Valley Electronics Lady-Comp User manual

Instructions:
The intelligent fertility computer.

23
Congratulations on choosing Lady-Comp, your
own personal family planning computer. With more
than 25 years of experience in women’s fertility
monitoring, you can rest assured that Lady-Comp
and Lady-Comp baby offer you complete confi-
dence in your family planning goals.
Please read these instructions carefully and follow
the easy steps. You will find everything that you
need to know about your device in the table of
contents or in the alphabetical index.
We wish you a successful start to your confident
life ahead.
Lady-Comp
Included
– Fertility computer
– Temperature Sensor
– 2 AAA rechargeable batteries
– Case
– Instructions
– USB cable
– Battery charger (optional)
Display
Control button
Sensor housing
with cable
1. Lady-Comp at a glance
Temperature sensor
Temperature sensor holder

45
Contents
1. Lady-Comp at a glance
Included 03
2. Getting started
Open device 06
Insert batteries 06
Close device 06
Home screen display 07
Control key 07
Sample values 07
Main menus 08
3. Time/date
Set the time 09
Set the date 10
4. Alarm
Alarm on / off 11
Set the alarm time 11
5. Menstruation
Activate “M” / Edit “M” 12
Past menstruation data 12
Enter “M” retrospectively 12
6. Take your temperature
Measuring every morning 13
Temperature reading time period 14
Fertility Indicators 16
Past and future fertility display/prediction 16
Fever display 17
When not to take your temperature 17
Cancel temperature measurement 17
7. Fertility calendar
Fertility calendar 18
8. Pregnancy planning
Lady-Comp baby display 19
Enter sexual intercourse 19
Gender prediction 20
Pregnancy display 21
Conception date & birth date 21
Restart after pregnancy 21
9. Fertility & planning statistics
Fertility statistics 22
Planning statistics (only Lady-Comp baby) 23
Temperature curve 24
Personal notes 26
10. Settings
Body Mass Index 27
Device settings 29
Temperature / time units 30
Personal note entry 30
Gender prediction on /off 31
Deleting data 32
Temperature self-test 33
Device information 33
Brightness 34
Volume 34
Alarm tone 35
Key tone on /off 35
11. Important notes
Analysis of your fertility data – read out 36
Mini USB cable 36
Micro SD card 36
AAA Charger 36
Loss of data 37
After the pill 37
Pearl Index 37
Program 37
Prognosis 37
Travel and time zones 37
Summer and winter time 37
Shift work 37
Restart after interruption in use 37
12. Troubleshooting & error messages
Charge batteries 38
Batteries depleted (112-11) 38
Button battery low (112-12) 38
Button battery depleted (112-13) 38
USB: Improper function (117-1) 38
M input: check (111-10) 39
Memory almost full (111-11) 39
Memory full (111-12) 39
Bootloader error (120-1) 39
Maintenance, care and safety 40
Service and support 42
Notes on electromagnetic compatibility 43
Index 48
Contact 52

67
2. Getting started
Insert batteries
Batteries must be inserted before operating the device. 2 AAA rechargeable batteries are included.
Commercial AAA batteries (1.5 V) can also be used. The included 2 batteries (type AAA) must be
recharged for 12 hours before inserting. The serial number of the device is inside the battery box.
1. Remove the temperature sensor
2. Open the device
Open the device by unscrewing the top cover
in a counterclockwise direction.
3. Insert the batteries
Insert the appropriate batteries.
4. Close the device
Align the two notches with each other and
screw the top in a clockwise direction.
Select menu by using the control
keys, left, right, up, down
forward/back
left/right
yes/no
date/time forward/back
up/down
Confirm menu selection
Confirm entry
Hold down for 3 seconds
= Return to home screen
“Return” activated (blue square
highlighted) + “ok” key (confirms entry)
= return to the previous menu level
+
Operating the control key
Home screen display
The time, date, and year is already factory set, when you receive the fertility computer.
Control button / On switch
Press the control key until the time/date appears in the display. All menus can be reached by tapping
up/ down or right/ left on the control key. Press on the center of the control key to select
the corresponding menus and to confirm selection.
Back to home screen
Press and hold the middle key for 3 seconds to return to the time/date display.
Automatic switch-off
If no key is pressed for 60 seconds, the device will switch off automatically. The display will remain
off until it is activated again or the alarm goes off.
Sample values
Lady-Comp comes with pre-set example values. These are automatically deleted once you have taken
your first temperature or entered menstruation data. The sample values will appear again if you delete
all your data.

