Vacon NXL User manual

vacon nxl
ac drives
user manual
multi-control
application manual
®

AT LEAST THE 11 FOLLOWING STEPS OF THE START-UP QUICK GUIDE MUST BE PERFORMED
DURING THE INSTALLATION AND COMMISSIONING.
IF ANY PROBLEMS OCCUR, PLEASE CONTACT YOUR LOCAL DISTRIBUTOR.
Start-up Quick Guide
1. Check that the delivery corresponds to your order, see Chapter 3.
2. Before taking any commissioning actions read carefully the safety instructions in
Chapter 1.
3. Before the mechanical installation, check the minimum clearances around the unit and
check the ambient conditions in Chapter 5.
4. Check the size of the motor cable, mains cable, mains fuses and check the cable
connections, read Chapter 6.
5. Follow the installation instructions, see Chapter 5.
6. Control cable sizes and the grounding system are explained in Chapter 6.1.1.
7. Instructions on using the keypad are given in Chapter 7.
8. All parameters have factory default values. In order to ensure proper operation, check
the rating plate data for the values below and the corresponding parameters of
parameter group P2.1. See Chapter 8.3.2.
•nominal voltage of the motor, par. 2.1.6
•nominal frequency of the motor, par. 2.1.7
•nominal speed of the motor, par 2.1.8
•nominal current of the motor, par. 2.1.9
•motor power factor, cosϕ, par. 2.1.10
All parameters are explained in the Multi-Control Application Manual.
9. Follow the commissioning instructions, see Chapter 8.
10. The Vacon NXL Frequency Converter is now ready for use.
11. In the end of this manual, you will find a quick help with the default I/O, control panel
menus, monitoring values, fault codes and basic parameters
Vacon Plc is not responsible for the use of the frequency converters against
the instructions.

CONTENTS
VACON NXL USER’S MANUAL
INDEX
1SAFETY
2EU DIRECTIVE
3RECEIPT OF DELIVERY
4TECHNICAL DATA
5INSTALLATION
6CABLING AND CONNECTIONS
7CONTROL KEYPAD
8COMMISSIONING
9FAULT TRACING
10 DESCRIPTION OF BOARD OPT-AA
11 DESCRIPTION OF BOARD OPT-AI
VACON MULTI-CONTROL APPLICATION MANUAL

Safety vacon •3
24-hour support: [phone] • Email: [e-mail]
1
ABOUT THE VACON NXL USER'S MANUAL
AND THE MULTI-CONTROL APPLICATION MANUAL
Congratulations for choosing the Smooth Control provided by Vacon NXL frequency converters!
The User's Manual will provide you with the necessary information about the installation,
commissioning and operation of Vacon NXL Frequency Converter. We recommend that you carefully
study these instructions before powering up the frequency converter for the first time.
In the Multi-Control Application Manual you will find information about the application used in the
Vacon NXL Drive.
This manual is available in both paper and electronic editions. We recommend you to use the
electronic version if possible. If you have the electronic version at your disposal you will be able to
benefit from the following features:
The manual contains several links and cross-references to other locations in the manual which
makes it easier for the reader to move around in the manual, to check and find things faster.
The manual also contains hyperlinks to web pages. To visit these web pages through the links you
must have an internet browser installed on your computer.
NOTE: You will not be able to edit the Microsoft Word version of the manual without a valid password.
Open the manual file as a read-only version.
All specifications and information are subject to changes without further notice.

