VENTRA XDR-1280/D User manual

XDR-1280/D
12 CH Hybrid HD Mobile DVR
(4) 1080P IPC + (8) Analo 1080P/720P AHD, D1
User Guide
Please read and follow all instructions and
features before use. Save for future reference.
Specification, models and features are subject
to chan e without prior notice
www.ventrainc.com
Manual Ver 08 18
This manual covers the setup, connection and
features of the XDR. For mana ement
software, refer to Ventra software manual
THIS MANUAL CONTAINS UPDATED FEATURES
AND SPECIFICATION. PLEASE REFER TO
UPDATE NOTICE

Table of Content
TECHNICAL SPECIFICATION …………………………………………………………………………………………………………………………4
RECORDING FRAME RATE / VIDEO STREAM AND STORAGE RATE ………………………………………………………………5
WARNING: SAFETY PRECAUTIONS…………………………………………………………………………………………………….…….....6
WARNING: LAWS AND REGULATIONS………………………………………………………………………………………………………….7
HARD DRIVE, SD CARD PRECAUTION, REQUIREMENT………………………………………………………………………………….8
SYSTEM LAYOUT FRONT …………………………………………………………………………………………………………………………….9
SYSTEM LAYOUT REAR ..…………………………………………………………………………………………………………………………….10
SYSTEM DIMENSION……....………………………………………………………………………………………………………………………….11
HARD DRIVE INSTALLATION ……………………………………………………………………………………………………………………….12
SYSTEM COMPONENTS…………………………………………………………………….............................................................13
SYSTEM CONNECTION SIMPLIFIED..............................................................................................................……14
SYSTEM CONNECTION FULL OVERVIEW......................................................................................................……15
EX12-CAM8 EX4-XC4 SERIES AHD CAMERAS ............................................................................................……16
EX12-ALC ALARM CABLE….........................................................................................................................……..17
CONNECTION
POWERING THE XDR-1280, CONNECTING POWER CABLE / FUSE...............................................................……18
CONNECT EX4-XC SERIES AHD CAMERAS (EX12-CAM8)..............................................................................……19
CONNECT XDR-PON 4 PORT SWITCH TO XDR-1280……………............................................................................20
CONNECT XDR-PON 4 PORT SWITCH FOR EX5-HD CAMERAS...........................................................................21
VIDEO OUT CONNECTION TO LCD MONITOR …………........................................................................................22
XDR SYSTEM SETUP VIA EX4-PGM….................................................................................................................23
SECTION 1: SYSTEM SETUP / FORMAT SD CARD
OSD MENU SCREEN ……………………………………………………………………………… ……………………………………………………24
1.1 – 1. GETTING STARTED – FORMAT CARD / ENTER SYSTEM SETTING……………………………………………………25
SECTION : SYSTEM SETTING
.0 BASIC SETUP – REGISTER SYSTEM, DRIVER ID, VEHICLE ID….…………..…………………………………………..26
.1 – . BASIC SETUP – DATE / TIME SETUP, DAY LIGHT SAVINGS..………...…….……………………..……….…………27

