Valor 1100MN User manual

WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious
injury, death, or property damage.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
▪Do not try to light any appliance.
▪Do not touch any electrical switch; do
not use any phone in your building.
▪Leave the building immediately.
▪Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
▪If you cannot reach your gas supplier,
call the fire department.
Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
Hot glass
will cause burns.
Do not touch glass
until cooled.
Never allow children
to touch glass.
A barrier designed to reduce
the risk of burns from the hot
viewing glass is provided with this
appliance and must be installed for
the protection of children and
other at-risk individuals.
DANGER
4008356-04
Homeowner’s Manual
Direct Vent Gas Fireplaces
natural gas 1100MN
propane gas 1100MP
H5

2
The information contained in this manual is believed
to be correct at the time of printing. Miles Industries
Ltd. reserves the right to change or modify any
information or specifications without notice. Miles
Industries Ltd. grants no warranty, implied or stated,
for the installation or maintenance of your heater,
and assumes no responsibility for any consequential
damage(s).
© Copyright Miles Industries Ltd., 2022. All rights reserved.
Designed and manufactured for Miles Industries Ltd.
Valor Fireplaces
190–2255 Dollarton Highway
North Vancouver, BC, Canada V7H 3B1
T 604.984.3496 F 604.984.0246
valorfireplaces.com
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where
not prohibited by local codes. This
appliance is only for use with the type
of gas indicated on the rating plate.
This appliance is not convertible for
use with other gases, unless a certified
kit is used.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for
future reference.
Massachusetts:
The piping and final gas connection must be
performed by a licensed plumber or gas fitter
in the State of Massachusetts. Also, see Carbon
Monoxide Detector requirements in the fireplace
installation manual.
WARNING
This product can expose you to chemicals including Benzene,
which is known to the State of California to cause cancer and
birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
Note: Natural gas, in its original state, contains Benzene.

3
Homeowner: Please read this manual before
operating this appliance, and save for future
reference.
Thank you for purchasing a Valor Fireplace.We
appreciate your business and wish you many happy
years enjoying your new fireplace.
Your new radiant gas heater is a technical appliance
that must be installed by a qualified dealer. Each
Valor®fireplace is fully tested during the production
process for your safety and comfort.
Your unit has been professionally installed by:
Dealer Name: ___________________________________
Phone: _________________________________________
If you experience any problems, call your dealer
immediately. To avoid injury or damage to your
fireplace, do not try to repair the unit yourself.
Your Valor Fireplace
Here are some important details about your Valor
fireplace, should you need to contact your dealer.
Model: _________________________________________
Serial: __________________________________________
Options: ________________________________________
________________________________________________
________________________________________________
Please ask your installer for these details if they are
not already provided, or see page 7.
Welcome to Valor®
Contents
Safety and your fireplace ..........................................4
Child safety and your fireplace................................. 6
Getting started............................................................7
First time operation...................................................... 7
Locating fireplace and lighting information ............. 7
Parts of your fireplace................................................ 8
Operating your fireplace ...........................................9
Fireplace control devices............................................. 9
Preventing inadvertent ignition ...............................10
Replacing batteries................................................... 11
Annual service and maintenance........................... 12
Cleaning your fireplace ............................................13
Checking pilot and burner flames.......................... 17
Frequently asked questions....................................19
Valor®Warranty ........................................................21
Valor®Outdoor Installation Warranty...................22
Appendix A-Remote Control Operation................23
Important—Register your warranty
Registration of your Valor is highly
recommended, and can be completed by
scanning the QR code on the serial number
label placed on the fireplace's installation
manual cover by the installer or by visiting
valorfireplaces.com/warranty.
Completing your registration enables us to
properly address any warranty or service-
related concerns that you may have. This
information is strictly for customer service and
warranty purposes, and will never be shared
with any third party.

