Vents OV 200 EC User manual

Electric axial fans
USER’S MANUAL
OV(K) 200/250/300/350/400/450/500() 

2
OV(K) 200/250/300/350/400/450/500(С) ЕС
www.ventilation-system.com
Safety requirements..................................................................................................................................................................... 2
Purpose................................................................................................................................................................................................ 4
Delivery set........................................................................................................................................................................................ 4
Designation key.............................................................................................................................................................................. 4
Technical data.................................................................................................................................................................................. 4
Design and operating principle ........................................................................................................................................... 6
Mounting and set-up.................................................................................................................................................................. 6
Connection to power mains .................................................................................................................................................. 8
Technical maintenance.............................................................................................................................................................. 9
Troubleshooting............................................................................................................................................................................. 10
Storage and transportation regulations.......................................................................................................................... 10
Manufacturer’s warranty........................................................................................................................................................... 11
Certificate of acceptance.......................................................................................................................................................... 15
Seller information.......................................................................................................................................................................... 15
Installation certificate.................................................................................................................................................................. 15
Warranty card................................................................................................................................................................................... 15
This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the
OV(K) 200/250/300/350/400/450/500(С) ЕС unit and all its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to
work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
Connection to the mains must be made through a disconnecting device, which is integrated
into the fixed wiring system in accordance with the wiring rules for design of electrical units,
and has a contact separation in all poles that allows for full disconnection under overvoltage
category III conditions.
CAUTION: In order to avoid a safety hazard due to inadvertent resetting of the thermal cut-
out, this unit must not be supplied through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by the utility.
Precautions must be taken to avoid the back-flow of gases into the room from the open flue of
gas or other fuel-burning appliances.
This unit is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the unit by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the unit.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Cleaning and user maintenance shall not be made by children without supervision.
Children shall not play with the appliance.
CONTENTS
SAFETY REQUIREMENTS

3
www.ventilation-system.com
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS
SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE
All operations described in this manual must be performed by qualified personnel only, properly
trained and qualified to install, make electrical connections and maintain ventilation units.
Do not attempt to install the product, connect it to the mains, or perform maintenance yourself.
This is unsafe and impossible without special knowledge.
Disconnect the power supply prior to any operations with the unit.
All user’s manual requirements as well as the provisions of all the applicable local and national
construction, electrical, and technical norms and standards must be observed when installing
and operating the unit.
Disconnect the unit from the power supply prior to any connection, servicing, maintenance, and
repair operations.
Connection of the unit to power mains is allowed by a qualified electrician with a work permit
for the electric units up to 1000 V after careful reading of the present user’s manual.
Check the unit for any visible damage of the impeller, the casing, and the grille before starting
installation. The casing internals must be free of any foreign objects that can damage the
impeller blades.
While mounting the unit, avoid compression of the casing! Deformation of the casing may result
in motor jam and excessive noise.
Misuse of the unit and any unauthorised modifications are not allowed.
Do not expose the unit to adverse atmospheric agents (rain, sun, etc.).
Transported air must not contain any dust or other solid impurities, sticky substances, or fibrous
materials.
Do not use the unit in a hazardous or explosive environment containing spirits, gasoline,
insecticides, etc.
Do not close or block the intake or extract vents in order to ensure the efficient air flow.
Do not sit on the unit and do not put objects on it.
The information in this user’s manual was correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration
of its products at any time in order to incorporate the latest technological developments.
Never touch the unit with wet or damp hands.
Never touch the unit when barefoot.
BEFORE INSTALLING ADDITIONAL EXTERNAL DEVICES, READ THE RELEVANT USER MANUALS.
Ensure that the unit is switched off from the supply mains before removing the guard.

