Freezer
Congélateur
Diepvriezer
Congelador
2/2


1
2
3
4
5
6
7




2 EN2 EN
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
the products of the VALBERG brand are easy to use,
reliable and of an impeccable standard.
Thanks to this appliance, you can be sure that each
use will bring you satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr
www.electrodepot.be

3 EN3 EN
Table of contents
APreview of the
appliance
CUseful information
BUsing the appliance
The instructions are also available on the site
http://www.electrodepot.fr/sav/notices/
http://www.electrodepot.fr/sav/notices
Description of the appliance
Positioning
Start-up
Temperature control
Freezer maintenance
Troubleshooting
Energy-saving tips

4EN
Preview of the appliance
A
Description of the appliance
1Hinge 5Power cord
2Housing 6Door
3Drainage hole 7Temperature control panel
4Shelving basket
(The picture above for reference purposes only. The actual configuration will depend on the
physical product, or on the notice provided by the distributor.)
• The low temperature of freezer can keep food fresh for a long time, and the appliance is
mainly used to store frozen foods and for making ice.
• The freezer is suitable for storing meat, fish, shellfish, pastries class and other foods
which are not intended for immediate consumption.
• You should not store bottled or sealed liquids for a long period. If you want to store bottled
or sealed liquids, the stored items should not be placed close to the wall of the freezer.
There is a certain deviation between the temperature inside the box and the actual setting
temperature, which does not affect normal use.
• Please note that food should be consumed within its shelf life.
• The fast-freezing function is designed to maintain the nutritional values of the food. It can
quickly freeze the food in a short time. If a large amount of food needs to be frozen at one
time, it is recommended that users turn on the fast-freezing function 5 hours in advance.
With this function activated, the freezer freezes at a faster speed, so it can quickly freeze
food and effectively preserve the food's nutritional values.

5EN
Using the appliance
B
Positioning
• Before using the freezer, remove all packaging materials, including the bottom glides and
the foam pads and tapes inside the freezer, remove the protective film on the door and the
freezer unit.
• The freezer should be installed in a well-ventilated, indoor place; the ground must be flat
and solid.
• Keep away from heat sources and avoid direct sunlight. To avoid rust and to ensure optimal
insulation, do not position the freezer in damp or humid environments.
• There should be at least 70 cm of clear space above the freezer and at least 20 cm of clear
space around all sides to facilitate heat dissipation.

6EN
Using the appliance
B
Start-up
• Open the cover plate from the side, using the tool provided.
• Open the cover plate, take out the power cord, and then replace the cover plate.
• After transportation, please let the freezer stand for at least 2 hours before turning on
the power supply, otherwise its cooling capacity will be decreased or the freezer may be
damaged.
• The freezer should be run for 2 to 3 hours before loading it with fresh or frozen foods; the
freezer should run for more than 4 hours in summer, as the ambient temperature is higher
in this season.
• Unplug the freezer in the event of a power failure or during cleaning operations. Do not
connect the freezer to the power supply for at least five minutes, in order to prevent
damages to the compressor due to successive starts.
(The picture above is for reference purposes only. The actual configuration will depend on the
physical product, or on the notice provided by the distributor.)

7EN
Using the appliance
B
Temperature control
1
2
3 4 5
6
7
8
1Temperature display 5Centigrade temperature indicator light
2Indicator light display 6Fahrenheit temperature indicator light
3High temperature warming
indicator light 7Super-freeze/Lock/Unlock key
4Super-freeze indicator light 8Tempering key
(The picture above is for reference purposes only. The actual configuration will depend on the
physical product, or on the notice provided by the distributor.)
Display control
• When the freezer powers on, the display window will come on for 3 seconds, before
switching normal operation display, the original electric display should be under 18 °C;
• Normal operation display: AIf there are no errors, the set temperature or function mode
will be displayed; Bif there are any errors, the error code will be displayed;
• Display sleep function: The sleep function will activate by default after powering up, once
the set temperature has been reached, and the display will go out after another 30s.

8EN
Using the appliance
B
Sleep mode can be switched via key combinations:
- By pressing the " " and " " keys simultaneously for 5 seconds, when "ON" is displayed
in the temperature display, it indicates the sleep function has been activated.
- By pressing the " " and " " keys simultaneously for 5 seconds, when "OFF" is displayed
in the temperature display, it indicates that the sleep function has been deactivated.
Operation control: Opening the sleep function. After reaching the set temperature, the
display will go out for another 30s;
Closing the sleep function. After reaching the set temperature, the display will not go out
and will stay on;
Locking and unlocking
After the initial power-up, the key is locked by default; it's required for operation after
unlocking.
• Lock: after pressing the " " key and holding it for 3s, the display will blink once and the
set temperature will be applied immediately, once the freezer settings have been locked,
the display will not blink; after no key operations for 30s, the freezer may also switch to a
locked status, and the display will blink once.
• Unlocking: After pressing the " " key down for 3s, the display will blink once to unlock.
When locked, you need to enter key operations after unlocking.
PLEASE NOTE:
The various following key operations will be implemented
when the freezer is unlocked
Fahrenheit and centigrade temperature conversion
By pressing and holding the " " key for 3s, you can switch between Fahrenheit and
centigrade. When the centigrade temperature is displayed, the centigrade temperature
indicator light will be on; when the Fahrenheit temperature is displayed, the Fahrenheit
temperature indicator light in the display will be on.

