Vega VEGAMET 342 User manual

Operating Instructions
Built-in controller and display instrument
for level sensors
VEGAMET 342
4 … 20 mA
Document ID: 63731

2
Contents
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
Contents
1 About this document ............................................................................................................... 4
1.1 Function ........................................................................................................................... 4
1.2 Target group ..................................................................................................................... 4
1.3 Symbols used................................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 5
2.3 Warning about incorrect use............................................................................................. 5
2.4 General safety instructions............................................................................................... 5
2.5 Installation and operation in the USA and Canada ........................................................... 6
2.6 Safety instructions for Ex areas ........................................................................................ 6
3 Product description ................................................................................................................. 7
3.1 Conguration.................................................................................................................... 7
3.2 Principle of operation........................................................................................................ 8
3.3 Adjustment ....................................................................................................................... 9
3.4 Packaging, transport and storage................................................................................... 10
4 Mounting................................................................................................................................. 11
4.1 General instructions ....................................................................................................... 11
4.2 Mounting instructions ..................................................................................................... 11
5 Connecting to power supply................................................................................................. 12
5.1 Preparing the connection ............................................................................................... 12
5.2 Sensor input mode active/passive.................................................................................. 12
5.3 Connecting..................................................................................................................... 12
5.4 Wiring plan ..................................................................................................................... 13
5.5 Switch-on phase............................................................................................................. 14
6 Access protection.................................................................................................................. 15
6.1 Bluetooth radio interface ................................................................................................ 15
6.2 Protection of the parameterization.................................................................................. 15
6.3 Storing the codes in myVEGA........................................................................................ 16
7 Set up with the integrated display and adjustment unit .................................................... 17
7.1 Adjustment system......................................................................................................... 17
7.2 Measured value and menu item display ......................................................................... 18
7.3 Menu overview ............................................................................................................... 19
7.4 Setup steps .................................................................................................................... 20
8 Setup with smartphone/tablet (Bluetooth).......................................................................... 26
8.1 Preparations................................................................................................................... 26
8.2 Connecting..................................................................................................................... 26
8.3 Parameter adjustment .................................................................................................... 27
9 Setup with PC/notebook (Bluetooth)................................................................................... 28
9.1 Preparations................................................................................................................... 28
9.2 Connecting..................................................................................................................... 28
9.3 Parameter adjustment .................................................................................................... 29
10 Applications and functions................................................................................................... 30
10.1 Levelmeasurementinstoragetankswithoverllprotection/dryrunprotection .............. 30

3
Contents
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
10.2 Pump station with pump control function........................................................................ 33
10.3 Screen control................................................................................................................ 40
10.4 Flowmeasurementume/weir........................................................................................ 41
11 Diagnostics and servicing .................................................................................................... 45
11.1 Maintenance .................................................................................................................. 45
11.2 Rectify faults................................................................................................................... 45
11.3 Diagnosis, fault messages ............................................................................................. 45
11.4 Software update ............................................................................................................. 48
11.5 How to proceed if a repair is necessary.......................................................................... 48
12 Dismount................................................................................................................................. 49
12.1 Dismounting steps.......................................................................................................... 49
12.2 Disposal ......................................................................................................................... 49
13 Certicatesandapprovals.................................................................................................... 50
13.1 Radio licenses................................................................................................................ 50
13.2 Approvals for Ex areas ................................................................................................... 50
13.3 Approvalsasoverllprotection....................................................................................... 50
13.4 Conformity...................................................................................................................... 50
13.5 Environment management system ................................................................................. 50
14 Supplement ............................................................................................................................ 51
14.1 Technical data ................................................................................................................ 51
14.2 Overview applications/functionality ................................................................................ 54
14.3 Dimensions .................................................................................................................... 56
14.4 Industrial property rights................................................................................................. 57
14.5 Licensing information for open source software ............................................................. 57
14.6 Trademark ...................................................................................................................... 57
Editing status: 2022-11-03

4
1 About this document
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,theexchangeofpartsandthesafetyofthe
user. Please read this information before putting the instrument into
operation and keep this manual accessible in the immediate vicinity
of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
This symbol indicates special instructions for Ex applications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Disposal
This symbol indicates special instructions for disposal.

