1 About this document
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,theexchangeofpartsandthesafetyofthe
user. Please read this information before putting the instrument into
operation and keep this manual accessible in the immediate vicinity
of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
This symbol indicates special instructions for Ex applications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.

5
2 For your safety
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
The VEGAPOINT 21 is a sensor for point level detection.
Youcannddetailedinformationabouttheareaofapplicationin
chapter " Product description".
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
2.3 Warning about incorrect use
Inappropriate or incorrect use of this product can give rise to applica-
tion-specichazards,e.g.vesseloverllthroughincorrectmounting
or adjustment. Damage to property and persons or environmental
contamination can result. Also, the protective characteristics of the
instrument can be impaired.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives.The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument. When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed.
2.5 Installation and operation in the USA and
Canada
This information is only valid for USA and Canada. Hence the follow-
ing text is only available in the English language.

6
2 For your safety
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code
A Class 2 power supply unit has to be used for the installation in the
USA and Canada.
2.6 Safety instructions for Ex areas
For Ex applications, only devices with corresponding Ex approval may
beused.ObservetheEx-specicsafetyinstructions.Thesearean
integral part of the operating instructions and are enclosed with every
device with Ex approval.

7
3 Product description
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• VEGAPOINT 21 point level switch
• Information sheet " Documents and software" with:
– Instrument serial number
– QR code with link for direct scanning
• Information sheet " PINs and Codes" (with Bluetooth versions)
with:
– Bluetooth access code
Note:
Optional instrument features are also described in this operating
instructions manual.The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
• Hardware version from 1.0.0
• Software version from 1.3.0
The VEGAPOINT 21 consists of the components:
• Housing with integrated electronics
• Processtting
• Plug
1
2
3
4
5
Fig. 1: VEGAPOINT 21
1 LED illuminated ring
2 Instrument housing
3 Processtting
4 Sensor
5 Plug connection
Youwillndthetypeplateonthesensorhousing.
Scope of delivery
Scope of this operating
instructions
Constituent parts
Type label

8
3 Product description
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument.
VEGAPOINT
s/n 1234567CP - 222 22X
IP65, TYPE 4X
MWP 25bar (2500kPa)
PEEK, FKM, 316L
2020
www.vega.com
D-77761 SCHILTACH,
Made in Germany
12...35V 1W
0044
PNP/NPN 250mA
5
6
7
8
9
10
12
11
1
13
4
2
3
12
3
+
-
123456
Fig. 2: Layout of the type label (example)
1 Order number
2 Approvals (option)
3 Warning instructions
4 Voltage supply and signal output
5 Protection rating
6 Permissible process pressure
7 Material, wetted parts
8 Connection diagram
9 QR code for device documentation
10 Conformities and approvals (optional)
11 Bluetooth access code
12 Serial number
13 Product name
Move to " www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Thereyoucanndthefollowinginformationabouttheinstrument:
• Order data
• Documentation
• Software
Alternatively,youcanndallviayoursmartphone:
• Scan the QR-code on the type label of the device or
• Enter serial number manually in the VEGA Tools app (available
free of charge in the respective stores)
3.2 Principle of operation
The VEGAPOINT 21 is a capacitive point level sensor for point level
detection
Documents and software
Application area

9
3 Product description
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
It is designed for industrial use in all areas of process technology and
can be used in water-based liquids.
Typicalapplicationsareoverllanddryrunprotection.Withathe
small sensor unit, VEGAPOINT 21 can be also mounted e.g. in thin
pipelines.The sensor allows use in vessels, tanks and pipes. Thanks
to its simple and robust measuring system, VEGAPOINT 21 is virtu-
allyunaectedbythechemicalandphysicalpropertiesoftheliquid.
Italsoworksunderdicultmeasuringconditionssuchasturbulence,
air bubbles, strong external vibrations or changing media. In addition,
the sensor can also detect foam.
Function monitoring
The electronics module of VEGAPOINT 21 continuously monitors the
following criteria via frequency generation:
• Failure of the signal generation
• Line break to the sensor element
If a malfunction is detected or in case of voltage supply, the electron-
icstakesonadenedswitchingstatus,i.e.theoutputisopen(safe
state).
Analternatingelectriceldisgeneratedatthetipofthemeasur-
ing electrode. If the sensor is covered with medium, the resonance
frequency changes.This change is detected by the electronics and
converted into a switching command.
Buildupisignoredtoacertaindegreeandthereforehasnoinuence
on the measurement.
3.3 Adjustment
The switching status of VEGAPOINT 21 can be checked from outside
(LED illuminated ring).
The optionally integrated Bluetooth module enables in addition a wire-
less adjustment of VEGAPOINT 21.
This is done via standard operating devices:
• Smartphone/tablet (iOS or Android operating system)
• PC/notebook with Bluetooth LE or Bluetooth USB adapter (Win-
dows operating system)
Functional principle
Local adjustment
Wireless adjustment

