English
SCUBAPRO WETSUITS USER
MANUAL
This manual is published in accordance to the requirements
of EN 14225-1:2005.
The products described in this manual are manufactured
according to the specifications set by SCUBAPRO.
This manual describes materials, construction, use, care,
maintenance, repair, and inherent risks involved in the use
of neoprene wetsuits for SCUBA Diving.
Introduction and safety advice
Thanks for choosing the high quality of a SCUBAPRO
wetsuit, ensuring a new level of comfort and safety for all
your diving adventures.
If you desire more information or have questions not
answered in this manual, please do not hesitate to contact
your SCUBAPRO authorized dealer, or SCUBAPRO
directly.
NOTE: SCUBAPRO RECOMMENDS THAT ALL
DIVERS OBTAIN THE REQUIRED TRAINING AND
LEARN HOW TO USE THIS PRODUCT UNDER
THE SUPERVISION OF A CERTIFIED DIVING
INSTRUCTOR BEFORE USE UNDERWATER.
The amount of weights used must be enough to achieve
neutral buoyancy with an empty tank, it is not required to
have any more weight than this. With the correct amount
of weight you should be neutrally buoyant at a depth of
3 meters (10 feet) to make a 5 minute safety stop with 30bar
(500 psi) or less of tank pressure. Check the zip operation
before using the wetsuit. The suit must be serviced only by
trained personnel and/or a SCUBAPRO authorized dealer.
English
1

2
SCUBAPRO WETSUITS –
INFORMATION AND SPECIFICATIONS
This manual covers SCUBAPRO neoprene wetsuits,
protective clothing manufactured with limestone neoprene:
a special insulating material designed to reduce the flow of
water next to the diver’s skin and thus reduce dissipation
of body heat. And SCUBAPRO innovates even further, our
wetsuits are made with an exclusive SCUBAPRO formula:
X-Foam neoprene. X-Foam is the only formula which
complies to very strict P.A.H. test requirements. P.A.H.
(Polycyclic Aromatic Hyrocarbons) are found in many things
including petroleum based products, and can be toxic in
certain compounds. We are very encouraged to be able
to offer this neoprene blend in order to better protect both
divers and our seas.
SCUBAPRO manufactures wetsuits of various thickness
(0.5mm to 7mm) and designs to adapt to differing thermal
conditions and uses.
!ATTENTION
DO NOT RELY ON THE WETSUIT AS A BUOYANCY/
SAFETY DEVICE.
Zipper
SCUBAPRO wetsuits adopt plastic zippers that can be
located in a diagonal or vertical position on the front or back
of the wetsuit or horizontally across the shoulders.
Front and back zippers are installed to close from the
bottom-up, while across-shoulders zippers are closed with
a left-to-right movement. This choice is based on the fact
that the majority of people are right handed and so will find
it easier to close the zipper without damaging it. When an
across-shoulders zipper is present ask your dive buddy to
keep one finger in front of the zipper slider while closing it;
this allows the flatening of any neoprene that might interfere
with closing the zipper and also keeps undersuit material
away, that could get trapped in the zipper teeth. Before
closing ensure that the inner gusset has been correctly
deployed under the zipper. All slide fasteners are equipped
with gussets or flaps that reduce the water flow through
the closure. External flaps are secured in position by velcro
fasteners.
Open and close all vertical zippers while standing, this
prevents the formation of folds along the zipper length.
To minimize the chances of damage, all across-shoulder
zippers should be closed while keeping your arms extended
in front of you when zipper is in the back. Closing a

