Protocol
JPEG Joint Photographic Experts
Group
M-JPEG Motion – JPEG
MPEG Motion Picture Experts Group
MX-Bus Utah Router Control Comm.
Bus
RMS Router Management System
RU Rack Unit
SDI Serial Digital Interface
U-Net Utah Control Panel Comm.
Network
UTP Unshielded Twisted Pair
VTR Video Tape Recorder
