VBC Racing Lightning 10M 235 User manual

COMPETITION GRADE HIGH PERFORMANCE RADIO CONTROL RACING CAR CHASSIS KIT
1/10 SCALE ELECTRIC COMPETITION CAR KIT
E
INSTRUCTIONS MANUAL
5
Thank you for purchasing VBC Racing product.
This VBC Racing kit is a high performance, racing grade car kit
intended for experienced racers. The kit compose of VBC
formulated composite materials, top quality full carbon fiber
chassis and high grade 7075 material which will give you a
competitive edge over the others.
Novice racer should seek advice from more experienced racer
before assembly.
Always keep this instruction manual handy at all times for quick
reference even after completing the assembly.
Before your assembly, sand the chassis edges.
Things that we should remind you.
Sand the chassis edges with #600 sand paper and apply CA
glue to the edges and counter sink holes.
Need help or support.
If you need help or you would like to leave us a comment,
please email to our support team: [email protected] or
visit our web site www.vbcracing.com

BAG MARKED
STEP1
1
Graphite Edges Protection Procedure
01© VBC Racing LIGHTNING10M235
CA
Sand the chassis edges with #600 sand paper(not included) and
apply CA glue(not included) to the edges of the chassis.
Sand the below graphite edges with #600 sand paper and apply CA glue to the edges.
*Not included in this kit
A-01-P51395 Lightning10M 2.5mm Graphite Main Chassis
A-01-P51398 Lightning10M Rear Tweak Plate
A-01-P51396 Lightning10M 235 Graphite Lower Pod Plate

BAG MARKED
02© VBC Racing LIGHTNING10M235
Pivot Brace D-05-VBC-0101 x 1
Pivot Brace Cover D-05-VBC-0101 x 1
Pivot Balls A-03-VBC-1027 x 5
M3x6 Flathead C-02-SC-F0306 x 5
Pivot ball shoulder should be facing downwards
Pivot Brace
Pivot Brace Cover
M2x6 Cap Head Use screws to adjust the
play of the piviot ball Movement. Do not
overtighten to avoid stripping
M2x6 Cap Head C-02-SC-R2.0x6 x 2
STEP2-5
02
2
Pivot Brace Assembly Part 1
M3x6 Flathead
Pivot Balls
Pivot Balls

BAG MARKED
03© VBC Racing LIGHTNING10M235
M3x10 Flathead C-02-SC-F0310 x 2
M2x6 Cap Head C-02-SC-R2.0x6 x 4
Pivot Brace Assembly Part2
STEP2-5
Lightning Pod Link Set
2
Rear Bulkhead Assembly Part1
3
M3 Locknut C-02-SC-NN03 x 2
Tighten each side screw
slowly, Make sure the lower pod
plate can rotate freely.
03
Note the direction screw in from
the larger hole side
03
M2x6 Cap Head
M2x6 Cap Head
M3x10 Flathead
M3x10 Flathead
M2x6 Cap Head
M2x6 Cap Head
M3 Locknut
M3 Locknut
Lightning Pod Link Set
Make sure direction
Make sure direction Make sure direction
Make sure direction
M3x6 Flathead
M3x6 Flathead

04
© VBC Racing LIGHTNING10M235
BAG MARKED
STEP2-5
3
4
M3x6 Flathead C-02-SC-F0306 x 2
Chassis Brace Assembly
14mm Aluminum Standoff B-02-VBC-5073 x 2
Side Spring (Medium/Gold) A-03-VBC-1047 x 2
Aluminium Side Spring Retainer B-02-VBC-5074 x 2
M3x6 Roundhead C-02-SC-R0306 x 2
M3x8 Set Screw C-02-SC-SS-0308 x 2
A-01-P51398 Lightning10M Rear Tweak Plate
Aluminium Side Spring Retainer
Aluminium Side Spring Retainer
M3x6 Roundhead
M3x6 Roundhead
M3x8 Set Screw
M3x8 Set Screw
Side Spring
Side Spring

