U87-AA-Be/U85-AA-Re
Air Steerable Agile
Let’s get started

Let’s talk safety
Basic
safety
precautions
Don’ts
Do’s
This vacuum cleaner is intended for household use only and
NOT for commercial or industrial use.
•
Only use the vacuum cleaner indoors on dry surfaces and keep
the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts
and openings whilst using the vacuum cleaner.
• Don’t use this vacuum cleaner if it has been dropped, damaged
or left outdoors.
• Don’t run over the power cord or use vacuum cleaner if the power
cord or plug is damaged. Please contact our Customer Care Line on:
0330 026 8455 (Mon-Fri 8:30am to 6:30pm, Sat 9:00am to 5:00pm).
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
Don’t use the power cord as a handle, pull the power cord around
corners, sharp edges or close a door over the power cord.
• Don’t unplug vacuum cleaner by pulling on the power cord.
• Turn o all controls on the vacuum cleaner before disconnecting
or connecting the plug from the mains socket.
• Always keep the power cord away from the brushes during use.
• After use always wrap the power cord around the cord clips provided.
• Always make sure both the pre-motor/post-motor lters are
in place before use.
• Always ensure the brushbar is switched o when using the
vacuum cleaner on the stairs and take extra care when positioning
the vacuum cleaner on the stairs.
• Always switch o the vacuum cleaner before disconnecting
or connecting the hose and accessories.

• This vacuum cleaner can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction
concerning use of the vacuum cleaner in a safe way and understand
the hazards involved. Children shall not play with the vacuum cleaner.
Cleaning and user maintenance shall not be made by children without
supervision. Only Vax recommend tools should be used with this vacuum
cleaner, use of non-branded Vax accessories/tools will invalidate your warranty.
• Don’t vacuum up any ammable or combustible materials (lighter uid,
petrol, kerosene etc.) or use the vacuum cleaner in an area with explosive
vapours or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause damage
to your vacuum cleaner, remove blockages only as instructed in this guide.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws or coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.
• Turn o all controls on the vacuum cleaner before disconnecting
or connecting the plug from the mains socket.
• Always keep the power cord away from the brushes during use.
• After use always wrap the power cord around the cord clips provided.
• Always make sure both the pre-motor/post-motor lters are
in place before use.
• Always ensure the brushbar is switched o when using the
vacuum cleaner on the stairs and take extra care when positioning
the vacuum cleaner on the stairs.
• Always switch o the vacuum cleaner before disconnecting
or connecting the hose and accessories.
• Keep all openings clear and free from debris as this may aect the
airow/suction.
• Always replace the fuse in the plug with a British 13amp fuse. Always protect
the power cable from heated surfaces and open ames.
• Use only CE approved 13amp extension cords, non-approved extension cords
may overheat. Care should be taken to arrange the extension cord as it can
be a trip hazard.
• Store your vacuum cleaner in a cool, dry area. If the lters have been cleaned as
per user guide instructions ensure they are thoroughly dry before storing away.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY
AS INSTRUCTED IN THIS GUIDE.

Thank you for buying this Air Steerable Agile.
Taking care of your carpets and hard oors
The Air Steerable Agile is designed to make vacuuming carpets and hard oors regularly,
as eective and ecient as possible and this user guide will help you get the most out
of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer.
You’ve chosen the carpets and hard oors for your home for a reason and Vax will help
you take good care of them.
Taking care of your Air Steerable Agile
Also inside this guide are instructions on maintaining your new vacuum cleaner, so that it’s
always ready when you are to tackle your carpets and hard oors.
Let us know what you think @VaxUK
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich,
Worcestershire, WR9 0LW, UK
This user guide can be found online at: vax.co.uk/support

Contents
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
What to do if it goes wrong
Getting in touch
Air Steerable Agile
(Included with all models)
2-in-1 Crevice Tool
and Dusting Brush
Included with
your machine
Pre-motor Filter
Post-motor Filter
Initial Setup for normal operation
1. Use the base accessories.
– Shortest hose.
– Extension tube set to shortest practicable length.
2. Clean lters installed.
3. Dust receptacle empty.
4. All Bleeds must be closed.
5. Floor heads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation set turned ON for carpet cleaning.
7. Floor heads/tools set to Hard Floor Mode for hard oor cleaning.
8. Mechanical Agitation set turned OFF for hard oor cleaning.
Air Steerable Agile
Reach
Stretch Hose
TurboTool
+

