Valentine 2000 Series User manual

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 1
Operating Instructions
for deep fat fryers
Applicable to models: SERIES 2000
V200 (T) V2200 (T)
V250 (T) V2525 (T)
V400 (T) V600
Your model:
Please give the information
below when ordering or requesting
repairs.
Spares: see page 11
Your service centre:
Declaration of conformity
Valentine Fabrique SA
6, Avenue d’Epenex
CH - 1024 ECUBLENS
Tél.: [phone] Fax: [phone]
Internet: www.valentine.ch Mail: [email protected]
confirms that the above-mentioned products conform to the following standards:
Machine safety: EN 60335-2-37:95+A1:96: Par. 11, 13 and 19
EMC: EN 55014:93 and EN 55014-2:97
EN 61000-3-2:95 and EN 61000-3-3:95
Ecublens, 15 January 1998
The responsible officer from Valentine Fabrique SA The EEC representative:
Name: M. F. Wenger Name: M. A. Holliday
Board of Directors Director of Valentine Equipment LTD
Reading RG1 8JS (GB)

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 2
Contents
Page No.:
1. Important information ___________________________________________________ 3
1.1 Warning _____________________________________________________________________ 3
1.2 Risks from food remnants______________________________________________________ 3
1.3 Periodic inspections __________________________________________________________ 3
2.Technical data _________________________________________________________ 4
3. Installation ____________________________________________________________ 4
3.1 Electrical connection __________________________________________________________ 4
3.2 Installation examples
3.2.1 Installation example I (Fig. 1)__________________________________________________________ 4
3.2.2 Installation example II (Fig. 2) _________________________________________________________ 4
3.2.3 Installation example III (Fig. 3)_________________________________________________________ 4
3.3 Cleaning ____________________________________________________________________ 5
4. Instructions for use_____________________________________________________ 7
4.1 Pouring in oil ________________________________________________________________ 7
4.2 Operation - Melting - Frying ____________________________________________________ 7
4.3 How to save oil _______________________________________________________________ 7
4.4 Oil care _____________________________________________________________________ 8
4.5 Maintenance of fryer, changing oil_______________________________________________ 8
5. Repairs _______________________________________________________________ 9
5.1 Simple faults _________________________________________________________________ 9
5.2 Complex faults _______________________________________________________________ 9
5.3 Security thermostat __________________________________________________________ 10
5.4 Safety switch _______________________________________________________________ 10
5.5 Spare parts _________________________________________________________________ 11
5.6 Circuit diagram _____________________________________________________________ 12
Warning:
The information given in these operating instructions may be amended at any
time. Valentine Fabrique SA accepts no liability for errors in these instructions
and any consequent damage.

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 3
Dear Customer,
Congratulations on purchasing a Valentine fryer, a product of the best quality well known in
Europe for 50 years.
The following operating instructions are based on EC and international regulations, as well
as on the new product liability.
1. Important information
1.1 Warning
Before using the fryer you must:
⇒study the following operating instructions and follow them closely
⇒instruct the operating personnel and make them aware of the risk presented by
food remains.
Valentine Fabrique SA accepts no liability for damage caused through improper
operation and failure to adhere to these operating instructions.
1.2 Risks from food
remnants
•Hot oil can cause severe burning.
Therefore avoid any direct contact with the hot oil.
•Thoroughly drain the food to be fried before frying.
•Never allow water or ice to come into contact with the hot oil,
otherwise the oil will spatter.
•Ensure that your face is not near the oil pan when food is
immersed in it.
•Beware of clouds of steam and hot oil spray.
•Never allow anything but food to drop into the oil pan, e.g. gas
cartridges, sealed bushings, etc. These explode and cause
considerable spattering of oil.
•The fryer must not be operated without supervision. If a large
amount of smoke develops, switch off immediately (switch to
“ 0 ”)
•The oil level must not drop below the "MIN" oil level mark. If the
oil level is too low there is a fire risk.
•N.B.: Old or frequently used oil/fat has a lower flash point and is
more easily ignited. It may suddenly boil over when food is
immersed.
•If the fryer catches fire, never extinguish with water. It is
recommended that a fire extinguisher or fire extinguishing
blanket be installed near the fryer.
Valentine fryers conform to the most stringent safety standards and are equipped with
breakage-proof temperature limiters. Damage or fault must be excluded wherever humanly
possible.
1.3 Periodic inspections
♦Have the operation of the working thermostat and security thermostat checked (see 5.3)