4
This manual contains very important information about the safe operation and maintenance of your fireplace.
Read and understand all instructions carefully before operating your fireplace. Failure to follow these
instructions may result in possible fire hazard and will void the warranty.
Replacement manuals are available by contacting Valor Customer Service at 1-800-468-2567, or by visiting
valorfireplaces.com.
Safety and your fireplace
Do not put
furniture or other objects
in this space in front of
WKHȴUHSODFH
36” [0.9 m]
)LUHSODFH
Hearth
Do not put
furniture or other objects
in this space in front of
the replace:
36” (0.9 m)
Fireplace
Hearth
WARNING: Extremely Hot!
Heat and flammability
• Some parts of your fireplace are extremely hot, par-
ticularly the glass window. Use the provided barrier
screen and a gate to reduce the risk of severe burns.
• The glass windows can exceed temperatures of
500°F at full capacity.
• Always keep the appliance clear and free from com-
bustible materials, gasoline, and other flammable
vapors and liquids.
• Be aware of hot wall surfaces. The wall directly above
the fireplace can get very hot when the fireplace
heats. Although safe, it may reach temperatures in
excess of 200ºF depending on choice of trims or
optional accessories. Do not touch!
• Be aware of hot surfaces in front of the fireplace
windows. A shelf directly in front of the fireplace can
get very hot when the fireplace heats. Although safe,
they may reach temperatures in excess of 200ºF
depending on elevation of the shelf. Do not place
anything on it.
• Some materials or items, although safe, may dis-
color, shrink, warp, crack, or peel due to the heat
produced by the fireplace. Avoid placing candles,
paintings, photos and other combustible objects
sensitive to heat or furniture within 36 inches (0.9m)
around the fireplace.
• Solid wood flooring in front of the fireplace (if al-
lowed) may shrink during the heating season due
to heat.
• Due to its high temperature, the appliance should be
located away from high-traffic areas, furniture, and
draperies.
• Clothing or flammable material should not be placed
on or near the appliance.
Barrier screen and safety
• A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
• Children and adults should be alerted to the hazards
of high surface temperature and should stay away to
avoid burns or clothing ignition.
• Young children should be carefully supervised when
they are in the same room as the appliance. Tod-
dlers, young children, and others may be suscep-
tible to accidental contact burns. A physical barrier
is recommended if there are at-risk individuals in
the house. To restrict access to a fireplace or stove,
install an adjustable safety gate to keep toddlers,
young children, and other at-risk individuals out of
the room and away from hot surfaces.
• Any safety screen, guard, or barrier removed for ser-
vicing an appliance must be replaced prior to operat-
ing the appliance.

5
Safety and your fireplace
Front outlet
WARNING
Optional HeatShift
System:
Do not cover or
place items in
front of outlet!
Top outlet
Sides outlets
Glass window
• The glass window fronts must be in place and sealed
before the unit can be placed into safe operation.
• The glass fronts must only be replaced as complete
units, as supplied by the fireplace manufacturer. No
substitute material may be used.
• Do not use abrasive cleaners on the glass front as-
sembly. Do not attempt to clean the glass front when
it is hot.
Venting
• This unit must be used with a vent system as de-
scribed in the installation manual. No other vent
system or components may be used.
• Never obstruct the flow of combustion and venti-
lation air. Keep the front of the appliance clear of
all obstructions for optimal operation and ease of
servicing.
• This unit must be vented directly outside and must
never be attached to a chimney serving a separate
solid fuel burning appliance. Each gas appliance
must use a separate vent system. Common vent
systems are prohibited.
Intended use
• This appliance is designed and approved as a supple-
mental heater to be used while attended. The use of
an alternate primary heat source is advisable.
• This unit is not for use with solid fuel.
• Do not use this heater as a temporary source of heat
during construction.
WARNING
Do not operate this appliance with the
glass front removed, cracked, or broken.
Do not strike or slam the glass front.
Replacement of the glass front should
be performed by a licensed or qualified
service person.
Initial and annual inspection
• Installation and repair should be performed by
a qualified service person. The appliance should
be inspected before use and at least annually by a
professional service person. More frequent clean-
ing might be required due to excessive lint from
carpeting, bedding material, etc. It is imperative that
control compartments, burners, and circultaing air
passageways of the appliance be kept clean.
• Do not use this appliance if any part has been under
water. Immediately call a qualified service technician
to inspect the appliance and to replace any part of
the control system and any gas control that has been
under water.
Maintenance
• Keep the unit’s control compartment, burner, and
circulating air passageways clean to enable adequate
combustion and ventilation air.
• Inspect the external vent cap on a regular basis to
ensure that no debris, plants, trees, or shrubs are
interfering with air flow.

