2Overview
2.1Introduction
Thank you for choosing Vantron. It is our commitment to provide our valued customers
with the embedded devices equipped with the state-of-the-art technology and the best
product services.
Tablet enables the interaction between operators/users and applications, connecting
industrial control products suchas wireless, transducer, battery inside, storage, etc. Tablet
adopts a display for displaying and input units such as touch screen, keyboard, audio,
kind of sensors etc. for writing working parameters or inputting operation commands. As a
digital device for realizing information interaction between human and machine, Tablet is
composed of hardware and software. Based on its ample functioninterfaces and powerful
user operational interface, it is very suitable for control units such as medical device,
intelligent transportation, industrial field, etc.
Vantron’s VT-Tablet products are based on the most advanced ARM, Rockchip
processors and have low-power consumption and high integration. The products are
designed for applications such as industrials, medicals, and transportations etc.

IQ Hub v1.1
9/ 22
2.2Ordering Information
CPA-G1A-UNA4
7’ TFT LCD
1024*600
RK-3368H, Octa-core 1.5GHz
Speaker and MIC
3.7V/2600mAh battery
WIFI/BT
Z-wave
LTE-1
SRF
Note: LTE modules cannot transmit with other wireless Function at the same time.

IQ Hub v1.1
10/ 22
3IQ HubHardware Instructions
3.1Product Appearance
Front View
Back View

IQ Hub v1.1
11/ 22
3.2Specifications
CPU
Processor
RK-3368H , ARM Octa-core
Cortex-A53, Quad Core CPU,1.5GHz
Memory
RAM
2GB LPDDR3
Flash
16GB EMMC Flash
Display
LCD
7" TFT LCD
Resolution
1024*600 24bit Color
Display Colors
16.7M
Brightness
300cd/m2
View Angle
85U/85D, 85L/85R
Touch Screen
Cap-touch, multi-point
Supported
format
Audio
MP3, 3GPP, WAV
Video
MP4, 3GPP
BMP, GIF, JPEG, PNG
Interface
Wireless
1xwifi 802.11a/b/g/n/ac,
1xBluetooth4.2
1x Z-wave
1x LTE
1x SRF
Internal Audio
Internal Speaker, Buzzer
Internal MIC
RTC
Supported
10-85%RH
(Non-Condensation),
operating and
storage
Supported
LED
Bi-color LED (Green and Red)
Software
OS
Android 7.1+
Power
Battery
3.7V, 2600mAh

IQ Hub v1.1
12/ 22
DC Power Supply
12V,1.0A
Mechanical
Dimensions
196.4x155x25.6mm
Weight
0.65 Kg
Environment
Condition
Temperature
Operating Temperature: 0℃~ +40℃
Storage:-30℃~ +70℃
Humidity
10-85%RH(Non-Condensation),
operating and storage
3.3Interface Instructions
Front View
MIC
Bi-color LED
Speaker

IQ Hub v1.1
13/ 22
Back View
3.4Dimension
Whole device Size: 196.4x155x25.6mm
3.5Power/Sleep/Wake Button
Power/Sleep/Wake Button
When you are not using the panel, you can turn off the display by press button
Lock tablet
Press the Power/Sleep/Wake button
Unlock tablet
Press the Power/Sleep/Wake button to wake from sleep, then drag the slider.
Turn tablet on from power-off
Press and hold the Power/Sleep/Wakebutton until logo appears.
Never apply excessive pressure to a button, because this may cause
unexpected damage that is not covered under the warranty
Tablet cannot be turned off by pressing the button
DC Jack
Power/Sleep/
Wake button
Buzzer