BAG MARKED
STEP2-5
05
© VBC Racing LIGHTNING10M235
4
05
STEP2-5
Lightning 10M235 Graphite Rear Shock Mount A-01-P51397 x 1

BAG MARKED
STEP2-5
06
© VBC Racing LIGHTNING10M235
5
06
M3x6 Roundhead C-02-SC-R0306 x 2
M3x6 Roundhead
M3x6 Roundhead

BAG MARKED
STEP6
07
© VBC Racing LIGHTNING10M235
M2.5x4 Roundhead C-02-SC-R2504 x 4
Ball Connector 4.7x12mm A-02-VBC-5015 x 2
Lightning12 Front Axle B-02-VBC-5060 x 2
Pivot Ball B-02-VBC-5068 x 4
M3x15mm Turnbuckle, Black A-02-VBC-5053 x 2
Lightning12 Front Upper Arm Eyelet
A-02-VBC-5092 x 2
M3x10 Roundhead C-02-SC-R0310 x 4
M3x12 Flathead C-02-SC-F0312 x 4
Lightning12 Front Upper Arm Spacer, 1.5mm
A-01-VBC-5048 x 2
M3.3x0.4 Kingpin Shim C-02-VBC-5069 x 22
Lightning12 Kingpin C-02-VBC-5044 x 2
Front Spring (Medium/Gold) C-02-VBC-5042 x 2
6
M2.5x4 Roundhead
Ball Connector 4.7x12mm
Lightning Front Axle
Pivot Ball
Lightning12 Front Upper Arm Eyelet
M3x15mm Turnbuckle, Black
Lightning12 Front Upper Arm
Pivot Ball
Lightning10 ALU7075 Steering Knuckle
Lightning12 Front Lower Arm
A-02-VBC-5067
Lightning12 Front Upper
Arm Spacer, 1.5mm
Lightning12 Aluminum Upper Arm Mount
Lightning12 Aluminum
Front Bulkhead, Right
M3x12 Flathead
M3x10 Roundhead
Make Two (Leff And Right Side)
M3.3x0.4 Kingpin Shim
M2x8 Caphead C-02-SC-R2.0x8 x 2
Lightning12 Kingpin
Front Spring
(Medium/Gold)
M3.3x0.4 Kingpin Shim x 3
M3.3x0.4 Kingpin Shim x 7
M2.5x4 Roundhead
10
5
0
Note : 10 Is The Standard Setup
Note : Lower arm in the same direction,
dot marking should be facing up
<< Front >>
<< Rear >>
Dot Marking Dot Marking
M2x8 Caphead
Note : Tighten the screw slowly to
adjust the pivot ball movement
Upper Arm Mount Active Caster Setup
OPTIONAL FRONT SPRINGS :
Front Spring (Soft/Silver) C-02-VBC-5041
Front Spring (Hard/Black) C-02-VBC-5043
OPTIONAL FRONT UPPER ARM SPACER SET :
0.5mm/1.0mm Adjust Spacer
(D-05-VBC-0109)
07
Please note the direction of
the Upper Arm Eyelet as they
are offset.
3.5mm
M2.5 x 6 x 0.5 Spacer C02P50259 x 2
M2.5 x 6 x 0.5 Spacer
M3x3 Set Screw C-02-SC-SS-0303 x 2
OPTIONAL LIGHTNING FRONT AXLE :
Lightning Inline Front Axle C-02-P50211
M3x3 Set Screw