4
OV(K) 200/250/300/350/400/450/500(С) ЕС
www.ventilation-system.com
The unit is classified as a class I electrical appliance.
The Electric axial fans is designed for supply and exhaust ventilation of domestic, public and industrial premises with high requirements
to the noise level and with limited space for mounting.
The unit is rated for continuous operation.
The unit is a component part and is not designed for stand-alone operation.
Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals, sticky substances, fibrous materials,
coarse dust, soot and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust,
pathogenic germs).
PURPOSE
DELIVERY SET
DESIGNATION KEY
TECHNICAL DATA
 250 
Electronically commutated motor
Motor modication
_ - standard capacity
C - increased capacity
Size
Model
OV - Axial ventilator with a square plate
OVK - Axial ventilator with a round plate
NAME QUANTITY
Fan 1 pc.
User’s manual 1 pc.
Packing box 1 pc.

5
www.ventilation-system.com
OV…EC
Model
Overall and connecting dimensions
[mm]
Mounting
hole
diameter
[mm]
Weight
[kg]
В
A
H1
H
D1
d
D
(D+10)
A B d H H1 D D1
OV 200 EC 312 260 7 81 93 210 260 210 2.04
OV 200C EC 312 260 7 81 93 210 260 210 2.04
OV 250 EC 370 320 7 81 93 262 325 260 2.54
OV 250C EC 370 320 7 81 93 262 325 260 2.56
OV 300 EC 430 380 9 104 116 317 365 317 3.4
OV 300C EC 430 380 9 104 116 317 365 317 3.51
OV 350 EC 485 435 9 97 157 374 420 374 4.77
OV 400 EC 540 490 9 97 157 416 468 416 5.65
OV 450 EC 576 535 11 176 294 470 520 465 7.05
OV 500 EC 655 615 11 180 294 520 568 520 8.31
OVK…EC
Model
Overall and connecting dimensions
[mm]
Mounting
hole
diameter
[mm]
Weight
[kg]
H1
H
d
D
(D+10)
D2
D1
d H H1 D D1 D2
OVK 200 EC 7 81 93 210 250 280 210 1.6
OVK 200C EC 7 81 93 210 250 280 210 1.7
OVK 250 EC 7 81 93 262 318 340 260 2
OVK 250C EC 7 81 93 262 318 340 260 2
OVK 300 EC 9 104 116 317 380 397 317 2.7
OVK 300C EC 9 104 116 317 380 397 317 2.8
OVK 350 EC 9 97 157 374 442 460 374 3.8
OVK 400 EC 9 97 157 416 504 528 417 4.6
OVK 450 EC 11 176 294 470 578 607 465 6.3
OVK 500 EC 11 180 294 520 590 655 520 7

6
OV(K) 200/250/300/350/400/450/500(С) ЕС
www.ventilation-system.com
WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT
MAINTENANCE AND REPAIR.
BEFORE MOUNTING MAKE SURE THE CASING DOES NOT CONTAIN ANY FOREIGN
OBJECTS E.G. FOIL, PAPER.
• Check the electrodes and make sure there are no cuts or cracks in the insulation after unpacking the fan. Check the fan casing and
make sure it is not deformed or damaged.
• Make sure the impeller rotates smoothly and never touches the entry flange or casing. Make sure the electric circuit parameters
match the technical data specified on the fan’s label, which is on the casing, prior to connecting.
• In case the fan is used in conditions where it is exposed to water ingress, it must be protected. A possible protection option may be
installing the fan under a hood or a roof.
• Since the unit is classified as a class I electrical appliance, it requires grounding: connect the terminal box to the protective
grounding circuit.
Fan series OV…EC, OVK…EC are wall-mounted using a connecting casing and fastening holes.
DESIGN AND OPERATING PRINCIPLE
MOUNTING AND SETUP
OV…EC and OVK…EC consist of casing 1 with a square or round flange, to which a grille 2 is attached with bolts 4, assembled with the
motor and the impeller. Its rotation direction is determined by the type of the motor that is used with the external rotor. The fans have a
terminal box with a cable suitable for external connection.
The motor casing has a threaded M4 hole for connection to the protective grounding circuit.
OV…EC OVK…EC
3
4
1
2
4
1
2
3

