Venicci EMPIRE Guide
1
user manual & warranty
EMPIRE
EN IMPORTANT - READ CAREFULLY AND KEEP
FOR FUTURE REFERENCE.
WARNING!
»Never leave the child
unattended.
»Ensure that all the locking
devices are engaged before
use.
»To avoid injury ensure that
the child is kept away when
unfolding and folding this
product.
»Do not let the child play with
this product.
»This product is not suitable
for running or skating.
»Always engage the brake
when placing the child in and
taking the child out of the
pram.
»Any load attached to the
handle/ back of the seat unit
or both sides of the pram
affects the stability of the
vehicle.
»Pram is only suitable for
specied number of children
and can only be used for
stated age groups.
»Before putting your child in
the carry cot/pushchair seat
unit/car seat make sure to
check for any small objects
that could cause a choking
hazard.
»Check that the pram body
or seat unit or car seat
attachmentdevices are correctly
engaged before use.
»Always use the restraint system.
»Two-point locking system
for carrycot, seat unit and car
seat.The locking mechanism
is triggered automatically
when placed in the slots of the
carrycot, seat unit, or car seat
adapters
»Buttons to deactivate the locking
system.To detach carrycot,
seat unit, car seat, before lifting
it up, press the buttons, on the
left and right side of the chassis.
Before you reuse the product,
ensure that the locking system
is working correctly by lifting the
detachable part.
»Only use on a rm, horizontal,
level and dry surface.
»The seat unit is suitabe for a
maximum weight of the child
22kg or for 4 years, whichever
comes rst.
0-4
MAX 22 kg
4
1. 2.
3. 4.
5. 6.
1
2
1
2
5
7. 8.
9. 10.
11. 12.
6
13. 14.
15. 16.
17. 18.
2
21 1
1
2
1
2
7
19. 20.
21. 22.
23. 24.
8
25. 26.
27. 28.
29. 30.
3
1
2
9
6m +
0-6m +
31. 32.
33. 34.
2
11
10
EN IMPORTANT!
Before use, read the following manual carefully and keep it. The safety of the child may
be compromised if the recommendations included in this manual are not followed.
The manufacturer of the pram is not responsible for effects from not following notes,
warnings and recommendations included in the product documentation.
After purchased, ensure you correctly maintain all the components specied by the
manufacturer inthis manual guide. This pram requires regular maintanance by the
user. It is the user’s responbility to undertake routine inspectio and maintance of the
pram in order to avoid damage of the product and/or injury to your child.
Backrest adjustment in the stroller version.The stroller seat is equipped with an
adjustable backrest. To lower the backrest to half-sitting or to the lying position, pull
the handle in the back part of the backrest upwards, select the required position
and release the handle. The backrest is equipped with a springloaded auto-lock
mechanism that does not require the handle to be lifted when lifting the backrest
from lying to sitting position. Every time you change the position of the backrest
check whether thefastening system is working correctly and adjust the harness
settings accordingly to t your baby’s new position.
Do not allow the child to stand on the seat as it may damage the stability of the
stroller and cause the stroller to fall down. In order to increase the stability of the
product while in use, make sure that the baby is positioned in the central part of the
carrycot or the seat unit.
Do not carry the pram holding the hood, upper edge of the backrest, footrest or
the element creating the pram version. Do not use the pram on steps or leave the
pram with the child on uneven surfaces (even with the brake on) as it may go down.
Carrying the pram up or down the steps, placing the pram to the bus, etc. should be
carried out with the aid of another person. The person holding the pram handle tube
passes the obstacle rst while holding the pram handle tube, and he person holding
the other end of the pram should grasp the pram by a stable element such as a xed
upright of the frame. When carrying the pram downstairs the person who is helping
comes down rst.
Pram handle height adjustment. To change the height of the pram handle, press and
hold button, select the required height and release both button. After adjusting the
heightof the handle, hold it in the upper part and move it twice up and down to make
sure the locks function correctly.
In the case of prams equipped with transferable handle tubes, ensure that the child’s
hands are notoutside the internal outline of the seat when changing the handle tube
position. After each change ofthe handle tube position, check the effectiveness of
the self fastening locking mechanism by pullingthe handle tube up and down several
times.
When changing the position of the backrest or the bassinet, pay attention to child’s
hands and head.Footrest adjustment. The pram is equipped with adjustable footrest.
To lower the footrest press the adjustment buttons on both sides of the footrest,
adjust the footrest position and release the buttons.The footrest is equipped with
an auto-lock system that does not require the buttons to be releasedwhen lifting
the footrest.
11
EN
Do not allow the child to stand or sit on the footrest. The impact of a larger load
on the footrest may cause damage to the locking mechanisms. When the child
independently gets in and out of the stroller, position the footrest to its lower
position.
Keep the pram elements clean. Dirt on the frame should be removed with a damp
sponge and then wiped with a dry cotton cloth. Do not use caustic, sharp, or hard
agents for cleaning as these may be harmful to the pram elements (discolouration,
scratches, etc.). It is recommended to use cleaning agents appropriate for a particular
surface. In the case of any dirt on the pram cover, remove it with the use of a damp
sponge, adding a delicate cleaning agent. Avoid over wetting the stroller seat,
bottom of the carry cot, and bottom of additional sleeping bag (pram of changeable
function) as this may cause deformation of stringer ring elements.