4 •vacon Safety
Telephone: [phone] • Fax: [phone]
1
Vacon NXL User's Manual
Document code: DPD01446A
Table of contents Date: 24.02.2014
1. SAFETY............................................................................................................................. 7
1.1 Warnings ................................................................................................................................... 7
1.2 Safety instructions.................................................................................................................... 7
1.3 Earthing and earth fault protection ......................................................................................... 8
1.4 Running the motor.................................................................................................................... 9
2. EU DIRECTIVE ................................................................................................................ 10
2.1 CE marking ............................................................................................................................. 10
2.2 EMC directive .......................................................................................................................... 10
2.2.1 General............................................................................................................................ 10
2.2.2 Technical criteria............................................................................................................ 10
2.2.3 Environments defined in the product standard EN 61800-3:2004+A1:2012................. 10
2.2.4 Vacon frequency converter EMC classification ............................................................. 10
2.2.5 Manufacturer's declaration of conformity..................................................................... 11
3. RECEIPT OF DELIVERY................................................................................................... 13
3.1 Type designation code ............................................................................................................ 13
3.2 Storage.................................................................................................................................... 14
3.3 Maintenance............................................................................................................................ 14
3.4 Warranty.................................................................................................................................. 15
4. TECHNICAL DATA .......................................................................................................... 16
4.1 Introduction............................................................................................................................. 16
4.2 Power ratings.......................................................................................................................... 18
4.2.1 Vacon NXL – Mains voltage 208 – 240 V......................................................................... 18
4.2.2 Vacon NXL – Mains voltage 380 – 500 V......................................................................... 18
4.3 Technical data......................................................................................................................... 19
5. INSTALLATION............................................................................................................... 21
5.1 Mounting ................................................................................................................................. 21
5.1.1 MF2 and MF3 .................................................................................................................. 21
5.1.2 MF4 – MF6....................................................................................................................... 24
5.2 Cooling .................................................................................................................................... 25
5.3 Changing EMC protection class from H to T.......................................................................... 26
6. CABLING AND CONNECTIONS ....................................................................................... 27
6.1 Power connections ................................................................................................................. 27
6.1.1 Cabling ............................................................................................................................ 28
6.1.1.1 Cable and fuse sizes............................................................................................... 29
6.1.2 Mounting of cable accessories....................................................................................... 30
6.1.3 Installation instructions ................................................................................................. 32
6.1.3.1 Stripping lengths of motor and mains cables ....................................................... 33
6.1.3.2 Installation of cables to Vacon NXL ....................................................................... 34
6.1.4 Cable installation and the UL standards ....................................................................... 42
6.1.5 Cable and motor insulation checks ............................................................................... 42
6.2 Control unit ............................................................................................................................. 43
6.2.1 MF2 – MF3....................................................................................................................... 43

Safety vacon •5
24-hour support: [phone] • Email: [e-mail]
1
6.2.2 MF4 – MF6....................................................................................................................... 43
6.2.2.1 Allowed option boards in MF4 – MF6:.................................................................... 43
6.2.3 Control connections ....................................................................................................... 44
6.2.4 Control I/O....................................................................................................................... 45
6.2.5 Control terminal signals ................................................................................................ 46
6.2.5.1 Jumper selections on Vacon NXL basic board...................................................... 47
6.2.6 Motor thermistor (PTC) connection ............................................................................... 50
7. CONTROL KEYPAD ......................................................................................................... 51
7.1 Indications on the Keypad display.......................................................................................... 51
7.1.1 Drive status indications.................................................................................................. 51
7.1.2 Control place indications................................................................................................ 52
7.1.3 Numeric indications ....................................................................................................... 52
7.2 Keypad push-buttons.............................................................................................................. 53
7.2.1 Button descriptions ........................................................................................................ 53
7.3 Start-up wizard ....................................................................................................................... 54
7.4 Navigation on the control keypad........................................................................................... 55
7.4.1 Monitoring menu (M1) .................................................................................................... 58
7.4.2 Parameter menu (P2)..................................................................................................... 61
7.4.3 Keypad control menu (K3).............................................................................................. 63
7.4.3.1 Selection of control place ...................................................................................... 63
7.4.3.2 Keypad reference ................................................................................................... 64
7.4.3.3 Keypad direction..................................................................................................... 64
7.4.3.4 Stop button activation............................................................................................. 64
7.4.4 Active faults menu (F4)................................................................................................... 65
7.4.4.1 Fault types .............................................................................................................. 65
7.4.4.2 Fault codes ............................................................................................................. 66
7.4.5 Fault history menu (H5).................................................................................................. 68
7.4.6 System menu (S6)........................................................................................................... 69
7.4.6.1 Copy parameters .................................................................................................... 71
7.4.6.2 Security ................................................................................................................... 71
7.4.6.3 Keypad settings ...................................................................................................... 72
7.4.6.4 Hardware settings.................................................................................................. 73
7.4.6.5 System information ................................................................................................ 74
7.4.6.6 AI mode ................................................................................................................... 77
7.4.7 Modbus interface............................................................................................................ 78
7.4.7.1 Modbus RTU protocol............................................................................................. 78
7.4.7.2 Termination Resistor.............................................................................................. 79
7.4.7.3 Modbus address area............................................................................................. 79
7.4.7.4 Modbus process data ............................................................................................. 79
7.4.7.5 Fieldbus parameters.............................................................................................. 81
7.4.8 Expander board menu (E7)............................................................................................. 83
7.5 Further keypad functions ....................................................................................................... 83
8. COMMISSIONING............................................................................................................ 84
8.1 Safety....................................................................................................................................... 84
8.2 Commissioning of the frequency converter........................................................................... 84
8.3 Basic parameters ................................................................................................................... 87
8.3.1 Monitoring values (Control keypad: menu M1).............................................................. 87
8.3.2 Basic parameters (Control keypad: Menu P2 B2.1).................................................. 88
9. FAULT TRACING............................................................................................................. 90

