VBC Racing LIGHTNING 12M User manual

COMPETITION GRADE HIGH PERFORMANCE RADIO CONTROL RACING CAR CHASSIS KIT
1/12 SCALE ELECTRIC COMPETITION CAR KIT
E
INSTRUCTIONS MANUAL
5
Thank you for purchasing VBC Racing product.
This VBC Racing kit is a high performance, racing grade car kit
intended for experienced racers. The kit compose of VBC
formulated composite materials, top quality full carbon fiber
chassis and high grade 7075 material which will give you a
competitive edge over the others.
Novice racer should seek advice from more experienced racer
before assembly.
Always keep this instruction manual handy at all times for quick
reference even after completing the assembly.
Before your assembly, sand the chassis edges.
Things that we should remind you.
Sand the chassis edges with #600 sand paper and apply CA
glue to the edges and counter sink holes.
Need help or support.
If you need help or you would like to leave us a comment,
please email to our support team: [email protected] or
visit our web site www.vbcracing.com

BAG MARKED
STEP1
1
Graphite Edges Protection Procedure
01© VBC Racing LIGHTNING12M
CA
Sand the chassis edges with #600 sand paper(not included) and
apply CA glue(not included) to the edges of the chassis.
Sand the below graphite edges with #600 sand paper and apply CA glue to the edges.
*Not included in this kit
A-01-P50667 Lightning12M 2.5mm Graphite Main Chassis
A-01-P50634 Lightning12M Graphite Chassis Brace
A-01-P50642 Lightning12M Graphite Lower Pod Plate

BAG MARKED
2
02© VBC Racing LIGHTNING12M
Pivot Brace D-05-VBC-0101 x 1
Pivot Brace Cover D-05-VBC-0101 x 1
Pivot Balls A-03-VBC-1027 x 5
Pivot ball shoulder should be facing downwards
Pivot Brace
Pivot Brace Cover
M2x6 Cap Head
M3x6 Flathead M3x6 Flathead
Pivot Balls
Pivot Balls
Use screws to adjust the
play of the piviot ball Movement. Do not
overtighten to avoid stripping
M2x6 Cap Head C-02-SC-R2.0x6 x 2
M3x6 Flathead C-02-SC-F0306 x
M3x10 Flathead C-02-SC-F0310 x 2
M3x10 Flathead
M3x10 Flathead
M3 Locknut C-02-SC-NN03 x 2
M3 Locknut
M3 Locknut
Pivot Balls
Pivot Balls
M3x6 Flathead
M3x6 Flathead
Use a screw to tap the Locknut before install
Use a screw to tap the Locknut before install

BAG MARKED
03© VBC Racing LIGHTNING12M
M2x6 Cap Head C-02-SC-R2.0x6 x 4
Pivot Brace Assembly Part2
STEP2-5
Lightning Pod Link Set
A-03-VBC-5009 x 2
2
Rear Bulkhead Assembly Part1
3
M3 Locknut C-02-SC-NN03 x 2
Tighten each side screw
slowly, Make sure the lower pod
plate can rotate freely.
Note the direction screw in from
the larger hole side
M3x6 Flathead C-02-SC-F0306 x 2
03
M3x6 Flathead C-02-SC-F0306 x 1
Aluminium Motor Mount B-02-P50664 x 2
Aluminium Motor Mount
Aluminium Motor Mount

04
© VBC Racing LIGHTNING12M
M3x6 Flathead C-02-SC-F0306 x 2
BAG MARKED
STEP2-5
Chassis Brace Assembly
3
14mm Aluminum Standoff B-02-VBC-5073 x 2
4
14mm Aluminum Standoff
14mm Aluminum Standoff
M3x6 Flathead
M3x6 Flathead
Side Spring (Medium/Gold) A-03-VBC-1047 x 2
4.7mm Ball Nuts B-02-VBC-5020 x 2
Aluminium Side Spring Retainer B-02-VBC-5074 x 2
M3x10 Set Screw C-02-SC-SS-0310 x 2
M3x6 Roundhead C-02-SC-R0306 x 2
Side Spring (Medium/Gold)
Thead Lock
Thead Lock
OPTIONAL SIDE SPRINGS SET :
Side Spring (Soft/Silver)
Side Spring (Medium/Gold)
Side Spring (Hard/Black)
(A-03-VBC-1047)
M3x10 Set Screw
M3x10 Set Screw