6
A heating gas appliance does require safe handling. For this reason, we very strongly recommend children not be
allowed to touch the fireplace or its controls.
Read and carefully follow all safety warnings and operating instructions contained in this manual, and follow
these important child safety precautions and recommendations:
• Parts of your Valor Fireplace become extremely
hot while in operation. The glass window tempera-
ture can exceed 500º F at full capacity.
• Do not let children touch the glass or any parts
of your fireplace even after it is turned off, as the
surfaces will remain hot for some time.
• Even momentary contact with a hot glass surface
can cause a severe burn, including when the fire-
place is operating at reduced heating capacity.
• The glass window will remain hot for an extended
period of time after the fireplace has been turned
off. Make sure that children do not touch the fire-
place during the cool down period.
• Children and adults should be alerted to the haz-
ards of high surface temperature and should stay
away to avoid burns or clothing ignition.
• Young children should be carefully supervised
when they are in the same room as the appliance.
Toddlers, young children, and others may be sus-
ceptible to accidental contact burns.
A physical barrier is recommended if there are
at-risk individuals in the house. To restrict access
to a fireplace or stove, install an adjustable safety
gate to keep toddlers, young children, and other
at-risk individuals out of the room and away from
hot surfaces.
• Keep the remote control handset out of reach of
children at all times. A child safety lockout feature
is included with your remote control, see Operating
your fireplace on pages 9-10 for details.
• Make sure that the fireplace, including the pilot
light, is completely turned offwhen children are
present and close supervision is not available—see
pages 9 for details.
• If the fireplace is not going to be used for an ex-
tended period of time, remove the batteries from
the remote control handset and battery holder un-
der the firebox. It is recommended that batteries
are replaced annually —see page 11 for details.
Child safety and your fireplace
Hot glass
will cause burns.
Do not touch glass
until cooled.
Never allow children
to touch glass.
A barrier designed to reduce
the risk of burns from the hot
viewing glass is provided with this
appliance and must be installed for
the protection of children and
other at-risk individuals.
DANGER

7
Getting started
WARNING
Do not attempt to access the card while
the fireplace is hot! Let the fireplace cool
first before touching it!
First time operation
When operating your new fireplace for the first time,
some vapors may be released due to the burning of
curing compounds used during manufacturing. They
may cause a slight odor and could cause the flames
to be the full height of the firebox, or even slightly
higher, for the first few hours of operation.
It is also possible that these vapors could set offany
smoke detection alarms in the immediate vicinity.
These vapors are quite normal on new fireplaces.
We recommend opening a window to vent the
room. After a few hours of use, the vapors will have
disappeared and the flames will be at their normal
height.
Valor automatic gas shut-off
For your safety, Valor fireplaces are fitted with a
flame supervision device which will shut-offthe gas
supply if, for any reason, the pilot flame goes out.
This device incorporates a fixed probe, which senses
the heat from the pilot flame. If the probe is cool,
the device will prevent any gas flow unless manually
lighting the pilot. See the full Fireplace and Lighting
Information card attached to the fireplace or as
reproduced in Appendix A of the Installation Manual.
Locating fireplace and lighting information
The Fireplace and Lighting Information is located on a
card at the right of the firebox, behind the side door.
To access the card, remove the barrier screen and
right side door. See diagrams at right.
The card contains important information on both
sides of the card. It must be left with the fireplace
when you are done.
Fireplace
model
Serial
number

8
Parts of your fireplace
Here are the major components of your installed fireplace, with the protective barriers installed. Your
individual fireplace may appear differently depending on your installed options.
Barrier Screen Window Frame
Window
Frame
Liner Panels
Side Door—
Fireplace info card
behind right door
Fuel Bed
Burner Plaque
Trim
Window Frame
Window
Latch
Info
Card
Here
Gas ValveReceiver Window Latches Handle
Window
Latch
Window Latch
Window Latch