.3 – .4 BASIC SETUP – SYSTEM STARTUP, BATTERY PROTECTION…………..………..……………………………….……..28
.5 BASIC SETUP – USER SETUP, PASSWORD …………………………...………….…………………………….…...…………29
3.0 NETWORK CONNECTION …………………………………………………… …………………………………..…………..………30
SECTION 4: SURVEILLANCE / RECORD SETTING
4.0 - 4. SURVEILLANCE – LIVE VIEW, AUTO LOOP, ON SCREEN DISPLAY..………………...….…………..….……….....31
4.3 – 4.4 SURVEILLANCE – RECORD GENERAL SETTING, MAIN STREAM……..………………………………………….......32
4.4 SURVEILLANCE – RECORD MAIN STREAM CONTINUED……..………………………….……………………………...33
4.5 – 4.6 SURVEILLANCE – RECORD DUAL STREAM, ON SCREEN DISPLAY…….……………………..…………..………….34
4.6 – 4.7 SURVEILLANCE – EX5 HD /IPC CAMERA SETUP………………………..…….……………………..……….…….……….35
4.9 SURVEILLANCE – PTZ CAMERA SETUP……………..……………………..…….……………………..……….………………36
SECTION 5: COLLECTION OF DATA (COD) / SENSOR SETTING
5.0 – 5. COD SENSOR – GENERAL SENSOR, SERIAL, SPEED..……………..….……….……..…………………….…………...37
5.3 – 5.4 COD SENSOR – IMAGE SNAPSHOT TIME, TRIGGER SETTING……...……..……………………………….……….38
SECTION 6: ALARM SETTING
6.0 ALARM – OVERSPEED….……………...............................…………………..…………………………….….….………..39
6.1 ALARM – PANIC ALARM……………...............................…………………..…………………………….….……………40
6. ALARM – INPUT ALARM……………...............................…………………..…………………………….….……………41
6.3 ALARM – VIDEO LOSS ………………...............................…………………..…………………………….….……………42
6.4 ALARM – ADVANCE….………………..................................…………………..…………………………….….…………43
SECTION 7: SYSTEM MAINTENANCE
7.0 – 7.1 MAINTENANCE – CONFIGURATION, DATA FILE IMPORT / EXPORT……...……..……………….……………..44
7. MAINTENANCE – FIRMWARE UPGRADE……………………………………………...……..……………………………...45
7.3 MAINTENANCE – STORAGE FORMAT…..……………………………………………...……..………………………….…..46
WARRANTY / RMA .............................…………………..…………………………….….………..............................................47
Table of Content

Function Overview Preview, Recordin , Playback, Route History
System OS Linux 3.0.8
Control Mode Remote Controller, USB Corded Mouse, EX4-PGM
Cameras IPC + AHD 12 Cameras max - Up to (8) AHD / Analo + (4) IP (requires PON switch)
Video
Input 12 channels (8) 1080P AHD, 720P AHD, D1 Resolution
(4) 1080P IPC, 720P IPC
Output 2 channels
Video System NTSC/PAL optional (1Vpp 75 Ohm)
Audio Input 12 channels (Camera if applicable)
Output 2 channels
Display
Display Split 1, 4, 9
OSD GPS information, alarm, temperature, date/time, device information
Operation Interface Semi-transparent GUI
Recording
Video/Audio Compression H.264 / ADPCM
Ima e Resolution
NTSC: 8 x 1080P @ 10 FPS (AHD) + 4 x 1080P @ 30 FPS (IPC) or
8 x 720P @ 30 FPS (AHD) + 4 x 1080P @ 30 FPS (IPC) or
8 x D1 @ 30 FPS (AHD) + 4 x 1080P at 30 FPS (IPC)
Ima e Quality 1 ~ 8 levels adjustable (1 is the best)
Recordin Mode Manual/ Schedule/ Alarm (sensor tri er, speed, acceleration, video loss, temperature)
Pre Recordin / Post-recordin Pre-Recordin 0 – 60 Minutes / Post-Recordin 0 - 30 Minutes
Mirror Recordin Support
Playback & Backup
Playback Channel 1 channel by local playback
Search Mode Date/time, channel, file type
GPS GPS route history, speed detection and time sync
Storage HDD (SATA / SSD) Max: 1TB 2.5” SATA 5400RPM HDD / 1TB SSD
Interface
USB USB 2.0 ×2 (Front / Rear)
SD SD ×1 (For Back up Purpose) - 32GB ~ 128GB Minimum Class 10 SDHC
Sensor 8 inputs, 2 outputs RS232 x 2, RS485 x 2
Ethernet RJ45 x 1 (10/100M)
Remote Viewing Router Support external cellular, WiFi router (monthly fee and cellular data fee)
Power
Input DC8-36V
Output 5V @ 500mA, 12V @ 500mA
Power Consumption Max Power Consumption: 69.6W Standby Power Consumption: ~ 0W
Impulse current: input [email protected] Workin current: input [email protected], [email protected]
Environment
Operatin Temperature 14 F ~ 158 F ( -10 C ~ 70 C )
Operatin Relative Humidity 8% - 90% (Non Condense)
Dimension L x W x H 11.61” x 8.74” x 3.50” ( 295mm x 222 mm x 89mm ) 4
Technical Specification

