VALBERG UF NF 240 E S180C User manual

MADE IN PRC
ELECTRO DEPOT
1 route de Vendeville
59155 FACHES-THUMESNIL
FRANCE
EN
WARRANTY CONDITION
This product has a 2-year warranty as of the date of purchase*, covering any fault resulting from
a manufacturing or material defect. This warranty does not cover defects or damage resulting
from incorrect installation, improper use or abnormal wear of the appliance.
*upon presentation of the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute
défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les
vices ou les dommages résultant d’une mauvaise installation, d’une utilisation incorrecte ou
de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor
elke storing die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door
slechte installatie, onjuist gebruik of abnormale slijtage van het product worden niet gedekt
door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
El certificado de garantía de este producto tiene una duración de 2 años a partir de la fecha de
compra* que se limita a los defectos de fabricación y averías del material. Se excluyen de la
garantía deficiencias o daños originados por una mala instalación, errores en la manipulación
o por un uso inadecuado.
*previa presentación del comprobante de compra.

977518 - UF NF 240 E S180C
2/2 02/2023-V2
Freezer
Congélateur
Diepvriezer
Congelador
INSTRUCTIONS FOR USE .....................02
CONSIGNES D'UTILISATION .....................34
GEBRUIKSAANWIJZINGEN .....................66
INSTRUCCIONES DE USO .....................98

10
11
9
1
2
4
5
6
7
8
3

2 FR2 EN
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
the products of the VALBERG brand are easy to use,
reliable and of an impeccable standard.
Thanks to this appliance, you can be sure that each
use will bring you satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr

3FR
Aperçu de l’appareil
A
3 EN
Table of contents
APreview of the
appliance
CUseful information
BUsing the appliance Installing your new appliance
Display controls
Using your appliance
Reversing the door
Cleaning and care
Helpful hints and tips
Troubleshooting
Disposal of the appliance
Description of the appliance

4EN
Preview of the appliance
A
Description of the appliance
1Cabinet
2LED light
3Glass shelf
4Upper drawer parts
5Display
6Middle drawer parts
7Lower drawer part
8Adjustable bottom feet
9Freezer door
10 Handle (optional)
11 Freezer gasket
•
Due to unceasing modification of our products, your freezer may be slightly different from
this instruction manual, but its functions and using methods remain the same.
•
To get the best energy efficiency of this product, please place all shelves, drawers and
baskets on their original position as the illustration above.

5EN
Using the appliance
B
Installing your new appliance
Before using the appliance for the first time, you should be informed of the following tips.
WARNING
For proper installation, this freezer must be placed on a
level surface of hard material that is the same height as the
rest of the flooring. This surface should be strong enough
to support a fully loaded freezer.
The rollers, which are not castors, should be only used for forward or backward movement.
Moving the freezer sideways may damage your floor and the rollers.
Ventilation of appliance
In order to improve efficiency of the cooling system and save energy, it is necessary to maintain
good ventilation around the appliance for the dissipation of heat. For this reason, sufficient
clear space should be available around the freezer.
Suggest: It is advisable for there to be 50-75mm of space from the back to the wall, at least
100mm from its top, at least 100mm from its side to the wall and a clear space in front to
allow the doors to open 130°. As shown in follow diagrams.

6EN
Using the appliance
B
NOTE
This appliance performs well within the climate class from
SN to T showed in the table below. It may not work properly
if being left at a temperature above or below the indicated
range for a long period.
Climate class Ambient temperature
SN +10°C to +32°C
N+16°C to +32°C
ST +16°C to +38°C
T+16°C to +43°C
• Stand your appliance in a dry place to avoid high moisture.
•
Keep the appliance out of direct sunlight, rain or frost. Stand the appliance away from
heat sources such as stoves, fires or heaters.
Leveling of appliance
• For sufficient leveling and air circulating in the lower rear section of the appliance, the
bottom feet may need to be adjusted. You can adjust them manually by hand or by using
a suitable spanner.

7EN
Using the appliance
B
• To allow the doors to self-close, tilt the top backwards by 10-15mm.
Adjustable
bottom feet
Rear roller
Installing the door handles
For the convenience of transportation, the door handles are separately provided in a plastic
bag, you can install the door handles as follows.
1.
Lever screw covers on the left side of the door, and then put them back to the plastic bag.
2. Match the handle on the left side of the door, keeping axes of the screw holes in the handle
and the door in a line, as the picture shows.
3. Fix the handle with the special screws provided in the plastic bag.