3
English
horizontal front zipper requires a slightly different technic. To
make donning easier, the arm that is NOT holding the zip
slider should be positioned to facilitate the alignment of the
zip and the movement of the slider.
The left arm should be straight and pointing backwards
when the slider is engaged and then, the right arm should
be pointing backwards when the left hand pulls the slider
to the stopper. Do not hesitate to firmly pull the slider to
initiate closure.
Make sure that the zipper slider is brought to rest against
the stop at the right end of the zipper. If the slider is not
completely closed, water will be able to enter the suit and
cause the zipper to open.
Zipper maintenance
After each dive rinse the zipper with clean fresh water to
prevent salt deposits which could cause the zipper to block.
This is especially important for zippers equipped with a metal
slider. Titex type zippers (polymer zipper) must be lubricated
using the specific product included with the wetsuit.
Seams
The seams joining the panels of all SCUBAPRO wetsuits
which are 3mm or thicker, are blind stitched and
waterproofed using glues and other substances that stop
water from passing through the seams.
Wetsuit t
• Wetsuits are designed to fit closely against the body of
the diver, nevertheless the wetsuit must not be overly
tight, impair movement or breathing or be restrictive in
any area.
• At the crotch area the wetsuit must not constrict nor be
too loose.
Ensuring a correct t
Simulate a deep inhalation to make sure that the wetsuit
does not impair the expansion of your rib cage. Make sure
you are able to join your hands above your head, touch your
toes, squat and kneel on your knees without restriction.
Please refer to the Wetsuit Size Chart to determine the best
match of your measurements in relation to SCUBAPRO
standard sizes.
Donning your wetsuit
• Lay the suit out flat and do a quick overall inspection to
ensure it is in good condition.
• Remove all jewelry – sharp edges can damage the
fairskin seals at the neck, ankles and wrists.
• Sit down if possible and insert the foot first into the suit.

4
• Fold the neoprene of the ankle gusset (if present) away
from the inner seals.
• Grasp the suit material at calf level and gently ease the foot
through the lower opening. Pull the suit up over the leg.
• Repeat with the other leg.
• Grasp the torso and ease the suit up, making sure that
the crotch of the suit is in the correct position.
• Fold the neoprene of wrist gusset (if present) away from
the inner seals.
• Insert the first arm all the way, taking care not to
damage the fairskin seal when pushing the hand
through the opening.
• Repeat with the second arm. During this process make
sure that the inner zipper flap is not folded inside the suit.
• If your suit is equipped with an across-shoulders zipper,
grasp the upper part of the neck with both hands, with
fingers on the inside and thumbs on the outside. Slightly
stretch open the neck area to help in passing your
head through, then adjust the neck seal in the most
comfortable position. Ask your diving buddy to draw
the zipper closed, moving the slider left to right, keeping
one finger in front of the slider to avoid clothing and
foreign objects from being trapped between the zipper
teeth. Make sure the slider is drawn up tight against the
right side stop.
Wetsuit usage
All SCUBAPRO wetsuit models are manufactured using
top quality materials according to the highest manufacturing
standards, however the suits must be used within
reasonable limits.
DO NOT:
• Exceed the maximum depth you are qualified for by
your certification level.
• Use the wetsuit in contaminated or heavily polluted
environments, nor in toxic or hydrocarbon-rich waters.
• Use the wetsuit as a safety/buoyancy device.
• Use the wetsuit with a weight harness or other weight
system not equipped with a quick-release system.
Pre-dive checks
Before EVERY dive make sure that the wetsuit is in good
condition by checking seams, visible damage to materials
or components, tears and holes. Ensure that the zipper is
working and not damaged or prone to blocking.
Post-dive checks
After EVERY dive, repeat the pre-dive checks and inspect
the suit for possible new damage that might have occurred
during the dive. If you detect any kind of damage, repair

5
English
it as soon as possible or take the suit to a SCUBAPRO
authorized dealer for repair.
Assessment of risks
Diving with a wetsuit carries an inherent amount of risk, just
as any other SCUBA diving activity. These risks include:
Hypothermia – Hyperthermia
Wetsuits are used in varying temperature conditions, where
there may be combinations of cold at the surface and in the
water or warm/hot surface conditions and cold water. It is
important to be aware of your own thermal comfort range,
so as to be able to prevent overheating or chilling.
A wetsuit provides excellent thermal protection but it does
have limits and your safety and fun will depend on the
combined action of water temperature, workload and your
own body type.
If the body loses too much heat and the body temperature
reaches unsafe levels, we are in a condition known as
hypothermia. Hyperthermia takes place when the body
temperature rises beyond the normal range. While using
a wetsuit hyperthermia can be experienced during surface
intervals in warm climates or while diving in warm, shallow
waters when engaged in activities that require a high
workload.
It is strongly advisable to always wear gloves, boots and
hood together with a wetsuit anytime the water temperature
may expose the diver to the risk of hypothermia.
It is important to know your own limitations and comfort
range, this allows you to recognize a situation of discomfort
as a danger signal. Hypothermia and/or hyperthermia are
both harmful and possibly fatal conditions.
During any diving activity, constantly monitor your workload
to prevent excessive gas consumption, fatigue, stress,
overheating and other risks.
Please refer to the following table to determine the
wetsuit model best suited to your needs and usual water
temperatures; make sure to check the thermal performance
class printed on the suit.
WETSUIT THERMAL PROTECTION CLASS
Thermal performance
class of wet suit material
Water temperature ranges
(°C)
A 7°C/45°F to 12°C/54°F
B 10°C/50°F to 18°C/64.5°F
C 16°C/60.8°F to 24°C/75.2°F
D >22°C/72°F