BAG MARKED
STEP6
08
© VBC Racing LIGHTNING10M235
Lightning Height Adjust Spacer, 1.5mm
A-01-VBC-5045 x 2
Front Suspension Assembly
6
1.80
1.2mm Spacer
0.8mm Spacer
No Spacer
3.25
6.15
Caster Adjustments
M2x4 Roundhead Screw C-02-SC-R0204 x 2
2mm Upper Hinge Pin C-02-VBC-5054 x 2
Caster Spacer, 0.8mm D-05-VBC-0110 x 2
M3x2mm Set Screw C-02-SC-SS-0302 x 2
Lightning10 Front Hinge Brace A-01-G50229 x 1
Caster Spacer, 1.2mm D-05-VBC-0110 x 2
M3x2mm Set Screw
Caster Spacer,
1.2mm
Caster Spacer,
0.8mm
2mm Upper Hinge Pin
M2x4 Roundhead Screw
OPTIONAL HEIGHT ADJUST SPACER SET :
0.5mm/1.0mm Height Adjuster Spacer
(D-05-VBC-0108)
2mm Upper Hinge Pin
M2x4 Roundhead Screw
M3x2mm Set Screw
Caster Spacer,
1.2mm
Caster Spacer,
0.8mm
M3x8 Roundhead C-02-SC-R0308 x 4
M3x8 Roundhead
M3x8 Roundhead
4

BAG MARKED
STEP7
Ball Differential Assembly
09
© VBC Racing LIGHTNING10M235
Differental Drive Ring B-02-VBC-1001 x 2
Thrust Cone B-02-VBC-5081 x 1
7
Differential Seal O-ring B-02-VBC-5082 x 2
Ball Bearing 3/8”x1/4” C-02-BB-3814 x 1
Bevelled Washer C-02-VBC-5076 x 3
64 Pitch 88T Spur Gear A-03-P50232 x 1
Ball Bearing Flanged 3/8”x1/4”
C-02-BB-3814F x 4
Differential Seal O-ring
Lightning10M235 Steel Rear Axle C-02-G51410 x 1
Ball Bearing Flanged 3/8”x1/4”
Differental Drive Ring
64 Pitch 88T Spur Gear A-03-P50232
1/8” Differential Balls
1/8” Differential Balls C-02-DB-0801S x 16
Ball Bearing 3/8”x1/4”
Lightning10 Rear Diff Hub
B-02-P50214
Ball Bearing Flanged 3/8”x1/4”
Thrust Cone
Bevelled Washers
M4 Nylon Nut
Bevelled Washers
Note : The Direction Of Washers
Diff Grease
M4 Nylon Nuts A-02-VBC-5075 x1
Differental Drive Ring
Differential Seal O-ring
64 Pitch 88T Spur Gear
Ball Bearing Flanged 3/8”x1/4”
Ball Bearing Flanged
3/8”x1/4”
Ball Bearing Flanged 3/8”x1/4”
Ride Height 3.0mm Spacer A-01-P51399 x 4
Lightning 12M Rear Hub Axle Housing B-02-P50666 x 2
Lightning10M235 Carbon Cross Tube A01P51401 x 1

BAG MARKED
STEP7-8
10
© VBC Racing LIGHTNING10M235
M2.5x8 Cap Head Screw C-02-SC-R2508 x 2
7
Ball Differential Assembly
Lightning10 Left Rear Wheel Hub B-02-P50213 x 1
8
Servo And Top Plate Assembly
M3x6x0.5mm Spacer B-02-VBC-5093 x 4
M3x8 Roundhead C-02-SC-R0308 x 4
3 Difference Servo Adaptor
For Sanwa/KO [A) /Futaba [F] /JR/Hitec [H]
Servo Saver Set
Turnbuckle Cup (Long)
3x52mm Hardened SpringSteel Turnbuckle
Turnbuckle Cup (Long)
M3x6x0.5mm Spacer
M3x6x0.5mm Spacer
M3x8 Roundhead
M3x8 Roundhead
Alum Servo Mount
Ball Connector 4.7x17mm
M3 Locknut
Make sure the screw is
correct for your servo
Optional : Tie Rod Wrench Set D-05-VBC-0048
SERVO IS NOT INCLUDED
M3 Locknut C-02-SC-NN03 x 2
Servo Saver Set B-03-VBC-5017 x1
T1 7075 Spacer B-02-VBC-0019-10 x 2
T1 7075 Spacer
Alum Servo Mount for Low Profile Servo B-02-P50262
Ball Connector 4.7x17mm A-02-VBC-5092 x 2
T2 7075 Spacer B-02-VBC-0019-20 x 4
Servo Spacer 2mm A-03-VBC-0033 x 2
Servo Spacer 1mm A-03-VBC-0032 x 2
Servo Spacer 1mm
Servo Spacer 1mm
Servo Spacer 2mm
Servo Spacer 2mm
T2 7075 Spacer
T2 7075 Spacer
<< LEFT >>
<< RIGHT >>
34.30mm
Ball Cups,, Long A-03-VBC-6030 x 4
3x52mm Hardened Springsteel Turnbuckle C-02-VBC-6003 x 2
B02-G-50279 Lightning
2mm Rear Axle Spacer
B02-G-50279 Lightning
2mm Rear Axle Spacer
M2.5x8 Cap Head
M2.5x8 Cap Head
Lightning10 Left Rear Wheel Hub