6 •vacon Safety
Telephone: [phone] • Fax: [phone]
1
10. DESCRIPTION OF EXPANDER BOARD OPT-AA............................................................... 93
11. DESCRIPTION OF EXPANDER BOARD OPT-AI................................................................ 94

Safety vacon •7
24-hour support: [phone] • Email: [e-mail]
1
1. SAFETY
1.1 Warnings
HOT SURFACE
1
The components of the power unit of the frequency converter are
live
when Vacon NXL is connected to mains potential.
Coming into contact
with this voltage is extremely dangerous and may cause death or
severe injury.
The control unit is isolated from the mains potential.
2
The motor terminals U, V, W (T1, T2, T3) and the DC-link/brake resistor
terminals –/+ (in Vacon NXL ≥1.1 kW) are
live
when Vacon NXL is
connected to mains,
even if the motor is not running
.
3
The control I/O-terminals are isolated from the mains potential.
However, the relay outputs and other I/O-terminals may have a
dangerous control voltage present even when Vacon NXL is disconnected
from mains.
4
The earth leakage current of Vacon NXL
exceeds 3.5mA a.c
. According
to EN61800-5-1, a reinforced protective ground connection must be
ensured
.
See Chapter 1.3.
5
If the frequency converter is used as a part of a machine, the machine
manufacturer is responsible for providing the machine with a
disconnecting device (EN60204-1).
6
Only spare parts delivered by Vacon can be used.
7
The heat sink of types MF2 and MF3 may be hot when the frequency
converter is in use.
Coming into contact with the heat sink may cause
burns
.
1.2 Safety instructions
1
The Vacon NXL frequency converter is meant for fixed installations only.
2
Do not perform any measurements when the frequency converter is
connected to the mains.
3
After disconnecting the frequency converter from the mains, wait until
the fan stops and the indicators on the display go out. Wait 5 more
minutes before doing any work on Vacon NXL connections.
5
Do not perform any voltage withstand tests on any part of Vacon NXL.
There is a certain procedure according to which the tests shall be
performed. Ignoring this procedure may result in damaged product.
6
Prior to measurements on the motor or the motor cable, disconnect the
motor cable from the frequency converter.
7
Do not touch the IC-circuits on the circuit boards. Static voltage
discharge may damage the components.
ONLY A COMPETENT ELECTRICIAN MAY CARRY OUT
THE ELECTRICAL INSTALLATION
WARNING

8 •vacon Safety
Telephone: [phone] • Fax: [phone]
1
1.3 Earthing and earth fault protection
The Vacon NXL frequency converter must always be earthed with an earthing conductor connected to
the earthing terminal .
The earth leakage current of Vacon NX_ exceeds 3.5mA AC. According to EN61800-5-1, one or more
of the following conditions for the associated protective circuit shall be satisfied:
a. The protective conductor shall have a cross-sectional area of at least 10 mm2Cu or 16 mm2Al,
through its total run.
b. Where the protective conductor has a cross-sectional area of less than 10 mm2Cu or 16 mm2Al, a
second protective conductor of at least the same cross-sectional area shall be provided up to a
point where the protective conductor has a cross-sectional area not less than 10 mm2Cu or 16
mm2Al.
c. Automatic disconnection of the supply in case of loss of continuity of the protective conductor. See
chapter 6.
The cross-sectional area of every protective earthing conductor which does not form part of the
supply cable or cable enclosure shall, in any case, be not less than:
-2,5mm2 if mechanical protection is provided or
-4mm2 if mechanical protection is not provided.
The earth fault protection inside the frequency converter protects only the converter itself against
earth faults in the motor or the motor cable. It is not intended for personal safety.
Due to the high capacitive currents present in the frequency converter, fault current protective
switches may not function properly.

