Valor Inspire 1000FS Instructions for use

08/53230/0 REV: 06
Please keep me in a safe place for future use.
odels; 600FS, 600RC
800FS, 800RC
1000FS, 1000RC
nset live fuel effect gas fire
We trust that this guide gives sufficient details to enable this appliance to be installed,
operated and maintained satisfactorily. However, if further information is required, our
Valor Technical Helpline will be pleased to help.
Telephone [phone] (National call rates apply in the United Kingdom).
n the Republic of reland Telephone [phone].
INSTALLER ANDOWNER GUIDE
© GDC Group Ltd. NOV 2017

© GDC Group Ltd.
All rights reserved. No part of this publication may be reproduced in any material form
(including photocopying), stored in any medium by electronic means (including in any
retrieval system or database) or transmitted, in any form or by any means, whether
electronic, mechanical, recording or otherwise, without the prior written permission of
the copyright owner.
Applications for the copyright owner's permission to reproduce any part of this
publication should be made, giving details of the proposed use, to the following
address: The Marketing Communications Manager, GDC Group Ltd, Millbrook House,
Grange Dive, Hedge End, Southampton, SO30 2DF.
Warning: Any person who does any unauthorised act in relation to a copyright work
may be liable to criminal prosecution and civil claims for damages.
Because our policy is one of constant development and improvement, details may vary
slightly from those given in this publication
© GDC Group Ltd. NOV 2017 Page 2
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20).
THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED
KINGDO (GB) AND THE REPUBLIC OF IRELAND (IE).

Page 3
Safety First.
Valor fires are CE Approved and designed to meet the appropriate British Standards
and Safety Marks.
Quality and Excellence.
All Valor fires are manufactured to the highest standards of quality and excellence
and are manufactured under a BS EN SO 9001 quality system accepted by the
British Standards nstitute.
The Highest Standards
Valor is a member of the Benchark scheme and HH C (Heating and Hot water
ndustry Council) that work to ensure high standards of safety, quality and
performance.
Careful Installation
This gas fire must be installed by a competent GAS SAFE REG STER operative in
accordance with this installer guide.
© GDC Group Ltd. NOV 2017

NSTALLER GU DE
FOR OWNER GU DE SEE PAGES 45 TO 64
© GDC Group Ltd. NOV 2017 Page 4
INSTALLER GUIDE

CONTENTS
Section Page
INSTALLER GUIDE 4 - 44
OWNER GUIDE 45 - 64
1. APPLIANCE DI ENSIONS 8
2. SAFETY 9
3. THE BENCH ARKING SCHE E 10
4. APPLIANCE DATA, EFFICIENCY AND NOx 11
4.1 General information. 11
4.2 Efficiency. 12
4.3 NOx 12
4.4 Accessories 12
5. GENERAL INSTALLATION REQUIRE ENTS 13
5.1 Regulations, Standards and Law. 13
5.2 Ventilation requirements. 13
5.3 The Atmosphere sensing device (ASD). 14
5.4 Fireguard requirements. 14
5.5 Room considerations. 14
5.6 Chimney preparation. 14
5.7 Fireplace preparation. 14
5.8 The fireplace. 15
5.9 Fireplace clearances. 15
5.10 nstallation options. 16 - 17
5.11 Flues. 17
6. PACK CONTENTS 18 - 19
7. FIREPLACE CHECK 20
7.1 Soundness for appliance attachment. 20
7.2 Fireplace flue pull. 23
8. GAS SUPPLY CONNECTION 20
9. PREPARING APPLIANCE FOR INSTALLATION 21 - 22
10. IGNITION CHECK 23
10.1 Fitting batteries to the remote control handset (RC) 23
10.2 Fitting batteries to the battery box (RC) 23
10.3 Setting the handset and receiver relationship (RC) 24
10.4 Checking the ignition operation (RC) 24
10.5 Fitting slider handle to control cam (FS) 25
10.6 Fitting the battery into spark ignition generator (FS) 25
10.7 Checking the ignition operation 25
Continued on next page
Page 5
© GDC Group Ltd. NOV 2017
INSTALLER GUIDE