9EN
Using the appliance
B
Setting the temperature
(For settings of -30 °C/-22 °F, an ambient temperature of 25 °C/77 °F or lower is
recommended)
• By pressing the " " key, the display will show the refrigerator temperature, and by
pressing the " " key once each time, the refrigerator temperature will be adjusted by
1 degree Celsius/Fahrenheit;
• The specific temperature change is cycled according to the figure below:
Centigrade temperature setting range:
Fahrenheit temperature setting range:
Thermostat setting for ambient T°C : NORMAL ≈ +24°C (± 4°C) : 3°C/-19°C
Thermostat setting for ambient T°C : COLD ≈ +16°C (± 4°C) : 3°C/-20°C
Thermostat setting for ambient T°C : HOT ≈ +32°C (± 4°C) : 3°C/-18°C
Super-freeze function
Activating super-freeze:
• 1By pressing the " " key, the super-freeze indicator light " " will come on;
• When setting the centigrade temperature, " -30 " will be displayed in the temperature
display. If the compressor is operating continuously, the centigrade temperature indicator
light " " will come on.
• When setting the Fahrenheit temperature, " -22 " will appear in the temperature display.
If the compressor operates continuously, the Fahrenheit temperature indicator light " "
will come on.
Exiting super-freeze:
1Powering on after power error;
2Continuous compressor operation for 24 hours;
3If a sensor error occurs in super-freeze mode, you can exit super-freeze mode;
4In super-freeze mode, you can exit super-freeze mode by pressing the " " key again.
High temperature alarm
The indicator light " " will come on to indicate a high temperature alarm.

10 EN
Using the appliance
B
Power error safeguarding
When a power error occurs, the operating status will be locked. Once the power has been
restored, the operation will be continued with the same setting as before the power error.
The super-freeze function will be exited after a power error.
Error code
If an error occurs, the display will show the corresponding error codes as shown in the table
below. The user can then contact a specialist for maintenance services, so as to ensure the
normal use of freezer.
Error code E2
Description Temperature sensor error

11 EN
Useful information
C
Freezer maintenance
Cleaning
detergent
•Dust that collects behind the freezer and underneath it
should be regularly cleaned to improve the appliance's
cooling and energy-saving actions.
•Check the door seal regularly to make sure that there is
no trapped debris. Clean the door seal with a soft cloth
dampened with soapy water or diluted detergent.
•The interior of the freezer should be cleaned regularly to
avoid any odours. Please turn off the power and remove
all food, baskets, containers, etc. before any cleaning
operations.
•Use a soft cloth or sponge to clean the inside of the freezer,
using a mixture of two tablespoons of baking soda and
approx. 1 litre of warm water. Then, rinse with water and
wipe down. After cleaning, open the freezer door and let it
air-dry before turning the power back on.

12 EN
Useful information
C
•For areas that are difficult to clean inside the freezer (e.g.
gaps or corners), it is recommended to regularly wipe them
over with a soft cloth, soft brush, etc. When necessary, use
additional tools (such as pipe-cleaners) to ensure that no
contaminants or bacteria accumulate in these areas.
•Do not use soaps, detergents or spray cleaners, etc. to
clean the inside of your freezer, as these products may
create odours or contamination.
•Clean the baskets with a soft cloth dampened with soapy
water or diluted detergent. Dry with a soft cloth or leave to
air-dry.
•Wipe the outer surface of the freezer with a soft cloth
dampened with soapy water, detergent, etc., and then wipe
dry.
•Do not use hard-bristled brushes, wire brushes, abrasives
(such as toothpaste), organic solvents (e.g. alcohol,
acetone, etc.), boiling water, acid or alkaline products,
which may damage the freezer's surface and its interior.
Boiling water and organic solvents, such as benzene, may
deform or damage plastic parts.
•Do not rinse directly with water or other liquids during the
cleaning process to avoid short-circuits or impacts on the
electrical insulation after immersion.

13 EN
Useful information
C
CAUTION:
Make sure to unplug the freezer for defrosting and
cleaning operations.
Defrosting
•The freezer must be manually defrosted.
Unplug the freezer and open the freezer door, and remove
any food and shelving baskets before defrosting; Open
the outflow hole and drainage hole (and place a container
underneath the outflow hole to catch any drainage); interior
frost will naturally melt away, so you can wipe the defrosted
water with a soft, dry cloth. Once the frost has softened, an
ice scraper can be used to the speed up the de-icing process.
•Please remove any food and store in a cool place while
defrosting the freezer, and remove any accessories
beforehand.
CAUTION:
Other mechanical devices or other means must not be
used to accelerate the freezer function, except those
recommended by the manufacturer. Do not damage the
cooling circuit.
This manual suits for next models
1
Table of contents
Languages:
Other VALBERG Freezer manuals

VALBERG
VALBERG BI CS 249 F W742C User manual

VALBERG
VALBERG CNF 327 E X742C User manual

VALBERG
VALBERG 2D 206 E S180C User manual

VALBERG
VALBERG CNF 270 E W625C User manual

VALBERG
VALBERG 967845 User manual

VALBERG
VALBERG 967799 UF NF 194 E W180C User manual

VALBERG
VALBERG UF NF 240 E S180C User manual

VALBERG
VALBERG SBS 532 F B625C2 User manual

VALBERG
VALBERG UF 242 F W742C User manual

VALBERG
VALBERG CNF 326 D X742C User manual