89
Lady-Comp baby
Lady-Comp
Lady-Comp basic
Set the time
3. Time/Date
“Return” illuminated
Go to minutes
Press key Press key
“Return”
Set hour Set minutes
Main menus for the Lady-Comp models and their symbols
The different menu levels of the Lady-Comp models.
Time / Date Alarm
Pregnancy planning
Settings
Temperature
Menstruation
Return Fertility & planning
statistics
Fertility
calendar

10 11
4. Alarm
Prior to the first temperature measurement,
set the alarm time and activate the alarm.
Alarm on/off
“Return” illuminated
Press key
“Confirm”
Press key Press key
“Return”
Alarm on
Alarm off
Set the alarm time
“Return” illuminated
Go to minutes
Press key Press key
“Return”
Set hour Set minutes
Good to know:
If the alarm is on, it is shown on the
home screen.
Set the date
“Return” illuminated
Press key Press key Press key
“Return”
Set day
Important:
If the device has already saved one or
more temperature measurements, it is only
possible to reverse the date setting by one
day. If the date is reversed, no temperature
measurement can be made the following day.
You can always advance the date by one day.
The date cannot be changed accidentally.
The date may also be adjusted when traveling
in different time zones. Do not take your
temperature on the day of travel.

12 13
5. Menstruation
“Return” illuminated
Select date Press key
“Return”
“M” Yes
“M” No
Activate “M” or edit “M”
Past menstruation data
If you have records of past menstruations,
you can enter this data into the device prior
to the first temperature measurement.
Activate “M” as described above.
Enter “M” retrospectively
If you have not taken a temperature for an
extended time and had your period during
that time, you can enter it retrospectively.
Please input carefully, as incorrect entries
Important:
Only the first “M” day has to be activated
for each cycle when entering “M” data
retrospectively. The device automatically
stores three “M” days. Start with the input
of the furthest menstruation back in time.
Important:
“M” entry after stopping hormonal contra-
ception: The first bleeding after stopping
hormonal contraception is not a men-
struation but a hormone – conditioned
withdrawal bleeding. Do not enter “M” for
this bleeding.
can be corrected only for the previous 3 days.
Start with the first day of menstruation.
Taking your basal body temperature reliably every
morning is one of the key elements of our system.
The basal body temperature is the temperature im-
mediately after waking up, before getting up, before
becoming active in any way. The more regularly you
take your temperature, particularly at the beginning,
the faster the device gets to know your personal cycle.
Place the temperature sensor under your tongue right
at the back, either to the left or the right, and close
your mouth. While taking your temperature, the tem-
perature sensor should not be moved.
6. Take your Temperature
Press key to turn
the alarm off
Temperature
symbol blinks
Signal tone signifies the
end of the temperature
measurement
Automatically turns off,
or “Return” is illuminated
Temperature symbol illuminated
Alarm goes off
Press key to
start temperature
measurement
Press key
“Return”
Put sensor under
the tongue
Temperature value and
fertility are displayed
Measuring every morning
Temperature unit
Date
Temperature
reading value
Intercourse
“M” Menstruation
Fertility indicators
Temperature
symbol
Cycle day
Personal note *
* Only for Lady-Comp, Lady-Comp baby
Boy/girl display

