Vents VKP SERIES User manual

USER'S MANUAL
INLINE RECTANGULAR FANS
VKP SERIES
VENTS VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC SERIES

2
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
Application .............................................................................................................................
Delivery set ............................................................................................................................
Fan designation key .........................................................................................................
Basic technical data ...........................................................................................................
Safety requirements ...........................................................................................................
Installation and safety guidelines..................................................................................
Fan inline rectangular duct mounting example ....................................................
Connection to power mains.............................................................................................
Maintenance ..........................................................................................................................
Troubles and troubleshooting .......................................................................................
Storage rules ..........................................................................................................................
Manufacturing warranty ...................................................................................................
Acceptance certicate ........................................................................................................
Warranty card .........................................................................................................................
3
3
4
5
13
14
14
15
23
25
25
25
27
27
CONTENT
THE PRODUCT MUST BE COLLECTED SEPARATELY AT THE END OF SERVICE
LIFE.
DO NOT DISPOSE OF AS UNSORTED MUNICIPAL WASTE.

3
Inline rectangular fans are intended for supply and exhaust ventilation of residential, public
and industrial premises (production and storage facilities, sport halls, water pools, large
auditoriums, conference halls, etc.). The fans are designed for mounting into rectangular
ducts.
The fans are rated for continuous operation always connected to power mains.
Ingress protection rating is IPX4.
The transporting medium must not contain dust, solid impurities, sticky
substances or brous materials.
Due to constant improvements the design of some models may slightly
dier from those described in this manual.
The delivery set includes:
fan;
user's manual;
packing box.
APPLICATION
DELIVERY SET

4
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
Designation key example:
VKPF 4E 400x200 – rectangular inline fan equipped with single-phased 4-pole
motor and impeller with forward curved blades for mounting into 400x200 mm
air duct.
VKP 800x500 EC – rectangular inline fan equipped with EC-motor and impeller
with backward curved blades for mounting into 800x500 mm air duct.
FAN DESIGNATION KEY
VKP XXXX XXXxXXX X
Fan name
VKP: rectangular inline fan
Number of the motor poles:
2, 4, 6, 8
Impeller design
_: backward curved blades
F: forward curved blades
Fan casing
_: no extra sound insulation
I: sound-insulated casing
Phase
Е: single-phase; D: three-phase
Rectangular duct size
400x200, 500x250, 500x300, 600x300, 600x350,
700x400, 800x500, 900x500, 1000x500
Motor type
_: asynchronous motor
EC: electronically commutated motor

5
BASIC TECHNICAL DATA
VKPF /
VKPFI
4E400x200
VKPF /
VKPFI
4D400x200
VKPF /
VKPFI
4E500x250
VKPF /
VKPFI
4D500x250
VKPF /
VKPFI
6E 500x250
Voltage [V / 50 Hz] 1~ 230 3~ 400 1~ 230 3~ 400 1~ 230
Power [W] 295 282 535 570 244
Current [A] 1.32 0.60 2.49 0.94 1.22
Max. air capacity [m3/h] 1440 1470 1750 1850 1460
RPM [min-1] 1350 1300 1250 1270 910
Noise level at 3 m [dBA] 50 / 42* 52 / 43* 53 / 44* 54 / 44* 45 / 37*
Transported air temperature [°C] -25 +40 -25 +45 -20 +40 -20 +40 -20 +50
Protection rating IPX4 IPX4 IPX4 IPX4 IPX4
* parameter applicable for VKPFI fan
VKPF /
VKPFI
6D500x250
VKPF /
VKPFI
4E500x300
VKPF /
VKPFI
4D500x300
VKPF /
VKPFI
6E500x300
VKPF /
VKPFI
6D500x300
Voltage [V / 50 Hz] 3~ 400 1~ 230 3~ 400 1~ 230 3~ 400
Power [W] 274 710 855 283 303
Current [A] 0.67 3.10 1.70 1.59 0.8
Max. air capacity [m3/h] 1490 2350 2350 1550 1620
RPM [min-1] 930 1230 1300 890 910
Noise level at 3 m [dBA] 45 / 38* 57 / 47* 56 / 47* 47 / 39* 51 / 41*
Transported air temperature [°C] -20 +60 -25 +70 -20 +50 -20 +70 -20 +60
Protection rating IPX4 IPX4 IPX4 IPX4 IPX4
* parameter applicable for VKPFI fan
technical data:
VKPF /
VKPFI
4E600x300
VKPF /
VKPFI
4D600x300
VKPF /
VKPFI
6E600x300
VKPF /
VKPFI
6D600x300
VKPF /
VKPFI
4E 600x350
Voltage [V / 50 Hz] 1~ 230 3~ 400 1~ 230 3~ 400 1~ 230
Power [W] 1240 1560 419 397 2840
Current [A] 6.45 2.73 2.05 0.78 13.90
Max. air capacity [m3/h] 2950 3740 2260 2320 4260
RPM [min-1] 1210 1310 870 920 1260
Noise level at 3 m [dBA] 59 / 51* 57 / 50* 50 / 42* 49 / 41* 59 / 51*
Transported air temperature [°C] -25 +50 -25 +65 -20 +70 -20 +70 -20 +40
Protection rating IPX4 IPX4 IPX4 IPX4 IPX4
VKPF / VKPFI