10
3 Product description
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
3
2
4
1
Fig. 3: Wireless connection to standard adjustment devices with integrated
Bluetooth LE or alternatively Bluetooth USB adapter.
1 Sensor
2 Smartphone/Tablet
3 PC/Notebook
4 Bluetooth USB adapter
3.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging consists of environment-friendly, recyclable card-
board. For special versions, PE foam or PE foil is also used. Dispose
of the packaging material via specialised recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
• Protected against solar radiation
• Avoiding mechanical shock and vibration
Packaging
Transport
Transport inspection
Storage

11
3 Product description
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
• Storage and transport temperature see chapter " Supplement -
Technical data - Ambient conditions"
• Relative humidity 20 … 85 %
3.5 Accessories
The instructions for the listed accessories can be found in the down-
load area on our homepage.
Various threaded and hygienic sockets are available for devices with
threaded version.
Youcanndfurtherinformationinthe"Technicaldata"
Storage and transport
temperature
Threaded and hygienic
socket

12
4 Mounting
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
4 Mounting
4.1 General instructions
The instrument is suitable for standard and extended ambient condi-
tions acc. to DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1. It can be used
indoors as well as outdoors.
Note:
For safety reasons, the instrument must only be operated within the
permissibleprocessconditions.Youcannddetailedinformationon
the process conditions in chapter " Technical data" of the operating
instructions or on the type label.
Hence make sure before mounting that all parts of the instrument ex-
posed to the process are suitable for the existing process conditions.
These are mainly:
• Active measuring component
• Processtting
• Process seal
Process conditions in particular are:
• Process pressure
• Process temperature
• Chemical properties of the medium
• Abrasionandmechanicalinuences
The VEGAPOINT 21 can be mounted in any position.The instrument
must be mounted in such a way that the sensor is at the height of the
requested switching point.
1
3
2
Fig. 4: Installation examples
1 Upperleveldetection(max.)asoverowprotection
2 Lower level detection (min.) as dry run protection
3 Dry run protection (min.) for a pump
Ambient conditions
Process conditions
Switching point

13
4 Mounting
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
Note that the switching point varies depending on the type of medium
and the mounting position of the sensor.
Protect your instrument against moisture ingress through the following
measures:
• Use a suitable connection cable (see chapter " Connecting to
power supply")
• Tighten the cable gland or plug connector
• Lead the connection cable downward in front of the cable entry or
plug connector
This applies mainly to outdoor installations, in areas where high
humidity is expected (e.g. through cleaning processes) and on cooled
or heated vessels.
The level switch is a measuring device for stationary screw mounting
and must be treated accordingly. Damage to the measuring tip will
destroy the instrument.
Use the hexagon above the thread for screwing in.
Aftermounting,makesurethattheprocessttingisscrewedincor-
rectly and thus securely seals even at maximum process pressure.
4.2 Mounting instructions
In adhesive and viscous media, the surfaces of the sensor should
protrude into the vessel to avoid buildup.Therefore mounting bosses
should not exceed a certain length.
Fig. 5: Adhesive products
In horizontal pipelines, avoid mounting in the upper or lower area of
the pipe.
In the upper part of the pipe cavities can form due to air inclusions.
Solids can settle in the lower pipe area. Both can lead to measure-
ment errors.
In horizontal pipelines, lateral installation is therefore recommended.
Protection against mois-
ture
Handling
Adhesive products