5
XDR-1 80/D Camera Frames Per Second (FPS) Chart
Camera Resolution Channels FPS
AHD-720 8 30
IPC-1080P 4 30
AHD-1080P 8 10
IPC-1080P 4 30
AHD-1080P 4 10
IPC-1080P 8 20
AHD-1080P 2 30
IP1080P 8 20
AHD-720P 4 30
IPC-1080P 8 20
Video Stream Rate and Storage Based On Video Quality Level (1 – 8)
1 3 4 5 6 7 8
CIF 35 x 40
Stream (kB/s) 1024 768 640 512 440 350 312 280
MB / Hour /
CH 450 338 281 225 193 154 137 123
D1 / VGA 704 X 480
Stream (kB/s) 2048 1536 1280 1024 900 800 720 640
MB / Hour /
CH 900 675 563 450 396 352 316 281
7 0P 1 80 x 7 0
Stream (kB/s) 6144 4800 4128 3456 2784 2112 1440 768
MB / Hour /
CH 2700 2109 1814 1519 1223 928 633 338
1080P 19 0 x 1080
Stream (kB/s) 8192 6390 5505 4068 3712 2816 1919 1024
MB / Hour /
CH 3600 2808 2419 1788 1631 1238 843 450

Failure to follow these safety warnings could potentially result in an accident, collision resulting in serious injury or death
•Install the device in a manner that does not obstruct the driver’s view of the front or sides of the vehicle, or interfere with the safety of operating the vehicle.
•Do not operate, adjust or view this recorder while driving or when vehicle is in motion
•Do not place the device unsecurly on the dashboard, or place the device in front of or above an airbag
•Please comply with all driving and traffic regulations
•To reduce the risk of fire or electric shock, do not expose the DVR to water, liquid, rain or moisture
•Disconnect the power from the XDR if equipment or wire is exposed to liquid
•Disconnect and replace the cable if wire is stripped or damaged
•When exposed to direct sunlight for a period of time, the equipment may become hot. Please exercise caution when touching the equipment
•Do not disassemble or alter the equipment, cable or accessories as this may lead to equipment error and failure, thus voiding all warranty
•In the event of an impact or accident, please check to ensure the equipment is properly secured. Inspect the mounting bracket and screws for any signs of damage
•Disconnect and replace the cable if wire is stripped or damaged
•When using the power connection cable, ensure all connections are secured
•Metallic coating on front window of vehicle may cause interference in GPS signal
•Use only recommended Micro SD card specifications as it may affect data storage. SDXC Min Class 10 and Up
•When Power is connected, do not remove the micro SD card as it may cause memory card failure
•Do not modify the name of file folders in the SD card as it will cause directory and recording issues
6

Windshield Mounted Device Legal Notice
Please check and comply with ALL local, state and federal laws and or re ulations re ardin windshield mounted devices. Some state laws prohibit drivers
from usin suction mounts on their windshield when operatin motor vehicles. Other state laws allow the suction mount to be mounted to be located only in
specific locations on the windshield. Numerous states have enacted restrictions a ainst placin objects on the windshield in locations that may obstruct the
driver’s vision.
IT IS THE USER’S RESPONSBILITY TO MOUNT VENTRA EQUIPMENT IN COMPLIANCE WITH ALL PPLICABLE LAWS AND
ORDINCANCE
Audio and Video Recording Legal Notice
Certain local, state and federal laws may prohibit recordin of audio and or video in vehicles or public area, or without knowled e and or consent, please
check and comply with ALL local, state and federal laws and re ulations.
Certain local, state and federal laws may require si na e or display that indicate recordin of audio and or video in vehicles or public area. Please check and
comply with ALL local, state and federal laws and re ulations
IT IS THE USER’S RESPONSBILITY TO USE VENTRA EQUIPMENT IN COMPLIANCE WITH ALL PPLICABLE LAWS AND ORDINCANCE
Use of this product other than its intended purpose is strictly prohibited.
Ventra Technolo ies Inc. does not assume any responsibility for any fines, violation, penalties or dama es that may be incurred as a result of the use of the
product
Ventra Technolo ies Inc. is not responsible for any direct, indirect, incidental or consequential dama es, arisin out of use, misuse or inability to use of
our products.
7