To avoid weepings or smudges which may occur after rainfall, for instance, secure
the pram against over soaking by the use of rain cover for the whole pram. It is
recommended to protect the pram against the effects of strong sunlight. The
manufacturer cannot accept responsibility for deterioration to the pram cover, which
result from failure to follow these recommendations.
Before mounting and dismounting the wheels, lift the locking mechanism of the
brake upwards (unblocked break). We recommend that the pram axles should be kept
clean. Where prams are equipped with wheels without bearings, pram axles should
be kept lubricated with a thick agent (cup grease, machine oil) to reduce friction on
tube ends.In models equipped with wheels with bearings, it is recommended to
lubricate the axles with a lubricating agent e.g. WD40.WARNING: Accessories or
spare parts that the manufacturer or distributor has not approved must not be used.
For chassis equipped with mounting holes for the car seat - all connectors that the
manufacturer or distributor has not approved must not be used. The manufacturer
is not liable for the consequences of installing other car seats onto the chassis that
do not have their approval. List of car seats with suitable approvals are posted on the
manufacturer’s website.
Adaptors for the car seat that the manufacturer or distributor has not approved must
not be used. WARNING: Check that the car seat attachment devices are correctly
engaged before use.
While folding and unfolding the chassis, and during assembling stage, keep your
hands at a safe distance from moving parts to avoid injuries.
Do not use the combination of the car seat and chassis as a place for the child to
sleep for long periods of time. If your child wants to sleep, always use the carry cot or
cot bed. The pram is used as a means of transport, do not rock the product. Moving
the pram forward and backward on short distances the front wheels should be locked
on to the xed position. Technological looseness of the spinning mechanism, may
cause a change in direction which does not prove product defectiveness.
The manufacturer recommends tting the car seat in the opposite direction to the
direction of traveling (parent facing), it makes easier to observe the child in the car
seat.
For pram designed from birth upwards it is recommended that the child lays in at
position at all times.
For carrycots equipped with a harness, always make sure that if the harness is not in
12
EN
use, that it is removed from the carrycot. Carrycots tted with top central carrying
handle; before lifting ensure that the handle is positioned perpendicularly to the
carrycot, and the lock in its base are turned on and working properly.
The load of the basket fastened to the pram frame should not exceed 3 kg, Accessible
load of the bag hung on the pram handle is 1 kg. Pockets of the pram are for decorative
purposes only, no objects of total weight exceeding 0.15 kg should be placed within
each pocket or weight of 0.35 kg for all pockets.
For any warranty and post-warranty repairs only use the parts supplied or
recommended by the relevant manufacturer or distributor. The pram should not
be used if any sort of defect has been noticed or any of the elements have been
damaged.
The hood of the seat unit has been designed using exible strips of steel, which
under the inuence of pressure can be deformed. This may result in decreased
spacing between the internal metal bars and other parts of the system and lead to
damage such as causing fabric to tear. ln the case of deformation you must make a
correction by gently squeezing, stretching the internal metal bars.
ln the case of travel systems tted with reversible seat unit, it is not allowed to
change its position while baby is in it.
After unfolding the chassis, check whether the front and rear wheels are tted
properly by trying to detach them from the chassis without pressing the button that
unlocks the locking mechanism.
‘D’ rings are provided for the attachment of an additional harness. These are located
on the existing harness close to where it is attached to the seat frame. ‘D’ rings are
provided for tting a separate harness if required. Replacement Harness can be
purchased directly from distributor.
Operating the parking brake.Press down on the pedal to engage the parking brake.
Press down and release to disengage the parking brake. WARNING: Never leave the
vehicle without rst fully engaging the parking brake.
Not place the carry cot near an open re or other source of strong heat. The handles
and the bottom of the carry cot should be inspected regularly for signs of damage
and wear. If the carry cot is intended to be used with a stand, then it shall be checked
that the stand is the appropriate size to accommodate the base of the carry cot. The
head of the child in the carry cot should never be lower than the body of the child.
Before carrying or lifting, make sure that the handle(s) is (are) in the correct position
of use. Before carrying or lifting the base shall be adjusted in the lowest position.
13
EN Universal rain cover for the seat unit and carrycot.
EN Pram bag.
MAX 22 kg
EN The seat unit is suitable for a maximum weight of the child 22kg or for 4 years,
whichever comes rst.
0-4
EN Pram/pushchair is designed for children from birth to 4 years old.
EN This product is suitable for one (1) child.
EN Stroller seat equipped with the hood and the footmuff.
EN Pram chassis with wheels.
EN 1888-2:2018
Distributed in Europe: Babysky Sp z o.o Sp. k
Distributed in the United Kingdom: MAGICBABY LTD Unit 7 Brookelds Way,
S63 5DL Manvers Rotherham
Made in China