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 4
2. Technical data
Model:
Power [kW]
Connection 3P+N+E
3x400V [A]
Frequency [Hz]
Connection cable
Capacity in litres
Working thermostat
Safety thermostat
Timer
Chips fried [kg /h]
Protective system
Weight [kg]
Dimensions [cm]
V200 7.2 10 50-60 5x1.5 7-9 1 1 1 19-23 IP X4 34 20x58x85
V200T 11 16 50-60 5x1.5 7-9 1 1 1 26-32 IP X4 34 20x58x85
V2200 14.4 20 50-60 5x2.5 2x 7-9 2 2 2 38-46 IP X4 52 40x58x85
V2200T 22 32 50-60 5x4 2x 7-9 2 2 2 52-64 IP X4 53 40x58x85
V250 7.2 10 50-60 5x1.5 8-10 1 1 1 19-23 IP X4 35 25x58x85
V250T 11 16 50-60 5x1.5 8-10 1 1 1 26-32 IP X4 35 25x58x85
V2525 14.4 20 50-60 5x2.5 2x 8-10 2 2 2 38-46 IP X4 55 50x58x85
V2525T 22 32 50-60 5x4 2x 8-10 2 2 2 52-64 IP X4 56 50x58x85
V400 14.4 20 50-60 5x2.5 18-20 1 2 1 38-46 IP X4 49 40X58X85
V400T 22 32 50-60 5x4 18-20 1 2 1 52-64 IP X4 50 40X58X85
V600 21.6 32 50-60 5x4 25-28 1 3 1 57-68 IP X4 69 60X58X85
3. Installation
Erect fryer, to level rotate the setscrews underneath the front feet.
The fryer must not stand on combustible surfaces. Local safety regulations must be complied with.
N.B.: The slimline fryers V200 and V200T, as well as V250 and V250T, must not be freely erected (risk of
tipping over). They must be installed between 2 units of furniture, or they must be supported on the sides.
3.1 Electrical connection
Only experts may connect and commission the fryers.
Your mains data (voltage, current, fuse protection) must conform to the data on the fryer rating plate (The rating
plate is mounted on the inside of the door (Figs. 1 to 3 = D).
The electrical connection must conform to local regulations, essentially as follows :
- Fitting a mains plug on the connecting cable. Earth conductor = yellow/green, neutral conductor = blue
Phase sequence is immaterial.
- Any fixed connection must be made via a mains switch with all-pole isolation (min. contact distance 3 mm.).
- Before connection is made to the mains, check that the main switch "E" of the fryer is in the "0" position.
Never heat without oil !
3.2 Installation examples
A considerable amount of steam is generated when preparing chips. A good steam extractor is strongly
recommended.
3.2.1 Installation example I (Fig. 1)
Wall socket [F] resistant to dripping water IP X2 or water spray IP X4
3.2.2 Installation example II (Fig. 2)
Fryer free-standing or next to cooking range. Connection column [H] with socket IP X2 or IP X4
3.2.3 Installation example III (Fig. 3)
Connection box [J] with 3P+N isolating switch arranged above fryer. Cable permanently connected. Because of
the considerable steam generated the box must be watertight IP X5.
3.3 Cleaning
Pull the fryer forward [K] to clean the rear wall and bottom (Fig. 4). The cable must therefore be long enough to
do this.

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 5
Fig. 1: Fryer against wall Fig. 2: Fryer free-standing Fig. 3: Fryer against wall,
with socket IP X2 (next to cooking range) with swichbox IP X5
N.B.: The V200 and V250 fryers, which are only 200 and 250 mm wide respectively, must be
secured on the sides (risk of tipping over).
A Steam extractor F Wall socket IP X2
B Wall G Connecting cable 1,9 m
C Heating element folded up H Connection column
(cleaning) J Connection box with isolating switch IP X5
D Rating plate with unit no. K Fryer pulled forward for cleaning the rear
E Main switch behind door wall and bottom
Fig. 4