6
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
VKPF /
VKPFI
6D 900x500
VKPF /
VKPFI
8D900x500
VKPF /
VKPFI
6D 1000x500
VKPF /
VKPFI
8D1000x500
Voltage [V / 50 Hz] 3~ 400 3~ 400 3~ 400 3~ 400
Power [W] 3870 2000 3870 2000
Current [A] 7.0 4.1 7.0 4.1
Max. air capacity [m3/h] 9540 7175 9540 7175
RPM [min-1] 930 680 930 680
Noise level at 3 m [dBA] 61 / 55* 59 / 50* 61 / 55* 59 / 51*
Transported air temperature [°C] -20 +55 -20 +40 -20 +55 -20 +40
Protection rating IPX4 IPX4 IPX4 IPX4
* parameter applicable for VKPFI fan
VKPF /
VKPFI
6D700x400
VKPF /
VKPFI
4D 800x500
VKPF /
VKPFI
6D 800x500
VKPF /
VKPFI
8D800x500
Voltage [V / 50 Hz] 3~ 400 3~ 400 3~ 400 3~ 400
Power [W] 1150 5850 2790 1377
Current [A] 2.3 9.35 5.18 3.40
Max. air capacity [m3/h] 4050 8120 7610 5620
RPM [min-1] 890 1140 830 710
Noise level at 3 m [dBA] 58 / 49* 67 / 61* 59 / 53* 58 / 49
Transported air temperature [°C] -20 +70 -25 +40 -20 +50 -20 +40
Protection rating IPX4 IPX4 IPX4 IPX4
VKPF /
VKPFI
4D 600x350
VKPF /
VKPFI 6E600x350
VKPF /
VKPFI
6D600x350
VKPF /
VKPFI
4D 700x400
Voltage [V / 50 Hz] 3~ 400 1~ 230 3~ 400 3~ 400
Power [W] 2460 720 743 3630
Current [A] 3.93 3.6 1.47 6.00
Max. air capacity [m3/h] 5020 2755 3310 6450
RPM [min-1] 1300 820 940 1320
Noise level at 3 m [dBA] 60 / 52* 51 / 43* 55 / 46* 65 / 56*
Transported air temperature [°C] -20 +40 -20 +60 -20 +70 -25 +40
Protection rating IPX4 IPX4 IPX4 IPX4
technical data:

7
Type Dimensions [mm] Weight
[kg]
B B1 B2 H H1 H2 H3 L
VKPF 4E 400x200 400 420 440 200 220 240 255 500 17.5
VKPF 4D 400x200 400 420 440 200 220 240 255 500 17.5
VKPF 4E 500x250 500 520 540 250 270 290 335 640 24
VKPF 4D 500x250 500 520 540 250 270 290 335 640 24
VKPF 6E 500x250 500 520 540 250 270 290 335 640 24
VKPF 6D 500x250 500 520 540 250 270 290 335 640 24
VKPF 4E 500x300 500 520 540 300 320 340 365 680 33
VKPF 4D 500x300 500 520 540 300 320 340 365 680 33
VKPF 6E 500x300 500 520 540 300 320 340 365 680 33
VKPF 6D 500x300 500 520 540 300 320 340 365 680 33
VKPF 4E 600x300 600 620 640 300 320 340 375 680 35
VKPF 4D 600x300 600 620 640 300 320 340 375 680 35
VKPF 6E 600x300 600 620 640 300 320 340 375 680 35
VKPF 6D 600x300 600 620 640 300 320 340 375 680 35
VKPF 4E 600x350 600 620 640 350 370 390 425 735 49.5
VKPF 4D 600x350 600 620 640 350 370 390 425 735 49.5
VKPF 6E 600x350 600 620 640 350 370 390 425 735 49.5
VKPF 6D 600x350 600 620 640 350 370 390 425 735 49.5
VKPF 4D 700x400 700 720 740 400 420 440 480 780 60
VKPF 6D 700x400 700 720 740 400 420 440 480 780 56
VKPF 4D 800x500 800 820 840 500 520 540 580 820 74
VKPF 6D 800x500 800 820 840 500 520 540 580 820 70
VKPF 8D 800x500 800 820 840 500 520 540 580 820 70
VKPF 6D 900x500 900 920 940 500 520 540 580 954 90
VKPF 8D 900x500 900 920 940 500 520 540 580 954 90
VKPF 6D 1000x500 1000 1020 1040 500 520 540 580 954 95
VKPF 8D 1000x500 1000 1020 1040 500 520 540 580 954 95
Fan overall dimensions:
VKPFIVKPF

