Vanderbilt CD30 Codoor Instruction sheet

Vanderbilt International (IRL) Ltd.
CD30 Codoor
Configuration Manual

Liefermöglichkeiten und technische Änderungen vorbehalten.
Data and design subject to change without notice. / Supply subject to availability.
© 2016 Copyright by Vanderbilt International (IRL) Ltd.
Wir behalten uns alle Rechte an diesem Dokument und an dem in ihm dargestellten Gegenstand vor. Der Empfänger erkennt diese Rechte
an und wird dieses Dokument nicht ohne unsere vorgängige schriftliche Ermächtigung ganz oder teilweise Dritten zugänglich machen oder
außerhalb des Zweckes verwenden, zu dem es ihm übergeben worden ist.
We reserve all rights in this document and in the subject thereof. By acceptance of the document the recipient acknowledges these rights
and undertakes not to publish the document nor the subject thereof in full or in part, nor to make them available to any third party without our
prior express written authorization, nor to use it for any purpose other than for which it was delivered to him.
About this document
This configuration manual contains instructions for installation, setup,
configuration and operation of CD30.
Trade mark
All products or company names mentioned in this manual for purposes of identifi-
cation or description could be trademarks or registered trademarks of their respec-
tive owners.
Contacting us
If you have questions or suggestions regarding the product or this documentation,
please contact your local Vanderbilt representative.
You can also visit our Web site at: www.vanderbiltindustries.com
Training courses
Vanderbilt provides training courses for all products.

3
Vanderbilt International (IRL) Ltd.
05.2016
Contents
1Service description............................................................................5
2Safety ..................................................................................................5
2.1 Target group.........................................................................................5
2.2 General safety precautions..................................................................5
3Standards and guidelines .................................................................6
3.1 EU directives........................................................................................6
4Technical data ....................................................................................6
5Details for ordering............................................................................7
6Package contents...............................................................................7
7Description of Equipment .................................................................8
7.1 General use..........................................................................................8
7.2 Mounting ..............................................................................................8
7.3 Keypad.................................................................................................8
7.4 LED Status at battery warning .............................................................9
7.5 Buzzer..................................................................................................9
8Change Administrator code............................................................10
8.1 Present Administrator code is known.................................................10
8.2 Present Administrator code is not known...........................................11
9Mounting...........................................................................................12
9.1 Technical details ................................................................................12
9.2 Fitting CD30 to the door.....................................................................13
9.2.1 Test mechanical function of CD30.....................................................14
9.3 Change batteries................................................................................14
10 Programming....................................................................................15
10.1 Set Group code..................................................................................15
10.1.1 Enter Group code...............................................................................15
10.1.2 Change Group code...........................................................................16
10.1.3 Delete Group code.............................................................................16
10.2 Lock/unlock door................................................................................17
10.3 Disable/enable buzzer .......................................................................17
11 Erase memory ..................................................................................18
12 Operation ..........................................................................................19
12.1 Leaving the premises.........................................................................19
12.2 Automatic resetting ............................................................................19
12.3 Access blocking .................................................................................19
12.4 Backup power supply.........................................................................19
13 Command overview.........................................................................20
14 Troubleshooting...............................................................................21
15 Glossary............................................................................................21
16 Keyword index..................................................................................22