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 6
Heating element may be folded up : L = working position N = draining M = cleaning
1 Lid mounted in door 19 Red lamp = safety thermostat off
2
Door handle (door open) 20 Basket
3
Lid handle 21 Door (open)
4
Rating plate 22 Basket hook
5
Control panel mounting 23 Oil pan
6
Timer 24 MAX - MIN oil level mark
7
Main switch (behind door) 25 Heating element coil
8
Colourless lamp = melting 26 Oil cock lever
9
Colourless control lamp = frying 27 Filter
10
Thermostat (behind door) 28 Discharge tank
11
Yellow control lamp = heating 29 Thermostat sensor on heating element
12
Green control lamp = immersing basket 30 Security thermostat sensor
13
Basket suspension bracket 31 Foot with setscrew
14
Heating element box 32 Foot with roller
15
Security thermostat 33 Safety oil cock
16
Reset button for security thermostat 34 Connection or potential equalisation
17
Connecting cable 1,9 m. 35 Heating element interlock
18
Hook for increasing heating 36 Safety switch
Fig. 5 Detail control panels
- 1 Oil pan - 2 Oil pans
8
9
Behind the door
Above the door
12
11
6
0
0
0 0 0
0
0
0
16
19
10
7

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 7
4. Instructions for use
4.1 Pouring in oil
Grip lid [1] (Fig. 5, page 6) by handle [3] and
place inside the door [21] (hinge at the top)
◊Whilst working, the folded lid is supported inside the
door.
Pour peanut oil into the fryer basin as far as
the MAX level mark [24]
◊Solid fat must first be melted in a pan, not on the
heating element!
4.2 Operation : Melting - frying
Open door, move switch [7] to "Melt" position
Switch thermostat to 150°, for example
⇒Upper colourless signal lamp [8] on the right comes on.
Reduced power for block of fat in fryer, also economic
heating of oil, approx. 10-15 minutes.
⇒Yellow signal lamp on the left comes on.
As soon as the first order is taken, turn switch
[7] to "Fry".
Switch thermostat to approx. 180°
⇒Lower colourless lamp on the right comes on
⇒Yellow "Heat" lamp comes on
⇒The temperature reaches 180°in 2-3 minutes
As soon as the green cook light comes on,
immerse basket
Set timer, e.g. 3 minutes. As soon as the timer
sounds, raise basket, shake and suspend.
⇒After half the frying time raise and shake basket. Do
not knock against oil pan.
Always top up with oil after use. When the oil level is too low the power drops considerably
and the oil is overheating.
Never operate below the "MIN" oil level mark.
Never overfill basket.
Follow filling stages 1, 2, 3 in
table
•oil is cooled excessively
•frying time is extended
•
the food being fried absorbs
oil
Temp.
o
C Food being fried Minutes Basket filling height
190
Deep frozen chips
3 (1+1)
-
1/3
-
160 Prefrying raw chips 4 - 6 -3/4-
190 Finish frying, blanching chips 2 - 3 -1/3-
170 Veal pork schnitzel, cutlets 3 -1/2-
170 Deep frozen chicken legs 6 - 8 -1/2-
180 Fish 2 - 4 -1/2-
4.3 How to save oil
∗Do not heat the fryer for hours before or after service (The heating time is only 5-6 minutes).
➙
➙➙
➙ High temperatures ruin the oil, not the food!
∗Limit oil temperature to 180
o
C instead of 200
o
C
➙
➙➙
➙ Oil life is extended by approx. 40 % !
∗After each service pour oil through a microfilter (optional extra). This retains even microscopic waste.
Working time = 1 minute, including cleaning of filter !
otherwise
3/4
1/2
1/3