11. CONVECTION BOX INSTALLATION 26
11.1 Method 1 - Front fixing to fireplace surround. 26
11.2 Method 2 - Cable retention and floor fixing. 26 - 27
11.3 Sealing floor front - Method 1 & 2 inc Frameless 28
12. FITTING THE WALL LINERS & FUEL EFFECT 29
12.1A Fitting the Single piece rear wall liner (Ceramic/Glass) 29
12.1B Fitting the Two or Three piece rear wall liners (Vermiculite) 29
12.2 Fitting the Glass liners spacer support and filler piece. 29
12.3 Fitting the side wall liners (Vermiculite/Ceramic/Glass. 29
12.4 Fitting the log fuel effect 30
13. BURNER AND SUPPLY PIPE INSTALLATION 30
13.1 Burner installation. 30
13.2 Supply pipe installation. 30
13.3 Burner checks. 30
- 13.3.1 Lighting the fire (RC) 30
- 13.3.2 Adjusting flame height (RC) 31
- 13.3.3 Adjusting to pilot only (RC) 31
- 13.3.4 Turing off (RC) 31
- 13.3.5 Lighting the fire (FS) 31
- 13.3.6 Adjusting flame height (FS) 32
- 13.3.7 Turning off (FS) 32
13.4 Check inlet pressure. 32
14. REASSE BLE OF FIRE 33
14.1 Fitting the bottom tray into convector box 33
14.2 Fitting the top tray into the convector box 33
14.3 Positioning the ember wool accross the burners 33
14.4 Replacing the log fuel effect 34
14.5 Refit the window door panel 34
14.5 Refit the visual baffle 34
15. FULL OPERATING CHECKS 34
15.1 Check the burner operation. 34
15.2 Check for spillage. 34
15.3 Flame supervision and spillage monitoring system. 35
16. TRI OR FRA ELESS INSTALLATION 36
17. FINAL REVIEW 37
© GDC Group Ltd. NOV 2017 Page 6
Continued on next page
CONTENTS (Continued)
Section Page

18. SERVICING & PARTS REPLACE ENT 38
18.1 To remove the trim. 38
18.2 To remove the visual baffle. 39
18.3 To remove the window door panel. 39
18.4 To remove the fuel effect and ember wool 39
18.5 To remove the top tray. 40
18.6 To remove the base tray. 40
18.7 To remove the burner assembly and tray 40
18.8 To access and remove the nspection panel 40
18.9 Checking the aeration settings of the burners 40
18.10 To remove the wall liners 41
18.11 To remove the pilot unit. 41
18.12 To remove the Mertik GV60 gas valve. (RC) 42
18.13 To remove the Teddington gas valve and switch. (FS) 43
18.14 To remove the receiver box. (RC) 43
18.15 To remove the thermocouple interrupter block. (RC) 44
18.16 To replace the burner (s). 44
18.17 To remove the burner injector. 44
18.18 To remove the appliance from the fireplace. 44
CONTENTS (Continued)
Section Page
Page 7
© GDC Group Ltd. NOV 2017
INSTALLER GUIDE

1.APPLIANCEDIMENSIONS
© GDC Group Ltd. NOV 2017 Page 8
INSTALLER GUIDE
D
E
C
A
B
B
A
C
A
BC
C
B
A
GRANDE TRIM EDGE TRIM
FRAMELESS
Dimension 600FS / 600RC 800FS / 800RC 1000FS / 1000RC
A 470 mm 470 mm 470 mm
B 646 mm 846 mm 968 mm
C 293 mm 293 mm 293 mm
D 596 mm 796 mm 918 mm
E 443 mm 443 mm 443 mm
Dimens
ion
600FS /
600RC
Frameless
800FS /
800RC
Frameless
1000FS /
1000RC
Frameless
600FS /
600RC
Grande
Trim
800FS /
800RC
Grande
Trim
1000FS /
1000RC
Grande
Trim
600FS /
600RC
Edge Trim
800FS /
800RC
Edge Trim
1000FS /
1000RC
Edge Trim
A 443 mm 443 mm 443 mm 521 mm 521 mm 521 mm 476 mm 476 mm 476 mm
B 590 mm 790 mm 912 mm 697 mm 897 mm 1019 mm 652 mm 852 mm 974 mm
C 25 mm 25 mm 25 mm 10 mm 10 mm 10 mm 10 mm 10 mm 10 mm
Outside Dimensions stated.

