Valcom VE8024A User manual

Issue 3
1 947496
VE8024A/VE8024AR
QUAD ENHANCED NETWORKED TRUNK PORT
INTRODUCTION
The VE8024A/VE8024AR Quad Enhanced
Networked Trunk Port allows most loop start
station ports to be connected to a managed
IP-based LAN/WAN. SIP connectivity allows the
VE8024A/VE8024AR to act as a gateway device
between a SIP telephone system and the loop start
Valcom paging systems.
The VE8024A is designed for wall or table
placement. The VE8024AR is designed for 19”
rack mounting (1U).
SPECIFICATIONS
Access Methods
PBX, FXS Port
SIP
Features
RJ45 for network connection
4 RJ11 FXO connections
4 RJ11 failover telephone connections
Decode Caller ID signals
Front panel activity LED
Network activity LEDs
2.5mm jack for optional DC power
Power over Ethernet (PoE) 802.3af compatible
Dimensions/Weight (VE8024A)
1.38 H x 6.13" W x 5.25" D
(3.50cm H x 15.6cm W x 13.33cm D)
Weight: 1.25 lbs. (0.57 kg)
Dimensions/Weight (VE8024AR)
1 Standard 19” Rack Unit
1.75 H x 16.50" W x 5.25" D
(4.45cm H x 41.91cm W x 13.33cm D)
Weight: 5.10 lbs. (2.32 kg)
Nominal Specifications
Input Impedance: 600 Ohms
Input Level: -10dBm
Output Impedance: 600 Ohms
Output Level: - 10dBm nominal
VE8024A
VE8024AR
Nominal Power Requirements
Via back panel barrel connector:
Voltage: 24VDC
Current: 325mA
Via 802.3af PoE Ethernet Switch:
802.3af: Class 3
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
These products are intended for use with a UL
Listed power source marked “Class 2” or “LPS”
rated 24VDC, or 48VDC (PoE).
PoE and all interconnected ITE are intended for
intra-building.
Precautionary Designations
WARNING: To Reduce The Risk Of Fire Or
Electric Shock. Do Not Expose This
Apparatus To Rain Or Moisture.
AVERTISSEMENT: Afin de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système à la
pluie ou à l'humidité.
Apparatus shall not be exposed to
dripping or splashing and no objects
filled with liquids, such as vases, shall be
placed on the apparatus.
L’appareil ne doit pas être exposé à des
égouttements et éclaboussures et
aucun Objet Rempli de liquide, comme
vase, ne doit être placé sur l’appareil.

2 947496
CAUTION: To reduce the risk of electric shock,
Do not remove cover (or back).
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
NOTE: The telephone system referred to in this
manual is the customer premise equipment
such as an electronic key system, a PBX or a
dedicated single line telephone sets. The
VE8024A/VE8024AR is not intended for direct
or indirect connection to the public telephone
network. When used with a customer premise
telephone system such as a key system or PBX
system, these units are interfaced to the
system via a fully protected page port or
system central office port, which is a fully
protected interface device.
Also, the host system must be configured to
disallow central office trunk conferencing in
order to prevent indirect connection to the
public network.
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated in
a commercial environment. This equipment
generates, uses and can radiate radio
frequency energy and if not installed and used
in accordance with the instruction manual, may
cause harmful interference to radio
communications. Operation of this equipment
in a residential area may cause harmful
interference in which case the user will be
required to correct the interference at his own
expense.
General Mounting Information
A) Elevated Operating Ambient - If installed in a closed
or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater
than room ambient. Therefore, consideration should be
given to installing the equipment in an environment
compatible with the maximum ambient temperature
(Tma) specified by the manufacturer.
B) Reduced Air Flow - Installation of the equipment in a
rack should be such that the amount of air flow required
for safe operation of the equipment is not compromised.
C) Mechanical Loading - Mounting of the equipment in
the rack should be such that a hazardous condition is
not achieved due to uneven mechanical loading.
D) Circuit Overloading - Consideration should be given
to the connection of the equipment to the supply circuit
and the effect that overloading of the circuits might have
on overcurrent protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be
used when addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted
equipment should be maintained.
Particular attention should be given to supply
connections other than direct connections to the branch
circuit (e.g. use of power strips).
F) Equipment only suitable for mounting at heights less
than or equal to 2m (6.56’).
INSTALLATION
Mounting
VE8024A
Wall: Secure mounting brackets to the VE8024A,
then secure the VE8024A to the wall (See Figure
1).
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respecteztous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chiffon sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplificateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not fit into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la fiche polarisée ou de mise à la terre. Une
fiche polarisée possède deux lames dont une plus large que l'autre. Une fiche de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la fiche fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
N'utilisez que des fixations / accessoires spécifiés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specified
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécifié par le
fabricant ouvendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période detemps.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Confiez toute réparation à un personnel qualifié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Parexemple lorsque le cordon
d'alimentation ou la fiche est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.