Subject to technical change without notice.
Handle
Dirt container
release button
Brushbar blockage
indicator
Rotating brushbar
Carry handle
Power On/O button
Inner cyclones
Dirt container
Post-motor lter cover
Getting to know your machine
Name Air Steerable Agile
Voltage See rating label on machine for details
Wattage See rating label on machine for details
Cord length 6m/8m
Weight 4.5kg
Technical Specication
Pre-motor Filter (Type 58)
1-1-131167-00
Post-motor Filter (Type 100)
1-1-134235 -00
2-in-1 Tool (Type 2)
1-1-132115-00
Belt Kit (Type 26)
1-1-134530-00
TurboTool (Type 5*)
1-1-134418-00
Accessories & Consumables
* Selected models only.
To purchase consumables and accessories, please visit vax.co.uk
Stretch hose
Quick release
cord wrap
Wheels
Handle release button
Brushbar On/O button
Telescopic
extension tube

PLEASE READ SAFETY INFORMATION BEFORE USE
Before plugging the cord into the electrical outlet, make sure the switch is in the ‘o’ position.
Hold the vacuum cleaner rmly when starting and in use.
Assembling your upright
Getting started
1. Remove all packaging.
2. Insert the handle.
Attach the hose end to the oorhead ensuring it
clicks into place. (All accessories can be used by
either attaching them to the handle or the hose).
How to use
Twist the cord holder
to release the cord.
Plug in your machine
and turn it on.
For brushbar position, press the
brusbar On/O button at the top
of the unit.
Brushbar on — carpets.
Brushbar o — hard oors.
Recline the unit and
twist the handle to
manoeuvre under and
around furniture.
Don’t over ll the
container to avoid
clogging your lters.
Max
ll

Using your machine
Remove hose.
Remove extension tube.
Attach required tool
to the hose.
Attach hose to
extension tube.
Attach accessory to
extension tube.
IMPORTANT: Hold vacuum
cleaner when using hose
or extension tube for above
oor cleaning.
Hose
Telescopic extension tube
TIP
The 2-in-1 tool can be attached
to the tube or directly to the
hose. Switch o the brushbar
before using any accessories/
hose/telescopic extension tube.

Using your machine
Taking care of your machine
Emptying and cleaning the dirt container
Press dirt container
release button to remove
the dirt container.
Hold dirt container over a bin
and press dirt release button to
open, allowing dirt to fall out.
Lift lid to access
inner cyclones.
Tap
Lift out the inner cyclones.
Hold cyclones/separator over
bin and tap to remove dirt
and debris.
IMPORTANT: Filters require cleaning at least every three months.
Do not use your vacuum cleaner without all of the lters in place.
IMPORTANT: The motor is equipped with a thermal cut-out. If for any reason the unit should overheat,
the thermostat will automatically turn o. For further help go to the ‘what to do if it goes wrong’ page.
CAUTION
Always switch o and unplug
the vacuum cleaner from
the electrical socket before
assembling, opening or emptying
the dirt container, or before
connecting/disconnecting
the attachments.

Taking care of your machine
Unclip the dirt container lid
to open.
Remove the post-motor
lter by unclipping it from
the body of the vacuum.
IMPORTANT: The exhaust lter is designed to oer long life with no maintenance. The lter should be checked
periodically and when heavily discoloured it should be replaced. Please do not wash, scrub or brush the lter
as this will damage the delicate lter media.
Cleaning the pre-motor lter
Post-motor lter maintenance
Lift lid to access lter.
Check the post-motor lter
for discolouration.
Remove lter.
Tap
Tap lter clean. Wash in water 40˚C max and
leave for at least 24 hours or
until dry before replacing into
the machine.
24hr
40°C
max
!
40˚C
MAX
24hr

Taking care of your machine
Let’s talk technical
Using a crosshead
screwdriver, remove
3 screws from the side
of the oorhead.
Pull to remove the
brushbar location plate.
Remove belt.
Lift and separate
brushbar side cover.
Pull brushbar through
brushbar side cover to remove.
PULL
Changing the brushbar
Pull to remove the
end cap belt cover.
IMPORTANT: If the air inlet, hose or telescopic tube is blocked, switch o the vacuum cleaner and
remove the blockage(s) before re-starting the vacuum cleaner.
IMPORTANT: Unplug and switch o vacuum cleaner before maintenance or troubleshooting checks.
Removing debris from the brushbar
Switch o your vacuum cleaner
at the main socket. Using a pair
of scissors, cut any hair or debris
free from around the brushbar.
A RED light will indicate
a jammed brushbar.
A GREEN light indicates no
blockages in the brushbar.