BAG MARKED
STEP2-5
05
© VBC Racing LIGHTNING12M
M3x6 Roundhead C-02-SC-R0306 x 2
4
M3x6 Roundhead
05
M3x6 Roundhead
M3x6 Roundhead C-02-SC-R0306 x 2

M3x6 Roundhead C-02-SC-R0306 x 2
M3x6 Roundhead
M3x6 Roundhead
© VBC Racing LIGHTNING12M

BAG MARKED
STEP6
Front Suspension Assembly
07
© VBC Racing LIGHTNING12M
M2.5x4 Roundhead C-02-SC-R2504 x 4
Ball Connector 4.7x12mm A-02-VBC-5015 x 2
Lightning12 Front Axle B-02-VBC-5060 x 2
Pivot Ball B-02-VBC-5068 x 4
M3x15mm Turnbuckle, Black A-02-VBC-5053 x 2
Lightning12 Front Upper Arm Eyelet
A-02-VBC-5092 x 2
M3x10 Roundhead C-02-SC-R0310 x 4
M3x12 Flathead C-02-SC-F0312 x 4
Lightning12 Front Upper Arm Spacer, 1.5mm
A-01-VBC-5048 x 2
M3.3x0.4 Kingpin Shim C-02-VBC-5069 x 12
Lightning12 Kingpin C-02-VBC-5044 x 2
Front Spring (Medium/Gold) C-02-VBC-5042 x 2
6
M2.5x4 Roundhead
Ball Connector 4.7x12mm
Lightning12 Front Axle
Pivot Ball
Lightning12 Front Upper Arm Eyelet
M3x15mm Turnbuckle, Black
Lightning12 Front Upper Arm
A-02-VBC-5051
Please note the direction of
the Upper Arm Eyelet as they
are offset.
4mm
Pivot Ball
Lightning12 Steering Knuckle
D-05-VBC-0111
Lightning12 Front Lower Arm
A-02-VBC-5067
Lightning12 Front Upper
Arm Spacer, 1.5mm
Lightning12 Aluminum Upper Arm Mount
B-02-VBC-5057
Lightning12 Aluminum
Front Bulkhead, Right
B-02-VBC-5066
M3x12 Flathead
M3x10 Roundhead
Make Two (Leff And Right Side)
M3.3x0.4 Kingpin Shim
M2x8 Caphead C-02-SC-R2.0x8 x 2
M2x8 Caphead
Lightning12 Kingpin
Front Spring
(Medium/Gold)
M3.3x0.4 Kingpin Shim x 4
M3.3x0.4 Kingpin Shim
M2.5x4 Roundhead
10
5
0
Note : 10 Is The Standard Setup
Note : Lower arm in the same direction,
dot marking should be facing up
<< Front >>
<< Rear >>
Dot Marking Dot Marking
Note : Tighten the screw slowly to
adjust the pivot ball movement
Upper Arm Mount Active Caster Setup
OPTIONAL FRONT SPRINGS :
Front Spring (Soft/Silver) C-02-VBC-5041
Front Spring (Hard/Black) C-02-VBC-5043
OPTIONAL FRONT UPPER ARM SPACER SET :
0.5mm/1.0mm Adjust Spacer
(D-05-VBC-0109)

BAG MARKED
STEP6
08
© VBC Racing LIGHTNING12M
Lightning12 Height Adjust Spacer, 1.5mm
A-01-VBC-5045 x 2
Front Suspension Assembly
6
M3x8 Flat Head Screw C-02-SC-F0308 x 4
1.80
1.2mm Spacer
0.8mm Spacer
No Spacer
3.25
6.15
Caster Adjustments
M2x4 Roundhead Screw C-02-SC-R0204 x 2
2mm Upper Hinge Pin C-02-VBC-5054 x 2
Caster Spacer, 0.8mm D-05-VBC-0110 x 2
M3x2mm Set Screw C-02-SC-SS-0302 x 2
Caster Spacer, 1.2mm D-05-VBC-0110 x 2
Front Cross Brace Tube B-02-P50640 x 2
Front Cross Brace Insert B-02-P50641 x 1
Front Cross Brace Tube
Front Cross Brace Insert
Front Cross Brace Insert
TBB Shaft Sealer O-Ring B-03-0011 x 2
2mm Upper Hinge Pin
M2x4 Roundhead
Lightning12 Height Adjust Spacer, 1.5mm
Lightning12 Height Adjust Spacer, 1.5mm
M3x8 Flat Head Screw
M3x8 Flat Head Screw
Caster Spacer, 0.8mm
Caster Spacer, 1.2mm
M3x2mm Set Screw