5
2 For your safety
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
VEGAMET 342 is a universal controller for connection of two
4 … 20 mA sensors.
Youcannddetailedinformationabouttheareaofapplicationin
chapter " Product description".
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
2.3 Warning about incorrect use
Inappropriate or incorrect use of this product can give rise to applica-
tion-specichazards,e.g.vesseloverllthroughincorrectmounting
or adjustment. Damage to property and persons or environmental
contamination can result. Also, the protective characteristics of the
instrument can be impaired.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives.The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument.When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
During the entire duration of use, the user is obliged to determine the
compliance of the necessary occupational safety measures with the
current valid rules and regulations and also take note of new regula-
tions.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed.

6
2 For your safety
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
2.5 Installation and operation in the USA and
Canada
This information is only valid for USA and Canada. Hence the follow-
ing text is only available in the English language.
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code.
2.6 Safety instructions for Ex areas
For applications in explosion-proof areas (Ex), only devices with cor-
respondingExapprovalmaybeused.ObservetheEx-specicsafety
instructions.These are an integral part of the operating instructions
and are enclosed with every device with Ex approval.

7
3 Product description
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• Controller VEGAMET 342
• Two clamping elements for panel mounting
• Ex separating chamber (only for Ex version)
• Information sheet " Documents and software" with:
– Instrument serial number
– QR code with link for direct scanning
• Information sheet " PINs and Codes" with:
– Bluetooth access code
• Information sheet " Access protection" with:
– Bluetooth access code
– Emergency Bluetooth unlock code
– Emergency device code
The further scope of delivery encompasses:
• Documentation
– Ex-specic"Safety instructions" (with Ex versions)
– Radio licenses
– Ifnecessary,furthercerticates
Information:
Optional instrument features are also described in this operating
instructions manual.The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
• Hardware version from 1.0.0
• Software version from 1.10.0
Scope of delivery
Scope of this operating
instructions

8
3 Product description
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
1
4
3
2
Fig. 1: VEGAMET 342
1 Front plate with display and adjustment unit
2 Clamping elements
3 Ex separating chamber (only for Ex version)
4 Housing with type label and connection diagrams
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument:
• Instrument type
• Information about approvals
• Technical data
• Serial number of the instrument
• QR code for device documentation
• Number code for Bluetooth access
• Manufacturer information
Move to " www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Thereyoucanndthefollowinginformationabouttheinstrument:
• Order data
• Documentation
• Software
Alternatively,youcanndallviayoursmartphone:
• Scan the QR-code on the type label of the device or
• Enter serial number manually in the VEGA Tools app (available
free of charge in the respective stores)
Information:
If the serial number or the QR code on the type label cannot be read,
they can be found additionally on the display cover inside the device.
3.2 Principle of operation
The controller VEGAMET 342 feeds the connected 4 … 20 mA sen-
sors, processes the measured values and displays them. The built-in
housing is ideal for mounting in the switching cabinet. A large display
Constituent parts
Type label
Documents and software
Application area