9
Operating your fireplace
ON:
parallel
to pipe
OFF:
perpendicular
to pipe
Fireplace control devices
There are two ways to control your fireplace.
1. Thermostatic Remote Control turns fire and
lights ON and OFF, controls flame height and can
be programmed to function automatically.
2. Wall Switch turns fire ON and OFF, and controls
flame height.
Turn your fireplace ON
Press and hold:
- button on remote, or
- ON-OFF button on wall switch
until 8 short beeps confirm the start sequence has
begun; release button.
The pilot lights up, followed by the fireplace.
If you are using the handset, it displays a pilot flame
symbol ( ) during the ignition sequence.
If you need to light up the pilot manually, see the
Fireplace and Lighting Information card attached to
the fireplace - see page 7 to learn how to access it.
Also, a copy of this card is reproduced in Appendix A
of the Installation Manual.
Turn your fireplace OFF (including pilot)
Press and hold:
- button on remote, or
- ON-OFF button on wall switch
If the flames or pilot are on, they will go out and you
will hear the valve motor wind down. You will hear
a clunk and a beep indicating that the valve has
received the signal from the remote control.
In the unlikely event that you cannot turn offyour
fireplace with the remote control handset, use the
wall switch. If the wall switch malfunctions and
will not turn offthe fireplace, wait 3 hours and the
fireplace will automatically go to pilot. You can then
access the controls inside your fireplace, once it has
cooled.
Alternatively, you may turn offthe house gas supply.
In all cases, call your dealer for service assistance.
To use additional functions of your Remote
Control such as temperature or program
settings, see Appendix A-Remote Control
Operation on page 27 of this manual or visit
valorfireplaces.com/remotes
WARNING
Risk of severe burns! Surface of the
fireplace are very hot during operation!
Ensure fireplace has cooled offbefore
accessing control.
Remote Control Wall Switch
WARNING
STOP IF YOU SMELL GAS! DO NOT LIGHT!
See cover page immediately!

10
Operating your fireplace
ON
Child proofing your handset
Your remote control can be locked to prevent
operation by children.
To turn child proofing ON:
1. Press and hold the and buttons
simultaneously.
2. is displayed on the handset screen making
the handset inoperable, with the exception of the
OFF function.
To turn child proofing OFF:
1. Press and hold the and buttons
simultaneously.
2. disappears from the handset screen and the
handset is returned to full functionality.
Preventing inadvertent ignition
You can use one of the following two methods
to ensure that your fireplace will not turn on
unexpectedly.
• On gas valve, turn dial from ON position to MAN
position as shown. Turning dial to MAN will ensures
that main burner cannot come on. The pilot will
remain on if lit.
• Alternately, remove all batteries from the battery
holder next to wall switch and the handset.
Automatic shut-off(in certain conditions)
Your fireplace’s remote control is equipped with an
automatic shut-offmechanism which is activated in
certain conditions. See Appendix A-Remote Control
Operation on pages 22-28 or go to valorfireplaces.
com/remotes for a description
of this feature.
Battery
holder
& wall
switch
Fireplace
Receiver Gas valve
Receiver and gas valve located on bottom of fireplace
under removable panel. Battery holder located next to
wall switch.
Gaz valve

11
Replacing batteries
Low batteries signals:
• Handset: battery icon on display shows 1 lit bar
• Holder: frequent beeps for 3 seconds when valve
motor turns.
BEFORE changing the batteries, turn the fireplace off
(including pilot) and let it cool.
The fireplace uses four 1.5 V AA alkaline batteries
in a separate battery holder located next to the
wall switch and two 1.5V AAA alkaline battery in its
handset. Batteries should last one to two seasons,
depending on usage. Removing the batteries in the
off-season will extend the battery life.
To access the battery holder, remove the magnetic
cover on the remote wall switch by pulling on it; the
battery holder is attached to it.
WARNING
Do not attempt to access the batteries
while the fireplace is hot! Let the
fireplace cool first before touching it!
Caution
Do not use a screwdriver or other metallic
object to remove the batteries from the battery
holder or the handset! This could cause a short
circuit.
To replace the batteries:
1. Remove the used batteries from the battery
holder and replace with 4 new AA 1.5V alkaline
batteries.
2. Reinsert the battery holder in the wall switch box
snapping the magnetic cover in place.
Using Handset Wall Holder
Your fireplace equipment includes a wall holder to
store the handset. If it hasn’t been installed, refer to
the instructions in the fireplace Installation Manual.
Caution
Do not put batteries in the receiver as leaking
acid could damage its circuit board.
Remote and wall holder
Battery
holder
& wall
switch
Fireplace
Receiver Gas valve
Receiver and gas valve located on bottom of fireplace
under removable panel. Battery holder located next to
wall switch.