14
4 Mounting
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
x
x
A
B
Fig. 6: Installation in horizontal pipelines
x Recommended mounting area
A Not recommended - danger of air inclusions
B Not recommended - Danger of buildup
IfVEGAPOINT21ismountedinthellingstream,unwantedfalse
measurement signals can be generated. For this reason, mount VE-
GAPOINT 21 at a position in the vessel where no disturbances, e.g.
fromllingopenings,agitators,etc.,canoccur.
Inowingmedium

15
5 Connecting to power supply
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
5 Connecting to power supply
5.1 Preparing the connection
Always keep in mind the following safety instructions:
• Carryoutelectricalconnectionbytrained,qualiedpersonnel
authorised by the plant operator
• If overvoltage surges are expected, overvoltage arresters should
be installed
Warning:
Only connect or disconnect in de-energized state.
Thedataforpowersupplyarespeciedinchapter"Technical data".
Note:
Power the instrument via an energy-limited circuit (power max. 100 W)
acc. to IEC 61010-1, e.g.
• Class 2 power supply unit (acc. to UL1310)
• SELV power supply unit (safety extra-low voltage) with suitable
internal or external limitation of the output current
Keepinmindthefollowingadditionalfactorsthatinuencetheoperat-
ing voltage:
• Lower output voltage of the power supply unit under nominal load
• Inuenceofadditionalinstrumentsinthecircuit(seeloadvaluesin
chapter " Technical data")
Use cable with round cross section. Depending on the plug connec-
tion, you have to select the outer diameter of the cable respectively so
thatthesealeectofthecableglandisensured.
The instrument is connected with standard four-wire cable. If electro-
magnetic interference is expected which is above the test values of
EN 61326-1 for industrial areas, shielded cable should be used.
• Valve plug ISO 4400, ø 4.5 … 7 mm
• Valve plug ISO 4400 with IDC crimping technology, ø 5.5 … 8 mm
• Valve plug ISO 4400 with hinged cover, ø 4,5 … 7 mm
Safety instructions
Voltage supply
Connection cable

16
5 Connecting to power supply
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
5.2 Connecting
1 2
44
3
4
Fig. 7: Plug versions
1 Valve plug ISO 4400
2 Valve plug ISO 4400 with IDC method of termination
3 Valve plug ISO 4400 with hinged cover
4 LED illuminated ring
For this plug version, standard cable with round wire cross-section
can be used. Cable diameter 4.5 … 7 mm, protection IP65.
1. Loosen the screw on the rear of the plug connector
2. Remove the plug connector and seal from VEGAPOINT 21
3. Remove the plug insert from the plug housing
4. Remove approx. 5 cm of the cable mantle, strip approx. 1 cm
insulation from the individual wires
5. Lead the cable through the cable gland into the plug housing
6. Connect the wire ends to the screw terminals according to the
wiring plan
Instrument versions
Valve plug ISO 4400

17
5 Connecting to power supply
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
1
4
5
6
7
8
2 3
Fig. 8: Connection, valve plug ISO 4400
1 Pressure screw
2 Pressure disc
3 Seal ring
4 Fixing screw
5 Seal washer
6 Plug housing
7 Plug insert
8 Proleseal
7. Snap the plug insert into the plug housing and insert the sensor
seal
8. Plug the plug insert with seal to VEGAPOINT 21 and tighten the
screw
For this plug version you can use standard cable with round wire
cross-section.The inner conductors do not have to be stripped. The
plug connects the conductors automatically when screwing in. Cable
diameter 5.5 … 8 mm, protection IP67.
1 2 3 4
5
Fig. 9: Connection, valve plug ISO 4400 with IDC crimping technology
1 Compression nut
2 Cable
3 Seal ring
4 Terminal insert
5 Plug housing
Valve plug ISO 4400 with
IDC method of termina-
tion