14 15
Tips for taking your temperature
Lady-Comp wakes you up with the alarm. Press the key to turn the
alarm off. To take your temperature, press the key again. The “thermom-
eter” symbol is blinking; Lady-Comp is ready to take your temperature.
– Now place the sensor under your tongue and close your mouth.
– It will take about 60 seconds to take your temperature. If no temperature
can be taken after 3 minutes the process is automatically terminated.
– The display will show temperature reading values between 34.5 to
41.0 degrees Celsius or 94.20 to 105.00 degrees Fahrenheit.
– If your temperature value is above 37.8 �C or 99.9 �F, the tempera-If your temperature value is above 37.8 �C or 99.9 �F, the tempera-
ture display alternates with the letter “F” for fever.
– When finishing the temperature reading, you hear a signal tone and
the ascertained temperature reading value appears on the display.
Your fertility is displayed for that day.
Good to know:
Temperature reading time period
The temperature reading time limit is the time during which you
can perform the daily temperature measurement. Lady-Comp moni-
tors the daily temperature measuring time period. The temperature
measuring time period is generally independent of the alarm and is
calculated from the time you took your temperature previously (+/- 3
hours). The temperature measuring time period comprises 6 hours
and begins and ends three hours before and after the last tempera-
ture measuring time if this is different from the alarm time.
Tips for temperature reading time period:
– You can identify the reading time period from the illuminated thermometer symbol on the home screen.
– During the temperature reading time period, pressing any key will start a temperature reading.
– We recommend that you allow Lady-Comp to wake you up.
– If you wake up during the temperature reading time period, i.e. to look after your child, take your
temperature.
– If you wake up after the temperature reading time period then don’t take your temperature.
– You may reset the temperature reading time period at any point by changing the alarm time (i.e. on
weekends or for shift work).
If your temperature is not taken over a three-day period, then the temperature reading time period is cleared, and the temperature can be
taken the next day only by activating the alarm. The temperature measuring time period will then be set by the alarm time (+/- 3 hours).
Important:
Please confirm “M” on at least three consecutive days.
If you have “M” without being asked by the device,
activate “M” as described. If you have accidentally
entered “M”, you may return to “M” to edit it for the
past three days.
“Return” illuminated
If “M” is expected,
“M” will blink “Return” illuminated
“M” Display No “M” Display Yes
“M” Yes
“M” No
After taking your temperature, it is possible that the “M” for menstruation
will blink.
– To confirm “M” press the key up for Yes.
– To not confirm “M” press the key down for No.
Once Lady-Comp knows your cycle, the device will ask you about “M” on
the days that menstruation is expected.
– It begins to ask (“M” blinking) two days before menstruation is expected.
– When “M” is done, Lady-Comp will stop asking for “M”.
Activate “M” after temperature measurement

16 17
Fertility indicators
You can view all previous temperatures by repeatedly pressing the key
to the “left” on the temperature display. You can also view a six-day
forecast by repeatedly pressing the “right” key.
Past and future fertility display / prediction
“Return” illuminated
Go back Go forward
= Prediction
Press key
“Return”
When not to take your temperature
Lady-Comp uses its knowledge of your cycle and
available temperature values to calculate the future
cycle course and resulting from this, the fertility.
Increases in temperature due to flu, lack of sleep,
excess alcohol consumption and/or medication
with thermal effect are “abnormal” and will be rec-
ognized by the device as such. In general, it is rec-
ommended to cancel the daily temperature mea-
surement in case of a fever, when taking medication,
or after a night of partying, so as not to enter too
many “abnormal” temperatures into the device.
Fever display
If your temperature value is above 37.8 �C or 99.9 �F, the temperature display alternates with
the letter “F” for fever. Fever is recorded, however, the fever temperature value is not included
in the fertility calculation.
“Fever” display alternating
with temperature value “Return” illuminated
Thermometer
symbol blinks
Temperature symbol
and alarm illuminated
Place temperature
sensor under
your tongue
Pressing the key
switches alarm off
+ starts measurement
Press key for 3 sec.
after beginning to
stop measurement
Press key
“Return”
Cancel temperature measurement
By pressing the “OK” button for 3 seconds the temperature taking will be canceled and
you return to the home screen. You can retake your temperature anytime within the tem-
perature mesuring time period.
The device displays your temperature and your fertility for the day; this
data is valid for 24 hours, and accurate from the very first day. The number
of “green” days increases cautiously and systematically, while the “red”
days are narrowed down. The Pearl Index is calculated as 0.7 (99.3%)
from the first day on. If the device has not received any input for a longer
period of time, or receives information that it cannot evaluate, the
number of “yellow” days increases.
“Green” illuminated
= infertile
“Red” illuminated
= fertile
“Red” blinking =
ovulation day
“Yellow” illuminated
= learning phase
“Red” “Yellow”
“Green” blinking =
probable pregnancy
“Red” “Yellow”
“Green” illuminated =
pregnancy confirmed
Important:
Lady-Comp is not suitable to measure
the body temperature within the
meaning of self-monitoring of health
status as a fever thermometer is.