6
Buoyancy change at depth
All neoprene products used in SCUBA diving incorporate a
closed-cell foam to provide thermal protection. As the diver
descends, the pressure increase causes these bubbles to
shrink in volume, resulting in a reduction of buoyancy at
depth.
NOTE: Learning how to compensate for this loss of
buoyancy is one of the vital skills that must be learned
in the proper use of a wetsuit.
Thermal protection loss at depth
When neoprene thins under pressure (see above) the
thermal performance of the material is reduced. Divers
planning to spend time at greater depths must account
for the diminished thermal protection at depth by wearing
additional protection under the suit or using thicker suits.
Wetsuit ergonomics
It is very important that the wetsuit correctly fits the body of
the diver. A loose wetsuit will allow water to move inside the
suit and to flow in and out. Water exchange between the
inside and the outside of the suit will result in a much higher
thermal loss than that taking place through the wetsuit
material during normal usage.
The correct wetsuit size must be chosen to prevent the
formation of folds or “pockets” caused by excess material.
During the dive these folds will tend to pump water in and
out of the suit.
Neck, ankle and wrist seals must be able to reduce the
flow of water, but not be so tight as to restrict circulation
to the hands, feet and head. A restriction of blood flow to
the extremities can result in a loss of feeling, nitrogen build
up, or lack of oxygen to the brain with the risk of a loss of
consciousness while underwater.
Allergies
A small percentage of the population is known to experience
allergic reactions to neoprene, polyester and nylon. Make
sure you do not suffer from allergies to these materials
before purchasing or using any wetsuit containing them.
Cleaning and disinfection
After EVERY use of your wetsuit:
• Rinse the inside and outside of your suit with clean fresh
water.
• Hang the suit in a position that allows the water to flow
away from the suit.

7
English
• Allow sufficient time for the suit to dry both internally
and externally.
• From time to time perform an accurate cleaning of
the wetsuit (in a washing machine set on the “delicate
fabrics” program)
Storage and Transport
Wetsuits are best stored on the SCUBAPRO “Multi-
Hanger” that can hold all wetsuit components. Keep the
wetsuit in a dry, cool place and away from direct sunlight.
Other component-specific advice may be found in previous
sections of this manual.
Transport wetsuits in bags designed for SCUBA gear
to avoid folding the suit in several places and prevent
excessive neoprene compression. Clean excess dirt and
sand from the suit before storing it in a bag.
Disposal
When you will need to dispose of the suit, please
make sure to do so according to local regulations
and prescriptions.