•To avoid dama e and or data loss, power off the XDR BEFORE insertin or removin the HDD or SD card
•Turnin the power off or removin a HDD or memory card durin operation such as formattin , deletin , recordin and playback may cause system
error and or data loss.
•Only New HDD and SD card should be used and are hi hly recommended to ensure reliability and data inte rity
•When unspecified stora e are used, XDR may not record data properly and recordin s may be lost or dama ed
•Ventra is not responsible for any dama e , data loss, or system error resultin from HDD or SD card error and or dama e, computer issues or virus
•XDR utilizes a propriety file format for security , each HDD / SD card MUST be formatted IN the XDR prior to use
8
IMPORTANT HDD and SD Card Requirement and Compatibility
It is extremely important to use HDD and SD cards that are suitable for rugged environments, constant data writing, continuous
operation and models that are designed specifically for DVR.
•SD CARD: 32GB to 128GB Minimum Class U1 and up - 20MB Writin Speed or faster (SanDisk Extreme and Transcend
Ultimate SD card)
•HDD SATA or SSD : 500 GB - 1 TB Max Stora e 2.5”
Due to rugged environment of mobile recording in vehicles, Ventra does not warrant the HDD, video recordings
or data integrity. Warranty of HDD are provided by the respective manufacturer

System Layout
9
Front
1 HDD Slot 2.5mm HDD Removable cradle slot
SD Card Slot SD Card Slot
3
HDD Hard Drive access indicator
SD SD card access indicator
GPS GPS status indicator
NET Network connection indicator
HTR Internal Heater Indicator (if applicable)
PWR Power indicator
REC Recordin status indicator
VLOSS Camera video loss indicator
ALM Alarm / Event indicator
Err Stora e Error indicator
IR IR receiver
4 USB USB Interface
5DVR Cover
Sensor
DVR cover detection / Auto shutdown
when cover is opened
6 AV Out Video out connection
1
2
3
Labelin may differ due to product update
5 4
6
1. Removable Hard Drive Cradle – HDD provides the main stora e for
recorded data. Supports up to 2TB HDD. (Never remove or insert
HDD while XDR is on)
. Mirror SD Card Slot – SD card provides mirror recordin of events
(Never remove or insert HDD while XDR is on)
3. Status LED – Provides visual system operation status
4. USB Port - For USB flash drive to conveniently download recordin s/
data without removin SD card or Hard Drive. Upload firmware or
confi uration settin s. May also be used for USB mouse connection to
access system settin s
5. XDR Cover Detection – Cover must be completely closed and latched
for XDR to power on
6. AV OUT – Provides connection to external monitor

System Layout
10
Labelin may differ due to product update
Rear
1 Power Power cable connection 9 – 36V DC
Amplifier Amplifier connection
3 Panel EX4-PGM connection
4 LAN Ethernet RJ45 network connection
5 USB USB connection
6 Serial EX12-ALC Input / Output Alarm and
Serial cable connection harness
7 GPS GPS Antenna connection
11 VGA EX12-VGA Video out connection
1 AV IN
EX12-CAM8 8 AHD camera input
connection / 1 Video out connection
cable harness
1. Power Connection – Main power connection to vehicle fuse or XDR-PON network
switch. 9 – 36V DC
. Amplifier – Connection to external microphone and accessories (in development)
3. Panel – Connection to EX4-PGM touchscreen tablet
4. LAN Port - Connection for external WiFi or Cellular router, as well as XDR-PON EX5-HD
series IP camera switch
5. USB Port - Connection for external USB devices
6. Serial – Provides connection to EX12-ALC input / output tri er cable and serial cable
7. GPS – GPS antenna connection
11. VGA - Connection for VGA output cable
1 . AV IN - EX12-CAM8 8 AHD camera input connection + 1 video out cable connection

System Dimension
11

Hard Drive Installation
12
Note: Hard drive already pre-installed in each XDR

XDR-1280D MDVR 1TB SSD
HDD
(1) EX4-
XC1D
720P
AHD
Camera
GPS
Passive
Receiver
EX12-CAM8
Camera input
cable
EX12-MPIG Male
DIN to BNC Video
Cable
Remote
Controller Power Cable
Software /
Manual
System Components
13
Included:
Optional:
EX5-HD3IP1080
EX5-HD2 720P
HD Camera w/
IR + Audio
EX4-XC2 Analo
D1 Outdoor
Camera
EX4-XC4
Left/Ri ht Side
Outdoor D1
Analo Camera
EX4-PGM Tablet
for Pro rammin /
Back Up Monitor
XDR-PON 4 Port
Switch required
for EX5-HD series
cameras
EX5-CBLxx HD
Camera Patch
Cable 15ft, 30ft
and 50ft
EX4-CBLxx 4 pin
DIN Camera
Patch Cable 15ft
– 60ft
EX12-
ALC
Input /
Output Alarm
Cable