Service description
5
Vanderbilt International (IRL) Ltd.
05.2016
1 Service description
CD30 is a Scandinavian style Codoor. The CD30, a complete code lock suitable for
fitting to a single door, incorporates an electronic code lock, a mechanical locking
device and a power unit in the same housing.
2 Safety
2.1 Target group
Target readers Qualification Activity Condition of the prod-
uct
Installer Technical training for
building or electrical in-
stallations.
Installs the product, in-
dividual components of
the product or replace-
ment parts.
Components of the
product are not yet in-
stalled or need to be re-
placed or modified.
Operational startup per-
sonnel Technical training for building or electrical in-
stallations.
Special knowledge of
the device is required.
Puts the product into
operation for the first
time, or changes the ex-
isting configuration.
The product is installed
but not yet configured,
or the existing configu-
ration is to be changed.
Service personnel Technical training for
building or electrical in-
stallations.
Special knowledge of
the device is required.
Checks the product at
regular intervals to en-
sure that it is in good
working order, services
the device repairs it or
expands and upgrades
the device.
Product already in use
and requiring servicing.
2.2 General safety precautions
Read the general safety precautions before operating the device.
Keep this document for reference.
Always pass this document on together with the product.
Please also take into account any additional country-specific, local safety
standards or regulations concerning project planning, operation and disposal of
the product.
Damage to the device due to electrostatic discharge (ESD)
Always use wrist straps or similar connected to earth.
Damage due to unsuitable mounting location
The device should only be used for indoor applications.

Standards and guidelines
6
Vanderbilt International (IRL) Ltd.
05.2016
3 Standards and guidelines
3.1 EU directives
This product complies with the requirements of the European Directives. The EU
declaration of conformity is available from:
Vanderbilt International (IRL) Ltd.
Clonshaugh Business and Technology Park
Clonshaugh
Dublin 17
Ireland
4 Technical data
CD30
Operating voltage Two Lithium 9V type 6LR61 batteries (not in-
cluded).
For a safe function we strongly recommend the use
of our batteries Ultralife UL9V with 9V, 1200 mAh
and sustaining minimum 400 mA peak current.
Operational time
Approx. one year
Number of codes
Nine 4-digit
Indicators 3 x LED (red/yellow/green)
1 x buzzer
Operating temperature
0 to +50 °C
Environment
Indoor use only
IP rating
IP30
Colour
Stainless steel
Dimensions (W x H x D)
285 x 64 x 59 mm
Weight
0.76 kg
Approval
CE
NOTE
Lithium batteries must be used because they provide the following advantages:
The capacity is constant throughout battery life.
Longer battery life reduces the environmental impact as fewer batteries are needed.

Battery storage life can be up to ten years.

Details for ordering
7
Vanderbilt International (IRL) Ltd.
05.2016
5 Details for ordering
Type
Order No.
Designation
Weight
CD30
V54521-C101-A100
Codoor
0.76 kg
6 Package contents
Check that you have the following parts before discarding the packing materials:
1 x CD30 (batteries excluded).
4 extension sleeves for handle nipples (use only one pair, M4 or M5).
1 x reinforcing spring.
1 x reinforcing spring holder.

Description of Equipment
8
Vanderbilt International (IRL) Ltd.
05.2016
7 Description of Equipment
7.1 General use
The CD30, a complete code lock suitable for fitting to a single door, incorporates
an electronic code lock, a mechanical locking device and a power unit in the same
housing. When CD30 is fitted, the outside door handle is disengaged and may be
pressed down without opening the door. To open the door, a 4-digit code has to be
entered. The handle on the inside of the door is not affected by CD30, and works
normally for people leaving the premises.
7.2 Mounting
The CD30 may be fitted on most doors with handle operated ASSA modular type
mortise locks. See 9 Mounting for more information.
When fitted, the external handle is inoperable until a valid code is entered. The in-
ternal handle is not affected and will retract the latch bolt as required.
7.3 Keypad
Fig. 1 Keypad CD30

Red LED.

Yellow LED.

Green LED.
0-9
Are used for entering codes and/or programming.
A/B
Are used only for programming.
In this manual three symbols illustrate how the LEDs are used:
= OFF
= ON
= Flashing
1 2 3

Description of Equipment
9
Vanderbilt International (IRL) Ltd.
05.2016
7.4 LED Status at battery warning
First warning level for low battery: Flashing LED and a delay of the unlocking.
Second warning level for low battery: Fast flashing LED on each key press. Door
can be opened only with Administrator code.
7.5 Buzzer
CD30 also incorporates a buzzer to confirm each key press (if required).
The buzzer also sounds to confirm successful programming.