74
EVERFLEX, PROFILE AND ONEFLEX SUIT SIZE CHART
Size Chart Chest Waist Hips Height Weight
Tauchanzüge Brust Faille Hüfte Gröbe Gewicht
Tailles Poitrine Cinture Hanches Hauteur Poids
Taglie Torace Vita Fianchi Altezza Peso
Tallas Pecho Cadera Hanches Altura Peso
Maattabel Borst Taille Heupen Lengte Gewicht
Medida Peito Cintura Anca Altora Peso
Mérettáblázat Mellbőség Derékbőség Csípőbőség
Testmagasság
Súly
Karta Rozmiarów Klatka
piersiowa Talia Biodra Wzrost Ciężar
Tabel Marimi Bust Talie Solduri Inaltime Greutate
Men / Herren / Hommes / Uomo / Hombres / Heren / Homen / Férfi/ Męska / Barbat
2XS 44 78 - 82 64 - 68 76 - 80 160 - 165 60 - 65
XS 46 83 - 87 69 - 73 81 - 85 165 - 170 65 - 70
S 48 88 - 92 74 - 78 86 - 90 170 - 175 70 - 75
SR 24 93 - 97 79 - 83 91 - 95 170 - 175 75 -80
M 50 93 - 97 79 - 83 91 - 95 175 - 180 75 - 80
MT 98 93 - 97 79 - 83 91 - 95 180 - 185 75 - 80
MR 26 98 - 102 84 - 88 96 - 100 175 - 180 80 - 85
L 52 98 - 102 84 - 88 96 - 100 180 - 185 80 - 85
LT 102 98 - 102 84 - 88 96 - 100 185 - 190 80 - 85
LR 27 103 - 107 89 - 93 101 - 105 180 - 185 85 - 90
XL 54 103 - 107 89 - 93 101 - 105 185 - 190 85 - 90
XLR 28 108 - 112 94 - 98 106 - 110 190 -195 90 - 95
2XL 56 108 - 112 94 - 98 106 - 110 195 -200 95 - 100
3XL 58 113 - 117 99 - 103 112 - 116 200 - 205 100 - 105
Women / Damen / Femmes / Donna / Mujeres / Dames / Molher / Asszony / Damska / Femeie
2XS 34 72-77 59 - 63 81 - 85 150 - 160 40 - 45
XS 36 78-83 63 - 67 85 - 89 155 - 165 45 - 50
S 38 83-87 67 - 69 89 - 93 160 - 170 50 -55
SR 20 86-91 71 - 75 93 - 97 160 - 170 55 -60
ST 74 83-87 67 - 71 89 - 93 165 - 175 50 -55
M 40 86-91 71 - 75 93 - 97 165 - 175 55 -60
MR 21 90-95 75 - 79 97 - 101 165 - 175 60 - 65
MT 76 86-91 71 - 75 93 - 97 170 - 175 55 -60
L 42 90-95 75 - 79 97 - 101 170 - 175 60 - 65
XL 44 94-99 79 - 83 101 - 105 170 - 180 65 - 70
2XL 46 98-103 83 - 87 105 - 109 175 - 180 70 - 75

NOVASCOTIA SIZE CHART
Size Chart Chest Waist Hips Height Weight
Tauchanzüge Brust Faille Hüfte Gröbe Gewicht
Tailles Poitrine Cinture Hanches Hauteur Poids
Taglie Torace Vita Fianchi Altezza Peso
Tallas Pecho Cadera Hanches Altura Peso
Maattabel Borst Taille Heupen Lengte Gewicht
Medida Peito Cintura Anca Altora Peso
Mérettáblázat Mellbőség Derékbőség Csípőbőség
Testmagasság
Súly
Karta Rozmiarów Klatka
piersiowa Talia Biodra Wzrost Ciężar
Tabel Marimi Bust Talie Solduri Inaltime Greutate
Men / Herren / Hommes / Uomo / Hombres / Heren / Homen / Férfi/ Męska / Barbat
XS 46 76-80 62-66 77-81 165-170 65-70
S 48 81-85 67-71 83-87 170-175 70-75
M 50 86-90 72-76 88-92 175-180 75-80
MT 98 86-90 72-76 88-92 180-185 75-80
MR 26 91-95 76-80 93-97 175-180 80-85
L 52 91-95 76-80 93-97 180-185 80-85
LT 102 91-95 76-80 93-97 185-190 80-85
LR 27 96-100 81-85 98-102 180-185 85-90
XL 54 96-100 81-85 98-102 185-190 85-90
2XL 56 101-105 86-90 102-106 190-195 95-100
3XL 58 105-109 89-93 106-110 195-200 100-105
Women / Damen / Femmes / Donna / Mujeres / Dames / Molher / Asszony / Damska / Femeie
XS 36 78-83 60-64 79-83 155-165 45-50
S 38 83-87 62-66 83-87 160-170 50-55
M 40 86-91 65-69 87-91 165-175 55-60
L 42 90-95 70-74 92-96 170-175 60-65
XL 44 94-99 74-78 95-99 170-180 65-70

NOTE
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................
................................................................................................................................

P/N 45.021.450 • Rev. B - 06/2013 • Artbook 9867/13