12
We recommend having your fireplace serviced before initial use, and at least once per year by a qualified service
technician. Contact your dealer quoting the model serial number, if possible. It will be helpful if the fireplace’s
serial number can also be quoted. These numbers are on the information card— see page 7.
A list of replacement parts is included in your fireplace Installation Manual. When requesting spare parts please
quote the part number and description to ensure the correct part is ordered.
Annual Inspection
To ensure the optimal performance and safety of your fireplace, contact your dealer to have a qualified
technician review and verify the list below at least once every year.
Safe Operation List: to be performed by a qualified technician only.
Inspect and operate the pressure relief mecha-
nism to verify relief mechanisms are free from
obstruction to operate. See Cleaning your
fireplace on page 13.
Clean glass window with a suitable fireplace
glass cleaner. Abrasive cleaners must not be
used. Be careful not to scratch the glass when
cleaning. See Cleaning your fireplace on page
13.
Inspect the operation of the flame safety sys-
tem Pilot or Flame rectification device.
Inspect and ensure the lighting of the main
burner occurs within 4 seconds of the main
gas valve opening. Visual inspection should
match that outlined in the appliance instruc-
tion manual. Inspect primary air openings for
blockage. See Checking pilot and burner flames
on page 17.
Inspect condition of vent and vent terminal for
sooting or obstruction and correct if present.
Vacuum and clean any excess debris in the
firebox that is not supposed to be there.
Test and measure the flame failure response
time of the flame safety system. It must de-
energize the safety shut-offin less than
30 seconds.
Check all accessible gas-carrying tubes, con-
nections, pipes and other components for
leaks. See Set up Gas Supply section of the
fireplace Installation Manual.
Annual service and maintenance
Caution
Label all wires prior to disconnection when
servicing controls. Wiring errors can cause
improper and dangerous operation.
Verify proper operation after servicing.

13
Cleaning your fireplace
WARNING
Risk of severe burns! Do not touch the
glass while it is hot! Let the fireplace cool
first before cleaning it.
Remove Window
The window is held in place by 4 spring-loaded
latches 2 on each side of the firebox. A pull handle is
required to unhook the latches. The handle is located
at the bottom front of the fireplace under the trim's
removable panel.
1. Remove the barrier screen by pulling on it or un-
hooking it depending of the front trim installed.
2. Remove the side doors, lifting them straight up
using the tabs on the doors, then pulling straight
towards the center of the fireplace.
3. Remove the removable panel pulling it straight
towards you.
4. Locate the window latch pull handle on the bottom
of the fireplace. It is held in place by Velcro. Pull it
out.
5. Locate the four latches around the window frame.
6. Starting with the bottom latches, hook the pull
handle to the latches' vertical tabs and firmly pull
forward and outward to unhook.
7. Repeat with the top latches while holding the top
of the window frame.
8. Carefully lift up the window and pull it outward.
9. Set it aside in a safe place to avoid damage.
10. Reattach the handle to its Velcro at the bottom of
the fireplace so it is easy to find later.
Window latch
pull handle
Removable panel