Change Administrator code
10
Vanderbilt International (IRL) Ltd.
05.2016
8 Change Administrator code
8.1 Present Administrator code is known
NOTE
The Administrator code cannot be the same as the code 112186 to erase the memory.
See section 11 Erase memory.
If you are in administrator mode and don’t press a key the device will automatically leave the
administrator mode after 30 seconds.
CD30 is delivered with the default Administrator code set as 112233.
1. Press B.

2. Enter the 6-digit Administrator code.

3. Press A27.
The buzzer sounds a confirm tune.

4. Enter a new 6-digit Administrator code.
The buzzer sounds a confirm tune.
5. Verify by entering the same Administrator code again.
CD30 exits at the Administrator mode.

6. Make a note of the Administrator code.

Change Administrator code
11
Vanderbilt International (IRL) Ltd.
05.2016
8.2 Present Administrator code is not known
NOTE
The Administrator code cannot be the same as the code 112186 to erase the memory.
See section 11 Erase memory.
If you are in administrator mode and don’t press a key the device will automatically leave the
administrator mode after 30 seconds.
1. Remove the CD30 from the door.
2. Quickly press the reset button on the back of the CD30.
Fig. 2 Reset button on the back
The buzzer sounds a confirm tune.

3. Enter the desired 6-digit Administrator code.
The buzzer sounds a confirm tune.
4. Verify by entering the same Administrator code again.
The buzzer sounds a confirm tune.
If the second input doesn’t match the first input the buzzer will sound a error
tone and the Administrator code will not be changed.
5. Make a note of the Administrator code.

Mounting
12
Vanderbilt International (IRL) Ltd.
05.2016
9 Mounting
9.1 Technical details
NOTE 1
Do not mount two CD30 units back to back on one door. They cannot both control the latch.
CD30 is suitable for most doors with handle-operated mortise locks.
The distance between the centre of the handle and the centre of the cylinder
should be between 105 – 116 mm.
Latchbolt function.
The handle must have an 8 mm square spindle.
The handle’s fixing holes should be at 30 – 38 mm centres (diagonal).
The CD30 can be used with a variety of locks such as ASSA 8561 or 565 – but
not the ASSA 410 series.
The backset should be 70 mm.
Fig. 3 CD30 door mounting
Backset = 70 mm

Mounting
13
Vanderbilt International (IRL) Ltd.
05.2016
9.2 Fitting CD30 to the door
1. Check that the Administrator code has been set. See section 8 Change Ad-
ministrator code.
2. Make sure you have the following tools handy:
– Screwdriver for door handle and cylinder ring screws.
– Hacksaw for trimming lever handle spindle.
3. Remove the cylinder ring and door handle from the door by loosening the four
screws. See figure 1.
4. Ensure that the handle spindle does not project more than 20 mm on the
outside of the door. If the spindle is too long, push it through into the handle
on the inside. If this cannot be done, cut the spindle to the right length. See
figure 2.
5. Prepare the handle by extending the screws with the supplied extension
sleeves (M4 or M5). See figure 3.
6. Place the CD30 on the outside of the door with the handle attached, and pass
the lever handle spindle through the square hole. See figure 4.
7. Ensure that the red mark on the follower point downwards. See figure 5.
8. Tighten the four previously loosened screws to the nipples (the screws for the
handle first). These should be just firm. Over-tightening may distort the lock
structure so that it jams. See figure 6.
9. Test the mechanical function of the CD30. See section 9.2.1 Test mechanical
function of CD30.
1
2
3
4
5
6