9
3 Product description
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
for data visualisation as well as a turn/push button for easy adjust-
ment on site are integrated.
Itenablessimpleimplementationofpumpcontrols,owmeasure-
mentsonopenchannelsandweirs,totalizers,dierence,sumand
average value calculations.With VEGAMET 342, limit values can
bereliablymonitoredandrelayscanbeswitched,e.g.foranoverll
protection according to WHG.
Due to its various possibilities it is suitable for many industrial
branches as well as plant manufacturers.
The VEGAMET 342 controller can power the connected sensors
and process their measurement signals. The requested parameter is
shown on the display and also output to the integrated current output
for further processing.The measurement signal can thus be trans-
ferred to a remote display or a superordinate control system. Operat-
ing relays for control of pumps or other devices are also integrated.
3.3 Adjustment
On-site operation of the device is carried out via the integrated display
and adjustment unit. It consists of a graphic display and a central turn/
push button for menu adjustment.
The optionally integrated Bluetooth module enables in addition a wire-
less adjustment of VEGAMET 342 via standard adjustment tool:
• Smartphone/tablet (iOS or Android operating system)
• PC/notebook with Bluetooth LE or Bluetooth USB adapter (Win-
dows operating system)
Information:
Certain setting options are not possible or only possible to a limited
extent with the integrated display and adjustment unit, for example the
settingsforowmeasurementorpumpcontrol.Fortheseapplica-
tions, the use of PACTware/DTM or the VEGA Tools app is recom-
mended. An overview of the available applications and functions as
well as their adjustment options can be found in the appendix.
Functional principle
Local adjustment
Wireless adjustment

10
3 Product description
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
1
3
2
Fig. 2: Wireless connection to standard adjustment tools with integrated
Bluetooth LE or alternatively Bluetooth USB adapter.
1 VEGAMET 342
2 Smartphone/Tablet
3 PC/Notebook
3.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging consists of environment-friendly, recyclable card-
board. For special versions, PE foam or PE foil is also used. Dispose
of the packaging material via specialised recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Storage and transport temperature see chapter " Supplement -
Technical data - Ambient conditions"
• Relative moisture 20 … 85 %
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature

11
4 Mounting
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
4 Mounting
4.1 General instructions
The device is designed for recessed installation in a switching cabi-
net, housing front panel or switch cabinet door.The required cut-out is
92 x 92 mm (3.63 x 3.63 in) according to IEC 61554.
A VEGAMET 342 in Ex version is an auxiliary, intrinsically safe instru-
ment and may not be installed in explosion-endangered areas.
The instrument is suitable for standard and extended ambient condi-
tions acc. to DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1.
Makesurethattheenvironmentalandambientconditionsspeciedin
chapter " Technical data" are maintained.
4.2 Mounting instructions
1. Make sure that the cut-out required for mounting has a size of
92 x 92 mm (3.63 x 3.63 in).
2. Slide the device into the panel cut-out from the front.
3. Press the two tensioning elements into the provided gaps.
4. Screw in the two screws of the tensioning elements evenly with a
screwdriver.
3
2
1
Fig. 3: Front panel mounting
1 Front panel, front plate or switching cabinet door
2 Clamping elements
3 Slotted screw
Mounting options
Ambient conditions
Front panel mounting

12
5 Connecting to power supply
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
5 Connecting to power supply
5.1 Preparing the connection
Always keep in mind the following safety instructions:
• The electrical connection must only be carried out by trained,
qualiedpersonnelauthorisedbytheplantoperator.
• If overvoltage surges are expected, overvoltage arresters should
be installed.
Warning:
Only connect or disconnect in de-energized state.
Thedataforpowersupplyarespeciedinchapter"Technical data".
The voltage supply is connected with standard cable according to the
national installation standards.
Standard two-wire cable can be used to connect the sensors.
Note:
If the temperatures are too high, the cable insulation can be dam-
aged. Hence keep apart from the ambient temperature also the self-
heating of the instrument for the temperature resistance of the cable
in the connection compartment in mind. 1)
When used in the USA/Canada, only cables with copper conductors
may be used.
5.2 Sensor input mode active/passive
Through the selection of the terminals, you can choose between ac-
tive and passive operation of the sensor input.
• In active mode, the controller provides the power for the con-
nected sensors. Power and measurement data are transmitted
over the same two-wire cable.This mode is provided for connec-
tion of measuring transducers without separate power supply
(sensors in two-wire version).
• In passive mode the sensors are not powered, only the measured
value is transmitted. This input is for connection of transmitters
with their own separate voltage supply (sensors in four-wire ver-
sion).The VEGAMET 342 can also be looped into the existing
circuit like a normal ammeter.
Note:
With a VEGAMET 342 in Ex version, the passive input is not available.
5.3 Connecting
The power supply and the inputs and outputs are connected via
removablescrewterminals.Youcanndinformationonthemax.wire
cross-section in the technical data.
Safety instructions
Voltage supply
Connection cable
Connection technology
1) Withanambienttemperature≥50°C(122°F)theconnectioncableshould
besuitableforanambienttemperaturewhichisatleast20°C(36°F)higher.