2.SAFETY
Installer
Before continuing any further with the installation of this appliance please read the following
guide to manual handling.
-The lifting weight of this appliance (kg) is approx as below:
Model Weight
600RC nspire engine only* 18.0 Kg
600FS nspire engine only* 17.5 Kg
800RC nspire engine only* 26.5 Kg
800FS nspire engine only* 26.0 Kg
1000RC nspire engine only* 28.5 Kg
1000FS nspire engine only* 28.0 Kg
*e cludes all trims options & ceramic log sets.
These appliances are heavy. We therefore recommend that two person’s should be sufficient to
lift the fire. f fitting or moving the fire alone we recommend the use of suitable lifting apparatus.
-When lifting always keep your back straight. Bend your legs and not your back.
-Avoid twisting at the waist. t is better to reposition your feet.
-Avoid upper body/top heavy bending. Do not lean forward or sideways whilst
handling the fire.
-Always grip with the palm of the hand. Do not use the tips of fingers for support.
-Always keep the fire as close to the body as possible. This will minimise the
cantilever action.
-Use gloves to provide additional grip.
-Always use assistance if required.
-This product uses log fuel effect pieces, burner compartment walls and ceramic pebbles
containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.
Excessive exposure to these materials may cause irritation to eyes, skin and respiratory
tract. Consequently, it is important to take care when handling these articles to ensure that
the release of dust is kept to a minimum. To ensure that the release of fibres from these
RCF articles is kept to a minimum, during installation and servicing we recommend that
you use a HEPA filtered vacuum to remove any dust and soot accumulated in and around
the fire before and after working on the fire. When replacing these articles we recommend
that the replaced items are not broken up, but are sealed within a heavy duty polythene
bag, clearly labelled as RCF waste. RCF waste is classed as a stable, non-reactive
hazardous waste and may be disposed at a landfill licensed to accept such waste.
Protective clothing is not required when handling these articles, but we recommend you
follow the normal hygiene rules of not smoking, eating or drinking in the work area and
always wash your hands before eating or drinking.
-This appliance does not contain any component manufactured from asbestos or
asbestos related products.
Page 9
© GDC Group Ltd. NOV 2017
INSTALLER GUIDE

3.THE BENCHMARK SCHEME
GDC Group is a licensed member of the Benchmark Scheme which aims to improve
the standards of installation and commissioning of domestic heating and hot water
systems in the UK and to encourage regular servicing to optimise safety, efficiency
and performance. Benchmark is managed and promoted by the Heating and
Hotwater ndustry Council.
t places responsibilities on both manufacturers and installers. The purpose is to
ensure that customers are provided with the correct equipment for their needs, that it
is installed, commissioned and serviced in accordance with the manufacturer’s
instructions by competent persons and that it meets the requirements of the
appropriate Building Regulations.
The Benchmark Checklist (on the inside back pages of this guide) can be used to
demonstrate compliance with Building Regulations and should be provided to the
customer for future reference.
nstallers are required to carry out installation, commissioning and servicing work in
accordance with the Benchmark Code of Practice which is available from the Heating
and Hotwater ndustry Council who manage and promote the Scheme.
Visit www.centralheating.co.uk for more information.
At the time of commissioning, complete all relevant sections of the Benchmark
Checklist located on the inside back pages of this document.
© GDC Group Ltd. NOV 2017 Page 10
INSTALLER GUIDE