BAG MARKED
STEP7
Ball Differential Assembly
09
© VBC Racing LIGHTNING12M
Differental Drive Ring B-02-VBC-1001 x 2
Thrust Cone B-02-VBC-5081 x 1
7
Differential Seal O-ring B-02-VBC-5082 x 2
Ball Bearing 3/8”x1/4” C-02-BB-3814 x 1
Bevelled Washer C-02-VBC-5076 x 3
Kawada 64 Pitch 94T Spur Gear C-02-P50981 x 1
Ball Bearing Flanged 3/8”x1/4”
C-02-BB-3814F x 4
Differential Seal O-ring
Lightning12 Carbon Rear Axle B-02-VBC-5078
Ball Bearing Flanged 3/8”x1/4”
Differental Drive Ring
64 Pitch 94T Spur Gear
1/8” Differential Balls
1/8” Differential Balls C-02-DB-0801 x 18
Ball Bearing 3/8”x1/4”
Lightning12 Alum Diff Hub
B-02-VBC-5080
Ball Bearing Flanged 3/8”x1/4”
Thrust Cone
Bevelled Washers
M4 Nylon Nut
Bevelled Washers
Note : The Direction Of Washers
Diff Grease
M4 Nylon Nuts A-02-VBC-5075 x1
Ride Height 1.0mm Spacer A-01-P50968 x 4
Ball Bearing Flanged 3/8”x1/4”
Ball Bearing Flanged 3/8”x1/4”
Lightning 12M Rear Hub Axle Housing B-02-P50666 x 2
Carbon Cross Tube A01P50665 x 1
Carbon Cross Tube
Ride Height 1.0mm Spacer
Ride Height 1.0mm Spacer
Rear Hub Axle Housing
Rear Hub Axle Housing
M3x12 Flathead C-02-SC-F0312 x 4
M3x12 Flathead
M3x12 Flathead

BAG MARKED
STEP7-8
10
© VBC Racing LIGHTNING12M
M2.5x8 Cap Head Screw C-02-SC-R2508 x 1
Servo And Top Plate Assembly
7
Ball Differential Assembly
M3x6x0.5mm Spacer B-02-VBC-5093 x 4
Alum Servo Mount B-02-VBC-5012 x 2
Aluminum Wheel Hub, Left
B-02-VBC-5079 x 1
Turnbuckle Cup (Long) A-03-VBC-5016 x 6
42mm Turnbuckle, Black B-02-VBC-5014 x 2
Ball Connector 4.7x12mm A-02-VBC-5015 x 1
M2.5x8 Cap Head
26mm
Turnbuckle Cup (Long)
42mm Turnbuckle, Black
Turnbuckle Cup (Long)
M3x6x0.5mm Spacer
M3x6 Roundhead
Alum Servo Mount
<< LEFT >>
<< RIGHT >>
Optional : Tie Rod Wrench Set D-05-VBC-0048 (not included)
SERVO IS NOT INCLUDED
8
This side into axle
Aluminum Wheel Hub, Left
Alum Servo Mount
M3x6x0.5mm Spacer
M3x6 Roundhead
M3x6 Roundhead C-02-SC-R0306 x 5
Ball Connector 4.7x12mm
1.2mm
Turnbuckle Cup (Long) Turnbuckle Cup (Long)

