vacuubrand VACUU-SELECT User manual

Technology for Vacuum
Systems
Instructions for use
Original instructions EN OI no.: 20901171
Vacuum controller
VACUU·SELECT complete controller (lab scaffold version)
VACUU·SELECT complete controller (built-in version)
VACUU·SELECT complete controller (benchtop version)

Imprint
2 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Original instructions
Keep for further use!
This manual is only to be used and distributed in its complete and original form. It is strictly the user's responsibility to
carefully check the validity of this manual with respect to the product.
Manufacturer:
VACUUBRAND GMBH + CO KG
Alfred‑Zippe‑Str. 4
97877 Wertheim
GERMANY
Phone:
Head ofce [phone]‑0
Sales [phone]‑5550
Service [phone]‑5660
Fax: [phone]‑5555
Email: [email protected]
Web: www.vacuubrand.com
Thank you for purchasing this product from VACUUBRAND GMBH + CO KG. You have chosen a modern and
technically high quality product.

Contents
320901171_EN_VACUU·SELECT-Komp_V1.4_291021
TABLE OF CONTENTS
1 Introduction 6
1.1 User information .................................6
1.2 Manual structure.................................7
1.3 About this document..............................8
1.3.1 Display conventions ..........................8
1.3.2 Symbols and icons ...........................9
1.3.3 Handling instructions (action steps)..............10
1.3.4 Abbreviations ..............................11
1.3.5 Term denitions.............................12
2 Safety information 13
2.1 Usage........................................13
2.1.1 Intended use ...............................13
2.1.2 Improper use...............................14
2.1.3 Foreseeable misuse .........................14
2.2 Target group description..........................15
2.2.1 Personnel qualication .......................15
2.2.2 Responsibility matrix.........................15
2.2.3 Personal responsibility .......................16
2.3 Safety precautions ..............................16
2.3.1 Safety precautions, general ...................16
2.3.2 Awareness of potential dangers ................17
2.3.3 ATEX equipment category (sensor) .............18
2.4 Disposal ......................................19
3 Product description 20
3.1 VACUU·SELECT Complete .......................20
3.2 Product views ..................................22
3.2.1 VACUU·SELECT Complete (schematic design) ......22
3.2.2 VACUU·SELECT Sensor .....................25
3.2.3 Chemically resistant in‑line solenoid valve ........26
3.3 VACUU·BUS peripheral devices (option) .............27
3.4 Example ......................................28
3.5 Remote control and interfaces . . . . . . . . . . . . . . . . . . . . . 29
3.5.1 RS‑232 serial interface .......................29
3.5.2 Modbus TCP...............................29
4 Installation and connection 30
4.1 Transport .....................................30
4.2 Installation ....................................30
4.2.1 Benchtop version ...........................31
4.2.2 Lab scaffold version .........................31

Contents
4 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
4.2.3 Built‑in version .............................34
4.3 Electrical connection ............................36
4.4 Vacuum connection .............................38
4.5 Venting connection (option) .......................40
5 User interface 41
5.1 Switch on controller .............................41
5.1.1 Touchscreen ...............................42
5.1.2 Gestures for operation .......................42
5.2 Set up device ..................................42
5.2.1 Data storage message .......................42
5.3 Screen orientation ..............................43
5.4 Display and operating elements ....................44
5.4.1 Process screen (main screen) .................44
5.4.2 Display elements............................45
5.4.3 Operating elements and symbols ...............47
6 Operation 51
6.1 Applications ...................................51
6.1.1 Select and start application....................51
6.1.2 Adjust pressure setpoint . . . . . . . . . . . . . . . . . . . . . . 52
6.1.3 Vent .....................................54
6.1.4 Stop application ............................55
6.2 Application parameters (parameter list) ..............55
6.3 Pressure graph.................................57
6.4 Main menu ....................................58
6.4.1 Applications ...............................59
6.4.2 Favorites ..................................60
7 Main menu 61
7.1 Advanced operation .............................61
7.1.1 Application editor ...........................61
7.1.2 Menu bar and description .....................62
7.1.3 Overview of process steps ....................63
7.1.4 Process end ...............................64
7.1.5 Edit application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
7.1.6 Remove process step ........................67
7.1.7 Settings...................................68
7.1.8 Settings/administration .......................70
7.1.9 Administration – import/export .................72
7.1.10 Administration – VACUU·BUS .................73
7.2 Data logger....................................76
7.3 Service .......................................77
7.3.1 Service information..........................77
7.3.2 Diagnostic data .............................78