4. APPLIANCE DATA, EFFICIENCY, NO
x
AND Accessories
4.1 General information.
The appliance information label is located on the burner tray on the left hand side of
the fire. This can be found by removing the Visual Baffle and Trim if fitted.
Page 11
© GDC Group Ltd. NOV 2017
INSTALLER GUIDE
Models 600FS/600RC 800FS/800RC 1000FS/1000RC
Ga
Natural (G20) Natural (G20) Natural (G20)
FS & RC Input - Max (Gro ) 6.0kW (20,473 Btu/hr) 6.4kW (21,838 Btu/hr) 6.95kW (23,714 Btu/hr)
RC Input - Med (Gro ) 3.2kW (10,918 Btu/hr) 3.3kW (11,260 Btu/hr) 3.5kW (11,942 Btu/hr)
RC Input - Min (Gro ) 2.4kW (8,189 Btu/hr) 2.4kW (8,189 Btu/hr) 2.5kW (8,530 Btu/hr)
FS Input - Med (Gro ) 3.2kW (10,918 Btu/hr) 3.1kW (10,578 Btu/hr) 3.7kW (12,625 Btu/hr)
FS Input - Min (Gro ) 2.4kW (8,189 Btu/hr) 2.4kW (8,189 Btu/hr) 2.8kW (9,554 Btu/hr)
Inlet Te t Pre ure (Cold) 20.0 +/- 1.0 mbar (8.0 +/-
0.4in w.g.)
20.0 +/- 1.0 mbar (8.0 +/-
0.4in w.g.)
20.0 +/- 1.0 mbar (8.0 +/-
0.4in w.g.)
Ga Connection 8mm pipe 8mm pipe 8mm pipe
Front Burner Injector (FS)
Cat 18 - 180 Cat 18 - 180
Cat 18 - 220
Front Burner Injector (RC) Cat 18 - 200
Rear Burner Injector (FS &
RC) Cat 18 - 180 Cat 18 - 220 Cat 18 - 260
Pilot & Atmo phere Sen ing
Device NG9093 NG9093 NG9093
Ignition (RC)
Battery powered electronic
remote control & battery
pack
Battery powered electronic
remote control & battery
pack
Battery powered electronic
remote control & battery
pack
Ignition (FS) Electronic (Mounted on ga
valve)
Electronic (Mounted on ga
valve)
Electronic (Mounted on ga
valve)

4.2 Efficiency.
The efficiency of this appliance has been measured as specified in BS 7977 - 1 and
the results are as below :
odel Efficiency % (Gross) Efficiency % (Net)
600RC & 600FS nspire 68% 75%
800RC & 800FS nspire 72% 80%
1000RC & 1000FS nspire 70.5% 78%
The gross calorific value of the fuel has been used for this efficiency calculation.
The conversion of net efficiency to gross was achieved by multiplying the net
efficiency by the following conversion factor from Table E3 of SAP 2005, rounding
down to the nearest whole number.
4.3 NOx
For NG the 'Weighted' result for these appliances equates to NOx Class 4.
4.4 Accessories
Gather Hood Connector nspire 600FS/600RC Product Code: 061638
Gather Hood Connector nspire 800FS/800RC Product Code: 061645
& nspire 1000FS/1000RC
© GDC Group Ltd. NOV 2017 Page 12
INSTALLER GUIDE
Gas Conversion factor from net to gross efficiency
Natural Gas 0.901

5. GENERAL INSTALLATION REQUIREMENTS
5.1 Regulations, Standards and Law.
The installation must be in accordance with these instructions.
For the user’s protection, in the United Kingdom it is the law that all gas appliances
are installed by competent persons in accordance with the current edition of the Gas
Safety ( nstallation and Use) Regulations. Failure to install the appliance correctly
could lead to prosecution. GAS SAFE REG STER require their members to work to
recognised standards.
n the United Kingdom the installation must also be in accordance with:
All the relevant parts of local regulations.
All relevant codes of practice.
The relevant parts of the current editions of the following British Standards:-
BS EN 1856 Part 1 Chimneys - Requirements for metal chimneys.
BS 5440 Part 1 nstallation of flues.
BS 5440 Part 2 nstallation and maintenance of flues and ventilation for gas
appliances of rated input not exceeding 70 kw net (1st, 2nd
and 3rd family gases).
BS 6461 Part 1 Masonry chimney & flues - nstallation.
BS 1251 Fireplace components.
BS 5871 Part 2 nstallation - nset LFE gas fires.
BS 6891 Gas pipework installation.
-n England and Wales, the current edition of the Building Regulations issued by the
Department of the Environment and the Welsh Office.
-n Scotland, the current edition of the Building Standards (Scotland) Regulations
issued by the Scottish Executive.
-n Northern reland, the current edition of the Building regulations (Northern
reland) issued by the Department of the Environment for Northern reland.
-n the Republic of reland the installation must be carried out by a competent
person and also conform to the relevant parts of:
a) The current edition of S 813 “Domestic Gas nstallations”
b) All relevant national and local rules in force.
Where no specific instructions are given, reference should be made to the relevant
British Standard Code of Practice.
5.2 Ventilation requirements.
Normal adventitious ventilation is usually sufficient to satisfy the ventilation
requirements of this appliance. n GB reference should be made to BS 5871 Part 2
and in E reference should be made to the current edition of S 813 “Domestic Gas
nstallations” which makes clear the conditions that must be met to demonstrate that
sufficient ventilation is available.
Page 13
© GDC Group Ltd. NOV 2017
INSTALLER GUIDE