IQ Hub v1.1
14/ 22
3.6Interface Description
3.6.1 MIC
Internal MIC with outstanding sensitivity and high SNR makes it very suitable for recording while
suppressing the environment noise.
3.6.2 WIFI and BT
The tablet supports 802.11 a/b/g/n/ac WiFi and BT 4.2. With a good performance internal
antenna, both WIFI and BT can achieve better connectivity.
3.6.3 Z-wave
The tablet has the function of Z-wave connectivity so we can use it in a lot of aspects such as
access control, appliance control, AV control, building automation, energy management, lighting,
security, and sensor networks for the “Internet of Things”.
3.6.4 LTE
The tablet supports LTE Cat 1 function, delivering M2M-optmized speeds of 10Mbps downlink
and 5Mbps uplink. And it features ultra-low power consumption which can extend the battery
lifecycle without DC adapter plugging in. (Report reference FCC ID:XMR201909EG91NAX)
3.6.5 Z-wave and SRF
RF Card, 908MHz - 916MHz,319.5MHz(Report reference FCC ID:2AAJXQS-SRF319)
3.6.6 Speaker
The tablet has an internal 1 watt speaker
3.6.7 Buzzer
There is a high SPL buzzer in tablet. It features high sound when turned on
3.6.8 Gas Gauge
A gas gauge is used to monitor the capacity of the li-polymer battery so we can figure
out the status of it precisely and immediately
3.6.9 FrontCamera
The tablet has the ability to take beautiful photo and record the high resolution video.
3.6.10 RTC
The tablet has internal RTC so the system time can keep a long time if we didn’t turn it
on.

IQ Hub v1.1
15/ 22
3.7Packing List
No
Part Description
Quantity
Remark
1
CPA-G1A-UNA4
1 PCS
Power adapter
Table stand
Wall mount bracket

IQ Hub v1.1
16/ 22
4Software Instructions
4.1Brief Introduction
IQ Hub has been pre-loaded with Android image, so that the system can run
Androidtool to flash the system image

IQ Hub v1.1
17/ 22
5Safety Instruction
This section provides warnings that precede potentially dangerous procedures throughout this
manual. Instructions contained inthe warnings must be followed during all phases of operation,
service, and repair of this equipment. You should also employ all other safety
precautionsnecessary for the operation of the equipment in your operating environment. If you
are not sure about the precautions applicable to your operating environment, please contact your
company’s safety administrator. For basic information you may also refer to the safety
precautions per IEC704-1 listed below although Vantron disclaims all responsibility for the
accuracy of any state- ments contained therein and its applicability for your specific
environment.Failure to comply with these precautions or with specific warnings elsewhere in this
manual could result in personal injury or damage to the equipment.
Vantron intends to provide all necessary information to install and handle the IQ Hub in this
manual. Because of the complexity of this product and its various uses, we do not guarantee that
the given information is complete. If you need additional information, contact your Vantron
representative.
The product has been designed to meet the standard industrial safety requirements. It must not
be used except in its specific area as specified in product specification.
Only personnel trained by Vantron or persons qualified in electronics or electrical engineering is
authorized to install service or maintain the product. The information given in this manual is
meant to complete the knowledge of a specialist and must not be used as replacement for
qualified personnel. Operating personnel must not remove equipment covers. Only factory
authorized service personnel or other qualified service personnel may remove equipment covers
for internal subassembly or component replacement or any internal adjustment.
Do not install substitute parts or perform any unauthorized modificationof the equipment or the
warranty maybe voided. Contact your local Vantronrepresentative for service and repair to make
sure that all safety features are maintained.
Safety Precautions per IEC704-1
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.

IQ Hub v1.1
18/ 22
3. Disconnect this equipment from anyAC outlet before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must
be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may
cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
9. Positionthe power cord so that people cannot step on it. Do not place anything over the
power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. Forsafety reasons, the equipment should be opened only by
qualified service personnel.
14. If one of the following situations arises,get the equipment checked by service personnel:
*The power cord or plug is damaged.
*Liquid has penetrated into the equipment.
*The equipment has been exposed to moisture.
*The equipment does not work well, or you cannot get it to work according to the user's
manual.
*The equipment has been dropped and damaged.
*The equipment has obvious signs of breakage.
15. DONOT LEAVETHIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE
TEMPERATURE MAY GO BELOW -20°C (-4°F) OR ABOVE 60°C (140°F). THIS COULD
DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A CONTROLLED
ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.
REPLACEONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE
MANUFACTURER, DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER'S
INSTRUCTIONS.
The sound pressure level at the operator's positionaccording to IEC 704-1:1982 is no more than
70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1.Advantech disclaims all
