Vents VKM EC User manual

VKM EC
Centrifugal inline fan
USER’S MANUAL

2
VKM EC
www.ventilation-system.com
Safety requirements..................................................................................................................................................................... 3
Purpose................................................................................................................................................................................................ 5
Delivery set........................................................................................................................................................................................ 5
Designation key ............................................................................................................................................................................ 5
Technical data.................................................................................................................................................................................. 6
Installation and set-up................................................................................................................................................................ 7
Connection to power mains .................................................................................................................................................. 9
Maintenance .................................................................................................................................................................................... 11
Storage and transportation regulations.......................................................................................................................... 12
Manufacturer’s warranty........................................................................................................................................................... 13
Certificate of acceptance ........................................................................................................................................................ 14
Seller information ......................................................................................................................................................................... 14
Installation certificate.................................................................................................................................................................. 14
Warranty card................................................................................................................................................................................... 14
CONTENTS
This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the VKM EC unit and
all its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to
work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.

3
www.ventilation-system.com
SAFETY REQUIREMENTS
All user’s manual requirements as well as the provisions of all the applicable local and national
construction, electrical, and technical norms and standards must be observed when installing
and operating the unit.
Disconnect the unit from the power supply prior to any connection, servicing, maintenance, and
repair operations.
Only qualied electricians with a work permit for electrical units up to 1000 V are
allowed for installation. The present user’s manual should be carefully read before
beginning works.
Check the unit for any visible damage of the impeller, the casing, and the grille before starting
installation. The casing internals must be free of any foreign objects that can damage the
impeller blades.
While mounting the unit, avoid compression of the casing! Deformation of the casing may result
in motor jam and excessive noise.
Misuse of the unit and any unauthorised modifications are not allowed.
Do not expose the unit to adverse atmospheric agents (rain, sun, etc.).
Transported air must not contain any dust or other solid impurities, sticky substances, or fibrous
materials.
Do not use the unit in a hazardous or explosive environment containing spirits, gasoline,
insecticides, etc.
Do not close or block the intake or extract vents in order to ensure the efficient air flow.
Do not sit on the unit and do not put objects on it.
The information in this user’s manual was correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration
of its products at any time in order to incorporate the latest technological developments.
Never touch the unit with wet or damp hands.
Never touch the unit when barefoot.
This unit is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the unit by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the unit.
This appliance incorporates an earth connection for functional purposes.

4
VKM EC
www.ventilation-system.com
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or
similarly qualified persons in order to avoid a safety hazard.
CAUTION: In order to avoid a safety hazard due to inadvertent resetting of the thermal cut-
out, this unit must not be supplied through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by the utility.
Ensure that the unit is switched off from the supply mains before removing the guard.
WARNING: If there are any unusual oscillating movements, immediately stop using the unit and
contact the manufacturer, its service agent or suitably qualified persons.
The replacement of parts of the safety suspension system device shall be performed by the
manufacturer, its service agent or suitably qualified persons.
Precautions must be taken to avoid the back-flow of gases into the room from the open flue of
gas or other fuel-burning appliances.
Connection to the mains must be made through a disconnecting device, which is integrated
into the fixed wiring system in accordance with the wiring rules for design of electrical units,
and has a contact separation in all poles that allows for full disconnection under overvoltage
category III conditions.

5
www.ventilation-system.com
The product described herein is a centrifugal inline fan VKM EC for ventilation of small and medium domestic premises.
The unit is rated for continuous operation.
Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals, sticky substances, fibrous materials,
coarse dust, soot and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust,
pathogenic germs).
NAME QUANTITY
Fan 1 pc.
Fixing bracket 2 pcs.
User’s manual 1 pc.
Packing box 1 pc.
VKM XEC X
Variants
Q: low-power motor
R1: power cord with mains plug
P: integrated smooth speed controller
Un: speed controller with an electronic thermostat and an external temperature sensor fixed on
a 4-meter cable. Temperature-based operation logic
U1n: speed controller with an electronic thermostat and an external temperature sensor fixed
on a 4-meter cable. Timer-based operation logic
U2n: speed controller with an electronic thermostat and an external temperature sensor fixed
on a 4-meter cable. Temperature-based switching on/off
Motor type
EC: electronically commutated motor
Exhaust spigot diameter [mm]
Fan series
VKM: centrifugal fan enclosed in a metal casing
VKMS: centrifugal fan enclosed in a metal casing with a high-power motor
THE UNIT CAN BE USED IN KITCHEN SPACES ONLY IF THERE IS A GREASE FILTER.
INSTALL A KITCHEN HOOD WITH A GREASE FILTER IF AIR IS EXTRACTED FROM THE
COOKING SURFACE.
PURPOSE
DELIVERY SET
DESIGNATION KEY