5.3 The Atmosphere sensing device (ASD).
The appliance is fitted with an A.S.D (Atmosphere sensing device). f the appliance
closes down after a period of operation for no apparent reason, the consumer should
be informed to stop using the appliance until the installation and appliance have been
thoroughly checked. The A.S.D will shut the appliance down if an unacceptable
amount of harmful products of combustion accumulate. Under no circumstances
should the A.S.D be altered or bypassed in any way. Only a genuine manufacturer’s
replacement part should be fitted. The individual A.S.D components are not
replaceable.
5.4 Fireguard requirements.
A fireguard complying with BS 8423 should be fitted for the protection of young
children, the elderly, the infirm and pet animals.
5.5 Room considerations.
5.5.1 This appliance must not be installed in any room that contains a bath or shower
or where steam is regularly present.
5.5.2 An extractor fan may only be used in the same room as this appliance, or in
any area from which ventilation for the appliance is taken, if it does not affect the safe
performance of the appliance. Note the spillage test requirements detailed further on
in this manual. f the fan is likely to affect the appliance, the appliance must not be
installed unless the fan is permanently disconnected.
5.5.3 Do not place any flammable materials within a distance of 0.5 m of the
radiation of the appliance and ventilation grills.
5.6 Chimney preparation.
5.6.1 f the appliance is intended to be installed to a chimney that was previously
used for solid fuel, the flue must be swept clean prior to installation. All flues should
be inspected for soundness and freedom from blockages.
5.6.2 Any chimney damper or restrictor should be removed. f removal is not possible,
they must be secured in the open position.
5.7 Fireplace preparation.
5.7.1 f the fireplace opening is an underfloor draught type, it must be sealed to stop
any draughts.
5.7.2 The fireplace floor should be reasonably flat to ensure that the convection box
can be installed without it rocking and so that a good seal can be made at the bottom
front of the box.
5.7.3 The front face of the fireplace should be reasonably flat over the area covered
by the convection box top and side flange seals to ensure good sealing. These faces
should be made good if necessary.
© GDC Group Ltd. NOV 2017 Page 14
INSTALLER GUIDE

5.7.4 Like all efficient gas fires care should be taken to the choice and layout of
installed back panels. Marble and other similar natural materials may have
microscopic flaws or stress points, under heat these may open and crack. f in doubt
the use of a three/four piece back panel layout is recommended.
5.8 The fireplace.
The appliance can be fitted to a purpose made proprietary class “O”-150°C surround.
The hearth material must be at least 12mm thick. The periphery of the hearth (or
fender) should be at least 50mm above floor level to discourage the placing of
carpets or rugs over it.
The surface of the hearth must be sufficiently flat to enable the bottom of the front
surround and the bottom front cover to be aligned horizontally. Any excessive
unevenness (uneven tiles, Cotswold stone, etc.) should be rectified.
The appliance must not stand on combustible materials or carpets. Where no hearth
is fitted.
5.9 Fireplace clearances.
5.9.1 DO NOT install onto a combustable wall; all combustable materials must be
removed from the area shown in below diagram. The use of heat resistant plaster or
board is recomended within the below shaded areas.
5.9.2 A combustable shelf must be a minimum of 400mm above the top of the
appliance. This is based on a 150mm deep shelf. For every extra 13mm of depth add
25mm above the 400mm from the top of the appliance, not the trim.
5.9.3 A side wall must be a minimum of 300mm from the side of the appliance, not
the trim.
Page 15
© GDC Group Ltd. NOV 2017
INSTALLER GUIDE
850
100 X (MIN)
400450
Model Dimension X
600FS / 600RC 600 mm Min
800FS / 800RC 800 mm Min
1000FS / 1000RC 922 mm Min