Contents
520901171_EN_VACUU·SELECT-Komp_V1.4_291021
8 Troubleshooting 79
8.1 Error messages ................................79
8.1.1 Error indication .............................79
8.1.2 Acknowledge error indication ..................80
8.2 Error – Cause – Remedy .........................80
8.2.1 Pop‑up message ...........................80
8.2.2 General faults ..............................81
8.3 Device fuse....................................83
9 Appendix 85
9.1 Technical information ............................85
9.1.1 Technical data..............................85
9.1.2 Rating plate................................88
9.1.3 Wetted materials............................89
9.1.4 Vacuum data...............................89
9.2 Ordering information.............................90
9.3 Licensing information and data protection ............91
9.4 Service .......................................92
9.5 Index.........................................93
9.6 EC Declaration of conformity ......................94

6 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Introduction
11 IntroductionIntroduction
This manual is part of your product.
1.11.1 User informationUser information
Safety
Read this manual thoroughly and completely before using the
product.
Keep this manual in an easily accessible location.
Correct use of the product is essential for safe operation.
Comply with all safety information provided!
In addition to this manual, adhere to the accident prevention
regulations and industrial safety regulations applicable in the
country of use.
General
For easier readability, the general term controllercontroller is used
as an equivalent to and instead of the product name
VACUU·SELECTVACUU·SELECT CompleteComplete.
If passing the product on to a third party, also give them this
manual.
The illustrations in this manual are only intended to facilitate
comprehension.
We reserve the right to make technical and design changes in
the course of continuous product improvement.
Copyright
The content of this manual is protected by copyright. Only copies
for internal use are allowed, e.g., for professional training.
© VACUUBRAND GMBH + CO KG
General
information
Instructions for use
and safety
Copyright © and
copyright law

720901171_EN_VACUU·SELECT-Komp_V1.4_291021
Introduction
Contact
If your manual is incomplete, you can request a
replacement. Alternatively, you can use our download portal:
www.vacuubrand.com
When contacting our Service Department, please have the
serial number and product type at hand see Rating plateRating plate on
the product.
You are welcome to contact us at any time in writing or by
telephone if you would like more information, have questions
about our products or wish to share feedback with us.
1.21.2 Manual structureManual structure
The manuals have a modular structure with separate instruction
modules for the controller, vacuum pumps, pumping units, and
any accessories.
Instruction modules
123
1Safety information for vacuum equipment
2Description: Vacuum controller – control and operation
3Optional description: vacuum pump, accessories, etc.
Contact us
Modular instructions
for use
 Example
Breakdown of the
instructions for use

8 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Introduction
1.31.3 About this documentAbout this document
1.3.11.3.1 Display conventionsDisplay conventions
Warning levels
DANGERDANGER
Indicates an imminent hazardous situation.
Disregarding the situation could result in extremely
serious injury or death.
> Take appropriate action to avoid dangerous situations!
WARNING
Warns of a potentially hazardous situation.
Disregarding the situation could result in serious injury
or death.
> Take appropriate action to avoid dangerous situations!
CAUTION
Indicates a potentially hazardous situation.
Disregarding the situation could result in minor injury or
damage to property.
> Take appropriate action to avoid dangerous situations!
NOTENOTE
Indicates a potentially harmful situation.
Disregarding the situation could result in damage to property.
Additional notes
>Information or specic recommendation which must be
observed.
>Important information for trouble‑free operation of your
product.
> Helpful tips + tricks
> Additional information
IMPORTANT!
Display conventions

920901171_EN_VACUU·SELECT-Komp_V1.4_291021
Introduction
1.3.21.3.2 Symbols andSymbols and iconsicons
This manual uses symbols and icons. Safety symbols indicate
specic risks associated with handling the product. Symbols and
icons are designed to help you identify risks more easily.
Safety symbols
General
warning symbol. Danger: electricity.
Warning: hot surface. General
prohibition sign.
General
mandatory sign. Disconnect power plug.
Electrostatically sensitive
components ESD. Cadmium free
Additional symbols and icons
Positive example – Do this!
Result – OK
Negative example –
Don't do this!
Refers to content in this
manual.
Refers to content in other
supplementary documents.
Acoustic signal – signal sound/warning sound.
Frequency of beeping, frequency of acoustic signal
Electric/electronic devices and batteries must not be
disposed of in the domestic waste at the end of their
service life.
Flow arrow
Vacuum
Symbols and gestures for operation
See chapter: 5.1.2 Gestures for operation on page 425.1.2 Gestures for operation on page 42
Explanation of
safety symbols
Additional symbols