13
5 Connecting to power supply
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
Connect the device as described in the following wiring plan.
5.4 Wiring plan
+
-
L+
N- 6
7
8
4
3
1
3
92
91
42
41
+
-
544
43
2
1
2
6
5
4
61
62
63
64
65
66
67
68
69
Fig. 4: Wiring plan VEGAMET 342
1 Sensor input 1 (active/passive) 2)
2 Sensor input 2 (active/passive) 3)
3 Voltage supply of the controller
4 4 … 20 mA current output 1
5 4 … 20 mA current output 2
6 Relay output 1
7 Relay output 2
8 Relay output 3
Detail sensor connection 1
+-+-
123 123
3
1
6
5
4
2
Fig. 5: Sensor input 1 for two-wire/four-wire sensor (active/passive)
1 Active input with sensor supply for two-wire sensor
2 Passive input without sensor supply for four-wire sensor 4)
3 Two-wire sensor
4 Four-wire sensor
5 Power supply for four-wire sensors
6 2 mm sockets for connection of a VEGACONNECT/HART handheld
Connecting
2) Passive input 1 not available for Ex version
3) Passive input 2 not available for Ex version
4) Passive input not available for Ex version

14
5 Connecting to power supply
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
Detail sensor connection 2
3
1
5
4
2
+-+-
456 456
6
Fig. 6: Sensor input 2 for two-wire/four-wire sensor (active/passive)
1 Active input with sensor supply for two-wire sensor
2 Passive input without sensor supply for four-wire sensor 5)
3 Two-wire sensor
4 Four-wire sensor
5 Power supply for four-wire sensors
6 2 mm sockets for connection of a VEGACONNECT/HART handheld
The Ex separating chamber must be mounted before setting up the
Ex versions of VEGAMET 342.
1
Fig. 7: Mounting the Ex-separating chamber
1 Ex separating chamber
5.5 Switch-on phase
Afterswitchingon,thedevicerstcarriesoutashortself-check.
• Internal check of the electronics
• Output signals are set to failure, background lighting of the display
lights red
The current measured values are then displayed and transmitted to
the outputs.The background lighting of the display changes to white.
Ex separating
chamber
5) Passive input not available for Ex version