8
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
Type Dimensions [mm] Weight
[kg]
B B1 B2 B3 H H1 H2 H3 L
VKPFI 4E 400x200 400 420 440 470 200 220 240 360 500 29
VKPFI 4D 400x200 400 420 440 470 200 220 240 360 500 29
VKPFI 4E 500x250 500 520 540 570 250 270 290 410 640 40.5
VKPFI 4D 500x250 500 520 540 570 250 270 290 410 640 40.5
VKPFI 6E 500x250 500 520 540 570 250 270 290 410 640 40.5
VKPFI 6D 500x250 500 520 540 570 250 270 290 410 640 40.5
VKPFI 4E 500x300 500 520 540 570 300 320 340 460 680 52.5
VKPFI 4D 500x300 500 520 540 570 300 320 340 460 680 52.5
VKPFI 6E 500x300 500 520 540 570 300 320 340 460 680 52.5
VKPFI 6D 500x300 500 520 540 570 300 320 340 460 680 52.5
VKPFI 4E 600x300 600 620 640 670 300 320 340 480 680 56
VKPFI 4D 600x300 600 620 640 670 300 320 340 480 680 56
VKPFI 6E 600x300 600 620 640 670 300 320 340 480 680 56
VKPFI 6D 600x300 600 620 640 670 300 320 340 480 680 56
VKPFI 4E 600x350 600 620 640 670 350 370 390 530 735 72
VKPFI 4D 600x350 600 620 640 670 350 370 390 530 735 72
VKPFI 6E 600x350 600 620 640 670 350 370 390 530 735 72
VKPFI 6D 600x350 600 620 640 670 350 370 390 530 735 72
VKPFI 4D 700x400 700 720 – 800 400 420 – 620 880 103
VKPFI 6D 700x400 700 720 – 800 400 420 – 620 880 99
VKPFI 6D 800x500 800 820 – 900 500 520 – 720 935 120
VKPFI 4D 800x500 800 820 – 900 500 520 – 720 935 127
VKPFI 8D 800x500 800 820 – 900 500 520 – 720 935 120
VKPFI 6D 900x500 900 920 – 1000 500 520 – 720 1000 142
VKPFI 8D 900x500 900 920 – 1000 500 520 – 720 1000 142
VKPFI 6D 1000x500 1000 1020 – 1100 500 520 – 720 1000 150
VKPFI 8D 1000x500 1000 1020 – 1100 500 520 – 720 1000 150
Fan overall dimensions:

9
VKP EC
VKP
600x300 EC
VKP
600x350 EC
VKP
700x400 EC
VKP
800x500 EC
VKP
900x500 EC
VKP
1000x500 EC
Voltage [V / 50/60 Hz] 1~ 200-277 3~ 380-480 3~ 380-480 3~ 380-480 3~ 380-480 3~ 380-480
Power [kW] 0.48 0.99 1.70 2.95 2.98 2.98
Current [A] 3.10 1.70 2.60 4.60 4.60 4.60
Max. air capacity [m3/h] 3350 4550 6300 8900 10850 10850
RPM [min-1] 2300 2580 2600 2500 2040 2040
Noise level at 3 m [dBA] 58 60 63 65 69 69
Transported air temperature [°C] -25 +60 -25 +50 -25 +40 -25 +40 -25 +40 -25 +40
Protection rating IPX4 IPX4 IPX4 IPX4 IPX4 IPX4
Technical data:
Type
Dimensions [mm] Weight
[kg]
B B1 B2 H H1 H2 H3 L
VKP 600x300 EC 600 620 640 300 320 340 430 680 35.0
VKP 600x350 EC 600 620 640 350 370 390 480 735 49.5
VKP 700x400 EC 700 720 740 400 420 440 540 780 60.0
VKP 800x500 EC 800 820 840 500 520 540 640 880 68.8
VKP 900x500 EC 900 920 940 500 520 540 640 954 90.0
VKP 1000x500 EC 1000 1020 1040 500 520 540 640 954 95.0
Fan overall dimensions:
VKP EC

