Venset TS600B Installation instructions

TS600B Original
338390.8
EN - Assembly Instruction and User Manual (Page 2)

TABLE OF CONTENTS
1. Safety and warnings
2. Usage
3. Set up and installation
4. Operation
5. Maintenance and defects
6. Technical data
7. Parts
8. Assembly Instructions
9. Declaration of conformity
IMPORTANT NOTES!
A TV larger than 40" must never be mounted on the
TS600b, a larger TV than 40" would compromise the
stability of the lift.
1. Safety and warnings
Use the following safety guidelines to help protect your lift from potential damage and to ensure your own personal safety.
Read all the installation instructions before testing or installing your lift.
Follow all safety instructions.
Keep control switch out of reach of children.
To prevent bodily injury keep hands and clothing away from the lift while the lift is in operation.
Before installing the lift or working with its connections, unplug the lift from the electricity main supply.
Do not install the lift or power supply in places subject to high temperatures for example near a radiator, or heating vent.
The TV lift must only be mounted in a dry area and it must be ensured before use, that the lift is safe or protected from liquid
contact or spillage.
To avoid damaging the power supply and power cord, do not put anything on it or place it where it could become damaged.
Unplug the lift in the following conditions:
When the power cord or plug is damaged or frayed.•
If the lift or power supply has been exposed to rain or water or any liquid contamination whatsoever.•
If the lift exhibits a distinct change in performance, indicating a need for attention.•
2. Usage
Venset lifts are sold as a component to combine with other products, eg. With a flatscreen television on its own or combined with a
cabinet, both examples would be common usage. It is the responsibility of the installer of the lift to decide if the lift is suitable for
their purpose and for any safety aspects concerning their overall product and installation.
Example: if you fit a very large TV on a single lift without adding additional runners and it causes too much flex or tilt this cannot be
considered as a warranty claim
Notes on maximum load:
TV+ LID CONTACT LOAD must never exceed the maximum of 10kg(see page 8).•
TS600B is a lightweight compact TV lift - If you are adding a hinged lid then the design must cause minimal stress and load on
the TV lift
•
• The contact point for the lid lifter bracket must always be adequately far forward of the hinge line and spring close hinges or any
kind of restriction upon the lid opening must never be used such as magnetic catches or gas springs.
• Be aware that a lid panel weighing only 1kg can create more than 2.5kg contact load if the bracket contact point is not far
enough away from the hinge line.
• A TV larger than 40" must never be mounted on the TS600B, a larger TV than 40" would compromise the stability of the lift.
Any deviation from this maximum loading will invalidate the warranty.
3. Set up and installation
in a location that will allow full up and down movement of the lift.
4. Operation
UP/DOWN operation:
•Push the buttons for operation up or down
Optional RF emitter R315290
•
Prior to installment, use and maintenance of the lift, any installer and any user of the table must study this assembly
and operation manual carefully, so as to gain a complete understanding of its contents. WARNING: FAILURE TO
COMPLY WITH OR OBSERVE ALLASSEMBLY, SAFETY AND OPERATION INSTRUCTIONSAND WARNINGS REGARDING
THE USE OF THIS PRODUCT MAY RESULT IN SERIOUS BODILY INJURY
2

5. Maintenance and defects
The lift does not require any maintenance.•
The lift is only to be maintained with a damp cloth•
In the event of the occurrence of any abnormal noises during operation, STOP using the lift and please contact the dealer.•
6. Technical data
Frame, materials Steel, powder lacquered
Weight 6,2 kg
Width 150 mm
Depth 43 mm
Height 500-1100 mm
Max. load 0 to 10 kg (See usage for details!)
Speed *Dependent on load case
Duty cycle 10% by 50% of max. load on frame or max. 2 min. continuously
Operation Micro switches
Voltage 100-240 VAC | 50/60 Hz
Standby Consumption < 0,15 Watt
7. Parts
(Optional extra parts can be found on page 12) Standard included parts - See page 4.
8. Assembly Instructions
See page 5 - 12.
9. Declaration of conformity
We hereby declare, under our sole responsibility that the following products:- VENSET TV-lift product type TS600B is in accordance
with- Directive 2006/42/EF of the European Parliament and of the Council of 17 May 2006 onmachinery and on changes of directive
95/16/EFWith reference to the above please be aware that:- the TV-lift is considered a partly completed machinery and- the TV-lift
may not be used until it has been assembled and installedaccording to the instructions.
Manufacturer
VENSET A/S | Industrivej 23 | 6900 Skjern | Denmark
www.venset.com | Tlf.: [phone] | [email protected]
3

7. Parts
TS600BLift
x1
Control Box
x1
Rocker Switch
x1
AC Cord
x1
Rubber Washer
x4
Power Supply
x1
4

8. Assembly Instruction and User Manual
Parts for assembly
Lift dimensions
5

TK600 VESA mount adapter kit optional
Lid lifter optional
6

Connecting The Lift
Endstop adjustment
7

Selecting operation mode 1 of 2
Selecting operation mode 2 of 2
8

Choosing operation mode using jumpersettings in control box
Jumper Settings Load 1
9

Jumper Settings Load 2
Jumper Settings Load 3
10

Jumper Settings Load 4
Remote Learning optional
11

Possible add ons for TS600BTV lift
12