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 8
4.4 Care of oil
Filter the oil after each use, approx. at 60°C. N.B: Risk of combustion!
Open door, turn main switch [7] to “ 0 ” position. Turn red
lever [26] of oil cock complete downward, and at the
same time push the safety pin to the right. Oil flows
through the filter [27] into the tank [28]
⇒Do not heat when oil pan is empty!
⇒Is the cleaned filter on the tank ?
⇒Pour oil back into the fryer.
⇒Clean filter and tank.
Finally cover the oil pan with the lid mounted in the door.
Frying basket is stainless.
⇒The lid protects the oil from dust and light.
⇒Is washed once a week.
* Important: If you do not open the drain cock completely (red lever in vertical position), the drain
cock can be damaged!
4.5 Maintenance of fryer, changing oil
The fryer must be thoroughly cleaned when the oil is changed. As soon as the oil turns brown and
begins to smoke (after approx. 20 to 40 operating hours, according to the operating temperature and
grade of oil), the oil must be changed.
Waste oil must not be poured into the drain.
You must deliver waste oil to a disposal service.
Open door, turn main switch to “ 0 ”. Lift heating element
into the drain position “ L ”. Drain oil, remove tank and
clean filter.
⇒Do not lift heating element fully, otherwise
oil will run along the rod to the heating
element box = additional cleaning.
Pour boiling water with a degreasing agent (soda) into
the oil pan up to approx. 5 cm. above the "MAX" oil level
mark. If you clean daily you will never have encrustation
on the heating element or oil pan!
⇒Allow the oil pan to operate for 1-2 hours,
and clean heating element with a brush with
a handle. Do not damage the thermostat
sensor. Now raise heating element fully and
clean oil pan down to the bottom. After
cleaning, rinse thoroughly with hot water.
Residues of cleaning agents or detergents
ruin the fresh oil you are pouring in.
Wipe the oil pan and heating element clean with a dry
cloth. Close oil cock, pour in fresh oil up to the “ MAX ”
level [24]
⇒Raise the heating element. Push back the
interlock [35] and tilt the heating element
fully down above the drain position.
Exclusive advantages of your Valentine fryer:
Higher power due to dialogue
system (US + European patent)
⇒When the green cook light comes on, immerse
basket immediately. The thermostat does not
switch off and the fryer is at maximum power.
Automatic saving (patent) ⇒During the waiting time the fryer only heats at
half power, saving oil and power.
Super heating ⇒Very long heating elements, all in chromium
steel, low loading, saves oil.
Thermostat ⇒Reacts very quickly. Sensor in centre of oil pan.

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 9
5. Repairs
5.1 Simple faults
Fault Possible cause Remedy
The fryer is no longer heating.
No lamp lights up
The red lamp lights up
∗No power
∗Safety thermostat has
switched off
◊Check fuses, plugs and socket
◊Press reset button (see 5.3)
The fryer is not heating
sufficiently
∗One phase is missing on
the power supply cable
◊Check fuses
The fryer is not heating
sufficiently
∗The switch has remained
on "Melt"
◊Turn button to "Fry"
Oil cock is sticking ∗Sticking due to old oil
residues
◊Actuate frequently with hot oil.
i.e. filter oil daily
The special mains cable must only be replaced by the manufacturer or his customer service
representative.
5.2 Complex faults
Fault Possible cause Remedy
The signal lamps come on, but
the fryer is no longer heating
∗Heating element defective ◊Call the service centre *
The fryer is not heating
sufficiently
∗Interruption of a phase
∗Heating element defective
◊Call the service centre *
The fuses blow when fryer is
switched on
∗Short-circuiting ◊Call the service centre *
The fault current safety switch
(FI) in the fuse box switches off
∗Moisture or poor insulation
in the electrical circuit
◊Call the service centre *
The colourless signal lamp does
not come on or is flashing
∗Main switch defective ◊Call the service centre *
The yellow signal lamp does not
come on or is flashing
∗Thermostat defective ◊Call the service centre *
The green signal lamp does not
come on or is flashing
∗Thermostat defective ◊Call the service centre *
* Important: If you call the customer service dept,
you must give the following information:
Example:
- Type of fryer
- Unit no.
- Volts, amps, kilowatts
- V250
- U253A111K3
- 3x415V, 10.5A, 7.5kW
You will find this information on page 1 of these instructions and on the fryer rating plate.
If the information is correct the fitter gains time, the customer saves money!