Mounting
14
Vanderbilt International (IRL) Ltd.
05.2016
9.2.1 Test mechanical function of CD30
It must always be possible to open the door from the inside.
The handle on the outside should not be engaged, and should not open the door
until the correct code is entered.
When the correct code is entered, the handle on the outside should activate the
lock, but only once. As the handle is released, it should again disengage.
If the correct code is entered but the handle is not pressed down, the CD30
should automatically disengage the handle after about 4 seconds.
The handle on the outside must not be jammed in any position, and should
spring back up completely after being pressed down.
9.3 Change batteries
When the unit’s batteries run flat the CD30 will cease to release the latch so the
unit should be fitted with cylinder override. The lock has a backup power supply
that will allow the door to be opened a limited number of times, but the batteries
should be replaced as soon as the low battery warning is noticed. See sections
10.3 Disable/enable buzzer and 12.4 Backup power supply.
1. Remove the CD30 from the door.
2. Remove the two batteries from the rectangular shaped holes on the lower part
of the back of the unit (to power off the unit).
3. Always change both batteries at the same time. See section 4 Technical data.
4. Re-mount the CD30.

Programming
15
Vanderbilt International (IRL) Ltd.
05.2016
10 Programming
10.1 Set Group code
Up to nine 4-digit codes can be programmed into the CD30. The ninth code can
also be used to unlock/lock the door.
10.1.1 Enter Group code
NOTE
If you have entered the wrong Axx command (e g in step 3 below) you can abort the command and
exit to Administrator mode by pressing A again.
Nine 4-digit Group codes can be set. Each Group code needs to be assigned a
code number (1-9).
Note that the code 0000 cannot be used as group code because it is used for
deleting existing group codes. See 10.1.3 Delete Group code.
1. Press B.

2. Enter the 6-digit Administrator code. See section 8 Change Administrator
code.

3. Press A21.
The buzzer sounds a confirm tune.

4. Enter the desired 1-digit code number (1-9).
The buzzer sounds a confirm tune.

5. Enter the desired 4-digit Group code.
The buzzer sounds a confirm tune.

6. To set another Group code, follow steps 4-5.
7. Press B to enter the Administration mode.
8. Press B to leave the Administration mode.
Codes
Code 1: Code 4: Code 7:
Code 2: Code 5: Code 8:
Code 3: Code 6: Code 9:

Programming
16
Vanderbilt International (IRL) Ltd.
05.2016
10.1.2 Change Group code
1. Press B.

2. Enter the 6-digit Administrator code. See section 8 Change Administrator
code.

3. Press A21.
The buzzer sounds a confirm tune.

4. Enter the desired 1-digit code number (1-9).
The buzzer sounds a confirm tune.

5. Enter the desired 4-digit Group code.
The buzzer sounds a confirm tune.

The existing Group code will be over-written.
6. To change another Group code, follow steps 4-5.
7. Press B to enter the Administration mode.
8. Press B to leave the Administration mode.
10.1.3 Delete Group code
1. Press B.

2. Enter the 6-digit Administrator code. See section 8 Change Administrator
code.

3. Press A21.
The buzzer sounds a confirm tune.

4. Enter the desired 1-digit code number (1-9).
The buzzer sounds a confirm tune.

5. Enter 0000.
The buzzer sounds a confirm tune.

6. To delete another Group code, follow steps 4-5.
7. Press B to enter the Administration mode.
8. Press B to leave the Administration mode.

Programming
17
Vanderbilt International (IRL) Ltd.
05.2016
10.2 Lock/unlock door
Unlock door
1. Press A1A.
The buzzer sounds a confirm tune.

2. Enter the group code stored as the 9th code (four digits).
The buzzer sounds a confirm tune.

3. Open the door.
Lock door
1. Press A0A.
The buzzer sounds a confirm tune.

2. Enter the group code stored as the 9th code (four digits).
The buzzer sounds a confirm tune.
The door is now locked.
CD30 returns to normal operation.
10.3 Disable/enable buzzer
The default setting is for the buzzer to sound as each key is pressed. Change if
silent operation is required.
1. Press B.

2. Enter the 6-digit Administrator code. See section 8 Change Administrator
code.

3. Press A65.
The buzzer sounds a confirm tune.

4. To enable press 1.
- or -
To disable press 0.
The buzzer sounds a confirm tune.
The CD30 returns to the Administrator mode.
5. Press Bto leave the Administrator mode.