Safety vacon •9
24-hour support: [phone] • Email: [e-mail]
1
1.4 Running the motor
Warning symbols
For your own safety, please pay special attention to the instructions marked with the following
symbols:
= Dangerous voltage
WARNING
= General warning
HOT SURFACE
= Hot surface – Risk of burn
MOTOR RUN CHECK LIST
1
Before starting the motor, check that the motor is mounted properly and
ensure that the machine connected to the motor allows the motor to be
started.
2
Set the maximum motor speed (frequency) according to the motor and
the machine connected to it.
3
Before reversing the motor shaft rotation direction make sure that this
can be done safely.
4
Make sure that no power correction capacitors are connected to the
motor cable.
5
Make sure that the motor terminals are not connected to mains
potential.
NOTE! You can download the English and French product manuals with applicable safety, warning
and caution information from www.vacon.com/downloads.
REMARQUE Vous pouvez télécharger les versions anglaise et française des manuels produit
contenant l’ensemble des informations de sécurité, avertissements et mises en garde applicables
sur le site www.vacon.com/downloads.
WARNING

10 • vacon eu directive
Telephone: [phone] • Fax: [phone]
2
2. EU DIRECTIVE
2.1 CE marking
The CE marking on the product guarantees the free movement of the product within the EEA
(European Economic Area). It also guarantees that the product meets the various requirements
placed upon it (such as the EMC Directive and possibly other directives according to the so-called
new procedure).
Vacon NXL frequency converters carry the CE label as a proof of compliance with the Low Voltage
Directive (LVD) and the Electro Magnetic Compatibility (EMC). The company SGS FIMKO has acted as
the Competent Body.
2.2 EMC directive
2.2.1 General
The EMC Directive provides that the electrical apparatus must not excessively disturb the
environment they are used in, and, on the other hand, it shall have an adequate level of immunity
toward other disturbances from the same environment.
The compliance of Vacon NXL frequency converters with the EMC directive is verified with Technical
Construction Files (TCF) checked and approved by SGS FIMKO, which is a Competent Body.
2.2.2 Technical criteria
EMC compliance is a major consideration for Vacon NXL drives from the outset of the design. Vacon
NXL frequency converters are marketed throughout the world, a fact which makes the EMC
requirements of customers different. All Vacon NXL frequency converters are designed to fulfil even
the strictest immunity requirements.
2.2.3 Environments defined in the product standard EN 61800-3:2004+A1:2012
First environment: environment that includes domestic premises, it also includes establishments
directly connected without intermediate transformers to a low-voltage power supply network which
supplies buildings used for domestic purposes.
Note: houses, apartments, commercial premises or offices in a residential building are examples of
first environment locations.
Second environment: environment that includes all establishments other than those directly
connected to a low-voltage power supply network which supplies buildings used for domestic
purposes.
Note: industrial areas, technical areas of any building fed from a dedicated transformer are
examples of second environment locations.
2.2.4 Vacon frequency converter EMC classification
Vacon NX frequency converters are divided into five classes according to the level of electromagnetic
disturbances emitted, the requirements of the power system network and the installation
environment. The EMC class of each product is defined in the type designation code. Later in this
manual the division is made according to the mechanical sizes (MF2, MF3, etc.). The technical data
of the different sizes can be found in Chapter 4.3.

