VDH ALFA 30DP User manual
1
User manual ALFA 30DP
Thermometer.
VDH doc. 970627 Version: v1.1 Date: 01-07-1999
Software: ALFA 30DP File: DO970627.WP8 Range: -10,0/+40,0°C per 0,1°C
*Installation.
On the topside of the ALFA 30DP you can see how the sensor and power supply have to be
connected.
After connecting the ALFA 30DP to the power supply, a self test function is started. As this test is
finished the measured temperature appears in the display.
*Control.
The ALFA 30DP thermostat has for normal use no need for controls. Only for adjustment of the
sensor, the ALFA 30DP has three hidden push buttons on the front. These keys are:
SET - view / change the setpoint.
UP - increase the setpoint.
DOWN - decrease the setpoint.
These push buttons are placed at the following places at the front:
SET - To the lower right of the display.
UP - To the upper left of the display.
DOWN - To the lower left of the display.
2
*Internal parameter setting.
To adjust the sensor-offset use the following instructions;
By pushing the DOWN key more than 10 seconds, you enter the ‘internal programming menu’. In the
left display the upper and lower segments are blinking. Over the UP and DOWN keys the required
parameter can be selected (see table for the parameters). In this case only ‘04’ offset temperature
sensor.
If the required parameter is selected, the value can be read-out by pushing the SET key. Pushing the
UP and DOWN keys together with the SET key allows you to change the value of this parameter.
If after 20 seconds no key is pushed, the ALFA 30DP changes to its normal operation mode.
*Sensor adjustment.
Thesensor can be adjusted by using the Sensor Offset (parameter 04). Indicates the ALFA30DP e.g.
2°C too much, the Sensor Offset has to be decreased by 2°C.
*Error messages.
In the display of the ALFA 30DP the following error messages can appear:
Er - Sensor broken Solution:
- Check if the sensor is connected correctly.
- Check the sensor (1000Ω/25°C).
- Replace the sensor.
EE - Settings are lost. Solution:
- Reprogram the settings.
3
* Technical details.
Model : ALFA 30DP
Range : -10/+40°C, readout per 0,1°C
Supply : 230 Vac 50/60Hz
Control : by hidden pushbuttons on the front.
Front : Polycarbonate
Sensor : SM 811/2m (1000Ωat 25°C)
Sizes : 35 x 77 x 71,5mm (hwd)
Panel hole : 28 x 70mm (hw)
- Provided with memory protection during power failure.
- Connection with screw terminals on the backside.
- Equipped with self test function and sensor failure detection.
- Special version are available upon request.
*Parameters ALFA 30DP.
PARA-
METER DESCRIPTION PARAMETER RANGE STANDARD
VALUE
4 Offset temperature sensor -15..+15°C 0
*Address.
VDH Products BV Tel: +31 (0)50 30 28 900
Produktieweg 1 Fax: +31 (0)50 30 28 980
The Netherlands Internet: www.vdhproducts.nl
4
*Dimensions.
*Connection Diagram.