18 19
7. Fertility calendar
The calendar displays your past and future fertility pattern. You can view your menstruation forecast
for the next 6 months.
“Return” illuminated
Browse month Press key
“Return”
8. Pregnancy planning
Since the introduction of Baby-Comp in 1986, we have assisted countless
couples in planning a child. Lady-Comp baby shows you the best time to
get pregnant.
“Return” illuminated
Select date YesPress key
If you are planning a pregnancy, tell Lady-Comp
baby when sexual intercourse “SI” took place.
– Enter “SI” the following morning after you
take your temperature.
– It is possible to enter “SI” retrospectively
for up to three previous days.
“SI” enter sexual intercourse
Press key
“Return”

20 21
Gender prediction
“Return” illuminated
Browse by date Browse by date
Press key
If you wish to conceive a boy, only have intercourse on the two days when only the “boy” symbol is
shown. If you wish to conceive a girl, only have intercourse on the two days when only the “girl” symbol
is shown. The first “boy” symbol lights up two days before the optimum conception day. The “girl”
symbol lights up one day after the optimum conception day. During the optimum conception day, both
“boy” and “girl” are illuminated. This is a calculated prognosis.
Press key
“Return”
Pregnancy display
– As early as 4 to 5 days after fertilization, “red - yellow - green” blink
alternately (only if a “SI” entry was made). This early display is
especially valuable to allow you to change your lifestyle so you become
healthy in time.
– After the 15th day Lady-Comp baby will display “probable pregnancy”.
The fertility symbol will blink “Red – yellow – green”.
– After the 18th day post fertilization, Lady-Comp baby confirms
pregnancy. All three colors will be illuminated.
Good to know:
“Red”, “Yellow”,
“Green” blink alternately
= possible pregnancy
“Red”, “Yellow”,
“Green” blink =
probable pregnancy
“Red”, “Yellow”,
“Green” illuminated
constantly = pregnant
This menu shows you the possible conception
date and possible date of birth of your planned
baby. First it will be a prediction and will blink
from your 4th cycle day on. This prediction is
derived from the expected ovulation day within
your cycle. After ovulation is confirmed the blink-
ing stops and the display stays illuminated. When
inputting “SI”, a gender prediction will appear.
Restart after pregnancy
In the first weeks after birth you will not be fertile.
We recommend resuming your temperature
measurement six weeks after birth. At first
Lady-Comp baby shows “yellow”. Slight fluc-
tuations in temperature indicate that the normal
cycle is re-establishing itself. Lady-Comp baby
will then begin to show the calculated fertility.
Conception date and birth date
“Return” illuminated
Press key Press key
“Return”
Important:
In order to get the prognosis, you
must activate gender prediction in
the “settings” menu on page 31.