18
5 Connecting to power supply
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
For this plug version, standard cable with round wire cross-section
can be used. Cable diameter 4.5 … 7 mm, protection IP65.
1. Loosen the screw in the cover of the plug connector
2. Open the cover and remove it
3. Press the plug insert downwards
4. Loosen the screws of the strain relief and cable entry
4
32
1
3
2
1
Fig. 10: Loosen the plug insert
1 Plug insert
2 Strain relief
3 Cable gland
4 Plug housing
5. Remove approx. 5 cm of the cable mantle, strip approx. 1 cm
insulation from the individual wires
6. Lead the cable through the cable gland into the plug housing
7. Connect the wire ends to the screw terminals according to the
wiring plan
1
5
2
3
4
Fig. 11: Connection to the screw terminals
1 Cable gland
2 Cover
3 Plug housing
4 Plug insert
5 Plug seal
8. Snap the plug insert into the plug housing and insert the sensor
seal
Information:
Note the correct arrangement, see illustration
Valve plug ISO 4400 with
hinged cover

19
5 Connecting to power supply
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
9. Tighten the screws on the strain relief and cable entry
10. Hook in the cover and push onto the plug connection, tighten
cover screw
11. Plug the plug insert with seal to VEGAPOINT 21 and tighten the
screw
5.3 Wiring plan
For connection to binary inputs of a PLC.
1
3
4
2
12
3
+
-
Fig. 12: Wiring plan connector ISO 4400 - transistor output three-wire
1 Voltage supply
2 PNP switching
3 NPN switching
4 PA - Potential equalisation
Contact, plug connector Function/Polarity
1 Voltage supply/+
2 Voltage supply/-
3 Transistor output
4 PA - Potential equalisation
5.4 Switch-on phase
Afterswitchingon,thedevicerstcarriesoutaself-testinwhichthe
function of the electronics is checked.
The current measured value is then output on the signal cable.
Valve plug ISO 4400

20
6 Access protection
VEGAPOINT 21 • Transistor (NPN/PNP)
56623-EN-210210
6 Access protection
6.1 Bluetooth radio interface
Devices with a Bluetooth radio interface are protected against un-
wanted access from outside.This means that only authorized persons
can receive measured and status values and change device settings
via this interface.
A Bluetooth access code is required to establish Bluetooth com-
munication via the adjustment tool (smartphone/tablet/notebook).
This code must be entered once when Bluetooth communication is
establishedforthersttimeintheadjustmenttool.Itisthenstoredin
the adjustment tool and does not have to be entered again.
The Bluetooth access code is individual for each device. It is printed
on the device housing and is also supplied with the device in the infor-
mation sheet " PINs and Codes". It can be changed by the user after
therstconnectionhasbeenestablished.IftheBluetoothaccess
code has not been entered correctly, a new entry can only be made
after a waiting period has elapsed.The waiting time increases with
each additional incorrect entry.
The emergency Bluetooth access code enables Bluetooth communi-
cation to be established in the event that the Bluetooth access code
is no longer known. It can't be changed. The emergency Bluetooth
access code can be found in information sheet " Access protection".
If this document is lost, the emergency Bluetooth access code can
be retrieved from your personal contact person after legitimation.
The storage and transmission of Bluetooth access codes is always
encrypted (SHA 256 algorithm).
6.2 Protection of the parameterization
The settings (parameters) of the device can be protected against un-
wanted changes. The parameter protection is deactivated on delivery,
all settings can be made.
To protect the parameterization, the device can be locked by the user
with the aid of a freely selectable device code. The settings (param-
eters) can then only be read out, but not changed.The device code
is also stored in the adjustment tool. However, unlike the Bluetooth
access code, it must be re-entered for each unlock. When using the
adjustment app or DTM, the stored device code is then suggested to
the user for unlocking.
The emergency device code allows unlocking the device in case the
device code is no longer known. It can't be changed. The emergency
device code can also be found on the supplied information sheet " Ac-
cess protection". If this document is lost, the emergency device code
can be retrieved from your personal contact person after legitimation.
The storage and transmission of the device codes is always encrypt-
ed (SHA 256 algorithm).
Bluetooth access code
Emergency Bluetooth
unlock code
Device code
Emergency device code