EU directive vacon •11
24-hour support: [phone] • Email: [e-mail]
2
Vacon EMC Class C (MF4 to MF6):
Frequency converters of this class comply with the category C1 requirements of the product family
standard EN 61800-3:2004+A1:2012. The category C1 ensures the best EMC characteristics and it
includes converters with rated voltage less than 1000V and intended for use in the first environment.
Vacon EMC Class H:
Vacon NXL frames MF4 – MF6 are delivered from the factory as class H products with an internal
RFI filter. The filter is available as option for classes MF2 and MF3. With a RFI filter Vacon NXL
frequency converters comply with the category C2 requirements of the product family standard EN
61800-3:2004+A1:2012. The category C2 includes converters which are in fixed installations and the
rated voltage of which is less than 1000V. The class H frequency converters can be used both in 1st
and 2nd environment. Note: if class H converters will be used in the first environment they shall be
installed and commissioned only by a professional.
Vacon EMC Class L
Frequency converters of this class comply with the requirements of category C3 of the product
standard EN 61800-3:2004+A1:2012. Category C3 includes converters the rated voltage of which is
less than 1000V and which are intended for use in the second environment only.
Vacon EMC Class T:
Frequency converters of this class fulfil the product family standard EN 61800-3:2004+A1:2012 if
intended to be used in IT systems. In IT systems, networks are isolated from earth, or connected to
earth through high impedance to achieve a low leakage current. Note: if converters are used with
other supplies, no EMC requirements are complied with.
Vacon EMC Class N:
The drives of this class do not have EMC emission protection and are mounted in enclosures. Vacon
NXL frames MF2 and MF3 are delivered from the factory without an external RFI filter as class N
products.
All Vacon NX frequency converters fulfil all EMC immunity requirements of the product family
standard EN 61800-3:2004+A1:2012.
Note: For changing the EMC protection class of your Vacon NXL frequency converter from class H or
L to class T, please refer to the instructions given in Chapter 5.3.
2.2.5 Manufacturer's declaration of conformity
The following page presents the photocopy of the Manufacturer's Declaration of Conformity assuring
the compliance of Vacon frequency converters with the EMC-directives.
Warning!
In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.

12 • vacon eu directive
Telephone: [phone] • Fax: [phone]
2
EC DECLARATION OF CONFORMITY
We
Manufacturer's name: Vacon Oyj
Manufacturer's address: P.O.Box 25
Runsorintie 7
FIN-65381 Vaasa
Finland
hereby declare that the product
Product name: Vacon NXL Frequency converter
Model designation: Vacon NXL 0001 5…to 0061 5…
Vacon NXL 0002 2...to 0006 2
has been designed and manufactured in accordance with the following standards:
Safety: EN 61800-5-1:2007
EMC: EN 61800-3:2004+A1:2012
and conforms to the relevant safety provisions of the Low Voltage Directive
2006/95/EC and EMC Directive 2004/108/EC.
It is ensured through internal measures and quality control that the product
conforms at all times to the requirements of the current Directive and the relevant
standards.
In Vaasa, 24th of January, 2014
Vesa Laisi
President
The year the CE marking was affixed:
2002

Receipt of delivery vacon •13
24-hour support: [phone] • Email: [e-mail]
3
3. RECEIPT OF DELIVERY
Vacon NXL frequency converters have undergone scrupulous tests and quality checks at the factory
before they are delivered to the customer. However, after unpacking the product, check that no
signs of transport damages are to be found on the product and that the delivery is complete
(compare the type designation of the product to the code below).
Should the drive have been damaged during the shipping, please contact primarily the cargo
insurance company or the carrier.
If the delivery does not correspond to your order, contact the supplier immediately.
3.1 Type designation code
Figure 3-1. Vacon NXL type designation code for sizes MF2 and MF3
NXL 0004 C 1 N 1 SSS 00
5
Product range: NXL = NX Light
Nominal current (low overload)
Maximum continuous current of the unit at 40 deg
e.g. 0007 = 7Amps.
Nominal mains voltage:
2 = 208–240Vac, 5 = 380–500Vac
Control keypad:
B = No control keypad
C = standard seven-segment keypad
EMC emission level:
N = No EMC emission protection.An external EMC filter needed
Hardware modifications; Supply - Mounting - Boards
SSS = Standard
SDS = Din rail mounting
Enclosure classification:
1= IP20
Brake chopper
0 = nobrake chopper
1 = internal brake chopper
Factory installed I/0 boards and expanders:
00= no board,
AA= OPT-AAboard,
AI = OPT-AI board
C3 = profibus board
11553_uk
H = Fulfils EN61800-3:2004+A1:2012, category C2. External RFI-filter required

