Valeo SC600 Revo-E Byd Hybrid User manual

Rev. 21.11.2018
Id.No. DOK30609
BUS BODY ELECTRONICS
SC600 REVO-E BYD HYBRID
Operating instructions
-Busdriver

BUS BODY ELECTRONICS
1
Contents
Contents 1
List of Figures 2
List of Tables 2
1Introduction 3
1.1 Intended purpose 3
1.2 Symbols used 3
1.3 Description of the control panel 4
1.4 Description of the display 4
1.5 Mode overview 5
2Use 6
2.1 Activation/deactivation 6
2.1.1 Activation 6
2.1.2 Deactivation 6
2.2 Auto mode 6
2.2.1 Activation 6
2.2.2 Deactivation 7
2.3 Configuring the blowers manually 7
2.4 Fresh air/recirculating air function 7
2.5 Dehumidify 8
2.6 Setting the temperature 8
2.7 Errors 8
2.7.1 Error detection mode 8
2.7.2 Error overview 9

BUS BODY ELECTRONICS
2
List of Figures
Figure 1 - SC600 control panel..................................................................................4
Figure 2 - SC600 display.........................................................................................4
Figure 3 - SC600 mode overview...............................................................................5
Figure 4 - SC600 start display...................................................................................6
Figure 5 - SC600 deactivation...................................................................................6
Figure 6 - SC600 Auto mode activated ........................................................................6
Figure 7 - SC600 Auto mode activated, Cooling mode......................................................6
Figure 8 - SC600 Auto mode activated, Heating mode......................................................6
Figure 9 - SC600 Auto mode deactivated .....................................................................7
Figure 10 - SC600 recirculating air function activated.......................................................7
Figure 11 - SC600 dehumidify activated.......................................................................8
Figure 12 - SC600 setting the temperature....................................................................8
Figure 13 - SC600 errors.........................................................................................8
Figure 14 - SC600 Error detection mode ......................................................................8
Figure 15 - SC600 normal operating display..................................................................9
List of Tables
Table 1 - SC600 error code overview ..........................................................................9

BUS BODY ELECTRONICS
3
1 Introduction
1.1 Intended purpose
The SC600 is a system intended to control the HVAC components (heating, ventilation, air-
conditioning) in buses, for example roof-top air-condition systems, heating devices, etc. It con-
sists of a control panel (control device as an interface between human and machine) that is
integrated into the dashboard.
This control panel allows the driver to control the roof-top air-conditioning system that has ven-
tilation, cooling and heating functions for the roof. Additionally, this control panel can also be
used to control the heating system on the floor.
The controller for the air-conditioning systems components can operate automatically. To do
so, the bus driver simply has to set the desired temperature.
1.2 Symbols used
Note

BUS BODY ELECTRONICS
4
Figure 2 - SC600 display
1.3 Description of the control panel
The control panel components are depicted and described in the following image.
1.4 Description of the display
1. Display
2. On/off button
3. UP
4. DOWN
5. Function status light
6. Blower button
7. Fresh air/recirculating air button
8. Auto button
A. Desired value display, room temperature
B. Blower level manual
C. Cooling mode
D. Heating mode
E. Recirculating air on
F. Error display
G. Auto mode active
H. External temp. display
1
2
3
4
6
7
8
5
Figure 1 - SC600 control panel
B
H
C
A
D
F
G
E

BUS BODY ELECTRONICS
5
1.5 Mode overview
The SC600 system includes 2 different modes –Operating mode and Error mode.
Figure 3 - SC600 mode overview
SC600
Operating mode:
Includes all of the
functions and infor-
mation summarized
under point 2 as
well as Error mode.
The normal operat-
ing display includes
all of the elements
provided here in the
example:
Error detection
mode:
Mode to display all
errors that occurred
and their probability
of occurrence.
For more infor-
mation, see points
2.6.1 and 2.6.2.
The error display in-
cludes all of the ele-
ments provided
here in the example:

BUS BODY ELECTRONICS
6
2 Use
2.1 Activation/deactivation
2.1.1 Activation
Press button
➔Sets the last configured temperature; Auto mode off
(Figure 4).
2.1.2 Deactivation
Press button
➔Display deactivated.
Press button for 2 seconds until OFF appears
➔System deactivated.
2.2 Auto mode
2.2.1 Activation
Press button if Auto mode is off
➔Mode is on - corresponding status light and function
symbol light up on the display (Figure 6).
Note
Auto mode can be turned on only if the motor has been
started.
Note
If Auto mode is on, the system automatically turns on Cool-
ing Mode and Heating mode (if available) as needed
(Figures 7 and 8). Activate Auto mode in order5 to use all
functions.
Figure 6 - SC600 Auto mode activated
Figure 7 - SC600 Auto mode activated,
Cooling mode
Figure 4 - SC600 start display
Figure 5 - SC600 deactivation
Figure 8 - SC600 Auto mode activated,
Heating mode

BUS BODY ELECTRONICS
7
2.2.2 Deactivation
Press button if Auto mode is on
➔Mode is off - corresponding status light and function
symbol are off (Figure 9).
2.3 Configuring the blowers manually
2.4 Fresh air/recirculating air function
Press button when fresh air valves are open
➔System activates recirculating air function for 10
minutes (corresponding function status light and dis-
play symbol light up).
➔After running for 10 minutes, the system turns off the
manual recirculating air function. The system then
controls the fresh air valves automatically.
➔Pressing the button again within 10 minutes will de-
activate the manual recirculating air function. The
system then controls the fresh air valves automati-
cally.
Note
When Auto mode is deactivated, the air conditioning com-
pressor (after a run time of 90 seconds max.) and the heater
are turned off.
The blower will continue to be controlled automatically.
Note
It is not possible to control the blower manually.
Note
If the manual recirculating air function is on, the correspond-
ing status light and the display symbol will light up (Figure
10).
Figure 9 - SC600 Auto mode
deactivated
Figure 10 - SC600 recirculating air function
activated

BUS BODY ELECTRONICS
8
Figure 12 - SC600 setting the
temperature
2.5 Dehumidify
Press button for 2 seconds
➔Dehumidify air function is on (Figure 11).
2.6 Setting the temperature
Press button
➔Desired temperature +1 °C.
Press button
➔Desired temperature -1 °C.
2.7 Errors
2.7.1 Error detection mode
2.7.1.1 Activation
Press and buttons at the same time for 2 seconds
➔Mode is on.
➔Error code (F001) and occurrence count (1 here) will
be displayed (Figure 14).
2.7.1.2 Reading out errors
➔Scroll through the error codes with or .
Note
Dehumidify can only be activated when Auto mode is on.
Note
Temperature can be configured for1°Cintervals between 15
°C and 28 °C.
Note
If a system error occurs, the error symbol will appear on the
display (Figure 13).
Figure 14 - SC600 Error detection mode
Figure 13 - SC600 errors
Figure 11 - SC600 dehumidify activated

BUS BODY ELECTRONICS
9
➔Reset the counter with (after resetting, the coun-
ter shower the value 1 if the error persists).
2.7.1.3 Ending
Press and buttons for 2 seconds
➔Normal operating display appears (Figure 15).
2.7.2 Error overview
Error code
Component
Cause
Remedy
F001-015
Not used
F016
EDS
➢Restart system
F017
Pressure sensor
➢Defective sensor
➢Wiring harness de-
fective
➢Inspect wiring harness
➢Replace sensor
F018
Duct/convector temper-
ature sensor
➢Defective sensor
Wiring harness defec-
tive
F019
Ice sensor
➢Defective sensor
Wiring harness defec-
tive
F020
Room temperature sen-
sor
➢Defective sensor
Wiring harness defec-
tive
F021
Environmental tempera-
ture sensor
➢Defective sensor
Wiring harness defec-
tive
F022
Ice sensor
➢Icing
➢Temperature too low
Wait until sensor has de-
frosted
F023
F024
High pressure
Low pressure
Brief system over-
load because of
high motor speed at
high environmental
temperature
The system turns off for
5 minutes and tries to
restart. If the error code
persists, consult our
service center
F025-32
Not used
Table 1 - SC600 error code overview
Figure 15 - SC600 normal operating
display

Valeo Thermal Commercial Vehicles Germany GmbH
Postfach 1371 –82198 Gilching - Germany - Tel. [phone] - Fax [phone]
www.valeo-thermalbus.com - [e-mail]