BAG MARKED
STEP8
Servo And Top Plate Assembly
11
© VBC Racing LIGHTNING12M
8
M3x6 Roundhead C-02-SC-R0306 x 2
M3x6 Flathead C-02-SC-F0306 x 6
17mm Aluminum Standoff A-01-VBC-5005 x 1
Shock Mount Plate A-01-P50639 x 1
Alum Shock Mount B-02-P50638 x 1
M3 Hex Nut C-02-SC-FN03 x 1
Shock Mount Plate
M3x6 Flathead
M3x6 Flathead
M3x6 Roundhead
M3x6 Roundhead
17mm Aluminum Standoff
M3x8 Roundhead
Alum Shock Mount
M3 Hex Nut
M3x4 Roundhead C-02-SC-R0304 x 1
Ball Connector 4.7x12mm
B-02-VBC-5015 x 3
5x8 Ball Bearing C-02-BB-0805-B x 2
Lightning FX Steering Arm_A B-02-P50609 x 1
Lightning FX Steering Arm_B B-02-P50782 x 1
M3x4 Roundhead
Lightning FX Steering Arm_A
Lightning FX Steering Arm_B
1
Ball Connector 4.7x12mm
Ball Connector
4.7x12mm
M3x6 Roundhead
5x8 Ball Bearing
5x8 Ball Bearing
T2 Spacer
Steering Post B-02-P50633 x 1
Steering Post
M3x6 Flathead
M3x6 Flathead

BAG MARKED
STEP9
Assemble TBX Shock
12
© VBC Racing LIGHTNING12M
TBX Shock Body B-02-VBC-5023 x 1
TBX Shock Bottom Cap B-02-VBC-5025 x 1
TBX Piston [2 Holes] A-02-VBC-5027 x 1
TBX Shock Ball End B-02-VBC-5033
Shock Bottom O-ring Guard A-02-VBC-5030 x 1
M2x6mm O-ring (Blue) C-02-VBC-5037 x 1
Lightning12 TBX Shock Shaft C-02-VBC-5026 x 1
M1.5x10 O-ring C-02-VBC-5035 x 1
M1.5 E-Clip C-02-VBC-5038 x 2
TBX Shock O-ring Guard A-02-VBC-5029
TBX Shock Thru Cap A-02-VBC-5031 x 1
M1.0x7.5 O-ring C-02-VBC-5036 x 2
5mm Pivot Ball A-03-VBC-1027 x 1
9
TBX Spring Adjuster B-02-VBC-5024 x 1
TBX Piston [3 Holes] A-02-VBC-5028 x 1
Note The Direction Of
O-ring Guard On Top
Fill supplied shock oil
and remove air by
moving the piston up
and down until air
bubbles disappear
TBX Shock Body
TBX Spring Adjuster
M1.5x10 O-ring
Insert Sealer O-Ring inside the Spring Adjuster Groove
TBX Shock Bottom Cap
Shock Bottom O-ring Guard
M2x6mm O-ring (Clean)
TBX Piston [2 Holes]
Lightning12 TBX Shock Shaft
M1.5 E-Clip
TBX Shock Ball End
TBX Spring Retainer
A-02-VBC-5032 x 1
M1.0x7.5 O-ring
TBX Shock Thru Cap
M2x6mm O-ring (Blue)
TBX Shock O-ring Guard
Lightning12 TBX Sping
[Gold/Medium]
C-02-VBC-5034
OPTIONAL LIGHTNING12 TBX SPRINGS :
C-02-VBC-5039 (Med. Soft/Silver)
C-02-VBC-5040 (Med. Hard/Black)
Note The Direction Of
O-ring Guard On Top
M2x6mm O-ring (Clean) R-02-P50264 x 1

BAG MARKED
STEP9-10
TBX Shock Assembly
13
© VBC Racing LIGHTNING12M
9
10
Body Posts Assembly
M3x6 Roundhead C-02-SC-R0306 x 2
M3x8mm Flat Head Screw C-02-SC-F0308 x 2
Lightning12 Body Posts A-03-VBC-5010 x 4
Lightning12 Plastic Front Bumper D-05-VBC-0112 x 1
M3x8mm Flat Head Screw
Lightning12 Body Post
Lightning12 Body Post
Lightning12 Body Post
M3x6 Roundhead
M3x6 Roundhead

BAG MARKED
STEP9-10
Install Wheels And Motor
14
© VBC Racing LIGHTNING12M
4-40x5/16” Cap Head Screw x 6
Bearing 1/8x5/16, Flanged C-02-BB-1856F x 4
M3 Locknut C-02-SC-NN03 x 2
M3.3x0.4 Kingpin Shim C-02-VBC-5069 x 2
11
M3x8 Roundhead C-02-SC-R0308 x 2
12
Install Motor And Electronics
M3x6x0.5mm Spacer B-02-VBC-5093 x 4
Bearing 1/8x5/16, Flanged
Bearing 1/8x5/16, Flanged M3 Locknut
4-40x5/16” Cap Head Screw
M3x8 Roundhead
M3x6x0.5mm Spacer