14 •vacon Receipt of delivery
Telephone: [phone] • Fax: [phone]
3
Figure 3-2. Vacon NXL type designation code for sizes MF4 - MF6.
3.2 Storage
If the frequency converter is to be kept in store before use make sure that the ambient conditions
are acceptable:
Storing temperature –40…+70°C
Relative humidity <95%, no condensation
3.3 Maintenance
In normal conditions, Vacon NXL frequency converters are maintenance-free. However, we
recommend to clean the heatsink (using e.g. a small brush) whenever necessary.
Most Vacon NXL drives are equipped with a cooling fan, which can easily be changed if necessary.
NXL 0004 C 2 T 1 SSS 00 AA
5
Product range: NXL = NX Light
Nominal current (low overload)
Maximum continuous current of the unit at 40 deg
e.g. 0007 = 7 Amps.
Nominal mains voltage:
2 = 208–240Vac, 5 = 380–500Vac
Control keypad:
B = No control keypad
C = standard seven-segment keypad
EMC emission level:
Hardware modifications; Supply - Mounting - Boards
SSS = Standard
SSV = Varnished PCB’s
Enclosure classification:
2= IP21
5= IP54
Brake chopper
1 = internal brake chopper
Slot E: Factory installed I/0 boards,fieldbus boards and expanders:
00= no board, AA = OPT-AA expander I/O board,
AI = OPT-AI expander I/O board, e.g. C3=Profibus board
Slot D: Factory installed fieldbus boards:
00= no board, e.g: CI = Modbus/TCP Board,
C3 = Profibus board
C = Fulfils EN 61800-3:2004+A1:2012, category C1
H = Fulfils EN 61800-3:2004+A1:2012, category C2
T= Fulfils the standard EN 61800-3:2004+A1:2012 when used in IT
networks
11554_uk

Receipt of delivery vacon •15
24-hour support: [phone] • Email: [e-mail]
3
3.4 Warranty
Only manufacturing defects are covered by the warranty. The manufacturer assumes no
responsibility for damages caused during or resulting from transport, receipt of the delivery,
installation, commissioning or use.
The manufacturer shall in no event and under no circumstances be held responsible for damages
and failures resulting from misuse, wrong installation, unacceptable ambient temperature, dust,
corrosive substances or operation outside the rated specifications. Neither can the manufacturer be
held responsible for consequential damages.
The Manufacturer's time of warranty is 18 months from the delivery or 12 months from the
commissioning whichever expires first (General Conditions NL92/Orgalime S92).
The local distributor may grant a warranty time different from the above. This warranty time shall be
specified in the distributor's sales and warranty terms. Vacon assumes no responsibility for any
other warranties than that granted by Vacon itself.
In all matters concerning the warranty, please contact first your distributor.

16 •vacon Technical data
Telephone: [phone] • Fax: [phone]
4
4. TECHNICAL DATA
4.1 Introduction
Vacon NXL is a compact frequency converter with the output ranging from 250 W to 30 kW.
The Motor and Application Control Block is based on microprocessor software. The microprocessor
controls the motor basing on the information it receives through measurements, parameter
settings, control I/O and control keypad. The IGBT Inverter Bridge produces a symmetrical, 3-phase
PWM-modulated AC-voltage to the motor.
The control keypad constitutes a link between the user and the frequency converter. The control
keypad is used for parameter setting, reading status data and giving control commands. Instead of
the control keypad, also a PC can be used to control the frequency converter if connected through a
cable and a serial interface adapter (optional equipment).
You can have your Vacon NXL drive equipped with control I/O boards OPT-AA, OPT-AI, OPT-B_ or
OPT-C_.
All other sizes but MF2 have an internal brake chopper. For closer information, contact the
Manufacturer or your local distributor (see back cover). The input EMC filters are available as
options externally for MF2 and MF3. In other sizes the filters are internal and included as standard.

Technical data vacon • 17
24-hour support: [phone] • Email: [e-mail]
4
Figure 4-1. Vacon NXL block diagram
==
L1
L2
L3
U
V
W
3~
3~
nxlk57
Mains Motor
Brake
Chopper*
Measure-
ments
Gate
Drivers
Motor
Control
µP
Motor and
Application
Control
Control
Keypad
Fan
Current
Sensors***
Rectifier IGBT Inverter
Brake resistor*
Power
Supply
Control
I/O
1)
2)
3)
Integrated input module**
*Brake chopper belongs to the standard equipment in classes MF3 to MF6, brake resistor is available
as option
**Classes MF4 and bigger have an integrated input module
***This measuring method only in classes MF5 and bigger
Control
module
Power
module
Charg.res.
Option
board