14
Cleaning your fireplace
Cleaning glass mineral deposits
A by-product of the combustion process in a gas
fireplace is a mineral which can appear as a white film
on the ceramic glass windows of your appliance.
The composition of the deposit varies depending on
location and time, and can appear intermittently.
There is no definitive solution to this issue. Various
cleaning products have been tried with varying
results. The following are recommendations only and
cannot guarantee results.
Note: Mineral deposits occur naturally and are not
covered under the Valor®warranty.
• Clean the glass regularly to avoid a buildup of film
from mineral. If the film is left for a long period of
time, it can etch the glass, making it much harder, if
not impossible, to remove.
• Never use an abrasive cleaner or ammonia-based
cleaner on the ceramic glass. Any abrasion of the
surface can compromise the strength of the glass.
An emulsion-type cleaner is recommended.
• Use a soft damp cloth to apply the cleaner. Dry the
glass with a soft, dry, preferably cotton cloth. Most
paper towels and synthetic materials are abrasive
to ceramic glass and should be avoided. Follow all
instructions on the bottle/container.
• Our dealers have experienced good results from the
products listed below. We cannot, however, guaran-
tee results of these products.
»Brasso, Polish Plus by KelKem, Cook Top Clean
Creme by Elco, White Offby Rutland, Turtle Wax
Do not clean the glass while it is hot
• Always securely replace the windows and the barrier
screen before lighting (see next page).
• If broken, glass panes may only be replaced as a
complete window unit as supplied by the manufac-
turer.
• If the barrier screen becomes damaged, it must only
be replaced with the same model and version barrier
from Valor.
Cleaning other parts
• Clean the steel trims with mild soap and warm water.
Any alcohol/solvent-based cleaner may weaken and
damage the coating.
• Clean the barrier screens by dusting with a soft
brush.
• Clean the firebox ceramic fuel bed and walls by
dusting them with a soft brush or vacuum cleaner.
Dust and soot can also be removed from the burner
and logs using after removing the ceramic logs.
Minor amount of soot developing on logs is common
but soot that builds up, falls offand accumulates
indicates that the burner needs adjustment or the
logs may be installed correctly—see Checking pilot
and burner flames on page 17 or fireplace's
Installation Manual for proper log placement.
When cleaning, make sure that no particles are
brushed into the slots of the burner.
Log position
Log position is important in your Valor fireplace
because it can optimize the beauty of the flame and
the combustion efficiency of your fireplace.
To reinstall the logs after cleaning or other fireplace
maintenance, refer to your fireplace's Installation
Manual for specific instructions on how to place them
for optimal operation. If you are not comfortable
performing this task, please contact your dealer.
Caution
Choking Hazard! Make sure the fireplace area is
clear of firebed small particles to avoid ingestion
by small children. Vacuum thoroughly around
the fireplace area after cleaning.
WARNING
Risk of severe burns! The glass windows
are very hot during operation. Ensure the
fireplace and glass have cooled offbefore
touching them.

15
Cleaning your fireplace
WARNING
The window unit must be correctly
installed, fastened and sealed after
servicing or serious bodily injury and/or
damage to the appliance may result.
To ensure a safe operation:
• Double-check that the top of the window
frame is correctly installed;
• Verify that the spring-loaded latches are
hooked properly to the four window tabs
then;
• Pull out the top of the window and
release it to ensure the springs return it;
repeat with the bottom of the window;
• Ensure the window is sealed by pressing
firmly around it before operation.
WARNING
Failure to install the window correctly
can:
• Leak carbon monoxide.
• Affect the performance of the fireplace.
• Damage components.
• Cause overheating resulting in
dangerous conditions.
Damage caused by incorrect window
installation is not covered by the Valor
Warranty.
Reinstall and Check Window
To reinstall the window, you'll need the window latch
pull handle, located on the bottom of the fireplace.
1. Place the top window frame tabs—shown in red
below—on top of the firebox and push the window
against the firebox, ensuring it’s centered left to
right.
2. The window is secured by four spring-loaded latch-
es which hook to tabs on each side of its frame.
While holding the top of the window to the firebox,
hook the top two latches to the frame’s top tabs.
Repeat with the bottom tabs and latches.
Tabs at top
Window latch
pull handle
Removable panel

16
Cleaning your fireplace
WARNING
For safety purposes, make sure the
barrier screen is re-installed on the
fireplace front after maintenance.
3. Pull and release the top of the window to ensure
the spring-loaded mechanism returns the win-
dow to the firebox. Repeat with the bottom of the
window.
4. Apply firm hand pressure around window frame to
make sure it is sealed tight against firebox.
5. If the Hot Glass Warning plate has been removed
from the front lower corner of the window,
reinstall it by sliding it between the glass and the
frame as indicated.
6. Re-install the removable panel, inserting it in the
clips on each side support.
Hot Glass Warning Plate
7. Re-install the side doors, sliding them in the slots
behind the front panel of the trim and pushing
them down.
8. Re-install the barrier screen, either hooking it,
inserting it or securing it by its magnets depending
of the front trim installed.
LH Door RH Door
nger grip inboard,
with locator on right
nger grip inboard,
with locator on left
Bottom of
locator tabs
have hook

