Vega VEGAPOINT 11 User manual

Operating Instructions
Capacitive level switch
VEGAPOINT 11
Transistor (PNP)
Document ID: 56622

2
Contents
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
Contents
1 About this document ............................................................................................................... 4
1.1 Function ........................................................................................................................... 4
1.2 Target group ..................................................................................................................... 4
1.3 Symbols used................................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 5
2.3 Warning about incorrect use............................................................................................. 5
2.4 General safety instructions............................................................................................... 5
2.5 Installation and operation in the USA and Canada ........................................................... 5
3 Product description ................................................................................................................. 7
3.1 Conguration.................................................................................................................... 7
3.2 Principle of operation........................................................................................................ 8
3.3 Adjustment ....................................................................................................................... 9
3.4 Packaging, transport and storage..................................................................................... 9
3.5 Accessories.................................................................................................................... 10
4 Mounting................................................................................................................................. 11
4.1 General instructions ....................................................................................................... 11
4.2 Mounting instructions ..................................................................................................... 12
5 Connecting to power supply................................................................................................. 14
5.1 Preparing the connection ............................................................................................... 14
5.2 Connecting..................................................................................................................... 15
5.3 Wiring plan ..................................................................................................................... 15
5.4 Switch-on phase............................................................................................................. 15
6 Setup ....................................................................................................................................... 16
6.1 Indication of the switching status.................................................................................... 16
6.2 Function table................................................................................................................. 16
7 Diagnostics and servicing .................................................................................................... 17
7.1 Maintenance .................................................................................................................. 17
7.2 Rectify faults................................................................................................................... 17
7.3 Diagnosis, fault messages ............................................................................................. 17
7.4 How to proceed if a repair is necessary.......................................................................... 19
8 Dismount................................................................................................................................. 20
8.1 Dismounting steps.......................................................................................................... 20
8.2 Disposal ......................................................................................................................... 20
9 Certicatesandapprovals.................................................................................................... 21
9.1 Foodandpharmaceuticalcerticates............................................................................. 21
9.2 Conformity...................................................................................................................... 21
9.3 Environment management system ................................................................................. 21
10 Supplement ............................................................................................................................ 22
10.1 Technical data ................................................................................................................ 22
10.2 Dimensions .................................................................................................................... 24
10.3 Industrial property rights................................................................................................. 26
10.4 Licensing information for open source software ............................................................. 26

3
Contents
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
10.5 Trademark ...................................................................................................................... 26
Editing status: 2022-09-27

4
1 About this document
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,theexchangeofpartsandthesafetyofthe
user. Please read this information before putting the instrument into
operation and keep this manual accessible in the immediate vicinity
of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
ThissymbolindicatesspecialinstructionsforExapplications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Disposal
This symbol indicates special instructions for disposal.

5
2 For your safety
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
The VEGAPOINT 11 is a sensor for point level detection.
Youcannddetailedinformationabouttheareaofapplicationin
chapter " Product description".
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
2.3 Warning about incorrect use
Inappropriate or incorrect use of this product can give rise to applica-
tion-specichazards,e.g.vesseloverllthroughincorrectmounting
or adjustment. Damage to property and persons or environmental
contamination can result. Also, the protective characteristics of the
instrument can be impaired.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives. The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument. When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed.
2.5 Installation and operation in the USA and
Canada
This information is only valid for USA and Canada. Hence the follow-
ingtextisonlyavailableintheEnglishlanguage.

6
2 For your safety
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code
A Class 2 power supply unit has to be used for the installation in the
USA and Canada.

7
3 Product description
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• VEGAPOINT 11 point level switch
• Information sheet " Documents and software" with:
– Instrument serial number
– QR code with link for direct scanning
Information:
Optional instrument features are also described in this operating
instructions manual. The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
• Hardware version from 1.0.1
• Software version from 1.2.5
The VEGAPOINT 11 consists of the components:
• Housing with integrated electronics
• Processtting
• Plug
AB
1
2
3
4
5
Fig. 1: VEGAPOINT 11
A Device version with full metal housing 316L
B Device version with housing 316L and plastic
1 Plug connection
2 360° status indication
3 Instrument housing
4 Processtting
5 Sensor
Youwillndthetypeplateonthesensorhousing.
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument.
Scope of delivery
Scope of this operating
instructions
Constituent parts
Type label