10 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Introduction
> Additional detailed descriptions of symbols (icons) and
signals on the display can be found in chapter 5.4 Display5.4 Display
and operating elementsand operating elements.
1.3.31.3.3 Handling instructions (Handling instructions (action steps)action steps)
Instructions (single step)
>Perform the step described.
5Result of action
Instructions (multiple steps)
1. First step
2. Next step
5Result of action
Perform the steps in the order described.
Instructions (shown graphically)
1. First step
2. Next step
5Result of action
Action steps as text
Schematic diagram
Action steps as
graphics

1120901171_EN_VACUU·SELECT-Komp_V1.4_291021
Introduction
1.3.41.3.4 AbbreviationsAbbreviations
abs. Absolute
AK Separator ask
ATM Atmospheric pressure (bar graph, program)
di(di) Interior diameter
DN Nominal diameter
EX* Outlet
FKM Fluoroelastomer
GB Gas ballast
hh:mm:ss Time in hours/minutes/seconds
hPa Pressure unit, hectopascal (1 hPa = 1 mbar =
0.75 Torr)
IN* Inlet
KF Small ange
max. Maximum value
min. Minimum value
mbar Pressure unit, millibar (1 mbar = 1 hPa = 0.75 Torr)
PA Polyamide
PBT Polybutylene terephthalate
PC .... Pumping unit chemistry with type identication num‑
ber
PE Polyethylene
RMA no. Return Merchandise Authorization number
SW Wrench size (tool)
Torr Pressure unit (1 Torr = 1.33 mbar = 1.33 hPa)
USB Universal serial bus
VAC Vacuum (pressure curve)
resp. Responsible
VMS‑B Vacuum management system – module
e.g. For example
* Labeling on the vacuum pump
Abbreviations

12 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Introduction
1.3.51.3.5 Term denitionsTerm denitions
Fine vacuum Pressure measuring range in vacuum sys‑
tems, from: 1 mbar‑0.001 mbar (0.75 Torr–
0.00075 Torr)
Rough vacuum Pressure measuring range in vacuum systems,
from: atmospheric pressure–1 mbar
(atmospheric pressure–0.75 Torr)
VACUU·BUS Bus system from VACUUBRAND for com‑
munication between peripheral devices with
VACUU·BUS‑enabled gauges and controllers.
The maximum admissible cable length is 30 m.
VACUU·BUS
address
Address which enables the VACUU·BUS client
to be unambiguously assigned within the bus
system, e.g., for connecting multiple sensors
with the same measurement range.
VACUU·BUS
client
Peripheral device or component with
VACUU·BUS port, which is integrated in the
bus system, e.g., sensors, valves, level indica‑
tors, etc.
VACUU·BUS
conguration
Assigning a different VACUU·BUS address to
a VACUU·BUS component using a gauge or
controller.
VACUU·BUS
connector
4‑pin round connector for the bus system from
VACUUBRAND.
VACUU·SELECT Vacuum controller, controller with touchscreen;
consisting of operating panel and vacuum sen‑
sor.
VACUU·SELECT
Complete
Vacuum controller in two‑point version for exist‑
ing vacuum sources such as individual pumps
or powerful local area vacuum networks
VACUU·SELECT
Sensor *
External vacuum sensor
`for VACUU·SELECT
or
`separately as an independent vacuum sen‑
sor.
* Available with or without venting valve
Product‑specic
terms

1320901171_EN_VACUU·SELECT-Komp_V1.4_291021
Safety information
22 Safety informationSafety information
The information in this chapter must be observed by everyone
who works with the product described here.
The safety information is valid for the entire life cycle of the prod‑
uct.
2.12.1 UsageUsage
Only use the product if it is in perfect working condition.
2.1.12.1.1 Intended useIntended use
The VACUU·SELECT CompleteVACUU·SELECT Complete is a lab instrument intended to
regulate absolute pressure in the area of rough and ne vacuum
for existing vacuum sources such as individual pumps or power‑
ful local area vacuum networks.
The device may only be used indoors in a non‑explosive
atmosphere. It is designed for continuous operation between
10 °C–40 °C.
Intended use also includes:
observing the information in the document Safety information for
vacuum equipment,
observing the manual,
observing the manual of connected components,
using only approved accessories or spare parts.
Any other use is considered improper use.
Intended use