7
www.ventilation-system.com

8
OV(K) 200/250/300/350/400/450/500(С) ЕС
www.ventilation-system.com
• The unit is rated for connection to power mains with the parameters specified in the «Technical data» section according to the wiring
diagram.
• The unit must be connected to power mains using insulated electric conductors (cables, wires). The wire cross section selection
must be based on the maximum load current, maximum conductor temperature depending in the wire type, insulation, length and
installation method.
• The unit must be connected to power mains following the power connection scheme and the terminal designation.
• The external power input must be equipped with an automatic circuit breaker built into the stationary wiring to open the electric
circuit in case of overload or short-circuit. The circuit breaker installation place must provide quick access for emergency shutdown
of the unit. The trip current of the automatic circuit breaker must exceed the maximum current consumption of the unit (refer to the
«Technical data» section). The recommended trip current of the circuit breaker is the next current in the standard trip current row
following the maximum current of the connected unit. The circuit breaker is not included in the delivery set.
• The fan is connected to the power mains and additional external devices via the terminal box.
• External speeed controllers that are connected should provide the motor input voltage of 0 to 10 V or PWM-signal with an amplitude
of 10 V.
Wiring diagrams
OV(K) 200/250/300/350/400(S0)  OV(K) 450/500(S0) 
X1
+10V +10V
0-10V 0-10V
FG
GND
GND
PE
PE
N
L
N
L
X2
QF*
1
2
3
4
1
2
3
~230 V
50/60 Hz
External speed
controller*
X1
GND
+10V
FG
0-10V
PE
COM
NC
X2
1
2
3
4
1
2
3
RSB
RSA
5
6
N
L
4
5
PE
N
L
QF*
+10V
0-10V
GND
~230 V
50/60 Hz
External speed
controller*
*Not included in the delivery set
POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT.
THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN.
THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE
MANUFACTURER’S LABEL.
CONNECTION TO POWER MAINS

9
www.ventilation-system.com
Technical maintenance must only be performed after disconnecting the unit. The technical maintenance includes periodic cleaning of
the surfaces from accumulated dust and dirt. Use a soft dry brush or compressed air to remove dust from metal surfaces of the fan. Clean
the impeller blades once in 6 months with a warm water detergent solution. Avoid liquid dripping on the motor. Wipe the fan surfaces
dry afterward.
For technical maintenance of the fans, unscrew 4 bolts and remove the grille and motor from the casing.
DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE
OPERATIONS!
MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE
PROTECTION
TECHNICAL MAINTENANCE

10
OV(K) 200/250/300/350/400/450/500(С) ЕС
www.ventilation-system.com
Trouble Possible reasons Troubleshooting
The fan does not start
when turned on.
No power supply. Check the electric connections and the operation
status of the circuit breaker.
The motor is jammed. Turn off the fan. Troubleshoot the impeller clogging.
Turn the fan on again.
Automatic circuit breaker
tripping after the unit
start-up.
Overcurrent as a result of short circuit in the
electric circuit, triggering the circuit breaker.
Disconnect the fan from the power main and contact
the service centre. Do not turn the fan on again.
Low air flow.
Air ducts or other ventilatilation system
elements are clogged. The impeller is soiled. Air
ducts are damaged. The air dampers are closed.
Clean the air ducts as well as other ventilation system
elements, including the impeller.
Make sure the air ducts are not damaged.
Make sure that the air dampers and shutters are open.
If you struggle to troubleshoot the cause of fault, contact the service centre or the Seller.
STORAGE AND TRANSPORTATION REGULATIONS
• Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range
from +5 °C to + 40 °C and relative humidity up to 70 %.
• Storage environment must not contain aggressive vapors and chemical mixtures provoking corrosion, insulation, and sealing
deformation.
• Use suitable hoist machinery for handling and storage operations to prevent possible damage to the unit.
• Follow the handling requirements applicable for the particular type of cargo.
• The unit can be carried in the original packaging by any mode of transport provided proper protection against precipitation and
mechanical damage. The unit must be transported only in the working position.
• Avoid sharp blows, scratches, or rough handling during loading and unloading.
• Prior to the initial power-up after transportation at low temperatures, allow the unit to warm up at operating temperature for at least
3-4 hours.
TROUBLESHOOTING