8
3 Product description
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
1
3
2
5
6
7
8
9
10
4
2020
www.vega.com
D-77761 SCHILTACH,
Made in Germany
VEGAPOINT 11
CP - 222 3DA
12...35V 100mW
s/n 1234567
PNP 250mA
IP66/67/69, TYPE 6P
PEEK, EPDM, 316L
MWP 25bar (2500kPa)
Fig. 2: Layout of the type label (example)
1 Order number
2 Product name
3 Serial number
4 Voltage supply and signal output
5 Protection rating
6 Permissible process pressure
7 Material wetted parts
8 QR code for device documentation
9 Fabrication year
10 Approvals
Move to " www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Thereyoucanndthefollowinginformationabouttheinstrument:
• Order data
• Documentation
• Software
Alternatively,youcanndallviayoursmartphone:
• Scan the QR-code on the type label of the device or
• Enter serial number manually in the VEGA Tools app (available
free of charge in the respective stores)
3.2 Principle of operation
The VEGAPOINT 11 is a capacitive point level sensor for point level
detection
It is designed for industrial use in all areas of process technology and
can be used in water-based liquids.
Typicalapplicationsareoverllanddryrunprotection.Withathe
small sensor unit, VEGAPOINT 11 can be also mounted e.g. in thin
pipelines. The sensor allows use in vessels, tanks and pipes. Thanks
Documents and software
Application area

9
3 Product description
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
to its simple and robust measuring system, VEGAPOINT 11 is virtual-
lyunaectedbythechemicalandphysicalpropertiesofthemedium.
Itfunctionsevenunderdicultconditionssuchasturbulence,airbub-
bles,buildup,strongexternalvibrationorchangingproducts.
If a malfunction is detected or in case of voltage supply, the electron-
icstakesonadenedswitchingstatus,i.e.theoutputisopen(safe
state).
Analternatingelectriceldisgeneratedatthetipofthemeasur-
ing electrode. If the sensor is covered with medium, the resonance
frequency changes.This change is detected by the electronics and
converted into a switching command.
Buildupisignoredtoacertaindegreeandthereforehasnoinuence
on the measurement.
3.3 Adjustment
The switching status of VEGAPOINT 11 can be checked from outside
(360° status indication).
Note:
The LED illuminated ring is not available for device versions with full
metal housing.
3.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging consists of environment-friendly, recyclable card-
board. For special versions, PE foam or PE foil is also used. Dispose
of the packaging material via specialised recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Notexposedtocorrosivemedia
• Protected against solar radiation
• Avoiding mechanical shock and vibration
Functional principle
Packaging
Transport
Transport inspection
Storage

10
3 Product description
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
• Storage and transport temperature see chapter " Supplement -
Technical data - Ambient conditions"
• Relative moisture 20 … 85 %
3.5 Accessories
The instructions for the listed accessories can be found in the down-
load area on our homepage.
Various threaded and hygienic sockets are available for devices with
threaded version.
Youcanndfurtherinformationinchapter"Technical Data".
Storage and transport
temperature
Threaded and hygienic
socket

11
4 Mounting
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
4 Mounting
4.1 General instructions
Theinstrumentissuitableforstandardandextendedambientcondi-
tions acc. to DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1. It can be used
indoors as well as outdoors.
Note:
For safety reasons, the instrument must only be operated within the
permissibleprocessconditions.Youcannddetailedinformationon
the process conditions in chapter " Technical data" of the operating
instructions or on the type label.
Hencemakesurebeforemountingthatallpartsoftheinstrumentex-
posedtotheprocessaresuitablefortheexistingprocessconditions.
These are mainly:
• Active measuring component
• Processtting
• Process seal
Process conditions in particular are:
• Process pressure
• Process temperature
• Chemical properties of the medium
• Abrasionandmechanicalinuences
The VEGAPOINT 11 can be mounted in any position.The instrument
must be mounted in such a way that the sensor is at the height of the
requested switching point.
1
3
2
Fig. 3: Installation examples
1 Upperleveldetection(max.)asoverowprotection
2 Lower level detection (min.) as dry run protection
3 Dry run protection (min.) for a pump
Ambient conditions
Process conditions
Switching point

12
4 Mounting
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
Note that the switching point varies depending on the type of medium
and the mounting position of the sensor.
Protect your instrument against moisture ingress through the following
measures:
• Firmly tighten the plug connector
• Lead the connection cable downwards in front of the plug connec-
tor
This applies mainly to outdoor installations, in areas where high
humidityisexpected(e.g.throughcleaningprocesses)andoncooled
or heated vessels.
The level switch is a measuring device for stationary screw mounting
and must be treated accordingly. Damage to the measuring tip will
destroy the instrument.
Usethehexagonabovethethreadforscrewingin.
Aftermounting,makesurethattheprocessttingisscrewedincor-
rectlyandthussecurelysealsevenatmaximumprocesspressure.
4.2 Mounting instructions
In adhesive and viscous media, the surfaces of the sensor should
protrude into the vessel to avoid buildup. Therefore mounting bosses
shouldnotexceedacertainlength.
Fig. 4: Adhesive products
Inhorizontalpipelines,avoidmountingintheupperorlowerareaof
the pipe.
In the upper part of the pipe cavities can form due to air inclusions.
Solids can settle in the lower pipe area. Both can lead to measure-
ment errors.
Inhorizontalpipelines,lateralinstallationisthereforerecommended.
Protection against mois-
ture
Handling
Adhesive products