BAG MARKED
STEP8
Servo And Top Plate Assembly
11
© VBC Racing LIGHTNING10M235
8
LightningF Upper Deck Support Mount B-02-VBC-5096 x 2
M3x6 Flathead
M3x6 Flathead
M3x6 Flathead C-02-SC-F0306 x 4
Firebolt Center Battery Stopper A-03-VBC-6074 x 1
Option :Low CG Brass Weight 23.5gm
C-02-G50222
M3x6 Flathead
LightningF Upper Deck Support Mount
Firebolt Center Battery Stopper
Firebolt Center Battery Stopper
M3x6 Roundhead
Lightning 10M Graphite Front Shock Mount Plate A-01-P51400 x 1

BAG MARKED
STEP9
12
© VBC Racing LIGHTNING10
9
Shock Assembly

BAG MARKED
STEP10-12
Shock Assembly
13
© VBC Racing LIGHTNING10M235
9
10
Front Bumper Assembly
M2x12 Shaft Pin B-02-VBC-0022 x 2
Body Height Adjuster Support A-03-VBC-0015 x 2
Front Body Post A-03-VBC-0013 x 2
Body Height Adjuster Support
Body Height Adjuster Support
Front Body Post
Front Body Post
Lightning10 235 Graphite
Front Bumper A-01-P50273
M2x12 Shaft Pin
M2x12 Shaft Pin
M3x10mm Flat Head Screw C-02-SC-F0310 x 2
M3x10mm Flat Head
M3x8mm Flat Head
M3x10mm Flat Head
M3x8mm Flat Head
Lightning12 Plastic Front Bumper D-05-VBC-0112 x 1
M3x8mm Flat Head Screw C-02-SC-F0308 x 2
M3 Locknut C-02-SC-NN03 x 2

BAG MARKED
STEP18-20
14
© VBC Racing LIGHTNING10M235
11
Installing Front Bumper
12
Rear Body Post Assembly
M2x12 Shaft Pin B-02-VBC-0022 x 2
Body Height Adjuster Support A-03-VBC-0015 x 2
Front Body Post A-03-VBC-0013 x 2
Front Body Post
M3 Locknut C-02-SC-NN03 x 2
M3x10mm Flat Head Screw C-02-SC-F0310 x 2
M3x10mm Flat Head
M3 Locknut
M3x8 Roundhead C-02-SC-R0308 x 2
M3x8 Roundhead
Body Height Adjuster
Support
M2x12 Shaft Pin

BAG MARKED
STEP18-20
Install Wheels And Motor
15
© VBC Racing LIGHTNING10M235
4-40x5/16” Cap Head Screw x 8 Bearing 1/8x5/16, Flanged C-02-BB-1856F x 4
M3 Locknut C-02-SC-NN03 x 2
M3.3x0.4 Kingpin Shim C-02-VBC-5069 x 2
12
M3x8 Roundhead C-02-SC-R0308 x 2
13
Install Motor And Electronics
4-40x5/16” Cap Head
Bearing 1/8x5/16, Flanged
Bearing 1/8x5/16, Flanged
M3 Locknut
M3.3x0.4 Kingpin Shim
M3x8 Roundhead