17
Typical flame appearance - H5
The pilot light and burner flames should be checked
periodically. Check after the fire has been on for at
least 30 minutes. The pilot flame must cover the tip
of the thermocouple probe. The main burner flame
pattern will vary depending on the type of installation
and climatic conditions.
Performance of propane gas fireplaces may be
affected by the quality of commercial gas supplied
in your area.
The fireplace area must always be kept clear and
free from combustible materials, gasoline and other
flammable vapors and liquids.
Inspect the vent terminal outdoors regularly to ensure
that it is not obstructed by snow, trees, bushes, leaves,
or other objects. We recommend at least an annual
inspection.
Checking pilot and burner flames
Driftwood Logs
Birch Logs
Traditional Logs
Note
The height and color of your flames can vary
depending on fuel type, fuel quality and mixture,
altitude, and aeration adjustment at or after
installation.
The photos of typical flame appearance are for
illustrative purposes only. Your fireplace may
be operating normally but may appear slightly
different than the photos.
Venting configuration, elevation, burner aeration
setting and local fuel heating value can all affect
flame appearance.
Pilot light
Pilot Flame
Thermocouple Probe
must be in Flame
Pilot light
Pilot light

18
Frequently asked questions
Question Answer
What if my fireplace won't
turn on?
If you have followed all instructions for your remote control or wall switch
(see page 9, pages 22-28 or page 29 of this manual) and your fireplace still
won't turn on, the batteries located inside the wall switch kit may be low
and need replacing. See page 11 for instructions on how to replace the
batteries.
If the fireplace still won't turn on after that, call your dealer for further
information. Your fireplace may require service by a qualified service
technician. Visit valorfireplaces.com/contact for a list of dealers near you.
I've just started my fireplace
for the first time, what is
that smell?
When operating your fireplace for the first time, some vapors may
be released due to the burning of curing compounds used during
manufacturing. They may cause a slight odor and could cause the flames
to be the full height of the firebox, or even slightly higher, for the first few
hours of operation. This is perfectly normal. See First Time Operation on
page 7 for more information.
When I operate the fireplace,
why do I suddenly hear a
faster series of beeps than
usual?
This is an indication that the batteries in your fireplace are getting
critically low (not the batteries in your remote control handset, but the
batteries in the battery holder beside the wall switch). See page 11 for
instructions on how to replace the batteries.
Why do I hear popping or
snapping noises?
As your fireplace heats and cools with normal use, its metal parts will
expand and contract, which may cause some noise. This is perfectly
normal.
Why do I hear whirring
noises?
As you start or adjust your fireplace's flame, the control valve motor turns
to adjust the settings. This is perfectly normal.
How do I clean my fireplace? See Cleaning your fireplace on pages 13-16 for cleaning instructions to
keep your fireplace looking great.
There is condensation on
the inside of the glass, is this
okay?
This is normal when the fireplace first turns on, and will disappear
naturally when the fireplace heats up.
There is a white film on the
inside of the glass, is this
okay?
This happens due to composition of the gas from your supplier. A by-
product of the combustion process in a gas fireplace is a mineral which
can appear as a white film on the ceramic glass window of your appliance.
Clean as soon as possible (when the fireplace is cool) so it does not bake
onto the glass with time and become permanent. See pages 13-16 for
cleaning instructions.
When I start my fireplace,
the flame is blue or
transparent, is this normal?
This is normal, your flame will take on a more yellow/orange appearance
as the fireplace heats up.

