Valley Electronics daysy User manual

Instructions for Use English from page 03
Gebrauchsanweisung Deutsch ab Seite 31
Mode d’emploi Français à partir de la page 59
Istruzioni per l’uso Italiano da pagina 87
Instrucciones de Uso Español desde la página 115

3
english
Love your body:
Welcome to Daysy

4Table ofContents
Page 6 to 8 | Precautions
What you need to know.
Page 9 to 21 | Operation
How to use Daysy.
Page 22 to 30 | Technical notes and warranty
What else you need to know.

5
english
About Daysy
Daysy calculates a woman’s daily menstrual cycle status by interpreting her basal
body temperature. Daysy displays your menstrual cycle status using colored
lights. Daysy is to be used to facilitate conception. Daysy is not a replacement for
contraception, nor is it a medical thermometer.
Included in delivery:
– Daysy
– Sensor cap
– Micro USB cable
– Instructions for Use
– Quick Guide

6Precautions
– Before using your Daysy for the first time, please read these instructions
carefully and keep them in a safe place for later reference.
– Before you start using your Daysy, you need to entirely discontinue hormonal
methods of birth control.
– Daysy can better determine your cycle if you have regular cycles.
– Daysy is not suitable for use if you are undergoing hormonal treatment, or if
you are using hormonal methods of birth control.
– Daysy does not protect you from sexually transmitted diseases.
– You should always read your daily fertility status from Daysy itself, not the app.
– Before using Daysy for the first time, charge the battery fully.
– Never open the housing.
– Never chew on the sensor.
– Make sure that the device or its individual parts are not swallowed.
– WARNING: The device must not be modified.
– WARNING: Avoid using Daysy at or less than 30 cm away from other electrical
equipment, as this could result in improper operation.

7
english
– WARNING: Use of cables or equipment other than those specified in this docu-
ment may cause electrical interference or lead to failure of Daysy.
– Do not expose your Daysy to high temperatures (e.g. boiling water).
– Do not expose your Daysy to direct sunlight for long periods of time.
– Do not expose your Daysy to liquids such as running water.
– Only take measurements in your mouth.
– Do not insert the measuring sensor too far into your mouth.
– Do not take measurements if the housing and/or sensor is broken.
– Do not take measurements if you have an injury in your mouth.
– Do not expose your Daysy to heavy mechanical loads.
– Only take measurements when the USB cable is NOT connected.
– Only charge your Daysy using a standard 5V USB port (IEC 60950-1 compliant)
with a maximum output current of 1A and a maximum power of 4.5W with a cable
shorter than 50cm. Do not take measurements while your Daysy is charging.
– If your Daysy causes irritation to your skin, we recommend you stop using it
immediately and contact our Customer Support as soon as possible.

8
– Do not stick sharp objects into your Daysy.
– All serious incidents associated with this product should be reported to the
manufacturer and the relevant government authority responsible in the EU
member state.
– Your Daysy is intended for you alone. You should not share it with other
women. If you do wish to pass it on to a friend, you will need to delete your
data first and unpair Daysy in the app (if you use it).
– Only pass your Daysy on to another person with all instructions. You
will also find the instructions and further useful information available for
download at daysy.me.
– As a user, you can use every feature of your Daysy. You can also clean the
sensor yourself when your Daysy is switched off.
– Your Daysy is not a contraceptive.
– Keep Daysy away from children and pets.

9
english
All the features at a glance*
* Page13 shows you all the important display combinations
Protective cap
Measuring
sensor
Activation button
Activation ring (blue)
Menstruation query (violet)/
Bluetooth®mode (blue)
Fertile/possibly
Fertile (red)
Ovulation prediction
(flashing red)
Infertile (green)
Learning phase/
cycle fluctuation (yellow)
Possible pregnancy
(red, green, yellow)
Micro USB
port

10
Step1: ChargeyourDaysy
1. Connect your Daysy to the micro USB cable supplied in your package and
the cable to a USB port. Make sure it is a 5V port that does not supply more
than 1A current.
2. Press the activation button to see the charging status. The blue lights
moving from bottom to top indicate Daysy is charging. Daysy will enter
standby mode after 60 seconds but will continue charging.*
3. All blue lights remain illuminated when Daysy is fully charged. Simply press
the activation button once to check the status. (A low battery condition is
indicated by all blue lights flashing.)
4. Disconnect the cable from your Daysy. You can now begin using your Daysy.**
* Do not measure or try to sync whilst Daysy is charging.
** You can start measuring at any time in your cycle.

11
english
Measurement indicators:
What each indicator means
Flashing violet light: Your Daysy is asking if you are
menstruating. Confirm that you are menstruating by holding
down the activation button for 2 seconds.
Violet light remains constantly illuminated: Daysy confirms
your menstruation input. If you have entered your menstruation
incorrectly or by mistake, hold the activation button for
2 seconds until the violet light starts flashing again.
Blue light rotating in a clockwise direction: Your Daysy
is measuring your temperature. Holding down the activation
button for 2 seconds stops the measurement.

