Varytec Hero Wash 640FX User manual

Hero Wash 640FX
moving head
User manual

Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
Internet: www.thomann.de
24.03.2022, ID: 477541

Table of contents
1 General information.............................................................................................................. 5
1.1 Further information........................................................................................................ 5
1.2 Notational conventions................................................................................................. 5
1.3 Symbols and signal words........................................................................................... 6
2 Safety instructions................................................................................................................. 7
3 Features....................................................................................................................................... 9
4 Installation.............................................................................................................................. 10
5 Starting up............................................................................................................................... 12
6 Connections and controls................................................................................................ 13
7 Operating................................................................................................................................. 15
7.1 Starting the device....................................................................................................... 15
7.2 Main menu...................................................................................................................... 15
7.3 Operating modes.......................................................................................................... 16
7.4 Settings............................................................................................................................. 19
7.5 System information...................................................................................................... 23
7.6 Menu overview.............................................................................................................. 24
7.7 Functions in 13-channel DMX mode..................................................................... 25
7.8 Functions in 25-channel DMX mode..................................................................... 26
7.9 Colour macros................................................................................................................ 28
8 Technical specications.................................................................................................... 29
9 Plug and connection assignment................................................................................. 31
10 Troubleshooting................................................................................................................... 32
11 Cleaning.................................................................................................................................... 33
12 Protecting the environment........................................................................................... 34
Table of contents
Hero Wash 640FX 3
moving head

4Hero Wash 640FX
moving head

1 General information
This user manual contains important information on the safe operation of the device.
Read and follow all safety notes and all instructions. Save this manual for future refer‐
ence. Make sure that it is available to all persons using this device. If you sell the
device to another user, be sure that they also receive this manual.
Our products and user manuals are subject to a process of continuous development.
We therefore reserve the right to make changes without notice. Please refer to the
latest version of the user manual which is ready for download under
www.thomann.de.
1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and
details on the following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the
topics of interest for you quickly.
Online guides Our online guides provide detailed information on technical
basics and terms.
Personal
consultation
For personal consultation please contact our
technical hotline.
Service If you have any problems with the device the
customer service will gladly assist you.
1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
References to other locations in this manual are identied by an arrow and the speci‐
ed page number. In the electronic version of the manual, you can click the cross-
reference to jump to the specied location.
Example: See
Ä ‘Cross-references’ on page 5.
Letterings
Displays
Cross-references
General information
Hero Wash 640FX 5
moving head