BAG MARKED
STEP12
15
© VBC Racing LIGHTNING12M
12
Install Electronics And Battery
Install ESC And Receiver
[Items Are Not Included]
3.7V Lipo Battery
[Item Is Not Included]
Double Side
Tape

PARTS LIST
16
© VBC Racing LIGHTNING12
Order Number Package Descriptions Parts Number Parts Descriptions
A-01-VBC-5001 Lightning12 Decals A-01-VBC-5001 Lightning Decals
A-01-VBC-5002 Lightning12 2.5mm Graphite Main Chassis A-01-VBC-5002 2.5mm Graphite Main Chassis
A-01-VBC-5003 Lightning12 Alum Shock Mount Brace A-01-VBC-5003 Alum Shock Mount Brace
A-01-VBC-5004 Lightning12 Shock Mount Plate A-01-VBC-5004 Shock Mount Plate
B-02-VBC-5005 Lightning12 17mm Aluminum Standoff B-02-VBC-5005 17mm Aluminum Standoff
A-01-VBC-5006 Lightning12 Graphite Top Plate A-01-VBC-5006 Graphite Top Plate
A-03-VBC-5007 Pivot Brace (bottom)
A-03-VBC-5008 Pivot Brace (cover)
A-03-VBC-5009 Pod Link Set for Lightning/Assoc.R5 series A-03-VBC-5009 Pod Link
A-03-VBC-1027 Pivot Balls for Lightning/Assoc.R5 series A-03-VBC-1027 5mm Pivot Ball
A-03-VBC-5010 Body Post
A-03-VBC-5011 Body Height Adjuster
B-02-VBC-0076 Body Clips B-02-VBC-0076 Body Clips
B-02-VBC-5012 Alum Servo Mount for Lightning/Assoc.R5 series B-02-VBC-5012 Aluminum Servo Mount
B-02-VBC-5013 Servo Spacer for Lightning/Assoc.R5 series B-02-VBC-5013 Servo Spacer
B-02-VBC-5014 42mm Turnbuckle BK for Lightning/Assoc.R5 series B-02-VBC-5014 42mm Turnbuckle, Black
B-02-VBC-5015 Ball Connector 4.7x12mm (5pcs) B-02-VBC-5015 Ball Connector 4.7x12mm (5pcs)
A-03-VBC-5016 Turnbuckle Cup (Long) A-03-VBC-5016 Turnbuckle Cup (Long)
B-03-VBC-5017 Servo Saver Set for Lightning/Assoc.R5 series B-03-VBC-5017 Servo Saver Set
B-02-VBC-5018 Damper Tube Shaft
B-02-VBC-5019 Damper Tube
B-02-VBC-5020 4.7mm Ball Nuts B-02-VBC-5020 4.7mm Ball Nuts
A-03-VBC-5021 Turnbuckle Cup (Short) A-03-VBC-5021 Turnbuckle Cup (Short)
B-02-VBC-5022 TBX Shock Cap
B-02-VBC-5023 TBX Shock Body
B-02-VBC-5024 TBX Spring Adjuster
B-02-VBC-5025 TBX Shock Bottom Cap
C-02-VBC-5026 Lightning TBX Shock Shaft
A-02-VBC-5027 TBX Pistion (2 Holes)
A-02-VBC-5028 TBX Pistion (3 Holes)
A-02-VBC-5029 Shock O-ring Guard
A-02-VBC-5030 Shock Bottom O-ring Guard
A-02-VBC-5031 TBX Shock Thru Cap
A-02-VBC-5032 TBX Spring Retainer
B-02-VBC-5033 Shock Ball End
C-02-VBC-5034 Lightning TBX Spring (Medium)
C-02-VBC-5035 M1.5x10 O-ring
C-02-VBC-5036 M1.0x7.5 O-ring