13
4 Mounting
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
x
x
A
B
Fig. 5: Installation in horizontal pipelines
x Recommended mounting area
A Not recommended - danger of air inclusions
B Not recommended - Danger of buildup
IfVEGAPOINT11ismountedinthellingstream,unwantedfalse
measurement signals can be generated. For this reason, mount VE-
GAPOINT 11 at a position in the vessel where no disturbances, e.g.
fromllingopenings,agitators,etc.,canoccur.
Inowingmedium

14
5 Connecting to power supply
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
5 Connecting to power supply
5.1 Preparing the connection
Always keep in mind the following safety instructions:
• Carryoutelectricalconnectionbytrained,qualiedpersonnel
authorised by the plant operator
• Ifovervoltagesurgesareexpected,overvoltagearrestersshould
be installed
Warning:
Onlyconnectordisconnectinde-energizedstate.
Thedataforpowersupplyarespeciedinchapter"Technical data".
Note:
Powertheinstrumentviaanenergy-limitedcircuit(powermax.100W)
acc. to IEC 61010-1, e.g.
• Class 2 power supply unit (acc. to UL1310)
• SELVpowersupplyunit(safetyextra-lowvoltage)withsuitable
internalorexternallimitationoftheoutputcurrent
Keepinmindthefollowingadditionalfactorsthatinuencetheoperat-
ing voltage:
• Lower output voltage of the power supply unit under nominal load
• Inuenceofadditionalinstrumentsinthecircuit(seeloadvaluesin
chapter " Technical data")
The instrument is connected with standard four-wire cable. If electro-
magneticinterferenceisexpectedwhichisabovethetestvaluesof
EN 61326-1 for industrial areas, shielded cable should be used.
Make sure that the cable and the plug used have the required
temperatureresistanceandresafetyformax.occurringambient
temperature.
When mounting outdoors, on cooled vessels or in moist areas in
which cleaning is made with steam or high pressure, it is very impor-
tant that the plug is screwed on correctly.
Safety instructions
Voltage supply
Connection cable
Plug connections

15
5 Connecting to power supply
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
5.2 Connecting
AB
1
2
3
4
5
Fig. 6: VEGAPOINT 11 - M12 x 1 plug
A Device version with full metal housing 316L
B Device version with housing 316L and plastic
1 Plug connection
2 360° status indication
3 Instrument housing
4 Processtting
5 Sensor
This plug connection requires a prefabricated cable with plug. De-
pending on the version, protection IP66/IP67 or IP69.
5.3 Wiring plan
For connection to binary inputs of a PLC.
2 2
out 2
out 1
+
-
1
2
4
1
3
Fig. 7: Wiring plan M12 x 1 plug - Transistor output, three-wire
1 Voltage supply
2 PNP switching
Contact, plug connector Function/Polarity
1 Voltage supply/+
2 Transistor output 2
3 Voltage supply/-
4 Transistor output 1
5.4 Switch-on phase
Afterswitchingon,thedevicerstcarriesoutaself-check.
The current measured value is then output on the signal cable.
Instrument versions
M12 x 1 plug connection
M12 x 1 plug

16
6 Setup
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
6 Setup
6.1 Indication of the switching status
The switching status of the electronics can be checked via the 360°
status indication (LEDs) integrated in the upper part of the housing.
The colours of the 360° status indication have the following meaning:
1)
• Green lights up - power supply connected, sensor output high-
impedance
• Greenashing-Maintenancerequired
• Yellow lights up - power supply connected, sensor output low
impedance
• Red lights - shortcircuit or overload in the load circuit (sensor
output high-impedance)
• Redashing-Erroratsensororelectronics(sensoroutputhigh
impedance) or device is in simulation
6.2 Function table
The following table provides an overview of the switching conditions
depending on the set mode and the level (factory setting).
Coverage Switching sta-
tus 2)
Output 1
Switching sta-
tus 3)
Output 2
Control lamp 4)
Covered open closed Green
Uncovered closed open Yellow
Covered/Uncov-
ered
open open Red
1) Default setting
2) Default setting
3) Default setting
4) Output 1