12 Step 2: Measureyourtemperature
Use your Daysy every day after waking up and before you get out of bed.
Please be sure to sleep 1 consecutive hour immediately prior to measuring.
1. Remove the protective cap and briefly press the activation button once.
Your predicted fertility status will be displayed.
2. Press the button a second time and the activation ring will flash in a clockwise
direction. You can now take a measurement.
3. Place the sensor as far back as is comfortable under the right or left side of
your tongue and then close your mouth.
4. “Beep-beep” means that the measurement phase has successfully completed.*
5. The confirmed fertility status displayed after measurement is valid until
midnight. You can view your fertility status again later in the
day by pressing the activation button once briefly. The next day, your
Daysy switches to the predicted fertility status before your measurement.
* If you hear a “grumble-buzz” sound instead of a “beep-beep”, it means that
the measurement was unsuccessful, and you will need to try again.

13
english
Fertility indicators:
What each indicator means
Fertile/possibly fertile Ovulation prediction
Infertile Possible pregnancy
Learning phase/ Highly probable
cycle fluctuation pregnancy
(potentially fertile)

14 Step 3:
Enteryourmenstruation
If the violet “Menstruation” light is flashing in the activation ring, it means
that Daysy is asking for your menstruation input.*
– If you are menstruating: Press the activation button until the violet light
illuminates without flashing and you hear a “beep”. Confirm you are menstruating
for each day of active bleeding and flow for a minimum of 3 consecutive days.
Always confirm menstruation, even if you did not take your temperature that day.
– If you are not menstruating: You do not have to do anything,
just take your temperature.
– If you are menstruating, but Daysy is not showing the flashing violet light:
Press the activation button until the violet light is constantly illuminated.
* Menstruation can be edited for up to 3 past days. Please enter and edit menstruation
on the device itself. For instructions, watch our tutorials at daysy.me/tutorials.

15
english
DaysyDay:
Better informed with the Daysy app
DaysyDay provides valuable insights to your cycle
and additional viewing and tracking features, as well as
a Partner App.
Turn on Bluetooth®on your mobile phone, open DaysyDay
and select the Bluetooth® button. Follow the on-screen
instructions to turn Daysy on and press the Daysy activation
button twice briefly. A blue light will light up on your
Daysy followed by a brief melody. If the blue light stays lit,
it means the connection was successful.
Flashing blue light:
Daysy is connecting.
Continuous blue light:
Daysy is connected.

16 Temperature and fertility:
The course ofyourcycle
Infertile Infertile
Fertile/
Possibly Fertile
Pre-ovulatory phase Post-ovulatory phase
Low temperature phase
Unique to each individual(10 – 35 days)
Increase
0.25 – 0.45 °C /
0.45 – 0.81°F
High temperature phase
Relatively constant (10 –16 days)
Ovulation
Basal body temperature

17
english
Important:
How to you use your Daysy correctly
– Make sure the first thing you do is take your temperature every morning
before you get out of bed. For the optimal use of Daysy we recommend that
you sleep at least 1 consecutive hour before measuring. If you forget, and
have already gotten out of bed, do not proceed to take your temperature.
– If you are menstruating, enter this input accordingly. It is important to begin
with the first day of active red blood flow.*
– The more regularly you take your temperature, the faster Daysy will get to
know your cycle.
– When you start using your Daysy, you will initially see a lot of yellow and red
days. Over the course of the next 3 – 4 cycles, Daysy learns your unique
menstrual cycle rhythm.
* Important: The first bleeding after stopping the pill or other hormonal contraceptive methods is a
hormonal withdrawal bleeding and not a menstruation. DO NOT enter this bleeding as menstruation.

18 Cleaning
– Clean Daysy before and after every use.
– Use a damp cloth to carefully clean the sensor on your Daysy. You can also
use a little alcohol or soap if you wish. Since your Daysy is not waterproof,
make sure that only the neck of the sensor, and not the whole appliance
comes into contact with water. Do not clean under running water.
Battery
– A single battery charge will last 1– 2 months, depending on how often you
use your Daysy. To indicate that the battery is nearly empty, the activation
ring on your Daysy will flash at frequent intervals. Make sure you charge the
battery within a week. With normal use, the battery will still charge to 80% of
its capacity after 500 charging cycles.
– Note: You should not take measurements while your Daysy is charging.

19
english
Error messages /
Problems during use
My Daysy does not respond when I press the activation button.
Please charge your Daysy and try activating her again before contacting
our Customer Support. Make sure to charge your Daysy every 2 – 3 months.
The activation ring on my Daysy flashes blue at short intervals.
Please charge the battery on your Daysy.
My Daysy fails to start taking a measurement.
– Remove the USB cable before taking a measurement.
– If your Daysy makes a “beep-beep” sound, it means you have already
successfully taken a measurement today.
For more information, read our FAQ at daysy.me or contact our Customer Support.

20 My Daysy ends the measurement with a “grumble-buzz” instead
of a “beep-beep”.
The measurement took too long, was interrupted, or was unsuccessful.
Try following these tips:
– As before, place the sensor as far back as is comfortable under
the right or left side of your tongue.
– Close your mouth.
– Do not remove the your Daysy from your mouth until you hear the “beep-beep”.
– Daysy may not accept the measurement if you have a fever.
Stop taking measurements if you are sick.
– If the sensor gets dirty, simply clean it with a damp cloth.
The red indicator lights up and the activation ring flashes
at short intervals.
Something is wrong with your Daysy. Please contact our Customer Support.