C-02-VBC-5037 M2x6 O-ring
A-03-VBC-1027 5mm Pivot Ball
B-02-VBC-5015 Ball Connector 4.7x12mm (5pcs)
C-02-VBC-5038 M1.5 E-Clip
B-02-VBC-5022 TBX Shock Cap
B-02-VBC-5023 TBX Shock Body
B-02-VBC-5024 TBX Spring Adjuster
B-02-VBC-5025 TBX Shock Bottom Cap
C-02-VBC-5026 TBX Shock Shaft for Lightning/Assoc.R5 series C-02-VBC-5026 Lightning TBX Shock Shaft
A-02-VBC-5027 TBX Pistion (2 Holes)
A-02-VBC-5028 TBX Pistion (3 Holes)
A-02-VBC-5029 Shock O-ring Guard
A-02-VBC-5030 Shock Bottom O-ring Guard
A-02-VBC-5031 TBX Shock Thru Cap
A-02-VBC-5032 TBX Spring Retainer
B-02-VBC-5033 Shock Ball End
C-02-VBC-5034 TBX Spring (Medium) for Lightning/Assoc.R5 series C-02-VBC-5034 Lightning TBX Spring (Medium)
C-02-VBC-5035 M1.5x10 O-ring C-02-VBC-5035 M1.5x10 O-ring
C-02-VBC-5036 M1.0x7.5 O-ring C-02-VBC-5036 M1.0x7.5 O-ring
C-02-VBC-5037 M2x6 O-ring C-02-VBC-5037 M2x6 O-ring
C-02-VBC-5038 M1.5 E-Clip C-02-VBC-5038 M1.5 E-Clip
C-02-VBC-5042 Front Springs (Medium) for Lightning/Assoc.R5 series C-02-VBC-5042 Front Springs (Medium) for Lightning 1/12
C-02-VBC-5044 Kingpin for Lightning/Assoc.R5 series C-02-VBC-5044 Lightning12 Kingpin
A-01-VBC-5045 Lightning12 Height Adjust Spacer, 1.5mm A-01-VBC-5045 Lightning12 Height Adjust Spacer, 1.5mm
A-01-VBC-5048 Lightning12 Front Upper Arm Spacer, 1.5mm A-01-VBC-5048 Lightning12 Front Upper Arm Spacer, 1.5mm
A-02-VBC-5051 Front Upper Arm for Lightning/Assoc.R5 series A-02-VBC-5051 Lightning12 Front Upper Arm
A-02-VBC-5052 Front Upper Arm Eyelet for Lightning/Assoc.R5 series A-02-VBC-5052 Lightning12 Front Upper Arm Eyelet
A-02-VBC-5053 M3x15 Turnbuckle BK for Lightning/Assoc.R5 series A-02-VBC-5053 M3x15 Turnbuckle, Black
C-02-VBC-5054 2mm Upper Pin for Lightning/Assoc.R5 series C-02-VBC-5054 2mm Upper Hinge Pin
A-01-VBC-5055 Lightning12 Caster Spacer. 0.8mm
A-01-VBC-5056 Lightning12 Caster Spacer. 1.2mm
D-05-VBC-0110 Caster Spacer Set for Lightning/Assoc.R5 series
D-05-VBC-0107 TBX Plastic Parts Set for Lightning/Assoc.R5 series
D-05-VBC-0106 TBX Shocks Parts Set for Lightning/Assoc.R5 series
D-05-VBC-0105 TBX Shock Body Set for Lightning/Assoc.R5 series
D-05-VBC-0104 TBX Center Shock Set for Lightning/Assoc.R5 series
D-05-VBC-0103 Damper Tube Set for Lightning/Assoc.R5 series
D-05-VBC-0102 Body Posts for Lightning/Assoc.R5 series
D-05-VBC-0101 Pivot Brace for Lightning/Assoc.R5 series