22 23
With the fertility and planning statistics you have the opportunity to
retrieve important information about planning a child successfully. After
three cycles the computer has enough information to assist with your
family planning goals.
9. Fertility and planning statistics
Fertility statistics
Only for Lady-Comp and Lady-Comp baby
4. Length of luteal phase 1. Cycle length 2. Temperature increase 3. Ovulation range
Press key Browse statistics Browse statistics Browse statistics Browse statistics
**
6. CLI*
5. Monophase 7. Planning hits*
“Return” illuminated
Press key
“Return”
1. Average cycle length
The average length of your menstrual
cycle is shown.
2. Average temperature rise
after ovulation
The average temperature rise after
ovulation is shown.
3. Ovulation range in days
The ovulation fluctuation in days
is shown.
4. Length of luteal phase
The average length of luteal phase
is shown.
5. Number of monophase cycles
The number of monophasic cycles are shown.
If no ovulation takes place during a cycle
it will be displayed. During that cycle the
fertility indicator will remain “red”.
6. Number of cycles with CLI (CLI =
Corpus Luteum Insufficiency)*
A corpus luteum insufficiency (CLI) will be
detected by Lady-Comp baby. This is
detected by realizing that the length of the
high level after ovulation is too short or the
temperature increase is low. This information
is important for planning a child.
7. Planning hits *
Lady-Comp baby displays planning hits.
This is the number of times sexual inter-
course has corresponded with ovulation.
The number of hits over the last 20 cycles
is only shown when you activate “SI” Sexual
Intercourse.
*Only for Lady-Comp baby
Browse statistics Browse statistics

24 25
Display: 50 days
Forward/back
+/- 7 days
Press key
Display: 100 days
Temperature curve
Only for Lady-Comp and Lady-Comp baby
You can view your temperature curve here.
Display range of:
25 days / 14 days / 7 days
Time span:
zoom in/out
Show more
show less Show more Show less
1x = 25 days
Moon phase
Ovulation day
Temperature pattern
Fertility
Last day
Menstruation
Sexual intercourse
First day

26 27
This menu gives you the option of making up to 5 notes. You can enter the texts
yourself under “settings” (page 31) and change them if necessary. These inputs
have no effect on the evaluation of the cycles by the device. You can enter per-
sonal notes retrospectively for up to 3 days.
“Return” illuminated
Select input
Press key
Select datePress key Press key
Press key
“Return”
Personal notes
Yes
10. Settings
Body Mass Index (BMI) settings
Body Mass Index: Birth date, height, and weight.
Lady-Comp calculates your Body Mass Index.
BMI – enter name
“Return” illuminated
Press key Press key
Enter text Press key to
confirm each letter
Left arrow deletes
one letter

28 29
BMI – enter birth year
Default = 1980
Confirm year
Press key
Select year of birth Enter year
BMI – enter height
Select weight Select “Return”
Press key
Press key Enter weight
Default = 60 BMI calculated
Select height Enter height
Press key Confirm height
Default = 170 Home screen
Fahrenheit
12 hour am/pm | month/day
Home screen
Celsius
24 hour | day/month
Good to know:
Device settings
BMI – enter weight

30 31
Here, you can set your device to Celsius or
Fahrenheit. This will automatically change
the time and date format as follows:
�C: Time in 24-hour format and date with
day / month (i.e. 13:25 and 25.03.).
�F: Time in 12-hour format and date with
month / day (i.e. 01:35 pm and 03/25).
Temperature / time units
Press key Select input field
“Return” illuminated
Enter text Confirm each letter Press key
“Return”
Personal text entry
Press key Select “Return”
Press key
Celsius Fahrenheit
°F = Fahrenheit
°C = Celsius “Return” illuminated
Gender prediction on/off
You have the option of viewing the boy/girl prognosis with the fertility display. If you want
this display to appear, turn it on here.
Press key Display on
Display off
“Return” illuminated
Confirm Press key
“Return”
Here you can enter all particulars that might affect your cycle. For
example, if you take medication which you suspect may affect your
cycle, enter this medication here. This menu allows you to enter up
to 5 markings. To avoid changes in the order of the entries, we rec-
ommend that you do not change the text after it has been saved.
The notes may be entered retrospectively for up to 3 days. The en-
tries may be activated under personal notes (page 26).