19
Frequently asked questions
Question Answer
When I start my fireplace,
the flame is dirty or black, is
this normal?
No. This is possibly caused by a blocked opening in the burner which can
be cleaned by vacuuming it. See pages 13-16 for cleaning instructions, and
call your dealer if the problem persists after cleaning.
After running for some
time, my fireplace has
soot gathering on the
logs, panels, or roof, it this
normal?
Minor amount of soot developing on logs is common, but soot that builds
up, falls off, and accumulates indicates the burner needs adjustment,
or the logs may have been installed incorrectly. Contact your dealer for
remedies to excessive sooting.
Where can I purchase parts
for my fireplace?
Any of our Valor dealers are able to order parts or provide field service.
Please contact your dealer - see page 3 - or visit valorfireplaces.com/
contact for a list of dealers near you.
Who can service my
fireplace?
We recommend having your fireplace serviced before initial use, and at
least once every year by a qualified service technician. Contact our dealer,
quoting the model and serial numbers, if possible. These numbers can
be found on the fireplace information card attached to the fireplace - see
page 7.
Why does my pilot light go
out when I leave the house
for extended periods of
time?
Your fireplace has a built-in safety shutoff. If the flame height does not
adjust for 7 days, the fireplace will automatically turn the pilot off, and
would need to be turned on again using either the handset or wall switch.
Why doesn't the fireplace
turn down when it goes
above the temperature I've
set?
Rather than constantly turning your fireplace up and down, the
temperature feature of your remote control is designed to efficiently
give you a smooth maintenance of a comfortable temperature. With this
you may find temperature fluctuations beyond the set point to varying
degrees, depending on installation and room size.

20
190ɋ–ɋ2255 Dollarton Highway,
North Vancouver, BCɄCanadaɄV7H 3B1
If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you
attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the initial user
of this unit, are not transferable and are subject to the conditions and limitations in paragraphs 3, 4 and 5. Please review the
conditions and limitations carefully and strictly follow their requirements.
1. Extended Warranty Coverage
For a period of up to ten (10) years, Miles Industries
Ltd., (the “Company”) or its appointed distributor will at
its option pay the initial owner for the repair of, or will
exchange the following parts or components which are
found to be defective in material or workmanship under
normal conditions of use and service:
Maximum Warranty Period 10 years
Part or Component Defect Covered
Exterior steel casing Corrosion 9
Glass Loss of structural integrity 9
Cast iron parts Corrosion 9
Firebox and heat
exchanger
Corrosion (but not
discoloration) causing loss
of structural integrity
9
2. Two-Year Parts Warranty
In addition, for two (2) years from the date of purchase, the
Company, at its option, will repair or exchange all parts and
components not listed above but that are found to have a
bona ȴde defect in material or workmanship under normal
conditions of use.
3. Conditions and Limitations
a) The warranty registration card must be completed by
the initial owner and returned to the company within
90 days. Alternatively, the warranty registration form
may be ȴlled out online at
www.valorȴreplaces.com
b) Installation and maintenance must be performed by
an authorized and trained dealer in accordance with
the Company’s installation instructions.
c) This warranty is void where installation of the unit
does not conform to all applicable codes including
national and local gas appliance installation codes and
building and ȴre codes.
d) The owner must comply with all operating
instructions.
e) The Company is not responsible for the labor costs
to remove defective parts or re-install repaired or
replacement parts.
f) The initial owner of the unit will be responsible for
any shipping charges for replacement parts as well
as travel time incurred by the dealer to perform the
warranty work.
g) This warranty applies to non-commercial use and
service and is void if it is apparent that there is abuse,
misuse, alteration, improper installation, accident or
lack of maintenance to the unit.
h) The warranty does not cover damage to the unit
through:
i) Improper installation, operational or environmental
conditions.
ii) Inadequate ventilation in the area or competition
for air from other household equipment or
appliances.
iii) Chemicals, dampness, condensation, or sulphur
in the fuel supply lines which exceeds industry
standards.
i) This warranty does not cover glass, log breakage or
damage to the unit while in transit.
j) The Company does not allow anyone to extend, alter
or modify this warranty and assumes no responsibility
for direct, indirect or consequential damages caused
by the unit. State or provincial laws where the initial
user or user resides may provide speciȴc rights
extending this warranty and, if so, the Company’s sole
obligation under this warranty is to provide labor and/
or materials in accordance with those laws.
4. Discharge of Liability
After two (2) years from the date of purchase, the Company
may, at its option, fully discharge all obligations under this
warranty by paying to the ȴrst owner the wholesale price of,
or replacing, any defective parts.
5. No Other Warranty
All obligations to repair this unit are deȴned in this warranty.
Some states or provinces may speciȴcally mandate
additional obligations on the part of manufacturers, but in
the absence of such speciȴc legislation, there is no other
warranty or obligation expressed or implied.
Valor®Warranty