Let’s talk technical
Using a crosshead
screwdriver, remove
3 screws from the side
of the oorhead.
Pull to remove the
brushbar location plate.
Remove and dispose
of old belt.
Clean any debris from
spindle. Place new belt
onto spindle, lining up
teeth on belt over and
onto cog.
Changing the belt
Pull to remove the
end cap belt cover.
Removing blockages from the TurboTool*
Tabs
Slide the locking ring
to remove.
Lift and separate
the housing.
Using a pair of scissors,
remove any threads
or hair caught around
the brushbar.
Line up the tabs on front of
housing and push together
to ret. Slide locking ring
into groove to secure.
IMPORTANT: Unplug and switch o vacuum cleaner before maintenance or troubleshooting checks

Let’s talk technical
Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Pro cleaning kit (Type 2)
1-1-133326-00
All our best tools all in one kit that makes
cleaning your home quicker, easier and
with even better results. We’ve taken
care of cleaning all of the hard to reach
areas such as on top of cupboards and in
between blinds to the dust that collates
behind and within the radiator.
TurboTool (Type 6)
1-1-134418-00
A TurboTool for your vacuum cleaner.
Use the TurboTool for vacuuming your stairs,
upholstery and car interiors. It’s great for picking
up stubborn pet hair.
Stretch hose (Type 2)
1-1-132988-00
A stretch hose for your vacuum cleaner.
This hose makes it easy to clean right
to the top of your staircase, leaving the
machine safely at the bottom.

What to do if it goes wrong
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always
replace with a 13amp fuse.
• The motor thermostat may have tripped. If this has happened,
unplug the vacuum cleaner. Remove and empty the dirt container
and check the hose for blockages. Clean the lters and allow
the vacuum cleaner to cool for approximately 1 hour (if you have
washed the lters you will need to wait 24 hours for the lters
to fully dry before putting them back into the vacuum cleaner).
• There may be a blockage in the hose. Please remove the hose
from the vacuum cleaner, check and clear any blockages.
• Empty the dirt container and clean lters. Go to the ‘Taking care
of your machine’ pages.
• The brushbar may not be turning. Go to ‘My brushbar isn’t
turning?’ below.
• If the accessory/tool will not pick up, check and clear
any blockages.
• If the vacuum cleaner is making a whistling noise, please
remove the dirt container open the bottom and clean the seals.
Replace the dirt container and retry.
• If there is an air sucking noise from the top of the dirt container,
this would indicate a blockage in the machine. Go to ‘Why does
my vacuum cleaner have no power?’ above.
• The brushbar may not be switched on, please check the brushbar
On/O switch.
• If the vacuum cleaner is not reclined the brushbar will
automatically switch o.
• If the red light is ashing the brushbar may be jammed. Clear any
blockages for further help go to the ‘Let’s talk technical’ pages.
• To check the belt, go to ‘Changing the belt’ on the ‘Let’s talk
technical’ pages.
SolutionProblem
CAUTION:To reduce the risk of personal injury, unplug the vacuum cleaner before performing
maintenance/troubleshooting checks.
Why does my vacuum
cleaner have no power?
Why won’t the vacuum
cleaner turn on?
My brushbar
isn’t turning?
My vacuum cleaner
is making an
excessive noise?

* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
†Registration required. Terms and conditions apply, see vax.co.uk for details.
Getting in touch

Vax Ltd. Vax Ltd., 5th Floor 2 Colmore Square, 38 Colmore Circus, Queensway, Birmingham, B4 6BN, UK
email: inf[email protected] website: vax.co.uk
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility,
declare that the U87-AA-Be/U85-AA-Re is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive. EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
© 2014 All rights reserved. VAX®, VAX Lozenge, are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
@VaxUK
