VAXIS ATOM 500 User manual
VAXIX ATOM 500
Usermanual
Dearusers:
Thank you very much for choosing ATOM 500
wirelessvideotransmissionequipment.Thisproduct
adopts h.265 image coding and decoding technology
and 5g wireless transmission technology.Realize low
delayandhighqualityvideotransmission.We
sincerely hope that you can enjoy the long‐term
convenienceofusingtheproductandwishyouthe
bestexperiencefromtheproduct.
Alltheinformationcontainedinthismanualhasbeen
strictlyverifiedtobecorrectatthetimeofpublication.
However, due to the continuous upgrading and
improvement of the product, we hope that your
equipment and use may be different from the
descriptioninthismanual.Forthis,wehopeyouwill
take the actual product as the standard, and welcome
youtocallourservicephoneforconsultation.
■Main features:
Stable transmission distance 100m
Highest resolution 1080p 60,60-100ms delay
Built in antenna , easy to install and use
Support mobile APP monitoring and password protection
Support HDMI loop out
up to 9 free frequency switching options
OLED screen display the current channel,powerstatus,signalstength
Support USB type C andSony F97 battery power supply, meet the
needs of various environments
Any input and output ports with ±4 kV ESD protection level (HBM,
contact discharge)
Application scenario
Film shootingEducational recording and broadcasting
Live broadcastwedding ceremony
Sports eventsEnterprise activity
Packing list
Transmitter*1
Receiver*1
user'smanual*1
Expandingaccessories*1
Coldbootplatform*1
Type‐Cpowercord*1
Hexagonwrench*1
1
Introduction
Thank you for choosing our long-range wireless HDMI products.
Before you install the product, please read the user manual carefully
and follow the manual of the user manual to avoid product damaged
or other safety accidents.
Due to product version upgrade or other reasons, the contents of this
manual will be updated from time to time. Unless otherwise agreed,
this manual is used only as a guide, and all statements, information
and recommendations in this manual do not constitute any guarantee
either express or implied.
■Name of the product parts
Transmitter:
2
①Power switch
②Screen display
③HDMI Output
④HDMI Input
⑤Type-C DC Input
⑥Direction button1
⑦Direction button2
⑧Menu button
⑨Installation of extension accessories
Receiver:
3
①Power switch
②Screen display
③HDMI Output
④HDMI Output
⑤Type-C DC Input
⑥Direction button1
⑦Direction button2
⑧Menu button
⑨Installation of extension accessories
■Parameters:
4
Operation guide
1. Frequency switching
Transmitter Receiver
Interface HDMI input(Type A Female),
Output(Type A Female),Type-C
interface
HDMI Output 1(Type A Female),
Output 2(Type A Female),Type-C
interface
Supply Voltage
Range
5V DC 5V DC
Power consumption <6.5W <4.5W
Size (LxWxH):105x64x28mm (LxWxH):105x64x28mm
Mass 134g 130g
Input Video Format HDMI:
720p59.94/60,
1080i 50/59.94/60,
1080p23.98/24/25/29.9/30/50/59
.94/60;
/
Output Video
Format
/ HDMI:
720p59.94/60,
1080i50/59.94/60,
1080p23.98/24/25/29.9/30/50/59.9
4/60
Signal Indicator OLED Display OLED Display
Frequency Band 5150MHz-5250MHz
5725MHz-5850MHz
5150MHz-5250MHz
5725MHz-5850MHz
Transmitted Power Maximum 17dBm Maximum 17dBm
Occupied
Bandwidth
20MHz(802.11 a/n) 20MHz(802.11 a/n)
Temperature Range 0~40°C(operating condition);
-20~60°C(Storage)
0~40°C(operating condition);
-20~60°C(Storage)
Compliance FCC;CE. FCC;CE.
5
Press the transmitter "direction key" to switch the frequency
point, press the menu key to confirm the frequency point, and
the receiver will automatically switch the connected
frequency point synchronously. No frequency point switching
function of receiver.
2. Apppasswordmodificationmethod
Press "menu" key for menu interface, switch to "PWD <
current >", click "menu" to confirm, switch to "new", click
"menu" to confirm, wait for about 10s. (Note: password can be
modified when TX and Rx are in normal connection state)
3. Fan regulation mode
Press and hold the direction key for 3S to enter the fan
adjustment selection menu, and select "FAN LOW","FAN
HIGH""FAN AUTO""FAN OFF". (Note:Fan off can only be
turned off for 5 minutes at a time)。
4. APP monitoring switch mode
Press and hold the menu key on the menu interface of the
transmitter, and switch to app < on > L, which is on by default.
Click to switch to < off > to close the app connection
5. App installation and use
6
①App name is "vaxis vision" ，Download in app storeg
②Usage method
a． Open app "vaxis vision" to select the connection
device
b． Long press TX menu key for 3S, switch to SSID,
and input WiFi name (VX a00001) to app
c． The TX menu is switched to PWD<CURRENT>,
and the 8-digit number displayed is WiFi
password. Input it to app and click Connect.
Common troubleshooting
1. Connectionexception
a. PleasecheckwhetherTX/RXpowersupplyisnormal
b. WhenRXisalwaysdisplayedaslink,pleaserestartTXRX/
switchtoacleanfrequencypoint
2. Displayabnormalproblems
a.PleasecheckwhetherthevideosourceisconnectedtoHDMI
incorrectly
b. Pleasecheckwhetherthesignalformatcanbenormally
7
displayedontheOLEDscreen
3. Videopicturejam
a.Pleasecheckwhetherthesignalqualitydisplayedbythe
receiverisgood.Ifthesignalisweak,pleaseswitchthe
frequencypointorshortenthewirelessconnectiondistance
b. Ifitisimpossibletodeterminewhichchannelhaslow
environmentalinterference,pleaserestartTXandselecta
cleanerchannelforautomaticfrequencysweep
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
8
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/ TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure
limits, Human proximity to the antenna shall not be less than 20cm (8 inches) during normal
operation
This equipment mush not be colocated or operating with any other antenna or transmitter.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