11
www.ventilation-system.com
MANUFACTURER’S WARRANTY
The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby
declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European
Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking
Council Directive 93/68/EEC. This certificate is issued following test carried out on samples of the product referred to above.
The manufacturer hereby warrants normal operation of the unit for 24 months after the retail sale date provided the user's observance
of the transportation, storage, installation, and operation regulations. Should any malfunctions occur in the course of the unit operation
through the Manufacturer's fault during the guaranteed period of operation, the user is entitled to get all the faults eliminated by the
manufacturer by means of warranty repair at the factory free of charge. The warranty repair includes work specific to elimination of faults
in the unit operation to ensure its intended use by the user within the guaranteed period of operation. The faults are eliminated by means
of replacement or repair of the unit components or a specific part of such unit component.
The warranty repair does not include:
• routine technical maintenance
• unit installation/dismantling
• unit setup
To benefit from warranty repair, the user must provide the unit, the user's manual with the purchase date stamp, and the payment
paperwork certifying the purchase. The unit model must comply with the one stated in the user’s manual. Contact the Seller for warranty
service.
The manufacturer’s warranty does not apply to the following cases:
• User’s failure to submit the unit with the entire delivery package as stated in the user’s manual including submission with missing
component parts previously dismounted by the user.
• Mismatch of the unit model and the brand name with the information stated on the unit packaging and in the user's manual.
• User’s failure to ensure timely technical maintenance of the unit.
• External damage to the unit casing (excluding external modifications as required for installation) and internal components caused
by the user.
• Redesign or engineering changes to the unit.
• Replacement and use of any assemblies, parts and components not approved by the manufacturer.
• Unit misuse.
• Violation of the unit installation regulations by the user.
• Violation of the unit control regulations by the user.
• Unit connection to power mains with a voltage different from the one stated in the user's manual.
• Unit breakdown due to voltage surges in power mains.
• Discretionary repair of the unit by the user.
• Unit repair by any persons without the manufacturer’s authorization.
• Expiration of the unit warranty period.
• Violation of the unit transportation regulations by the user.
• Violation of the unit storage regulations by the user.
• Wrongful actions against the unit committed by third parties.
• Unit breakdown due to circumstances of insuperable force (fire, flood, earthquake, war, hostilities of any kind, blockades).
• Missing seals if provided by the user’s manual.
• Failure to submit the user’s manual with the unit purchase date stamp.
• Missing payment paperwork certifying the unit purchase.
FOLLOWING THE REGULATIONS STIPULATED HEREIN WILL ENSURE A LONG AND
TROUBLEFREE OPERATION OF THE UNIT
USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON
PRESENTATION OF THE UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL
WITH THE PURCHASE DATE STAMP

12
OV(K) 200/250/300/350/400/450/500(С) ЕС
www.ventilation-system.com

13
www.ventilation-system.com

14
OV(K) 200/250/300/350/400/450/500(С) ЕС
www.ventilation-system.com

15
www.ventilation-system.com
CERTIFICATE OF ACCEPTANCE
Unit Type Electric axial fans
Model
Serial Number
Manufacture Date
Quality Inspector’s
Stamp
SELLER INFORMATION
Seller
Seller’s Stamp
Address
Phone Number
E-mail
Purchase Date
This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are
acknowledged and accepted.
Customer’s Signature
INSTALLATION CERTIFICATE
The _____________________________________ unit is installed pursuant to the requirements stated
in the present user's manual.
Installation Stamp
Company name
Address
Phone Number
Installation
Technician’s Full Name
Installation Date: Signature:
The unit has been installed in accordance with the provisions of all the applicable local and national construction,
electrical and technical codes and standards. The unit operates normally as intended by the manufacturer.
Signature:
WARRANTY CARD
Unit Type Electric axial fans
Seller’s Stamp
Model
Serial Number
Manufacture Date
Purchase Date
Warranty Period
Seller

V275EN-01