XDR System Layout Dia ram
AHD1 Cameras AV 1 ~ 8
and Video output 1
Connect to:
•EX4-PON Switch
•External Cellular / WiFi
router
Passive GPS
VLCD-7 LCD monitor
14
To Vehicle Power Source
3 Wires:
- 1 / 4V DC ( Red )
- GND ( BLK )
- ACC / IGN ( YEL )
Inline Fuse
(Must be connected to XDR power
cable for system to power on)
1 V = Blue Fuse
4V = Red Fuse
EX4-PGM

XDR System Layout Dia ram
15
3 Wires:
- 1 / 4V DC ( Red )
- GND ( BLK )
- ACC / IGN ( YEL )

This cable provides connection for (8) AHD cameras and (1) video output to monitor
•Up to 8 AHD cameras (AV IN 1 – AV IN 8)
•1080P AHD, 720P HD, D1 Resolution
•4 pin DIN connection
•1 DIN female video out connection (AV OUT 1)
(Must connect to EX12-MPIG to convert to BNC connection) 16

For Sensor In:
Hi h Volta e: 5~12V
Low Volta e : 0~3V
For Sensor Out:
Tri ered Volta e: 12V
Default Volta e: 0V
EX12-ALC Input / Output Tri er Cable Guide
Trigger Cable Can Be connected for a wide array of applications
•Door Open / Close Contact
•Li ht Tri er
•Siren Tri er
•Reverse Gear Si nal
•PTO Tri er
•Lift Arm / Gate
•PTZ controller
17

Powering the XDR (1 V / 4VDC)
18
1. Insert the appropriate fuse blade into the Red power cable
Blue Fuse = 12V Brown Fuse = 24V
2. Connect the 3 power wires to the vehicle’s fuse
Red = 12VDC Power
Yellow = I nition / Accessory
Black = Ground
3. Connect the power cable to the Power connection on the XDR
XDR Cover / Latch MUST BE CLOSED in order for the XDR to Power ON!
Fi . 2 Fuse Blade
Fi . 1 Pic of Power Cable
Fi . 3 XDR Power connection
CAUTION
Installation by a Professional technician is highly recommended
Exercise caution when connecting the power to prevent shock. Do not use
sharp object to force cable
Ensure connection to the proper fuse to avoid damage or interference with
vehicle operation
Refer to vehicle owners manual for fuse guideline

Connect Ventra EX4-XC series 1080P, 720P AHD and D1 resolution camera (4 PIN DIN)
19
(EX4-XC1D, EX4-XC , EX4-XC D, EX4-XC4) with 4 PIN DIN
- Connect the EX12-CAM8 cable to the AV IN connector at the rear of the XDR
shown in Figure 1
- Each EX4-XC4 series camera that connects to the XDR requires an EX4-CBLxx
cable to XDR (Figure 2 EX4-CBLxx xx den tes length )
- XDR transmits Audio / Video & Power throu h the 4 PIN DIN cable (Figure 3)
-EX4-CBL available in 15, 33 and 60ft
-Maximum length / distance is 120ft by c nnecting (2) EX4-CBL4
Fi ure 3
EX12-CAM8 Fi ure 1 Fi ure 2
EX4-CBL

Connect XDR-PON Switch to XDR-1280
20
For EX5-HD1, EX5-HD , EX5-HD3IP1080 cameras
Requires Ventra EX5-CBLxx 6PIN DIN cable and XDR-PON 4
camera switch (s ld separately)
•Connect the power cable included with the XDR-PON to both
the XDR-1280 and the PON switch
-Switch wire connects to XDR-PON
-Output wire connects to XDR-1280
-Input wire connects to power cable of the XDR
Fi . 2 Connect Power to XDR and XDR-PON
Fi . 1 XDR-PON Switch