6
VKM EC
www.ventilation-system.com
TECHNICAL DATA
The fan is designed for indoor or sheltered application at ambient temperature from -25 °C up to +40 °C and relative humidity up to 80 %.
The unit is rated as a class I electric appliance.
Ingress protection rating against access to hazardous parts and water ingress is IPX4.
The unit design is constantly being improved, thus some models may be slightly different from those described in this manual.
TECHNICAL DATA
VKM100 EC VKM 125 EC VKM 150 EC VKM 160 EC VKM 200 EC VKMS 200 EC VKM 250 EC Q VKM 250 EC VKM 315 EC VKMS 315 EC VKM 355 EC VKM 400 EC
Power supply voltage, 50 (60) Hz [V] 1~230
Max. power consumption [W] 90 83 107 108 83 100 100 164 164 183 693 704
Current consumption [A] 0,70 0,58 0,89 0,90 0,63 0,74 0,74 1,15 1,15 1,44 3,07 3,13
Air capacity [m3/h] 345 480 700 785 845 1010 985 1230 1370 1820 3450 4790
RPM [min-1] 3600 3400 3060 3030 2500 2400 2500 2900 2900 2780 2768 2206
Noise level, 3 m [dBA] 44 45 48 48 47 48 44 46 48 49 62 67
Transported air temperature [˚C] -25...+60
SEC class B – – – – –
Для соответствия требованиям ErP 2018, необходимо применять типологию управления local demand control (подключить датчик).

7
www.ventilation-system.com
L
øD1
B
B1
L2
L3
L1
HøD
Terminal box
Casing
Impeller
Fixing bracket
øD2
4
holes
D D1 D2 H B B1 L L1 L2 L3
VKM100 EC 98 255 6 340 310 270 203 20 25 30
VKM 125 EC 123 255 6 340 310 270 203 20 25 30
VKM 150 EC 149 305 6 365 360 320 220 25 25 30
VKM 160 EC 159 305 6 365 360 320 220 25 25 30
VKM 200 EC 198 345 6 435 395 355 245 25 30 40
VKMS 200 EC 198 345 6 435 395 355 255 25 30 40
VKM 250 EC (Q) 248 345 6 435 395 355 250 25 30 40
VKM 315 EC 314 405 6 465 455 415 260 30 30 40
D D1 D2 B B1 L L1 L2 L3
VKMS 315 EC 313 409 9 502 472 462 60 60 50
VKM 355 EC 353 459 9 552 522 562 60 60 70
VKM 400 EC 398 568 9 663 633 599 60 60 70
L
øD1
B
B1
øD
L3
L1
L2
Terminal box
Casing
Impeller
Fixing bracket
øD2
4
holes

8
VKM EC
www.ventilation-system.com
INSTALLATION AND SETUP
The air motion in the system must be as shown with the pointer of the fan casing.
In case of the vertical installation the intake spigot must be protected with a ventilation hood.
To attain the best performance of the fan and to minimise turbulence-induced air pressure losses while mounting, connect straight air
duct sections to the fan spigots on both sides of the fan.
Minimum straight air duct length:
• equal to 1 air duct diameter on intake side
• equal to 3 air duct diameters on outlet side
min 1D min 3D
D
If the air ducts are too short or not connected at any spigot, protect the fan inner parts from ingress of foreign objects by installing a
protecting grille or other protecting device with mesh width not more than 12.5 mm to prevent uncontrollable access to the fans.
While installing the fan ensure convenient access for subsequent maintenance and repair.
The unit must be mounted on a an even wall.
BEFORE MOUNTING MAKE SURE THE CASING DOES NOT CONTAIN ANY FOREIGN
OBJECTS E.G. FOIL, PAPER.

9
www.ventilation-system.com
INSTALLATION STEPS
Disconnect the fan from power supply Install the fixing brackets
Lean the fan against the installation place and mark the fastening
holes
Drill the holes and insert the expansion anchors
Fix the fan Connect air ducts

10
VKM EC
www.ventilation-system.com
CONNECTION TO POWER MAINS
The unit is rated for connection to single-phase ac 230 V/ 50 (60) Hz power mains. For electric installations use insulated durable heat-
resistant conductors (cables, wires) with the minimum wire cross section 0.75 mm2. The conductor cross section value must be selected
depending on the wire type, maximum permissible heating temperature, insulation, length and installation method.
Connect the fan to power mains via an external automatic circuit breaker installed at the power input and integrated in the house cabling
to open the circuit in case of short circuit or overload.
The circuit breaker location must provide quick access for emergency shutdown of the fan.
The fan is connected to the terminal box attached to the fan casing in compliance with the wiring diagram and designation of terminals.
The terminal designation is shown on the sticker attached to the internal wall of the terminal block.
THE UNIT MUST BE MOUNTED BY A QUALIFIED EXPERT ONLY, PROPERLY TRAINED
AND HAVING THE REQUIRED TOOLS AND MATERIALS.
ACCESS TO THE TERMINAL BOX
Disconnect the fan from power supply Unscrew the 4 screws that fix the terminal box lid
Route the cables through the cable gland and complete electric
connection
Reinstall the terminal box lid
The fan can be equipped with a power cord with an IEC C14 connector. The fan is rated for continuous operation.
Thermostat
control knob
Speed
control knob
Speed
control knob
Un, U1n, U2n P
