Vent-Axia HR500IP User manual

Copyright © 2009 Vent-Axia Limited. All rights reserved.
HR500IP
Passive Semi-Remote
Wall Mounted Heat Recovery Unit
with Spigot Connections.
Installation Instructions
Stock Ref. N°
370447 - HR500IP
PLEASE RETAIN THESE INSTRUCTIONS WITH THE PRODUCT.

Warnings & Safety Information
2
IMPORTANT SAFETY
INFORMATION
PLEASE READ THESE
INSTRUCTIONS
CAREFULLY BEFORE
COMMENCING
INSTALLATION.
1. Do not install this product in areas
where the following may be present or
occur:
• Excessive oil or a grease laden
atmosphere.
• Corrosive or flammable gases,
liquids or vapours.
• Subject to direct water spray from
hoses.
• Ambient temperatures higher than
40°C.
• Possible obstructions that may
hinder access to or removal of the unit.
2. All wiring of the system must be in
accordance with the current IEE wiring
regulations BS7671, or appropriate
standards of your country. Installation
should be inspected and tested by a
suitably qualified person after
completion.
3. Ensure the mains supply (voltage,
frequency and phase) complies with
the rating labels on the inline fans (Not
provided).
4. Precautions must be taken to avoid
the back-flow of gases into the building
from the open flue of gas or other fuel-
burning appliances.
5. This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for
their safety.
6. Young children should be
supervised to ensure that they do not
play with the appliance.
INSTALLATION GUIDANCE
1. The installer is responsible for the installation and
electrical connection of the system on site. It is the
responsibility of the installer to ensure that the
equipment is safely and securely installed and left
only when mechanically and electrically safe.
2. All regulations and requirements must be strictly
followed to prevent hazards to life and property,
both during and after installation, and during any
subsequent servicing and maintenance.
Disposal
This product should not be disposed of with
household waste. Please recycle where facilities
exist. Check with your local authority for recycling
advice.

3
External extract grille
External Inlet grille
Introduction
The Vent-Axia HR500IP unit is designed for mounting in internal walls for installations
using ducted extraction and fresh air supply. Air movement is achieved by using in-line
duct fans or wall mounted units to suit the length and configuration of ducting systems.
The unit is compatible with Ø300mm flexible duct and is ideally suited for use with in-line
fans and external wall louvres.
Concentric reducers are available to convert inlet and exhaust spigots to 250mm or
200mm diameter for use with alternative sized fans and ducting if required.
Typical Installation

4
Installation
The HR500IP unit should be set in an inner wall with the grille flange set flush with the
inner surface (a steel lintel is provided for additional support of the building fabric if
required). If used this will automatically produce a 3° slope of the unit away from the inner
grille for drainage of any condensate which may form during operation.
A 22mm drain is situated between inlet and exhaust spigots and should be connected to a
suitable drain/soakaway.
Fixing hole opening
Supply Extract
370mm
600mm
FRONT
Ø290
PLAN

5
Maintenance & Cleaning
The HR500IP unit requires only occasional cleaning. By depressing the two buttons on either
side of the internal grille, the grille, pre-filters and heat exchanger can be easily removed and
cleaned by using a vacuum cleaner or by washing in luke warm soapy water.
In heavily polluted and smoky enviroments it is recommended that the heat exchanger unit is
examined for cleaning purposes every 3 months.
Spare heat exchanger cells and filters are available to enable immediate change over of soiled
units, which can be cleaned for later use.
The unit is supplied with four, 6-month Timestrip indicators. A Timestrip is a single use self-
adhesive label that once activated will turn red over 6 months. It should be used to keep track of
when the filter and cell need cleaning/replacement. Using the self-adhesive backing the strip
can stuck near the units controls, or in a easily visible place.
A normal cleaning schedule for a unit would be as follows:
Note: The above is the minimum requirement; more frequent cleaning intervals may be needed
depending on the environment the unit is installed in.
After installation Activate the 1st Timestrip
After 6 months Clean cell, clean filter, activate 2nd Timestrip
After 12 months Clean cell, clean filter, activate 3rd Timestrip
After 18 months Clean cell, clean filter, activate 4th Timestrip
After 24 months Clean cell, replace filters, the new filters will be supplied with 4
additional Timestrip indicators
Press buttons here and on
opposite side to gain access to
filters and heat exchanger cell
Internal Grille

6
Activating the Timestrip.
1. Activation: Fully squeeze the activation button between thumb and finger. A red line will
appear within 1-2 minutes to show that the Timestrip has been activated.
2. Peel off the backing liner and stick the Timestrip to the Unit or near the controls of the unit.
The location should make it obvious to the person responsible for maintenance that the unit
needs attention.
3. Once activated, the red dye will indicate elapsed time by moving through the white window
and past each time marker. The progress of the red dye is irreversible and each Timestrip can
only be used once.