17
7 Diagnostics and servicing
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
7 Diagnostics and servicing
7.1 Maintenance
If the device is used properly, no special maintenance is required in
normal operation.
The cleaning helps that the type label and markings on the instrument
are visible.
Take note of the following:
• Use only cleaning agents which do not corrode the housings, type
label and seals
• Use only cleaning methods corresponding to the housing protec-
tion rating
7.2 Rectify faults
The operator of the system is responsible for taking suitable meas-
ures to rectify faults.
Thedeviceoersmaximumreliability.Nevertheless,faultscanoccur
during operation. These may be caused by the following, e.g.:
• Sensor
• Process
• Voltage supply
• Signal processing
Therstmeasuretotakeistochecktheoutputsignal.Inmanycases,
thecausescanbedeterminedthiswayandthefaultsquicklyrectied.
Depending on the reason for the fault and the measures taken, the
steps described in chapter " Setup" must be carried out again or must
be checked for plausibility and completeness.
Should these measures not be successful, please call in urgent cases
the VEGA service hotline under the phone no. [phone].
The hotline is also available outside normal working hours, seven
days a week around the clock.
Sinceweoerthisserviceworldwide,thesupportisprovidedin
English. The service itself is free of charge, the only costs involved are
the normal call charges.
7.3 Diagnosis, fault messages
The 360° status indication on the device indicates the operating
status of the device. At the same time it indicates the switching state
of the output. This enables simple on-site diagnosis without the need
for tools.
Maintenance
Cleaning
Reaction when malfunc-
tion occurs
Causes of malfunction
Faultrectication
Reaction after fault recti-
cation
24 hour service hotline
Checking the switching
signal

18
7 Diagnostics and servicing
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
Error Cause Rectication
Greensignallampo Voltage supply interrupted. Check voltage supply and cable connection
Electronics defective Exchangetheinstrumentorsenditinforrepair
Greensignallampashes Maintenance required Carry out maintenance
Red signal lamp lights (switch-
ing output high-impedance)
Error with the electrical con-
nection
Connect device according to wiring plan
Shortcircuit or overload Check electrical connection
Measuring tip damaged Check whether the measuring tip is damaged
Redsignallampashes
(switching output high-imped-
ance)
Sensoroutsidethespeci-
cation
Check sensor adjustment
Switching points may be interchanged
Sensor is in simulation mode Terminate simulation mode
Information:
You can read out the error codes from the IO-Link data.
Under " Device Status"(ISDU36)youcanndthestatusofthe
device.
Failure/Error
Red control lamp lights up
Error Cause Rectication
F013 no measured value available Error in the electronics
Restart instrument
If the error occurs again, replace the device
F080 General software error Restart instrument
F105 Measured value is determined Device is still in the switch-on phase
Wait until the device is ready for operation
F111 Switching points interchanged Repeat sensor adjustment
The switching point (SP) must be smaller than the reset point
(RP)
F260 Error in the calibration Repeat device adjustment
If the error occurs again, replace the device
F261 Error in the instrument settings Carry out device reset
Reset device to delivery status
Outofspecication
Redsignallampashes
Error Cause Rectication
S600 Electronics temperature too
high
Error in the electronics
Allow device to cool down and restart
If the error occurs again, check the ambient temperature
Error messages

19
7 Diagnostics and servicing
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
Outofspecication
Redsignallampashes
Error Cause Rectication
S604 Overload on output Switching output overloaded
Check electrical connection
Reduce switching load
Function check
Redsignallampashes
Error Cause Rectication
C700 Simulation active Terminate simulation mode
7.4 How to proceed if a repair is necessary
Youcanndaninstrumentreturnformaswellasdetailedinformation
about the procedure in the download area of our homepage. By doing
this you help us carry out the repair quickly and without having to call
back for needed information.
Proceed as follows in case of repair:
• Printandlloutoneformperinstrument
• Clean the instrument and pack it damage-proof
• Attach the completed form and, if need be, also a safety data
sheet outside on the packaging
• Ask the agency serving you to get the address for the return ship-
ment.Youcanndtheagencyonourhomepage.

20
8 Dismount
VEGAPOINT 11 • Transistor (PNP)
56622-EN-221012
8 Dismount
8.1 Dismounting steps
To remove the device, carry out the steps in chapters " Mounting" and
" Connecting to power suplly" in reverse.
Warning:
When dismounting, pay attention to the process conditions in vessels
or pipelines.There is a risk of injury, e.g. due to high pressures or tem-
peraturesaswellasaggressiveortoxicmedia.Avoidthisbytaking
appropriate protective measures.
8.2 Disposal
Pass the instrument on to a specialised recycling company and do not
use the municipal collecting points.
Remove any batteries in advance, if they can be removed from the
device, and dispose of them separately.
If personal data is stored on the old device to be disposed of, delete it
before disposal.
If you have no way to dispose of the old instrument properly, please
contact us concerning return and disposal.