10
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
VKPI EC
Type
Dimensions [mm] Weight
[kg]
B H B1 H1 B3 H3 L G K
VKPI 600x300 EC 600 300 620 320 775 530 752 745 500 55.0
VKPI 600x350 EC 600 350 620 370 775 630 802 745 500 65.0
VKPI 700x400 EC 700 400 720 420 875 690 880 845 742 90.0
VKPI 800x500 EC 800 500 820 520 975 810 935 945 800 124.1
VKPI 900x500 EC 900 500 920 520 1075 810 1000 1045 800 128.0
VKPI 1000x500 EC 1000 500 1020 520 1175 810 1000 1145 800 129.0
Fan overall dimensions:
VKPI
600x300 EC
VKPI
600x350 EC
VKPI
700x400 EC
VKPI
800x500 EC
VKPI
900x500 EC
VKPI
1000x500 EC
Voltage [V / 50/60 Hz] 1~ 200-277 3~ 380-480 3~ 380-480 3~ 380-480 3~ 380-480 3~ 380-480
Power [kW] 0.48 0.99 1.70 2.95 2.98 2.98
Current [A] 3.10 1.70 2.60 4.60 4.60 4.60
Max. air capacity [m3/h] 3350 4550 6300 8900 10850 10850
RPM [min-1] 2300 2580 2600 2500 2040 2040
Noise level at 3 m [dBA] 49 51 54 57 60 60
Transported air temperature [°C] -25 +60 -25 +50 -25 +40 -25 +40 -25 +40 -25 +40
Protection rating IPX4 IPX4 IPX4 IPX4 IPX4 IPX4
Technical data:
VKPI EC

11
VKP / VKPI
4D 600x350
VKP
4D 1000x500
Voltage [V] 3~ 400 Δ 3~ 400 Y 3~ 400
Frequency [Hz] 50 60 50 60 50
Power [W] 510 750 380 515 3800
Current [A] 1.41 1.44 0.7 0.93 6.6
Max. air capacity [m3/h] 2970 3410 2660 2730 15000
RPM [min-1] 1415 1610 1235 1220 1360
Noise level at 3 m [dBA] 64 / 55* 64 / 55* 63 / 55* 63 / 55* 70
Transported air temperature [°C] -40 +60 -40 +60 -40 +80 -40 +40 -20 +40
Protection rating IPX4 IPX4 IPX4
* parameter applicable for VKPI fan
VKP / VKPI
VKP / VKPI
2E 400x200
VKP / VKPI 2E
500x250
VKP / VKPI
4E 500x300
VKP / VKPI
4D 500x300
Voltage [V] 1~ 220-240 1~ 220-240 1~ 220-240 3~ 400
Frequency [Hz] 50 60 50 60 50 60 50 60
Power [W] 138 200 305 380 140 165 136 165
Current [A] 0.60 0.88 1.32 1.65 0.57 0.53 0.34 0.53
Max. air capacity [m3/h] 930 1070 1720 1850 1700 1620 1380 1620
RPM [min-1] 2600 2850 2550 2830 1390 1530 1360 1600
Noise level at 3 m [dBA] 59 / 51* 71/63* 61 / 53* 78 / 67* 53 / 45* 55 / 46* 53 / 45* 55 / 46*
Transported air temperature [°C] -25 +45 -25 +45 -25 +45 -25 +50 -25 +65 -25 +55
Protection rating IPX4 IPX4 IPX4 IPX4
VKP / VKPI
4E 600x300
VKP / VKPI
4D 600x300
VKP / VKPI
4E 600x350
Voltage [V] 1~ 220-240 3~ 400 1~ 220-240
Frequency [Hz] 50 60 50 60 50 60
Power [W] 220 310 230 235 470 700
Current [A] 0.9 1.38 0.52 0.53 2.37 3.15
Max. air capacity [m3/h] 2470 2510 2530 2630 2950 3515
RPM [min-1] 1400 1450 1360 1600 1370 1460
Noise level at 3 m [dBA] 55 / 47* 55 / 57* 53 / 46* 53 / 46* 67 / 59* 68 / 59*
Transported air temperature [°C] -25 +45 -25 +70 -25 +65 -40 +80 -40 +55
Protection rating IPX4 IPX4 IPX4
Technical data:

