pair of deck mounted valves ¾”
installation & maintenance instructions
please leave these instructions with the customer

important - please read
general installation
12
dimensions
installation
operation
Please read these instructions carefully before starting installation and keep for future reference.
Remove all packaging and check the product for missing parts or damage before starting
installation.
Any alterations made to this product and ttings may infringe water regulations and will
invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority Regulations/
Byelaws and Building and Plumbing (UK:BS6700) Regulations.
We strongly recommend that you use a qualied and registered plumber.
Before making any inlet pipe connections, all supply pipes MUST be thoroughly ushed to
remove debris. Failure to do so could result in damage or low ow from the mixer unit. Water
Supply (Water Fittings) Regulations 1999 Schedule 2 Section 4 G13.1
The tting of isolating valves to the inlet feeds is advised for ease of maintenance.
Please take great care when installing this mixer not to damage its surface.
Please note if installing in an enclosed environment, access should be left for servicing and
maintenance. No costs relating to inadequate access can be accepted.
55mm
27mm
Operating Pressure:
Minimum operating pressure 0.2 bar - Maximum operating pressure 5 bar
98mm
3/4”
3/4”
care of the taps
Our products are nished to the highest standard and due care needs to be taken to ensure
their looks are retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly against
the use of ALL cleaning products i.e. powders and liquids.
If the above instructions are not followed this will invalidate your guarantee in the event of a
problem occurring.
55mm
41mm
Control
handle
‘O’ ring
Rubber
washer
33mm
hole
Nut
Valve
Before installing your new tap, ush
through the pipework to ensure removal
of debris, turn o the water supply.
Drill a 33mm hole in the required
position. Screw a nut onto the valve
body followed by a metal washer and
rubber washer, push the valve up
through the hole in the basin making
sure the outlet hole is pointing in the
right direction (towards the spout).
Screw on the cover making sure the ‘O’
ring is in position in the groove on the
underside.
Tighten the nut to clamp the valve to
the basin.
CAUTION: Do not over tighten the nut
as this might damage the basin.
Slide the ‘O’ ring onto the splines of the
valve, push on the handle and x in
position using a hexagonal key.
Connect the water supply to the
inlet pipes. The hot water should be
connected to the left hand pipe.
Finally connect the outlet to the spout.
Cover
Metal
washer
Hexagonal key
Hot/cold
inlet
Valve
outlet
Hot tap - turning the tap lever
clockwise will increase the
ow of hot water.
Cold tap - turning the tap lever
anti-clockwise will increase the
ow of cold water.