14 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Safety information
2.1.22.1.2 Improper useImproper use
Incorrect use or any application which does not correspond to the
technical data may result in injury or damage to property.
Improper use includes:
using the product contrary to its intended use,
operation under inadmissible environmental and operating condi‑
tions,
vacuum control of potentially explosive atmospheres which does
not correspond to the ATEX authorization of the sensor see
sensor rating plate,
operation despite obvious faults or defective safety devices,
usage despite incomplete assembly,
pulling plug‑in connections on the cable out of the socket,
use in mines or underground.
2.1.32.1.3 Foreseeable misuseForeseeable misuse
In addition to improper use, there are types of use which are
prohibited when handling the device:
installation and operation in potentially explosive atmospheres,
unauthorized extensions or conversions, in particular when these
impair safety,
fully exposing the device to the vacuum, immersing it in liquids,
exposing it to water spray or steam jets,
vacuum control of hot, unstable, or explosive media,
operation with sharp‑edged objects,
switching the device on/off with tools or one's foot,
operating the controller by remote control without knowledge of
the connected vacuum system.
Possible
foreseeable misuse
Improper use

1520901171_EN_VACUU·SELECT-Komp_V1.4_291021
Safety information
2.22.2 Target group descriptionTarget group description
Users in the areas of competence in the Responsibility matrixResponsibility matrix
must possess the relevant qualications for the activities listed.
2.2.12.2.1 Personnel qualicationPersonnel qualication
Operator Laboratory staff, such as chemists, laboratory
technicians
Specialist Person with professional qualication in mechanics,
electrical equipment or laboratory devices
Responsible
specialist
Similar to a specialist, with additional specialist
responsibility, or responsibility for a department or
division
2.2.22.2.2 Responsibility matrixResponsibility matrix
Activity Operator Specialist Responsible
specialist
Installation x x x
Commissioning x x x
Network integration x
Updates X X
Data import/export X X
Data logger download X X X
Troubleshooting X X X
Operation x x x
Advanced operation x x
Error report x x x
Remedy (x) x x
Changing circuit board
fuse x x
Repair order x
Cleaning, simple x x x
Sensor cleaning* X X
Sensor calibration* X X
Shutdown x x x
Decontamination** x x
* Option
** Alternatively,arrangefordecontaminationbyaqualiedserviceprovider
Responsibility
matrix and areas of
competence
IMPORTANT!
Meaning of
personnel
qualications

16 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Safety information
2.2.32.2.3 Personal responsibilityPersonal responsibility
The safety and protection of individuals has top priority. Activities
and processes which represent a potential safety hazard are not
permitted.
Always be conscious of safety and work in a safe manner. Ob‑
serve instructions issued by the operator, and national regula‑
tions on accident prevention and industrial safety.
>Use the controller only if you have understood its function
and this manual.
>In the case of activities which require protective clothing, per‑
sonal protective equipment as specied by the operator is to
be worn.
2.32.3 Safety precautionsSafety precautions
Products from VACUUBRAND GMBH + CO KG are subject
to stringent quality testing with regard to safety and operation.
Each product undergoes a comprehensive test program prior to
delivery.
2.3.12.3.1 Safety precautions, generalSafety precautions, general
>When handling contaminated parts, follow the relevant regula‑
tions and safety precautions.
>Repairs are only to be carried out by the manufacturer’s Ser‑
vice Department.
Prior to any service, contamination from hazardous
substances needs to be excluded.
>Please note that residual process media may pose a
danger to people and the environment. Take suitable
decontamination measures.
>Before sending devices to our Service Department, you
must rst ll out a Health and Safety Clearance form, sign it
to conrm the information, and return it to us.
Work safely
Quality standards
and
safety
Protective clothing
IMPORTANT!