PARTS LIST
17
© VBC Racing LIGHTNING12
Order Number Package Descriptions Parts Number Parts Descriptions
B-02-VBC-5057 Aluminum Upper Arm Mount for Lightning/Assoc.R5 series B-02-VBC-5057 Lightning12 Aluminum Upper Arm Mount
A-02-VBC-5058 Lightning12 Steering Knuckle, Left
A-02-VBC-5059 Lightning12 Steering Knuckle, Right
B-02-VBC-5060 Lightning12 Front Axles B-02-VBC-5060 Lightning12 Front Axle
A-01-VBC-5061 Graphite Hinge Brace 55mm for Lightning/Assoc.R5 series A-01-VBC-5061 Graphite Hinge Pin Brace, 55mm
B-02-VBC-5065 Alum Front Bulkhead L for Lightning/Assoc.R5 series B-02-VBC-5065 Lightning12 Alum Front Bulkhead, Left
B-02-VBC-5066 Alum Front Bulkhead R for Lightning/Assoc.R5 series B-02-VBC-5066 Lightning12 Alum Front Bulkhead, Right
A-02-VBC-5067 Front Lower Arm for Lightning/Assoc.R5 series A-02-VBC-5067 Lightning12 Front Lower Arm
B-02-VBC-5068 Pivot Ball for Lightning/Assoc.R5 series B-02-VBC-5068 Pivot Ball
C-02-VBC-5069 King Pin Shim, M3.3x0.4 for Lightning/Assoc.R5 series C-02-VBC-5069 Lightning12 King Pin Shim, M3.3x0.4 (20pcs)
A-02-VBC-5070 Lightning12 Plastic Front Bumper, Left
A-02-VBC-5071 Lightning12 Plastic Front Bumper, Right
A-01-VBC-5072 Lightning12 Graphite Chassis Brace A-01-VBC-5072 Lightning12 Graphite Chassis Brace
A-03-VBC-1047 Side Spring (Soft)
A-03-VBC-1047 Side Spring (Medium)
A-03-VBC-1047 Side Spring (Hard)
B-02-VBC-5073 14mm Aluminum Standoff B-02-VBC-5073 14mm Aluminum Standoff
B-02-VBC-5074 Alum Side Spring Retainer for Lightning/Assoc.R5 series B-02-VBC-5074 Aluminum Side Spring Retainer
C-02-BB-3814F Bearing, 3/8 x 1/4, Flanged
C-02-BB-3814 Bearing, 3/8 x 1/4
A-02-VBC-5075 M4 Nylon Nuts
C-02-VBC-5076 Bevelled Washer
C-02-VBC-5077 Xenon 64 Pitch 93T Spur Gear
B-02-VBC-5078 Carbon Rear Axle
B-02-VBC-5079 Aluminum Wheel Hub, Left
C-02-SC-R2508 M2.5x8mm Cap Head Screw
B-02-VBC-5080 Aluminum Diff Hub
B-02-VBC-5081 Thrust Cone
C-02-DB-0801 1/8" Ceramic Diff Balls
B-02-VBC-1001 D-Drive Ring
B-02-VBC-5082 Diff Seal O-ring
A-02-VBC-5075 M4 Nylon Nuts for Lightning/Assoc.R5 series A-02-VBC-5075 M4 Nylon Nuts
C-02-VBC-5076 Bevelled Washer C-02-VBC-5076 Belleville Washer
C-02-VBC-5077 64 Pitch 93T Spur Gear for Lightning/Assoc.R5 series C-02-VBC-5077 64 Pitch 93T Spur Gear
B-02-VBC-5078 Carbon Rear Axle for Lightning/Assoc.R5 series B-02-VBC-5078 Lightning12 Carbon Rear Axle
B-02-VBC-5079 Alum Wheel Hub L for Lightning/Assoc.R5 series B-02-VBC-5079 Lightning12 Aluminum Wheel Hub, Left
B-02-VBC-5080 Alum Diff Hub for Lightning/Assoc.R5 series B-02-VBC-5080 Lightning12 Aluminum Diff Hub
B-02-VBC-5081 Thrust Cone for Lightning/Assoc.R5 series B-02-VBC-5081 Thrust Cone
C-02-DB-0801 1/8" Ceramic Diff Balls for Lightning/Assoc.R5 series C-02-DB-0801 1/8" Ceramic Diff Balls
B-02-VBC-1001 Diff Drive Ring for Lightning/Assoc.R5 series B-02-VBC-1001 Diff Drive Ring
B-02-VBC-5082 Diff Seal O-ring B-02-VBC-5082 Diff Seal O-ring
