UWS TRUCK FENDER TOOL BOX User manual

UWSTA.COM •NEED ASSISTANCE? •8 7 7. 2 8 7. 8 6 3 4 •RA •PAGE 1
INSTALLATION MANUAL
Tools Required
Drill Drill bit set
Ratchet Socket set
Tape measure --
Level of Difficulty
Easy
Representative Product Photos (your specific box may vary in style, size or finish)
TRUCK FENDER
TOOL BOX
Maintenance
For polished, gloss and other smooth
finishes, polish may be used to clear
small scratches and scuffs on the finish.
Mild automotive detergent may be used to
clean the product. Do not use dish detergent,
abrasive cleaners, abrasive pads, wire
brushes or other similar products that
may damage the finish.
DANGER
Danger of explosion. Do not use this product for storing or transporting flammables,
explosives, hazardous materials or hazardous waste, such as containers of gasoline,
solvents, gun powder, dynamite, propane tanks, acetylene tanks and cutting torches.
WARNING
Never exceed the vehicle manufacturer's recommended capacity.
This product can reduce the driver's ability to clearly see roadways, vehicular or pedestrian
traffic and other objects through the rear and side windows of the vehicle, which may cause
an accident. Extra precaution should be taken when driving a vehicle with this product.
Do not interfere with factory-installed safety equipment.
NOTICE
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
To help prevent damage to the product or vehicle, refer to the torque
specifications when securing hardware during the installation process.
Do not use this product for purposes other than those
for which they were designed. Never modify this product.
Consult your dealer if you have any questions regarding
the installation, operation, use and limits of this product.
Treat or seal all fasteners and exposed metal in any
holes drilled in vehicle to prevent corrosion.
Parts List*
1Truck fender tool box
2Key
* Hardware not included. You must purchase
your own hardware to install this tool box.
Torque Specifications*
Metric
M6 bolt 3 ft-lbs.
M8 bolt 7 ft-lbs.
M10 bolt 16 ft-lbs.
M12 bolt 28 ft-lbs.
SAE
1/4" bolt 3 ft-lbs.
5/16" bolt 7 ft-lbs.
3/8" bolt 16 ft-lbs.
7/16" bolt 20 ft-lbs.
1/2" bolt 28 ft-lbs.
* Above specifications are general guidelines.
If purchasing hardware use the torque
specifications provided with that hardware.
Product Registration and Warranty
CURT Group stands behind our products with industry-leading warranties.
Provide feedback and help us to improve our products by registering your purchase at:
warranty.curtgroup.com/surveys

UWSTA .COM •NEED ASSISTANCE? •8 7 7. 2 8 7. 8 6 3 4 •RA •PAGE 2
Step 1
Remove the bottom two drawers from the tool box and place the tool box on the bed of the truck.
Ensure the paddle handle clears the bed rail of the truck and the tool box lid opens properly.
A custom shim may need to be placed under the tool box so the handle can be accessed.
Step 2
Locate two desired mounting points on the lip of the bed rail. Ensure there is nothing in the way of drilling or obstructing the tool box from
mounting properly. Measure these locations and mark your drill holes on the tool box. Drill 1/4" holes in the tool box in the marked locations.
Locate two desired mounting points on the base of the tool box where the drawers have been removed. Ensure there is nothing
in the way of drilling or obstructing the tool box from mounting properly. Drill 1/4" holes in the tool box in the marked locations.
Step 3
WARNING
Before drilling into your truck bed, check under your vehicle to ensure the drill location does not puncture,
cut or obstruct any brake or fuel fluid lines, electrical wires, fuel tanks, etc. Precaution must be taken that all
fasteners near the fuel tank do not create the possibility of fuel tank puncture or other damage during a collision.
Use the drilled holes in the tool box to mark the lip of the bed rail and the bed of the truck. Remove the tool box and drill 1/4"
holes in all marked locations. Align the holes in the tool box with the drilled holes in the bed of the truck and lip of the bed rail.
Insert a minimum of one bolt and flat washer (not provided) through each drilled hole of the tool box and secure with one
flat washer and nylock nut (not provided) on the underside of the mounting surface. Do this for each mounting hole.
Tighten all hardware to the recommended torque specifications on page 1.
Re-install the bottom two drawer slides.
Step 4
CAUTION
Ensure all knobs, bolts, screws, straps and
locks are firmly secured before every trip.
Periodically re-tighten and inspect all components
for signs of wear, corrosion and fatigue.
With the truck fender tool box installed,
periodic inspections should be performed to
ensure all mounting hardware remains tight.
To protect your investment, see the
'Maintenance' section on page 1.
Congratulations on the installation
of your new UWS truck fender tool box.