8EN
Using the appliance
B
Display controls
Use your appliance according to the following control regulations, your appliance has the
corresponding functions and modes as the control panels showed in the pictures below. When
the appliance is powered on for the first time, the backlighting of the icons on display panel
starts working. If no buttons have been pressed and the doors are closed, the backlighting
will turn off.
Display panel inside

9EN
Using the appliance
B
Controlling the temperature
For optimum food preservation, we recommend that when you start your freezer for the first
time the temperature for the freezer is set to -18°C (0°F) if you want to change the temperature
follow the instructions below.
CAUTION
When you set temperature, you set an average temperature
for the whole freezer cabinet. Temperature inside each
compartment may vary from the temperature values
displayed on the panel, depending on how much food you
store and where you place them. Ambient temperature may
also affect the actual temperature inside the appliance.
NOTE
High temperature setting will accelerate food waste.

10 EN
Using the appliance
B
Temp
In the unlocked state, you can switch the display mode from °C to °F by press the
button for 3 seconds.
In the unlocked state, press button, when the light is on, the freezer set
temperature is cyclically adjusted between -14°C and -24°C.
When the light is on, the freezer set temperature is cyclically adjusted between 7°F
and -11°F.
Thermostat setting for ambient T°C : NORMAL ≈ +24°C (± 4°C) -19°C
Thermostat setting for ambient T°C : COLD ≈ +16°C (± 4°C) -19°C
Thermostat setting for ambient T°C : HOT ≈ +32°C (± 4°C) -19°C
Super Freeze
Super Freeze will quickly lower the temperature within the freezer so food will freeze faster.
This feature also helps to keep thevitamins and nutrition of fresh food for longer period.
•
In the unlocked state, press button to enter the Super Freeze mode, the
Super Freeze icon is lit and the temperature is set to -24°C(-11°F).
• To freeze fresh food activate the Super Freeze function at least 24 hours before placing
the food to complete prefreezing
• Super Freeze mode automatically exits after about 52 hours.
•
When Super Freeze function is on, in the unlocked state, you can switch it off by pressing
button and the freezer temperature setting will revert back to the previous
setting.
Eco
If you are going to be away for a long period of time, you can turn it to Eco mode to save on
electricity.
•
In the unlocked state, press button to enter the Eco mode, the Eco icon is lit
and the temperature is set to -17°C 1°F.

11 EN
Using the appliance
B
• When the Eco function is on, in the unlocked state, you can switch it off by pressing
button. The freezer temperature setting will revert back to the previous setting.
Child Lock
When the light is On. the freezer is locked. Press and hold the button for 3
seconds, the light is off. The freezer is in the unlocked state, it can perform other button
operation.
If no button have been press for 20 seconds, the light will be on.
Alarm
In case of alarm, icon will be flashing and there will be buzzing sound.
Door Alarm
When the door is open for over 2 minutes, the door alarm will sound, meanwhile the display
panel show «dr» . In case of door alarm, buzzer will sound 3 times every 1 min.
After the door alarm time exceeds more than 10 minutes, the buzzer stops beeping, the
icon is off, and the display screen shows normal. The door alarm can also be cleared by
closing the door.
To save energy, please avoid keeping the door open for a long time when using the appliance.
Power
Pressing and hold the button for 3 seconds to turn the power function on or
off. When the freezer is working, In the unlocked state, you can switch the appliance off by
pressing button for 3 seconds, the light is on, meanwhile the display panel show “ - - “
IMPORTANT
Do not store any food in the freezer during this time.
When the freezer is in standby mode and unlocked, press the button for 3 seconds, the
light is off, the freezer will turn on and the display will shows normal.
NOTE
The display control only can be setted in the unlocked state.

12 EN
Using the appliance
B
Using your appliance
Your appliance has the accessories as the «Description of the appliance» showed in general,
with this part instruction you can have the right way to use them. We recommend that you
read through them carefully before using the appliance
Shelf in Refrigerator chamber
• There are shelves in freezer chamber, and they can be taken out to be cleaned.
Freezer Drawer
• It is sued to store food which needs to be frozen, including meat, fish, ice cream, etc.

13 EN
Using the appliance
B
Installing refrigerators in pairs
• Your freezer can be installed with fridge in pairs.
•
It can be installed by installation pairs supplied like this, but the energy consumption
will increase slightly.