BAG MARKED
STEP12
16
© VBC Racing LIGHTNING10M235
Install Electronics
15
Install ESC And Receiver
[Items Are Not Included]
Double Side
Tape

Instruction Book P-01-P51438 VBC Racing Lightning10M235 1/10 Pan Car Kit D-05-VBC-CK28
www.vbcracing.com
1/10 SCALE ELECTRIC COMPETITION PAN CAR KIT
COMPETITION GRADE HIGH PERFORMANCE RADIO CONTROL RACING CAR CHASSIS KIT

Order Number Package Descriptions Parts Number Parts Descriptions Quantity in a pkg
A-01-P51395 Lightning10M Graphite Main Chassis A-01-P51395 Lightning10M Graphite Main Chassis 1
A-03-VBC-5007 Pivot Brace (bottom) 1
A-03-VBC-5008 Pivot Brace (cover) 1
A-03-VBC-5009 Pod Link Set A-03-VBC-5009 Pod Link 2
A-03-VBC-1027 Pivot Balls A-03-VBC-1027 5mm Pivot Ball 5
B-02-P51284 FXM Aluminium Motor Mount B-02-P51284 FXM Aluminium Motor Mount 1
B-02-P50664 Aluminium Motor Mount B-02-P50664 Aluminium Motor Mount 1
B-02-P30890 T2 7075 Spacer (Red) B02P30890 T2 7075 Spacer (Red) 10
B-02-P30891 T1 7075 Spacer (Red) B02P30891 T1 7075 Spacer (Red) 10
B-02-P51288 4.7mm Thin Ball Nuts B02P51288 4.7mm Thin Ball Nuts 5
A-01-P51398 Lightning10M Rear Tweak Plate A01P51398 Lightning10M Rear Tweak Plate 1
A-01-P51397 Lightning10M 235 Graphite Rear Shock Mount Plate A01P51397 Lightning10M 235 Graphite Rear Shock Mount Plate 1
A-01-P51396 Lightning10M 235 Graphite Lower Pod Plate A01P51396 Lightning10M 235 Graphite Lower Pod Plate 1
B-02-P50666 Rear Axle Housing B02P50666 Rear Axle Housing 1
A-01-P51401 Carbon Cross Tube A01P51401 Carbon Cross Tube 1
A-01-P51399 Ride Height 3mm Spacer A01P51399 Ride Height 3mm Spacer 4
C-02-VBC-6003 3x52mm Hardened Springsteel Turnbuckle C-02-VBC-6003 3x52mm Hardened SpringSteel Turnbuckle 2
D-06-VBC-0138 Plastic Ball Cups Set A-03-VBC-6029 Ball cups, short 2
A-03-VBC-6030 Ball cups,, long 10
A-03-VBC-6047 Ball cups L Type, long, Right 1
A-03-VBC-6048 Ball cups L Type, long, Left 1
B-02-P-50262 Alum Servo Mount B-02-P-50262 Alum Servo Mount 2
A-03-VBC-0053 Servo Horn Type F (Composite) 1
A-03-VBC-0054 Servo Horn Type A (Composite) 1
A-03-VBC-0032 Servo Spacer 1mm 2
A-03-VBC-0033 Servo Spacer 2mm 2
D-06-VBC-0123 Firebolt Bumper & Battery Stopper Set A-03-VBC-6011 Front Bumper 1
A-03-VBC-6012 Rear Bumper 1
A-03-VBC-6074 Firebolt Center Battery Stopper 1
A-03-VBC-6075 Firebolt Side Battery Stopper X 1
A-03-VBC-6076 Firebolt Side Battery Stopper Y 1
B-02-VBC-5096 LightningF Upper Deck Support Mount B-02-VBC-5096 LightningF Upper Deck Support Mount 2