32 33
Device information includes:
– The device serial number
(13547206)
– The software version
designated by the last
two numbers (-31)
– The battery display
– Brightness displayed
as a percent
If the device has an error
or a warning, this will be
displayed. For a list of
possible errors see page 38.
To delete all your personal data and measurements press the “OK”
button in the delete menu 10x in a row. The indicator bar will decrease
step by step. If you press another key (left, right, up, down), the indicator
bar will revert back to the starting position and you have to press the
“OK” button 10x again in order to do the deletion process. After
deletion, the individual displays will only show the sample values like
a new device. After the first new temperature measurement, the sample
data will be automatically deleted.
Cancel
“Return”
Confirm by pressing
“OK” 10 times to
completely delete data.
“Return” illuminated
Press key
“Return”
Deleting data
“Return” illuminated
Signal tone indicates
end of measurement
The thermometer starts
to blink automatically
Press key
“Return”
Please measure
Temperature self test Device information
“Return” illuminated
Press key
“Return”
The temperature self test can be conducted to see if the temperature
sensor is working properly. The self test can be canceled by pressing
and holding the “OK” key for 3 seconds.
Good to know:

34 35
Brightness*
You can adjust the brightness of the displays.
“Return” illuminated
Press key
“Return”
Move the
brightness control
Volume*
You can adjust the volume of the Lady-Comp.
“Return” illuminated
Press key
“Return”
Move the
volume control Press key Choose tone
“Return” illuminated
Press key
“Return”
Alarm tone and key tone
Alarm tone*
You can choose an alarm tone.
Key tone on/off*
You can turn the key tone on and off.
Press key Key tone on Key tone off
“Return” illuminated
Press key
“Return”
Confirm
*Only for Lady-Comp; Lady-Comp baby

36 37
Mini USB cable
A mini USB cable is included with your Lady-
Comp. Use the mini USB cable to upload your
data to your computer. You, as well as your dis-
tributor or Valley Electronics GmbH, can analyze
and evaluate your cycle data. This can be done
through our web portal or via email.
Upgrades: Micro SD card
If you wish to get a software update and /or an
upgrade for more functions at a later date, we will
send you an SD card.
– Open the unit as described on page 6
– Remove batteries
– Insert the SD card
– After successful completion of updates/
upgrades, we recommend that you remove the
SD card again to avoid unnecessary power
consumption.
AAA Charger
The corresponding battery charger can be ordered
from us. Insert 2 AAA batteries into the charger.
The charging status is displayed on the charger.
Insert SD card
11. Important notes:
Notch to close the device
Mini USB connector
Serial port (for
servicing only)
SD card slot
Temperature sensor
connection port
Battery compartment
and serial number
Loss of data
There is no risk of losing your data, even if the
batteries are depleted.
After the pill
(or hormonal contraception)
Prior to starting Lady-Comp, you must stop taking
any form of hormonal contraception. The first
bleeding after stopping hormonal contraception
is not a menstruation, but a hormone-conditioned
withdrawal bleeding. Do not enter “M” for this
bleeding.
Pearl-Index
The Pearl Index is the value by which the safety
of a contraceptive method is specified in medi-
cine. The daily fertility displays of Lady-Comp
have a Pearl Index of 0.7 or to explain it more
easy of 99.3%.
Example:
If 100 women use contraception for one year and
one of them becomes pregnant, this corresponds
to a Pearl Index of 1.0.
Program
The program is based on all natural family planning
research data. It contains a database of more then
1 million cycles and uses biomathematical forecast-
ing calculations as well as the very latest computer
techniques. The more regularly you measure, the
faster the device gets to know and interpret your
individual cycle. It will show more and more green
days (infertile) and the red days will decrease
(fertile days) as the device learns your individual
rhythm. Depending on your individual cycle pattern
you will have between 7 and 12 red days per cycle.
Prognosis
Our displays in relation to ovulation and planning
are calculated prognoses. Once a menstrual cycle
is completed and a new one begins with menstru-
ation, Lady-Comp will confirm day of ovulation
retrospectively. The confirmed ovulation day will
be recognized after the 4th cycle day of your next
menstrual cycle.
Travel and time zones
When travelling in different time zones you have
the ability to change the date and time to the
local time. Set and activate the alarm to the desired
new reading time. Lady-Comp will be ready to
take your measurement the next morning. Repeat
the procedure when you return home.
Summer and winter time
Set the time forward or backward in summer or
in winter, as described on page 9.
Shift work
Set and activate the alarm to the desired new
reading time. Let the alarm tone wake you up the
next morning and take your measurement as
usual. Proceed likewise at the next shift change.
Restart after interruption in use
The time, date, and year continues to work auto-
matically. The measurement period is disabled
when you don’t take your temperature and needs
to be reset by activating the alarm clock. You do
this by setting the alarm for the next morning
(before midnight) continue as usual.
Analysis of your fertility data – read out:
Log on to the website: www.lady-comp.de Register and create your account and then follow
the online instructions to upload your data via the mini USB cable.
If you have any questions about your cycle please don't hesitate to contact us.
Please send us an email: [email protected] or call us.