5.10 Installation options.
n the United Kingdom, as supplied, the appliance can be installed in the following
situations:
Note: “D” dimension critical or clearance o the trim depth
5.10.1 Conventional fireplace and hearth.-
To a fireplace opening and hearth complying with BS1251 after removal of the
fireback and sufficient material behind the fireback for a debris catchment space.
5.10.2. ‘Hole-in-the-wall’ nstallations
-t is recommended that a hearth should be installed as in section 5.8.
-f a hearth is not fitted, the fire must be installed so that the distance from the base
of the fireplace opening in the wall to the finished floor level is at least 110mm. Where
there is no floor covering or carpet and the floor is of a type that is likely to be
covered in such a way in the future then the distance from the base of the fireplace
opening in the wall to the floor level should be increased to at least 180mm.
© GDC Group Ltd. NOV 2017 Page 16
INSTALLER GUIDE
A
B
D
50
C
E
Hearth & Fireplace opening dims
Dimension 600FS / 600RC 800FS / 800RC 1000FS / 1000RC
A 460 mm Max / 450 mm Min 460 mm Max / 450 mm Min 460 mm Max / 450 mm Min
B 635 mm Max / 600 mm Min 835 mm Max / 800 mm Min 957 mm Max / 922 mm Min
C 340 mm Min 340 mm Min 340 mm Min
D (Edge Trim) 5 mm Min 5 mm Min 5 mm Min
D (Grande Trim) 28 mm Min 28 mm Min 28 mm Min
E 300 mm Min 300 mm min 300 mm min

5.10.3. Gather hood installation in Stud work Chimney
The nspire gas fire products are intended to be used only in a fireplace of non-
combustible material.However if a stud work chimney breast is used the builder/installer
UST ensure to leave a minimum 75mm clear to the sides of the appliance and a
minimum of 100mm clear to the rear of the gather hood connector.
Directly above the appliance the area should be left clear to prevent a build-up of heat.
f the fireplace wall ends at ceiling height two air vents of at least 50cm2should be
installed one at the bottom and one at the top of the wall to reduce heat build-up.
Note: There are three suitable Convectional Flue Options;
1. Rear exit - Builders opening Unlined 178mm (7”) minimum.
2. Top Exit - Builders opening Lined 127mm (5”)
3. Stud work is Top Exit only - Twin Wall Rigid 127mm (5”)
5.11 Flues.
1. Suitable flues and minimum flue sizes are as follows: -
It should be noted that, as with many appliances, sharp bends or horizontal runs in
metal flues at the top of the system can be a cause of problems in these types of
installation.
- 225mm x 225mm conventional brick flue.
- 125mm and 175mm diameter lined brick or stone flue.
- 200mm diameter factory made insulated flue manufactured to BS4543 Part 2.
- 175mm diameter flue pipe. See BS6461 Part 1 for suitable materials.
- Single wall, twin wall or flexible flue liner with a minimum diameter of 125mm. The
materials to be used are stainless steel or aluminium as specified in
BS EN 1856 Part 1. The liner must be sealed to the surrounding area above the
fireplace opening and to the top of the chimney. An approved terminal must be fitted.
2. The flue must conform to BS 5440: Part 1 in design and installation.
The flue, measured from the bottom of the fireplace opening to the bottom of the
terminal, shall be not less than 3m in actual vertical height. When calculated in
accordance with BS 5440: Part 1 Annex A, the minimum equivalent height of the flue
shall be 2.0m of 125mm dia. flue pipe.
3. The flue must not be used for any other appliance or application.
4. Proprietary terminals must comply with BS 715 or BS 1289. Any terminal or
termination must be positioned in accordance with BS 5440 Part 1 to ensure that the
products of combustion can be safely dispersed into the outside atmosphere. Where
the appliance is connected to an unlined brick chimney it is generally unnecessary for
the chimney pot to be replaced or for a terminal to be fitted unless the flue has a
diameter smaller than 170mm.
Page 17
© GDC Group Ltd. NOV 2017
INSTALLER GUIDE

© GDC Group Ltd. NOV 2017 Page 18
INSTALLER GUIDE
Magnets to securethe Trims (4 off)Glass liner kit;Tray filler (1 off)Side wall spacer (2 off)(4 off) No.8 x 3/8" screwsFS only (2 off) M4 x 8machine screws to secure slider handleFloor sealingtape (2 off)Eyebolt (4 off)Fire retainingcables (2 off)Long length offoam seal (1 off)If Frameless trimselected (2 off)Inlet ‘T’ Connector(1 off)8 Button RC Handset (1 off)Burner and Convectorbox unit (1 off)Nut and Olive(1 off)Wood screw(6 off)Cable clamp(2 off)Smoke matchtube (1 off)FS onlyChrome & BlackFinish Handles(1 off each)RC only AA Battery(4 off)Fibre / wooden plugs(10 off)FS only AA Battery(1 off)RC only AAA Battery(2 off)Jiffy bagof Emberwool (1 off)Side Walls Liners (2 off)Back Wall Liner (1 or 2 or 3 pieces)NOTE: Liner detailwill vary dependingon style selected