A-01-P51400 Lightning10M Graphite Front Shock Mount Plate A01P51400 Lightning10M Graphite Front Shock Mount Plate 1
B-02-VBC-0045 Ball Connector B-02-VBC-0045 Ball Connector 10
A-02-VBC-5070 Lightning12 Plastic Front Bumper, Left 1
A-02-VBC-5071 Lightning12 Plastic Front Bumper, Right 1
A-03-VBC-0013 Front Body Post 2
A-03-VBC-0014 Rear Body Post 2
A-03-VBC-0015 Body Height Adjuster Support 4
B-02-VBC-0076 Body Clip 8
B-02-VBC-0020-12 M2x12 Shaft Pin 4
B-02-VBC-0076 Body Clips B-02-VBC-0076 Body Clips 20
B-02-VBC-5015 Ball Connector 4.7x12mm (5pcs) B-02-VBC-5015 Ball Connector 4.7x12mm (5pcs) 5
B-02-VBC-5018 Damper Tube Shaft 1
B-02-VBC-5019 Damper Tube 1
B-02-VBC-5020 4.7mm Ball Nuts B-02-VBC-5020 4.7mm Ball Nuts 5
A-03-VBC-5021 Turnbuckle Cup (Short) A-03-VBC-5021 Turnbuckle Cup (Short) 4
B-02-VBC-0120 TBB Shock Body 1
B-02-VBC-0121 TBB Shock Height Adjuster 1
A-03-VBC-0122 TBB Bottom Cap 1
A-03-VBC-0123 TBB Shock Piston (3 holes) 1
A-03-VBC-0124 TBB Shock Bottom Connector 1
B-02-VBC-0125 TBB Shaft Cap 1
A-03-VBC-0126 TBB Shaft Guide 1
B-03-VBC-0127 TBB Shock Shaft 1
B-03-VBC-0128 TBB Sealer O-Ring (Shock Height Adjuster) 1
B-03-VBC-0012 TBB Shaft Sealer O-Ring 1
B-03-VBC-0129 M2 E-Clip 4
A-03-VBC-0130 TBB Shock Top Connector 1
A-03-VBC-0131 TBB Spring Bottom Support 1
B-03-VBC-0132 TBB Short Oil Sealer Cap (Medium Soft) 1
B-02-VBC-0133 TBB Shock Body Cap 1
B-02-VBC-0134 TBB Shock Spring (Red-Medium Soft) 1
C-02-VBC-5042 Front Springs (Medium) C-02-VBC-5042 Front Springs (Medium) for Lightning 1/12 2
C-02-VBC-5044 Kingpin C-02-VBC-5044 Lightning12 Kingpin 2
A-01-VBC-5045 Lightning12 Height Adjust Spacer, 1.5mm A-01-VBC-5045 Lightning12 Height Adjust Spacer, 1.5mm 2
A-01-VBC-5048 Lightning12 Front Upper Arm Spacer, 1.5mm A-01-VBC-5048 Lightning12 Front Upper Arm Spacer, 1.5mm 2
A-03-G51101 Composite X Silver Front Upper Arm for Lightning Series A03G51101
Composite X Silver Front Upper Arm for Lightning Series
2
A-02-VBC-5052 Front Upper Arm Eyelet A-02-VBC-5052 Lightning12 Front Upper Arm Eyelet 2
A-02-VBC-5053 M3x15 Turnbuckle BK A-02-VBC-5053 M3x15 Turnbuckle, Black 2
C-02-VBC-5054 2mm Upper Pin C-02-VBC-5054 2mm Upper Hinge Pin 4
A-01-VBC-5055 Lightning12 Caster Spacer. 0.8mm 2
A-01-VBC-5056 Lightning12 Caster Spacer. 1.2mm 2
B
ody Posts Pack
D
amper Tube Set
D-05-VBC-0101
P
ivot Brace
D-05-VBC-0012
D-05-VBC-0110
C
aster Spacer Set
D-05-VBC-0103
D-05-VBC-0018
W
ildFire Servo Horn Set (Composite)
D-05-VBC-0252
T
rue Big Bore (TBB) Single Shock Set
D-05-VBC-0112
L
ightning12 Plastic Front Bumper
Parts List