3 947496
Table: Provided with the VE8024A are four rubber
pads. Peel pads off their carrier backing and place
at the four corners of the bottom of the unit.
VE8024AR
Rack: Secure mounting brackets to the VE8024AR
(See Figure 1). Place the VE8024AR into a
standard 19” rack and secure with proper hardware
(not included).
Figure 1. Mounting
Power Connections
The preferred method of powering a
VE8024A/VE8024AR is via a Power over Ethernet
(PoE) switch meeting the 802.3af specification.
If the rear panel barrel connector is used for power,
the preferred power supply is a Valcom VIP-324D.
Make all required signal connections before
applying power to the unit. If powering via 802.3af,
make sure all signal connections via the back
panel are made then connect the
VE8024A/VE8024AR to the Ethernet switch.
If power is supplied via the barrel connector, make
sure all signal connections are secure. Attach the
unit to the network via the front panel RJ45
Ethernet connector. Apply power by plugging the
power supply into the VE8024A/VE8024AR via the
barrel connector on the rear of the
VE8024A/VE8024AR.
Network Connection
The VE8024A/VE8024AR has one RJ45 Ethernet
network connector on the front panel.
Use the supplied patch cable to connect the
VE8024A/VE8024AR to an Ethernet switch
Signal Connections
FXS Connection: Connect standard analog FXS
circuits, capable of providing calling party
disconnect, to the VE8024A/VE8024AR via the
rear panel RJ11 jacks labeled Port 1 Line, Port 2
Line, Port 3 Line and Port 4 Line. Tip and Ring
appear on pins 3 and 4 of these jacks.
Failover Telephone Connections:
Connect standard analog telephones to the
VE8024A/VE8024AR via the rear panel RJ-11
jacks labeled Port 1 Phone, Port 2 Phone, Port 3
Phone and Port 4 Phone. Tip and Ring appear on
pins 3 and 4 of these jacks.
Rear View: VE8022A
Rear View: VE8024AR
Setup
Information specific to your application will need to
be programmed into the VE8024A/VE8024AR
using a computer. The PC used for programming
should be connected to the same subnet as the
VE8024A/VE8024AR. Setup will be done using
the IP Solutions Setup Tool. Download the latest
version of the free IP Solution Setup Tool from
Valcom website at www.valcom.com/vipsetuptool.
Status Indicator Lights
The VE8024A/VE8024AR has 3 status indication
lights on the front panel:
STATUS: Flashes during normal operation and
solid during system startup.
LINK: Indicates 100 Mbit Ethernet connection
when illuminated. No activity indicates 10 Mbit
connection.
ACT: Indicator flashes to indicate network activity.

4 947496
TECHNICAL ASSISTANCE
When trouble is reported, verify power is being
supplied to the unit and there are no broken
connections. Check voltages for proper polarity to
the one-way amplified speakers. If a spare unit is
available, substitute a spare unit for the suspected
defective unit.
Assistance in troubleshooting is available from the
factory. Call [phone] and ask for Valcom
Engineered Solutions Technical Support, or visit
our website at www.ValcomES.com.
Valcom equipment is not field repairable. Valcom,
Inc. maintains service facilities in Roanoke, VA.
Should repairs be necessary, attach a tag to the
unit clearly stating your company name, address,
phone number, contact person and the nature of
the problem. Send the unit to:
Valcom, Inc.
Repair & Return Dept.
5614 Hollins Road
Roanoke, Va. 24019-5056
WARRANTY
Warranty information may be found on our website
at www.valcom.com/warranty.