15
6 Access protection
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
6 Access protection
6.1 Bluetooth radio interface
Devices with a Bluetooth radio interface are protected against un-
wanted access from outside.This means that only authorized persons
can receive measured and status values and change device settings
via this interface.
Information:
If no Bluetooth connection to the device should be possible, Bluetooth
communication can be deactivated. Access via app or DTM is thus no
longer possible.The Bluetooth function can be deactivated/activated
in the menu item " Extended functions" under " Access protection -
Bluetooth communication".
A Bluetooth access code is required to establish Bluetooth com-
munication via the adjustment tool (smartphone/tablet/notebook).
This code must be entered once when Bluetooth communication is
establishedforthersttimeintheadjustmenttool.Itisthenstoredin
the adjustment tool and does not have to be entered again.
The Bluetooth access code is individual for each device. It is printed
on the device housing and is also supplied with the device in the
information sheet " PINs and Codes".The Bluetooth access code can
also be read out via the display and adjustment unit.
TheBluetoothaccesscodecanbechangedbytheuseraftertherst
connection is established. If the Bluetooth access code is entered
incorrectly, the new entry is only possible after a waiting period has
elapsed. The waiting time increases with each further incorrect entry.
The emergency Bluetooth access code enables Bluetooth communi-
cation to be established in the event that the Bluetooth access code
is no longer known. It can't be changed. The emergency Bluetooth
access code can be found in information sheet " Access protection".
If this document is lost, the emergency Bluetooth access code can
be retrieved from your personal contact person after legitimation.
The storage and transmission of Bluetooth access codes is always
encrypted (SHA 256 algorithm).
6.2 Protection of the parameterization
The settings (parameters) of the device can be protected against un-
wanted changes.The parameter protection is deactivated on delivery,
all settings can be made.
To protect the parameterization, the device can be locked by the user
with the aid of a freely selectable device code. The settings (param-
eters) can then only be read out, but not changed.The device code
is also stored in the adjustment tool. However, unlike the Bluetooth
access code, it must be re-entered for each unlock.When using the
adjustment app or DTM, the stored device code is then suggested to
the user for unlocking.
Bluetooth access code
Emergency Bluetooth
unlock code
Device code

16
6 Access protection
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
The emergency device code allows unlocking the device in case the
device code is no longer known. It can't be changed.The emergency
device code can also be found on the supplied information sheet " Ac-
cess protection". If this document is lost, the emergency device code
can be retrieved from your personal contact person after legitimation.
The storage and transmission of the device codes is always encrypt-
ed (SHA 256 algorithm).
6.3 Storing the codes in myVEGA
If the user has a " myVEGA" account, then the Bluetooth access code
as well as the device code are additionally stored in his account under
" PINs and Codes".Thisgreatlysimpliestheuseofadditionaladjust-
ment tools, as all Bluetooth access and device codes are automati-
cally synchronized when connected to the " myVEGA" account
Emergency device code

17
7 Set up with the integrated display and adjustment unit
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
7 Set up with the integrated display and
adjustment unit
7.1 Adjustment system
The integrated display and adjustment unit is used for measured
value display, adjustment and diagnosis of the VEGAMET 342. Dis-
play and adjustment are carried out via the central turn/push buttons
and a graphic-capable display with background lighting.
Certain setting options are not possible or only possible to a limited
extent with the integrated display and adjustment unit, for example the
settingsforowmeasurementorpumpcontrol.Fortheseapplica-
tions, the use of PACTware/DTM or the VEGA Tools app is recom-
mended. A tabular overview of the corresponding applications and
functions can be found in the appendix.
2
3
4
1
5
Fig. 8: Display and adjustment elements
1 LC display
2 Status indication relay
3 Status indication fault signal
4 Status indication operation
5 Turn/push button for menu adjustment
Via the HART communication sockets integrated in the terminals, a
parameter adjustment of the connected HART sensors can be carried
out without interrupting the measuring circuit.The resistor required
forthispurpose(230Ω)isalreadyintegratedinVEGAMET342.The
sockets have an inner diameter of 2 mm for direct connection of a
VEGACONNECT or other HART modems. The adjustment of the con-
nected sensor is carried out via the VEGA Tools app or via PACTware
and appropriate DTM.
Function
Display and adjustment
elements
HART communication
sockets