Parts List
B-02-VBC-5057 Aluminum Upper Arm Mount B-02-VBC-5057 Lightning12 Aluminum Upper Arm Mount 1
B-02-P50233 Lightning10 ALU7075 Steering Knuckle 2
C-02-P50259 M2.5x0.5 Shim 2
B-02-VBC-5060 Lightning Front Axles B-02-VBC-5060 Lightning Front Axle 2
B-02-VBC-5065 Alum Front Bulkhead L B-02-VBC-5065 Lightning12 Alum Front Bulkhead, Left 1
B-02-VBC-5066 Alum Front Bulkhead R B-02-VBC-5066 Lightning12 Alum Front Bulkhead, Right 1
A-03-G51102 Composite X Silver Front Lower Arm for Lightning Series A03G51102
Composite X Silver Front Lower Arm for Lightning Series
2
B-02-VBC-5068 Pivot Ball B-02-VBC-5068 Pivot Ball 4
C-02-VBC-5069 King Pin Shim, M3.3x0.4 C-02-VBC-5069 Lightning12 King Pin Shim, M3.3x0.4 (20pcs) 20
B-02-VBC-5073 14mm Aluminum Standoff B-02-VBC-5073 14mm Aluminum Standoff 4
B-02-VBC-5074 Alum Side Spring Retainer B-02-VBC-5074 Aluminum Side Spring Retainer 2
A-02-VBC-5075 M4 Nylon Nuts for Lightning/Assoc.R5 series A-02-VBC-5075 M4 Nylon Nuts 2
C-02-VBC-5076 Bevelled Washer C-02-VBC-5076 Bevelled Washer 6
A-03-P50232 64 Pitch 88T Spur Gear A-03-P50232 64 Pitch 88T Spur Gear 1
B-02-VBC-5081 Thrust Cone for Lightning/Assoc.R5 series B-02-VBC-5081 Thrust Cone 1
C-02-DB-0801S 1/8" Diff Balls for Lightning/Assoc.R5 series C-02-DB-0801S 1/8" Diff Balls 8
B-02-VBC-1001 Diff D Ring B-02-VBC-1001 Diff D Ring 2
B-02-VBC-5082 Diff Seal O-ring B-02-VBC-5082 Diff Seal O-ring 10
C-02-BB-1856F
Bearing 1/8 x 5/16, Flanged for Lightning/Assoc.R5 series
C-02-BB-1856F Bearing 1/8 x 5/16, Flanged 2
C-02-BB-3814 Bearing, 3/8 x 1/4 for Lightning/Assoc.R5 series C-02-BB-3814 Bearing, 3/8 x 1/4 2
C-02-BB-3814F
Bearing, 3/8 x 1/4, Flanged for Lightning/Assoc.R5 series
C-02-BB-3814F Bearing, 3/8 x 1/4, Flanged 2
A-02-VBC-5092 Ball Connector 4.7x17mm A-02-VBC-5092 Ball Connector 4.7x17mm 5
B-02-VBC-0019-20 3x5.5x2 Alum Spacer B-02-VBC-0019-20 3x5.5x2 Alum Spacer 10
B-02-VBC-0019-10 3x5.5x1 Alum Spacer B-02-VBC-0019-10 3x5.5x1 Alum Spacer 10
C-02-SC-C0440 4-40x5/16" Cap Head Screw C-02-SC-C0440 4-40x5/16" Cap Head Screw 20
C-02-SC-R2504 M2.5x4mm Roundhead Screw C-02-SC-R2504 M2.5x4mm Roundhead Screw 20
C-02-SC-R2508 M2.5x8mm Cap Head Screw C-02-SC-R2508 M2.5x8mm Cap Head Screw 20
C-02-SC-R2.0x6 M2.0x6mm Cap Head Screw C-02-SC-R2.0x6 M2.0x6mm Cap Head Screw 30
C-02-SC-R2.0x8 M2.0x8mm Cap Head Screw C-02-SC-R2.0x8 M2.0x8mm Cap Head Screw 20
C-02-SC-R0204 M2x4mm Roundhead Screw C-02-SC-R0204 M2x4mm Roundhead Screw 20
C-02-SC-NN03 M3 Locknut C-02-SC-NN03 M3 Locknut 20