6. PACK CONTENTS
The items required for this appliance are packed in sections.
The Ceramic/Vermiculite/Glass liner options are all fragile so care necessary
when handling. They are packed inside the top fitment as you open the carton.
Section 1 - Fire unit contains:
1 Burner and convection box unit.
1 Log fuel effect set
1 Literature packs
1 Frameless kit (ONLY f ordered instead of a Trim)
Section 2 - Accessory box contains:
1 Wall liners set (two sides and depending on Model & Style 1, 2 or 3 rear pieces)
1 Self adhesive foam seal
2 Self adhesive foam seal (ONLY with Frameless kit extra foam seal)
6 Wood screws
10 Wood Wall plugs
2 Cable clamps
2 Fire retaining cables
4 Eyebolts
2 Floor sealing tape
1 ‘T’ connector and pressure test point.
1 Nut and olive for 8mm inlet pipe.
1 Smoke match tube
1 Ember wool (600 approx 1 g / 800 approx 2 g / 1000 approx 3 g)
2 Slider handle (FS only - Choice of either Chrome or Black handle can be fitted)
2 M4 x 8 machine screws (FS only - to secure the Slider handle)
1 Alkaline ‘AA’ Battery (FS models only)
1 8 button remote control handset. (RC models only)
2 Alkaline ‘AAA’ Batteries. (RC models only)
1 Battery box (RC models only)
4 Alkaline ‘AA’ Batteries. (RC models only)
1 Tray filler (Only on models with Glass liners selected)
2 Side wall glass spacers (Only on models with Glass liners selected)
4 No.8 x 3/8” Tapping Screws (Used to fit the side wall spacers)
Section 3 - Trim pack contains:
1 Trim.
4 Square magnets (Used to secure Trim onto engine)
Carefully remove all the contents. Take special care in handling the ceramic pieces.
Check that all the listed parts are present and in good condition.
Page 19
© GDC Group Ltd. NOV 2017
INSTALLER GUIDE

7. FIREPLACE CHECK
8.1 Soundness for appliance attachment
Primary method of retaining the appliance is by fixing to the fireplace front.
2) Using concealed
The methods are detailed in section 11 of this manual. Before selecting the retention
method, consult with the customer. Method 2 is provided for instances where drilling
holes in the front surface of the fireplace surround is unacceptable to the customer or
otherwise impractical. N.B. It is unwise to attempt to drill into marble without the
proper tools and equipment.
f method 1 is chosen, make sure that the front surround area is sound enough to
take the wall plugs and wood screws. f necessary, make sound with suitable cement.
f method 2 is chosen, make sure that the areas at the back and towards the centre of
the fireplace floor are sound enough to take the eyebolts and screws. f these areas
have deteriorated due to prolonged use, they should be made sound with suitable
cement.
8.2 Fireplace flue pull.
Close all doors and windows in the room in which the appliance is to be installed.
After confirming with a match that smoke is drawn into the flue, light a 13 gram
smoke pellet and check that there is a definite flow through the flue. Verify outside
that the smoke exits from one terminal only and that the termination is suitable.
Observe where possible, upstairs rooms and loft spaces for signs of escaping smoke
indicating a defective flue. f there is not a definite flow warm the flue for a few
minutes and repeat the smoke pellet test. f there is still no definite flow the flue may
need remedial work – Do not fit the appliance until there is a definite flow
through the flue.
8.GAS SUPPLY CONNECTION
The fire is designed for a rear concealed connection only.
A nut and olive are provided for an 8mm pipe inlet connection to the ‘T’ connector at
the bottom front of the appliance. The ‘T’ connector can be rotated to allow
connection and includes a valve for isolating the gas supply and a pressure test point.
The supply pipe must be rigid material. Flexible pipe must not be used.
Before the appliance is fitted into the fireplace it will be necessary to extend the
supply line so that it will project through the hole in the back of the convection box
and run to the ‘T’ connector at the front. The pipe run from the supply line up to the
rear opening in the convection box must be kept away from the area which will be
taken by the convection box when it is installed.
© GDC Group Ltd. NOV 2017 Page 20
INSTALLER GUIDE