18
7 Set up with the integrated display and adjustment unit
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
Turn/Push button Function
Short pressure Entry to the menu level
Jump to selected menu item
Edit parameter
Select editing position
Save value
Turn Change between the measured value indications
Navigation in the menu items
Change parameter values
Long pressure Jump to next higher menu
Key pressing longer than 2 s, direct return to the
measured value indication
Cancel input without saving
Approx. 60 minutes after the last pressing of a key, an automatic reset
tomeasuredvalueindicationistriggered.Anyvaluesnotconrmed
will not be saved.
7.2 Measured value and menu item display
The measured value display shows the digital display value, the
measuring loop name (measuring loop TAG) and the unit. In addition,
an analogue bar graph can be displayed. Up to three measured value
indicationswithamaximumthreedierentmeasuredvaluescanbe
congured.Ifpumpcontrolisactivated,anadditionalstatusbarwith
display of the assigned pumps is available.
Measured values are displayed according to the following presenta-
tion:
1
2
3
4
5
6
7
TAG-No. 1
%
47.8
12
Fig. 9: Example measured value indication (measured value with bargraph)
1 Measurement loop name
2 Measured value
3 Unit
4 Status message acc. to NAMUR NE 107
5 Status bar for pump control
6 Bargraph measured value
7 Active measured value indication
The display is equipped with a background lighting for better visibility.
It serves simultaneously as a status display which is also visible from
Functions turn/push
button
Time functions
Measured value indica-
tion
Status display/back-
ground lighting

19
7 Set up with the integrated display and adjustment unit
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
a great distance.The colour of the background lighting changes in the
delivery status according to NAMUR NE 107.
• White: Error-free operation
• Red: Failure, error, fault
• Orange: Function check
• Blue: Maintenance required
• Yellow:Outsidethespecication
Alternatively, the status display can also show the switching status of
therelaysormeasuredvaluerangesindividuallywithfreelydenable
colours.Uptovemeasuredvalueranges,e.g.,dependingonthe
llinglevel,canbedisplayedindierentcolours.Thebackground
lightingcanalsobeconguredtoashinanycolourasanadditional
signalling option.
Information:
ThisindividualcoloursignallingisconguredwithPACTware/DTMor
the VEGA Tools app.
The menu items are displayed according to the following presentation:
1
2
Max. adjustment
Sensor value at 100% :
Actual measured sensor value :
19.970
mA
20.000
mA
Fig. 10: Menu item display (example)
1 Sensor measured value at 100 %
2 Current sensor measured value
7.3 Menu overview
Description Basic settings
Sensor input Allocation measuring point - input, deactivate
measuring point 2
Damping Time setting for damping
Linearisation Linearization settings
Adjustment Adjustment settings
Scaling Scaling settings
Outputs Relay/current output settings
Description Basic settings
Number of measured
value indications
Number of displayed measured value indications
Menu item display
Measurement loop
Indication

20
7 Set up with the integrated display and adjustment unit
VEGAMET 342 • 4 … 20 mA
63731-EN-221107
Description Basic settings
Measured value indi-
cation
Settings for the measured value displays, automatic
change of the measured value display
Options Display options e.g. brightness, contrast, illumina-
tion
Menu language Language settings
Description Basic settings
Fail safe relay Activate/deactivate fail safe relay
Access protection Access protection for Bluetooth and protection of
the parameter adjustment
Reset Reset of the device
Description Basic settings
Status Status indication, e.g. device, sensor, relay
Simulation Simulation function
Device-TAG Display device name
Device information Device information, e.g. serial number
7.4 Setup steps
Through parameter adjustment, the instrument is adapted to the
individual application conditions. A measurement loop calibration is
the most important step and should always be carried out. A scaling
of the measured value to the desired physical variable and unit, pos-
sibly including a linearization curve, is often useful. The adaptation of
the relay switching points or the setting of a damping to smooth the
measured value are further standard adjustment options.
Information:
When using PACTware and the respective DTM or the VEGA Tools
app, additional settings can be carried out which are not possible or
only partly possible with the integrated display and adjustment unit.
Communication takes place via the built-in Bluetooth interface.
Thedeviceisconguredexworksforuniversalapplications.The
followingapplicationscanbechangedoverandconguredviathe
VEGA Tools app or the DTM:
• Universal
• Level storage tank
• Calculationdierence
• Calculation total
• Calculation of average value
• Wells
• Pumping station
• Sewage screw lifting station
• Screen control
Extended functions
Diagnostics
Parameter adjustment
Applications