12
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
Type
Dimensions [mm] Weight
[kg]
B B1 B2 H H1 H2 H3 L
VKP 2E 400x200 400 420 440 200 220 240 240 500 11.25
VKP 2E 500x250 500 520 540 250 270 290 290 640 17.88
VKP 4E 500x300 500 520 540 300 320 340 340 680 19.80
VKP 4D 500x300 500 520 540 300 320 340 340 680 19.80
VKP 4E 600x300 600 620 640 300 320 340 342 680 27.77
VKP 4D 600x300 600 620 640 300 320 340 342 680 27.77
VKP 4E 600x350 600 620 640 350 370 390 390 735 36.38
VKP 4D 600x350 600 620 640 350 370 390 390 735 36.38
Fan overall dimensions:
Type
Dimensions [mm] Weight
[kg]
B B1 B2 B3 H H1 H2 H3 L
VKPI 2E 400x200 400 420 440 500 200 220 240 360 500 24.5
VKPI 2E 500x250 500 520 540 600 250 270 290 410 640 27.6
VKPI 4E 500x300 500 520 540 600 300 320 340 460 680 37.2
VKPI 4D 500x300 500 520 540 600 300 320 340 460 680 37.2
VKPI 4E 600x300 600 620 640 700 300 320 340 460 680 43.5
VKPI 4D 600x300 600 620 640 700 300 320 340 460 680 43.5
VKPI 4E 600x350 600 620 640 700 350 370 390 530 735 56.2
VKPI 4D 600x350 600 620 640 700 350 370 390 530 735 56.2
Type
Dimensions [mm] Weight
[kg]
B B1 B2 H H1 H2 H3 L
VKP 4D 1000x500 1000 1020 1040 500 520 540 720 1150 126.0
VKP VKPIVKP 4D 1000x500

13
Disconnect the fan from power mains prior to any connection, adjustment, maintenance
and repair operations.
Mounting and wireworks are allowed only by a duly qualied electrician with valid
electrical work permit for electric units up to 1000 V after careful reading of the present
user's manual.
The fans are not ready-to-use products and are allowed for operation only after connection
to air ducts and installation of protecting grilles.
Connect air ducts on both sides of the fan.
In case of the fan mounting outside protect the fan against water ingress.
For example, install the fan under the protecting outer hood.
Before connecting the fan to power mains make sure of no visible damages of the fan
impeller, casing, grille and no foreign objects inside the casing that can damage the impeller
blades. Misuse of the fan or any unauthorized modications are not allowed. Do not use
the fan for explosive and re-hazardous media. Take steps to prevent gas backdrafting
from the devices that operate with gas or open ame. The fan may have sharp edges. Make
steps to avoid being cut.
SAFETY REQUIREMENTS

14
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
The fan is designed for mounting and operation in any position. In case of ceiling mounting
the fan is recommended to be mounted with the motor cover downwards to facilitate
access to the terminal box.
Check the fan power cables for integrity and make sure the impeller has smooth rotation
prior to mounting.
Install exible connectors on both sides of the fan. Air ow direction in the system must
match the direction of the arrow on the fan casing.
Remember to mount the fan on the additional internal brackets to avoid load transfer to
the exible connectors. The most suitable mounting option is xation of the fan to the
ceiling with anchor bolts or suspension of the fan to the perforated metal plates. Apply
self-adhesive sealer on the fan end surfaces prior to mounting. Connect the fan to air ducts
with M8 bolts and nuts.
Provide reliable mounting of the fan!
Connect the terminal PE to the ground circuit.
Due to constant improvements the design of some models may slightly dier from those
described in this manual.
INSTALLATION AND SAFETY GUIDELINES
FAN INLINE RECTANGULAR DUCT MOUNTING EXAMPLE
1
3
2
4