Erase memory
18
Vanderbilt International (IRL) Ltd.
05.2016
11 Erase memory
In cases where the CD30 is moved to another door (with new users), old codes
should not remain. The best way to ensure this is to erase the memory.
1. Remove the CD30 from the door.
2. Press and hold the reset button on the back of the CD30 for at least 2
seconds.
The buzzer sounds a confirm tune.

Fig. 4 Reset button on the back
3. Press 112186.
The buzzer sounds a confirm tune.
The buzzer sounds a warning tone to alert that you are about to erase the
memory.

4. Press 112186.
The buzzer sounds a confirm tune.

The memory is erased.
The CD30 is in default mode with the following default settings:
– Administrator code: 112233
– The Administrator code can also be used for unlocking the door.
– All memory locations are empty.
– Buzzer on.

Operation
19
Vanderbilt International (IRL) Ltd.
05.2016
12 Operation
12.1 Leaving the premises
The CD30’s mechanical locking device only affects the outside door handle. The
door can always be opened from the inside as usual.
12.2 Automatic resetting
CD30 has two separate resetting systems to return the lock to the locked position
after a code has been entered. The lock is reset mechanically each time the door
handle is used during access. The lock is also electronically reset if the handle is
not used within 4 seconds after a code being entered.
This provides security against unauthorised access, since the CD30 can never
accidentally be left in the unlocked position.
12.3 Access blocking
To eliminate attempts to obtain an access code by trial and error, CD30
incorporates a blocking function to disable the unit after 12 false key presses (three
successive incorrect 4-digit codes). The unit remains blocked until 2 correct codes
are entered successively.
12.4 Backup power supply
When the batteries are running low. CD30 will flash the red LED for 3 seconds
before opening the lock. The lock has a backup power supply that will allow the
door to be opened 200 times or a time of two weeks has passed.
After the door has been opened 200 times the only way to open the door is with the
Administrator code.

Command overview
20
Vanderbilt International (IRL) Ltd.
05.2016
13 Command overview
Command
1.
2.
3.
4.
5.
6.
7.
Change Administrator code
Change Administrator
code
(Present Administrator
code is known)
Press B. Enter the
6-digit Admin-
istrator code.
Press A27. Enter a new
6-digit Admin-
istrator code.
Verify by en-
tering the
same Admin-
istrator code
again.
Make a note
of the Admin-
istrator code.
Change Administrator
code
(Present Administrator
code is not known)
Remove the
CD30 from
the door.
Press quickly
the reset but-
ton on the
back of the
CD30.
Enter the de-
sired 6-digit
Administrator
code.
Verify by en-
tering the
same Admin-
istrator code
again.
Make a note
of the Admin-
istrator code.
Change Group code
Enter Group code
Change group code Press B. Enter the
6-digit Admin-
istrator code.
Press A21. Enter the de-
sired 1-digit
code number
(1-9).
Enter the de-
sired 4-digit
Group code.
Press B to
enter the Ad-
ministration
mode.
Press B to
leave the Ad-
ministration
mode.
Delete Group code Press B. Enter the
6-digit Admin-
istrator code.
Press A21. Enter the de-
sired 1-digit
code number
(1-9)
Enter 0000. Press B to
enter the Ad-
ministration
mode.
Press B to
leave the Ad-
ministration
mode.
Unlock/Lock door
Unlock door Press A1A. Enter the
group code
stored as the
9th code (four
digits).
Lock door Press A0A. Enter the
group code
stored as the
9th code (four
digits).
Buzzer enable/disable
Disable buzzer Press B. Enter the
6-digit Admin-
istrator code.
Press A65. To enable
press 0. Press B to leave the Ad-
ministration
mode.
Enable buzzer Press B. Enter the
6-digit Admin-
istrator code.
Press A65. To disable
press 1. Press B to leave the Ad-
ministration
mode.
Erase memory
Erase memory Remove the
CD30 from
the door.
Press the re-
set button on
the back of
the CD30.
Press
112186. Press 112186.