B-02-VBC-5093 M3x6x0.5 Spacer B-02-VBC-5093 M3x6x0.5 Spacer 20
C-02-SC-F0310 M3x10mm Flathead Screw C-02-SC-F0310 M3x10mm Flathead Screw 20
C-02-SC-R0310 M3x10mm Roundhead Screw C-02-SC-R0310 M3x10mm Roundhead Screw 20
C-02-SC-F0312 M3x12mm Flathead Screw C-02-SC-F0312 M3x12mm Flathead Screw 20
C-02-SC-F0306 M3x6mm Flathead Screw C-02-SC-F0306 M3x6mm Flathead Screw 20
C-02-SC-R0306 M3x6mm Roundhead Screw C-02-SC-R0306 M3x6mm Roundhead Screw 20
C-02-SC-F0308 M3x8mm Flathead Screw C-02-SC-F0308 M3x8mm Flathead Screw 20
C-02-SC-R0308 M3x8mm Roundhead Screw C-02-SC-R0308 M3x8mm Roundhead Screw 20
C-02-SC-SS-0308 M3x8mm Set Screw C-02-SC-SS-0308 M3x8mm Set Screw 20
A-03-VBC-1047 Side Spring (Soft) 2
A-03-VBC-1047 Side Spring (Medium) 2
A-03-VBC-1047 Side Spring (Hard) 2
C-02-G50254 TiN Coated 2mm Upper Pin for Lightning Series C-02-G-50254 TiN Coated 2mm Upper Pin for Lightning Series 2
C-02-G50255 TiN Coated Kingpin for Lightning Series C-02-G-50255 TiN Coated Kingpin for Lightning Series 2
C-02-G50222 Low CG Brass Weight 23.5gm 2
C-02-SC-F0306 M3x6mm Flathead Screw 2
C-02-P50211 Lightning Inline Front Axle C-02-P50211 Lightning Inline Front Axle 2
C-02-P-50266 3x15mm SuperSteel Turnbuckle C-02-P-50266 3x15mm SuperSteel Turnbuckle 2
A-01-P-50273 Lightning10-235 Graphite Front Bumper A01P50273 Lightning10-235 Graphite Front Bumper 1
A-01-P-50274 Lightning10-235 Front Hinge Brace A01P50274 Lightning10-235 Front Hinge Brace 1
A-01-P-50275 Lightning10-235 Front Suspension Plate A01P50274 Lightning10-235 Front Suspension Plate 1
C-02-BB-3814F Bearing, 3/8 x 1/4, Flanged 2
C-02-BB-3814 Bearing, 3/8 x 1/4 1
A-02-VBC-5075 M4 Nylon Nuts 1
C-02-VBC-5076 Belleville Washer 3
A-03-P50232 64 Pitch 88T Spur Gear 1
C-02-P51410 Lightning10M235 Steel Rear Axle 1
B-02-P50213 Lightning10 Left Rear Wheel Hub 1
B-02-P50214 Lightning10 Rear Diff Hub 1
B-02-VBC-5081 Thrust Cone 1
C-02-DB-0801S 1/8" Diff Balls 16
B-02-VBC-1001 D-Drive Ring 2
B-02-VBC-5082 Diff Seal O-ring 2
B-02-G50279 Lightning 2mm Rear Axle Spacer 2
B-02-G50280 Lightning 1mm Rear Axle Spacer 2
C-02-P50282 Lightning10-235 Carbon Rear Axle C02P50282 Lightning10-235 Carbon Rear Axle 1
C-02-P51410 Lightning10M235 Steel Rear Axle C02P51410 Lightning10M235 Steel Rear Axle 1
D-05-VBC-0156 Steering Knuckles for Lightning10
A-03-VBC-1047 Side Spring Set for Lightning/Assoc.R5 series
C-02-G50222 Low CG Brass Weight 23.5gm
D-05-VBC-0272 Ball Differential Set for Lightning10M235