Product FICHE
7
PRODUCT FICHE
For Residential Ventilation Units (Complying Commission Delegated Regulation (EU)
No 1254/2014)
Name: Vent-Axia
Model ID (Stock Ref.) : HR 500 IP - 370447
SEC Class A
SEC Value ('Average') -39.00
SEC Value ('Warm') -17.84
SEC Value ('Cold') -76.72
Label Required? (Yes/No=Out of scope) Yes
Declared as: RVU or NRVU/UVU or BVU RVU/BVU
Speed Drive Variable Speed
Type HRS (Recuperative, Regenerative, None) Recuperative
Thermal Eff: [ (%), NA(if none)] 70.00
Max. Flow Rate (m3/h) 878.40
Max. Power Input (W): (@Max.Flow Rate) 0.00
LWA: Sound Power Level (dB) 17.52
Ref. Flow Rate (m3/s) 0.17080
Ref. Pressure Diff. (Pa) N/A
SPI [W/(m3/h)] 0.00
Control Factor & Control Typology: (CTRL/ Typology)
Control Factor; CTRL 1.00
Control Typology Manual Control
Declared: -Max Internal & External Leakage Rates(%) for
BVUs or carry over (for regenerative heat exchangers only),
-&Ext. Leakage Rates (%) for Ducted UVUs;
<5% Internal, <5%
External
Mixing Rate of Non-Ducted BVUs not intended to be equipped
with one duct connection on either supply or extract air side; N/A
Position and description of visual filter warning for RVUs
intended for use with filters, including text pointing out the
importance of regular filter changes for performance and
energy efficiency of the unit
N/A
For UVUs (Instructions Install Regulated Supply/Extract Grilles
Façade) N/A
Internet Address (for Disassembly Instructions) www.vent-axia.com
Sensitivity p. Variation@+20/-20 Pa: (for Non-Ducted VUs) N/A
Air Tightness-ID/OD-(m3/h) (for Non-Ducted VUs) N/A
Annual Electricity Consumption: AEC (kWh/a) 0.45
Annual Heating Saved: AHS (kWh/a)
AHS: Average 39.45
AHS: Warm 17.84
AHS: Cold 77.17

Guarantee and Contact information
8
Head Office: Fleming Way, Crawley, West Sussex, RH10 9YX.
UK NATIONAL CALL CENTRE, Newton Road, Crawley, West Sussex, RH10 9JA
SALES ENQUIRIES: Tel: [phone] Fax: [phone]
TECHNICAL SUPPORT Tel: [phone] Fax: [phone]
For details of the warranty and returns procedure please refer to www.vent-axia or write to Vent-Axia Ltd, Fleming Way, Crawley, RH10 9YX
370693D © 2018 Vent-Axia Limited. All rights reserved. 0118
The Guarantee
Applicable only to products installed and used in the United Kingdom.
For details of guarantee outside the United Kingdom contact your local supplier.
Vent-Axia guarantees its products for two years from date of purchase against faulty material or workmanship. In the event of any part being found
to be defective, the product will be repaired, or at the Company’s option replaced, without charge, provided that the product:
Has been installed and used in accordance with the instructions given with each unit.
Has not been connected to an unsuitable electricity supply. (The correct electricity supply voltage is shown on the product rating label
attached to the unit).
Has not been subjected to misuse, neglect or damage.
Has not been modified or repaired by any person not authorised by the company.
IF CLAIMING UNDER TERMS OF GUARANTEE
Please return the complete product, carriage paid to your original supplier or nearest Vent-Axia Centre, by post or personal visit.
Please ensure that it is adequately packed and accompanied by a letter clearly marked “Guarantee Claim” stating the nature of the fault and
providing evidence of date and source of purchase.
The guarantee is offered to you as an extra benefit, and does not affect your legal rights