A-01-VBC-5083 Lightning12 Graphite Lower Pod Plate A-01-VBC-5083 Lightning12 Graphite Lower Pod Plate
A-01-VBC-5084 Lightning12 Graphite Upper Pod Plate A-01-VBC-5084 Lightning12 Graphite Upper Pod Plate
C-02-BB-1856F Bearing 1/8 x 5/16, Flanged for Lightning/Assoc.R5 series C-02-BB-1856F Bearing 1/8 x 5/16, Flanged
C-02-BB-3814 Bearing, 3/8 x 1/4 for Lightning/Assoc.R5 series C-02-BB-3814 Bearing, 3/8 x 1/4
C-02-BB-3814F Bearing, 3/8 x 1/4, Flanged for Lightning/Assoc.R5 series C-02-BB-3814F Bearing, 3/8 x 1/4, Flanged
A-02-VBC-5085 Axle Height Adjuster, #1
A-02-VBC-5086 Axle Height Adjuster, #2
A-02-VBC-5087 Axle Height Adjuster, #3
A-02-VBC-5088 Axle Height Adjuster, #4
B-02-VBC-5089 Lightning12 Aluminum Right Bulkhead B-02-VBC-5089 Lightning12 Aluminum Right Bulkhead
B-02-VBC-5090 Lightning12 Aluminum Left Bulkhead B-02-VBC-5090 Lightning12 Aluminum Left Bulkhead
A-01-VBC-5091 Lightning12 Graphite Motor Mount Brace A-01-VBC-5091 Lightning12 Graphite Motor Mount Brace
A-02-VBC-5092 Ball Connector 4.7x17mm A-02-VBC-5092 Ball Connector 4.7x17mm
B-02-VBC-0019-20 3x5.5x2 Alum Spacer B-02-VBC-0019-20 3x5.5x2 Alum Spacer
B-02-VBC-0019-10 3x5.5x1 Alum Spacer B-02-VBC-0019-10 3x5.5x1 Alum Spacer
C-02-SC-C0440 4-40x5/16" Cap Head Screw C-02-SC-C0440 4-40x5/16" Cap Head Screw
C-02-SC-R2504 M2.5x4mm Roundhead Screw C-02-SC-R2504 M2.5x4mm Roundhead Screw
C-02-SC-R2508 M2.5x8mm Cap Head Screw C-02-SC-R2508 M2.5x8mm Cap Head Screw
C-02-SC-R2.0x6 M2.0x6mm Cap Head Screw C-02-SC-R2.0x6 M2.0x6mm Cap Head Screw
C-02-SC-R2.0x8 M2.0x8mm Cap Head Screw C-02-SC-R2.0x8 M2.0x8mm Cap Head Screw
C-02-SC-R0204 M2x4mm Roundhead Screw C-02-SC-R0204 M2x4mm Roundhead Screw
C-02-SC-NN03 M3 Locknut C-02-SC-NN03 M3 Locknut
B-02-VBC-5093 M3x6x0.5 Spacer B-02-VBC-5093 M3x6x0.5 Spacer
C-02-SC-F0310 M3x10mm Flathead Screw C-02-SC-F0310 M3x10mm Flathead Screw
C-02-SC-R0310 M3x10mm Roundhead Screw C-02-SC-R0310 M3x10mm Roundhead Screw
C-02-SC-F0312 M3x12mm Flathead Screw C-02-SC-F0312 M3x12mm Flathead Screw
C-02-SC-F0306 M3x6mm Flathead Screw C-02-SC-F0306 M3x6mm Flathead Screw
C-02-SC-R0306 M3x6mm Roundhead Screw C-02-SC-R0306 M3x6mm Roundhead Screw
C-02-SC-F0308 M3x8mm Flathead Screw C-02-SC-F0308 M3x8mm Flathead Screw
C-02-SC-R0308 M3x8mm Roundhead Screw C-02-SC-R0308 M3x8mm Roundhead Screw
C-02-SC-SS-0308 M3x8mm Set Screw C-02-SC-SS-0308 M3x8mm Set Screw
D-05-VBC-0114 Lightning12 Axle Height Adjuster
D-05-VBC-0113 Ball Differential Complete Set for Lightning/Assoc.R5 series
A-03-VBC-1047 Side Spring Set for Lightning/Assoc.R5 series
D-05-VBC-0112 Lightning12 Plastic Front Bumper
D-05-VBC-0111 Steering Knuckles for Lightning/Assoc.R5 series

COMPETITION GRADE HIGH PERFORMANCE RADIO CONTROL RACING CAR CHASSIS KIT
1/12 SCALE ELECTRIC COMPETITION CAR KIT
Instruction Book P01-P-51097 VBC Racing Lightning12M Car Kit D-05-VBC-CK18
www.vbcracing.com
