Vantrue S1 User manual

User Manual
OnDash S1
Dual Dash Cam
骑马钉
单页尺寸：103*145MM
封面：157G双铜纸过哑胶
内页：100G双胶纸

- 1 -
www.vantrue.net/contact facebook.com/vantrue.live
f
Always a surprise in Vantrue
Hey, find us here:

- 2 -
What’s in the box?
Was ist in der Box?
Qu'y a-t-il dans la boîte?
付属品を確認する？
Camera Overview
Die Übersicht über Kamera
Vue d'ensemble de la caméra
各部の名称とはたらき
Getting Started
Vorbereitung vor dem Einschalten
Préparation avant la mise en marche
入門
Basic Operation
Grundlegende Operation
Opération de base
基本的な使い方
Specifications
Spezifikationen
Spécification
製品仕様
Warranty & Support
Garantie und Unterstützung
Garantie et support
保証とサポート
VERZEICHNIS
CONTENU
1.
2.
3.
4.
5.
6.
3
26
50
75
4
27
51
76
6
29
54
78
10
33
58
83
23
47
72
96
24
48
73
97

- 3 -
1. What’s in the box?
A. Car Charger with Built-in
Mini USB Cable (10ft)
B. VANTRUES1 Dash Cam
C. Rear camera
D. Adhesive Sticker
E. Rear camera Bracket
F. Front Camera Bracket
G. USB Data Cable (3ft)
H. Rear Camera cable (20ft)
I. S1 Dash Cam User Manual
J. Quick Start Guide
K. Warranty Card
A
B
C
DE
F
G
H
IJK

- 4 -
2. Camera Overview
NO. Name Description
1
2
3
4
Microphone
Menu Button
MicroSD
Card Slot
Up Button
Records clear audio with the video footage.
Enter/exit setup menu.
Provides expandable storage.
Stop/Start the video recording; Move selector
up; Slow forward when playing back videos.
5 Screen Switch For single lens version, press it to change the
resolution. For dual lens version, press it to
switch 3 screen view option.
6 Down Button Move selector down; Microphone on/off.
Fast forward when playing back videos.
12
3
46
7
8
5
9
10
12
13
14
15
11
19
20
18
16
17
21
7 OK Button Confirms the action; Manually locks the
currently recording video clip following
emergency or to preserve important videos;
Snapshot; Long press to enter Parking Mode
when the camera is recording.

- 5 -
LED Indicator
Red light blinks on the
UP button [4]
Red light light on the
Down Button [6]
Camera is recording
Camera is Charging
9 Front dash cam
clip socket Connects to the dash cam bracket.
10 Speaker Delivers sound during video playback.
11 Front Camera
Lens Front facing F1.47 170°wide camera for video recording. Its angle can be adjusted.
12 USB port Use the car charger to supply DC 5V power
for device.
13 Rear Lens Port Use the rear camera cable connecting
the rear camera.
14 Reset Button Press to force reset the device.
15 Power Button Power ON/OFF; Short press to screen off / on.
16 Rear Camera
Lens Port Use the rear camera cable connecting the front camera.
17 Image Flip
Switch Toggle this switch to select the horizontal direction of the rear lens display as positive
or mirror.
18 Rear Lens Rear F1.8 160°wide camera for video
recording. Its angle can be adjusted.
19 Rear camera
Click Socket Connects to the rear dash cam bracket.
20 Lens knob Turn the knob to adjust the camera angle.
21 LED Status
Indicator Red light light on once connect the front camera.
8 Radiator To prevent the dash cam from
overheating in working state.
Red light light on the Rear Camera
LED Status indicator [22]
Rear Camera is recording.

- 6 -
A. Charge using the supplied USB Car Charger
3. Getting Started
3.1 Before first use, charge the camera for 4 hours.
Screen overview
00:00:16
14:42:252019/04/10
000MPH
EV
0.0
1920x1080P 30FPS
HDR
3
Loop Recording Time
G-Sensor OFF
G-Sensor ON
Recorded Driving Speed
(KMH or MPH)
Exposure
Value
Memory card inserted
NO Memory card inserted
MIC is ON
MIC is OFF
Emergency File Lock
Parking Mode
Video Resolution
HDR Mode on
Snapshot
Recording
Recording Time
(current clip)
POWER BANK USB Charger
GPS Signal Connecting
GPS Signal Locked

- 7 -
3.2 Installing memory card ( Please Don’t use Sandisk SD card,
Recommend Samsung Pro Endurance Card or Samsung
Evo Card ).
b. Ensure the Mini USB Cable and Car Charger are well connected
NOTE: When charging via computer with the mini USB cable, “Mass
Storage” and “Power On” will be displayed on the camera screen,
please select“Power On” to charge the dash cam.
NOTE: To insert the card, power off the camera first, then push the
card into the slot until it clicks again, otherwise the dash cam will
say goodbye and shut off. To remove the card, power off the
camera first too.
Pleaseuse a genuine microSD memory card with a speed rating of
class 10 or higher. We recommend Samsung Pro Endurance cards
or Samsung Evo cards. Samsung Micro SD cards would only be
made in either Korea or the Philippians. Please be sure to buy a
genuine Samsung card.
NOTE: When using a 64GB MicroSD card, please format it to FAT32
on the camera first.
Please insert the card into the camera. If it says 'NO SD Card
Inserted !' or 'error card please format' here, please press the UP
button and then press
the M button to access into the menu, go
'system setup' and choose
'Format SD Card'. Then choose the OK
section and wait for few seconds.
Then the card will be formatted successfully.
(If you format it on computer, please search online on "How to
format 64GB micro SD card to FAT32".）

- 8 -
REMINDER:
1. Install the bracket on the front dash cam .
2.
3.3 Installing the camera onto your windshield
3.
The MicroSD card should be formatted every 2 weeks to
maximize the lifetime of the memory card.
Please do not take the card out when the camera is recording
in case that the important video files missing.
2.
1.
Thoroughly clean the windshield using water or alcohol, and
wipe clean with a dry cloth.
Tear off the 3M tape, stick the Front Dash cam behind rear
view mirror, which is the suggested position, to make sure the
driver’s front view is no impact.

- 9 -
4. 5.
6.
7. 8.
vehicle’s cigarette
lighter port
Carefully route the power cable
around the windscreen and tuck
it under the trim.
Use the rear camera cable
connecting the rear camera to
the rear lens port of the device,
carefully route the cable and
tuck it under the trim.
Install the bracket on the rear dash cam, tear off the rear camera
3M sticker and stick it on the back windscreen.
With the Mini USB Cable,
connect the supplied Car
Charger to the Camera into
the device power interface.
Insert the Car Charger into
your vehicle’s cigarette
lighter port.