38 39
12. Trouble-shooting and error messages
Charge batteries
If the batteries are low, a warning is displayed
on the home screen.
Batteries depleted (112-11)
When the batteries are completely depleted,
reliable function of the device is no longer guar-
anteed. Upon this message, no further operation
is possible.
Actions:
– Recharge/change batteries
– If the message appears again, even though newly
Button battery low (112-12)
The device contains a button battery which ensures
that the clock continues to run even when the bat-
teries are depleted or not inserted. The capacity is
designed so that with normal use this battery lasts
about 7 years. When the voltage of the button bat-
tery gradually becomes too low, it displays this
warning, but further use is still possible.
Actions:
– The unit should be sent for service in the near
future, so that the button battery can be replaced.
– This message can also be shown when the
device has been exposed to extremely low tem-
peratures, and therefore the voltage is greatly
reduced. In this case, the device should be
Batteries low. Please recharge the
rechargeable batteries or replace
the batteries.
recharged batteries or new batteries are inserted,
the batteries are possibly defective and/or the
batteries are depleted and should be replaced.
The batteries can be easily removed and replaced.
Please note the polarity (see page 6).
maintained at room temperature for about one
hour. When the message switches off, the device
can be used normally.
Button battery depleted (112-13)
When the button battery is depleted, no use
is possible.
USB: improper function (117-1)
The device is connected via USB, but no com-
munications can be established.
Action:
If you do not need any data transfer via USB, you
can simply unplug the USB cable. If the device
does not automatically restart, please remove the
batteries and reinsert them. If you want to make
a data transfer via USB, check the function of the
connecting cable. USB communication is only
possible with those devices that allow connec-
tion to a USB mass storage device with FAT data
file system. This applies for example to PCs run-
ning Windows or Linux, and many other devices.
Memory almost full (111-11)
Action:
The existing data should be backed up via USB
connection or by saving to an SD card. The data
can then be deleted from the device and the
compressed data can be re-entered.
Memory full (111-12)
The memory of the device is sufficient for 20
years of records. If this period is exceeded, this
error message will appear.
Action:
The existing data should be backed up via USB
connection. The data can then be deleted from
the device and the compressed data can be re-
entered. Further details can be found on our
website or by calling support.
Error message/bootloader error
(120-1)
If a software update is canceled and the program
has not been fully resaved (i.e. dead battery) this
error message will appear. The number after the
dash will indicate the exact cause of the error.
Error message:
120-2 to 120-7 inclusive, please contact tech-
nical support.
Action:
The bootloader is able to reprogram the device
even without a utilization program. To do this,
insert the micro SD update card and the batteries
into the device. The bootloader will first erase
the program memory and then reinstall the
update. You can follow the progress on the indi-
cator bar. Make sure that you use fully charged
batteries for the update, so that the process can
be completed.
M input: check (111-10)
If the device has not taken any temperature
measurements or M input for a long period of
time (4 days) and a new cycle start is expected
during this time, it will remind the user to enter
any possibly forgotten data retroactively.
Action:
– Activate M retroactively.