1720901171_EN_VACUU·SELECT-Komp_V1.4_291021
Safety information
2.3.22.3.2 Awareness of potential dangersAwareness of potential dangers
Vacuum control of critical processes
DANGERDANGER
Risk of explosion through control of critical
processes.
Depending on the process, an explosive mixture can
form in systems.
> The control of critical processes must always be su‑
pervised!
Damaged components
Damaged components, especially those which impair safety,
must be promptly replaced.
>Ensure that you are not working with damaged components.
>Replace defective parts immediately, e.g., a broken cable or
faulty plug.
Dangers due to electrical energy
After the controller has been switched off and disconnected from
the power supply, there may still be dangers at the plug‑in power
supply due to residual energy:
>Replace the plug‑in power supply if there are any defects.
>Never open the plug‑in power supply.
Service shipments
Devices which represent a potential safety hazard should be sent
in, maintained or repaired only if all hazardous contamination has
been removed.
> The form for conrming safety is available as a PDF on
our website: Health and Safety Clearance form.
Risk of explosion
during
critical processes
IMPORTANT!
Electrical energy
Safety during
servicing

18 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Safety information
2.3.32.3.3 ATEX equipment category (sensor)ATEX equipment category (sensor)
Installation and potentially explosive atmospheres
Installation and operation in areas where potentially explo‑
sive atmospheres can develop to a hazardous degree is not
permitted.
ATEX approval only applies if applicable to the internal wetted
parts of the device, not to its surroundings.
ATEX equipment labeling
Vacuum equipment labeled with ` has ATEX approval in line
with the ATEX marking on the rating plate.
>Only use the product if it is in perfect working condition.
>The devices are designed for a low level of mechanical
stress and must be installed in such a way that they cannot
sustain mechanical damage from the outside.
>After any work on the device, check its leak rate.
When using the device on equipment with potentially explosive
atmospheres (according to ATEX approval), modications to the
device are not permitted and will invalidate the ATEX approval.
Wetted parts attached to the device must have ATEX approval
at least equivalent to that of the device itself, and must not
adversely affect the ATEX approval of the device, in particular
the temperature in the wetted area.
The use of gas ballast and/or venting valves is only permitted if
this would not normally, or only rarely, cause explosive mixtures
within the device, or do so only for a short time.
>If necessary vent with inert gas.
Information on the ATEX equipment category is also available on
our website at: www.vacuubrand.com/.../Information‑ATEX
ATEX‑
equipment category
Prevent explosive
mixtures
ATEX
approval

1920901171_EN_VACUU·SELECT-Komp_V1.4_291021
Safety information
2.42.4 DisposalDisposal
NOTENOTE
Electronic components and batteries must not be
disposed of in the domestic waste at the end of their
service life.
Used electronic devices and batteries contain harmful sub‑
stances that can cause damage to the environment or human
health. Disused electrical devices also contain valuable raw
materials, which can be recovered for reuse if the device is dis‑
posed of correctly within the recycling process.
End users are legally obliged to take used electric and elec‑
tronic devices to a licensed collection point and to return spent
batteries.
> It is your responsibility to save and delete any data before
disposing of your electronic device.
> If the device contains batteries: Remove spent batteries
before disposal.
> Correctly dispose of all electronic scrap and electric compo‑
nents at the end of their service life.
> Observe the national regulations regarding disposal and
environmental protection.
https://www.vacuubrand.com/20901491

20 20901171_EN_VACUU·SELECT-Komp_V1.4_291021
Product description
33 Product descriptionProduct description
3.13.1 VACUU·SELECT CompleteVACUU·SELECT Complete
The VACUU·SELECTVACUU·SELECT CompleteComplete is a fully equipped two‑point
vacuum controller for existing vacuum sources such as individual
pumps or powerful local area vacuum networks.
The controller comprises the VACUU·SELECTVACUU·SELECT vacuum controller
with integrated ceramic vacuum sensor and venting valve, a non‑
return valve and a chemically resistant in‑line solenoid valve.
Simply connect the controller between the vacuum pump and the
application.
The controller is available as a benchtop device, for lab scaffold
mounting, or as a built‑in version for lab workstations.
Benchtop version Lab scaffold version Built‑in version
The controller was developed for applications which require a
controlled vacuum. Various applications and menus are available
for operation and vacuum control. The controller is operated us‑
ing the touchscreen. The menus are designed to be user friendly.
Depending on the type of operation and peripheral devices con‑
nected, the controller regulates the process vacuum subject to
demand. In the case of solvent evaporation, it detects boiling
pressure automatically and switches to two‑point control mode.
Description of
vacuum controller
Controller versions