18 •vacon Technical data
Telephone: [phone] • Fax: [phone]
4
4.2 Power ratings
4.2.1 Vacon NXL – Mains voltage 208 – 240 V
Mains voltage 208-240 V, 50/60 Hz, 1~/3~ Series NXL
Frequency
converter type
Loadability
Motor shaft
power
Nominal
input
current
1~/3~
Mechanical
size
Enclosure
and
protection
class
Dimensions
WxHxD
Weight
(kg)
Low
High
Low
40°C
P(kW)
High
50°C
P(kW)
Rated
con-
tinuous
current
I
L
(A)
10%
over-
load
current
(A)
Rated
continuous
current IH
(A)
50%
overload
current
(A)
EMC-level N
NXL 0002 2 2,4 2,6 1,7 2,6 0,37 0,25 4,8/-- MF2/IP20 60x130x150 1,0
NXL 0003 2 3,7 4,1 2,8 4,2 0,75 0,55 7,4/5,6 MF3/IP20 84x220x172 2,0
NXL 0004 2 4,8 5,3 3,7 5,6 1,1 0,75 9,6/7,2 MF3/IP20 84x220x172 2,0
NXL 0006 2 6,6 7,3 4,8 7,2 1,5 1,1 13,2/9,9 MF3/IP20 84x220x172 2,0
Table 4-1. Power ratings and dimensions of Vacon NXL, supply voltage 208—240V.
NOTE! NXL 0002 2 is suitable for single phase supply only
4.2.2 Vacon NXL – Mains voltage 380 – 500 V
Mains voltage 380-500 V, 50/60 Hz, 3~ Series NXL
Frequency
converter type
Loadability
Motor shaft power
Nominal
input
current
Mechanical
size
Enclosure
and
protection
class
Dimensions
WxHxD
Weight
(kg)
Low High 380V supply 500V supply
Rated
con-
tinuous
current
I
L
(A)
10%
over-
load
curren
t (A)
Rated
con-
tinuous
current
I
H
(A)
50%
over-
load
current
(A)
10%
over-
load
40°C
P(kW)
50%
over-
load
50°C
P(kW)
10%
over-
load
40°C
P(kW)
50%
over-
load
50°C
P(kW)
EMC-level N
NXL 0001 5 1,9 2,1 1,3 2 0,55 0,37 0,75 0,55 2,9 MF2/IP20 60x130x150 1,0
NXL 0002 5 2,4 2,6 1,9 2,9 0,75 0,55 1,1 0,75 3,6 MF2/IP20 60x130x150 1,0
NXL 0003 5 3,3 3,6 2,4 3,6 1,1 0,75 1,5 1,1 5,0 MF3/IP20 84x220x172 2,0
NXL 0004 5 4,3 4,7 3,3 5 1,5 1,1 2,2 1,5 6,5 MF3/IP20 84x220x172 2,0
NXL 0005 5 5,4 5,9 4,3 6,5 2,2 1,5 3 2,2 8,1 MF3/IP20 84x220x172 2,0
EMC-level H/C
NXL 0003 5 3,3 3,6 2,2 3,3 1,1 0,75 1,5 1,1 3,3 MF4/IP21,IP54 128x292x190 5
NXL 0004 5 4,3 4,7 3,3 5,0 1,5 1,1 2,2 1,5 4,3 MF4/IP21,IP54 128x292x190 5
NXL 0005 5 5,6 5,9 4,3 6,5 2,2 1,5 3 2,2 5,6 MF4/IP21,IP54 128x292x190 5
NXL 0007 5 7,6 8,4 5,6 8,4 3 2,2 4 3 7,6 MF4/IP21,IP54 128x292x190 5
NXL 0009 5
9
9,9
7,6
11,4
4
3
5,5
4
9
MF4/IP21,IP54
128x292x190
5
NXL 0012 5 12 13,2 9 13,5 5,5 4 7,5 5,5 12 MF4/IP21,IP54 128x292x190 5
NXL 0016 5 16 17,6 12 18 7,5 5,5 11 7,5 16 MF5/IP21,IP54 144x391x214 8,1
NXL 0023 5 23 25,3 16 24 11 7,5 15 11 23 MF5/IP21,IP54 144x391x214 8,1
NXL 0031 5 31 34 23 35 15 11 18,5 15 31 MF5/IP21,IP54 144x391x214 8,1
NXL 0038 5 38 42 31 47 18,5 15 22 18,5 38 MF6/IP21, IP54 195x519x237 18,5
NXL 0046 5 46 51 38 57 22 18,5 30 22 46 MF6/IP21, IP54 195x519x237 18,5
NXL 0061 5 61 67 46 69 30 22 37 30 61 MF6/IP21, IP54 195x519x237 18,5
Table 4-2. Power ratings and dimensions of Vacon NXL, supply voltage 380 – 500V.