Date of creation: 15.01.98 by W/mm Date of modification: 03.09.03 by fd File:
Fabrique SA
Doc. N° A2000E Page No.: 10
5.3 Safety thermostat
Every heating element is fitted with a breakage-proof temperature limiter. The reset button is located
behind the door on the upper edge of the control panel. (Fig 5, no. 16, page 6). The red signal lamp
[19] to the right of the reset button lights up as soon as the temperature limiter switches off.
The safety thermostat ∗when oil temperature is over 230 oC
breaks the heating circuit ∗when capillary tube is damaged
∗when temperature drops below 0 oC
and also in the case ∗if fryer is heated without oil
of improper use ∗if the oil level is too low
∗if you drain the oil before switching off the fryer
∗If the heating element is not in the correct position in the oil pan
∗if a block of fat is melted on the heating element
Resetting the safety thermostat
Before resetting, find out why it has switched off (see above list).
- Allow fryer to cool. The thermostat sensor on the heating element cannot be switched on if it
has not cooled down (to accelerate cooling raise heating element to the drain position).
- Push the red button [16]. Lamp [19] will go out. N.B. Fryer is heating! If the safety thermostat
switches off again the fryer must be switched off. Inform the service centre.
5.4 Safety switch
As soon as the heating element is raised to the "drain" position the safety switch (Fig. 5, page 6, no.
36) interrupts the power supply.

Date of creation: 15.01.98 by W/mm Date of modification: 02.12.08 FC File:
Fabrique SA
Doc. N° A2000E Page No.: 11
5.5 Spare parts
Only use original spare parts. When ordering spare parts indicate not only the unit no. but also the article no.
given in the table.
This information is given on page no. 1
Your fryer:
Name
V200
V200T
V2200
V2200T
V250
V250T
V2525
V2525T
V400
V400T
V600
Art. Nr.
Diagram
code
Tech. data
Colourless control lamp (melt, fry) 2 2 4 4 2 2 4 4 2 2 2 6324 H3, H4,
H8, H9 230V
Yellow control lamp (heat) 2 2 4 4 2 2 4 4 2 2 2 6325 H1, H6 230V
Green control lamp (immerse) 1 1 2 2 1 1 2 2 1 1 1 6326 H2, H7 230V
Red control lamp (Security) 1 1 2 2 1 1 2 2 2 2 3 6327 H5, H10,
H15 230V
Resistance for control lamp 4 4 8 8 4 4 8 8 3 3 3 6328 R20 -
R26
120K;2
W
Safety t emperaturelimitor, sensor Ø4 1 1 2 2 1 1 2 2 2 2 3 631451 S1,S2,S3 20A
Working thermostat, sensor Ø4 1 2 1 2 1 1 6311 S20, S21 16A
Working thermostat, sensor Ø4
1 2 1 2 1 6310 S20, S21 16A
Safety switch XP-52 2 2 4 4 2 2 4 4 4 4 6 6321 S5 - S10 16A
Main switch 10A 42.04000.021 1 2 1 2 1 1 1 631652 S30 10A
Main switch 16A 43.34832.003 1 2 1 2 631751 S40,S41 16A
Connection terminal 20 EDS 4 4 4 4 4 4 4 637401 XT1 16mm²
Switch relay 3 x 20 A 2 2 3
6281 K1 - 3X20A
Fuse 6.3AT 5x20 mm
1 1 1 6402 F1 6.3AT
Fuseholder
1 1 1 6401 F1 FPG
Heating element
H E 7.2/7.5kW 3N400/415V 1 2 1 2
2 3 62911SA
H E 11/11.8kW 3N400/415V 1
2 1 2 2 63023SA
Miscellaneous
Timer 15 minutes 1 2 1 2 2 2 6341
Button for timer 15 min. 1 2 1 2 2 2 6335
Button for thermostat 110-190°C 1 2 1 2 1 1 6336
MELT - FRY button 1 2 1 2 1 1 6331
Ball cock 1"G (oil cock) 1 2 1 2 1 1 6431
Nut 1" G for oil cock 1 2 1 2 1 1 63419
Basket, filter
Basket V200 290 x 160 x H130 1 2
2 641704
Basket V250 290 x 210 x H130 1 2 641904
Basket V400 big 290 x 350 x H130
1* 641802 *(option)
Basket V600 small 290 x 255 x H130
2 642004
Basket V600 big 290 x 550 x H130
1* 642102 *(option)
Metal filter for drain tank V200 1 2 6427
Metal filter for drain tank V250 1 2 6428
Metal filter for drain tank V400
1 1 6429
Fryer type Type
Unit number No.
Voltage, current and power U, I, P
