V-TAC VT-7405 User manual

INSTRUCTION MANUAL
WEEE Number: 80133970
Thank you for selecting and buying V-TAC Wireless Charger device. V-TAC will serve you the
best. Please read these instructions carefully before starting the installation and keep this
manual handy for future reference. If you have any other query, please contact our dealer or
local vendor from whom you have purchased the product. They are trained and ready to serve
you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The
company gives no warranty against damage to any surface due to incorrect removal and
installation of the product. This product is warranted for manufacturing defects only.
SKU: 8600 SKU: 8601
INTRODUCTION & WARRANTY
Wireless charging desk lamp is an intelligent product. Designed with LED source which is the
most advanced lighting-tech with uniform and soft, high efficiency and CRI, advanced
constant current and flicker -free to protect your eyes. With 135’ rotating head and 90’ arm,
the lamp is able to reach almost every position you can imagine. Also, it has built-in wireless
charger which compatible with any Qi-Standard phones and devices. It is integrated with USB
output function which makes charging much easier
LED TABLE LAMP WITH WIRELESS CHARGER
MODEL VT-7405
RATING INPUT DC:5V/3A
INPUT POWER AC: 100-240V, 50/60Hz
COLOR TEMPERATURE 2700K- 6500K
CRI >80
DIMMING BRIGHTNESS 4 LEVELS
USB OUTPUT 5V, 0.5A (2.5W)
ILLUMINANCE 800 LM at 36cm
LONG LIFE 20,000 HOURS
WIRELESS CHARGING
OUTPUT 5V, 1A
ON/OFF CYCLE >10,000
OPERATION
TEMPERATURE -20° ~+45°
TIME TO REACH THE
BRIGHTNESS 2S
TECHNICAL DATA

Wireless Charging
Desk Lamp (1pc)
User Manual
(1pc)
USB Charging
Cable (1pc)
3A Adapter
Included (1pc)
Wireless Charging Indicator
Brightness Increase
Brightness Decrease
1Hour Power Off
2Hours Power Off
Power On/Off
Lighting Adjustment
PARTS INDICATOR
PACKAGE CONTENTS
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
This marking indicates that this
product should not be disposed
of with other household wastes.

1. Put the micro USB port into the power input of the desk lamp
2. Refer to the functions of each button in previous page (Outline) to use the lamp.
Short press is required to adjust the functions except that brightness increase and
decrease need long press.
OPERATION GUIDE
3. When using the wireless charging function, place phones with Qi receiver
onto the wireless charging area. At this time, the wireless charging indicator
turns on and flickers to indicate that wireless charging is ON. The indicator turns
off after the phone is removed.
4. To charge a digital device, use a piece of charging cable to connect the USB
output port of desk lamp with the charging port of the device.
FIG 1
FIG 2
FIG 3 USB Output Port
5V/3A Input Port

1. Please do not put the lamp on high temperature surfaces, and do not use it in
flammable or humid
environment to avoid the breakdown, short circuit etc.
2. The adapter must be under the specialized range.
3. Place the base of table lamp on steady base while adjusting the arm.
4. The lamp head of the table lamp can be adjusted up to certain angle only. Be
careful not to overturn the lamp head beyond the adjusting angle in order to avoid
any damage to the lamp.
OPERATION CAUTIONS
1. Please clean the lamp once in every two months to keep it smooth and bright.
2. Use cleaning cloth and water to clean the dust
3. For filthy marks, please use cleaning cloth and soapsuds.
4. Please do not clean the lamp by high-volatility and high-corrosive liquid which
can lead to discoloring or damaging the lamp.
5. To ensure using effect, please use an DC5V/3A adaptor and good quality cable
6. Among three functions of wireless charging, USB output and desk lamp. Only
two functions can be used the same time.
7. Please keep it away from water or other liquid
8. Power off the item before it is cleaned
MAINTENANCE
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: [e-mail]
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