15
CONNECTION TO POWER MAINS
Disconnect the fan from power mains prior to any operations with the fan.
Connection of the fan to power mains by duly a professional
electrician only!
The rated electric parameters of the fan are shown on the factory sticker.
Any tempering with internal connection is not allowed and will void
warranty.
Depending on the fan type it is rated either for single-phase ac 230 V/50/60 Hz or three-
phase ac 380-400 V/50/60 Hz power mains.
Connect the fan to power mains through insulated, durable and thermal resistant
conductors (cables, wires).
The automatic circuit breaker incorporated into the xed network that breaks all the phases
must be installed at the external electric input 230V/50/60 Hz or 380-400 V/50/60Hz. The
external circuit breaker QF location must provide free and unhampered access to the fan
for quick switching o in case of need.
The overcurrent protection must match the rated current consumption of the fan. The
recommended rated current of the automatic circuit breaker and wire cross section of
various fan types are stated in the table stated on page 16. The stated wire cross sections
are for reference only. The actually required wire cross section depends on the cable type,
insulation, length and its layout way - open, channel or wall mounting.
Connect EC-fans to power mains on the terminal block located in the external or integrated
terminal box following the wiring diagram and terminal designation. The sticker with the
terminal designation is inside the terminal box.
The terminals TW1, TW2 (TK1,TK2) are the lead-out terminals of the overheating
thermostat normally closed contact. Connect this terminal in series to the power circuit
of the magnetic starter KM1 that starts the motor after pressing the button S1. In case of
the motor overheating the motor contact breaks and switches the starter coil o to de-
energize and stop the motor.
The automatic circuit breaker QF, the magnetic starter KM1, the control buttons S1 and S2
are not included into the delivery set and are to be mounted by the customer.

16
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
The recommended rated current of the automatic circuit breaker
and the wire cross section
VKP, VKPI 2Е 400х200
VKP, VKPI 2Е 500х250
VKP, VKPI 4Е 500х300
VKP, VKPI 4D 500х300
VKP, VKPI 4Е 600х300
VKP, VKPI 4D 600х300
VKP, VKPI 4Е 600х350
VKP, VKPI 4D 600х350
VKP 4D 1000х500
VKP, VKPI 600х300 ЕС
VKP, VKPI 600х350 ЕС
VKP, VKPI 700х400 ЕС
VKP, VKPI 800х500 ЕС
VKP, VKPI 900х500 ЕС
VKP, VKPI 1000х500 ЕС
Automatic circuit
breaker current [A]
Recommended cable, n x S,
where n means number of wires,
S means cross section [mm2]
Fan type
1
2
1
1
1.6
1
4
2
8
4
2
4
6
6
6
2
4
4
8
16
1
1.6
2
5
5
6
8
8
10
8
3х0.75
3х0.75
3х0.75
5х0.75
5х0.75
5х0.5
3х0.75
5х0.75
5х1.0
3х0.75
5х0.75
5х0.5
5х1.0
5х1.0
5х1.0
3х0.75
3х0.75
3х0.75
3х1.5
3х2.5
5х0.75
5х0.75
5х0.75
5х0.75
5х1.0
5х1.0
5х1.5
5х1.5
5х1.5
5х1.5
VKPF, VKPFI 4E 400x200
VKPF, VKPFI 4Е 500х250
VKPF, VKPFI 4Е 500х300
VKPF, VKPFI 4Е 600х300
VKPF, VKPFI 4Е 600х350
VKPF, VKPFI 4D 400x200
VKPF, VKPFI 4D 500х250
VKPF, VKPFI 4D 500х300
VKPF, VKPFI 4D 600х300
VKPF, VKPFI 4D 600х350
VKPF, VKPFI 6D 800х500
VKPF, VKPFI 4D 700х400
VKPF, VKPFI 6D 900х500
VKPF, VKPFI 4D 800х500
VKPF, VKPFI 6D 1000х500

17
Wiring diagram of the fan
VKP/VKPI 2E 400x200; VKP/VKPI 2E 500x250;
VKP/VKPI 4E 500x300; VKP/VKPI 4E 600x300;
VKP/VKPI 4E 600x350 with a single-phase motor
to the alternating current power supply
Wiring diagram of the fan
VKP/VKPI 4D 500x300 (second option),
VKP/VKPI 4D 600x300 with a three-phase
motor to the alternating current
power supply
Wiring diagram of the fan
VKP/VKPI 4D 500x300 (rst option) with
a three-phase motor to the alternating current
power supply
Wiring diagram of the fan
VKP/VKPI 4D 600x350 with a three-phase
motor to alternating current power
supply
L
N
X1
1
2
3
N
L
QF
PE
~230 V
50/60 Hz
4
PE
L2
L1
QF
PE
~400 V
50/60 Hz L2
L1
X1
2
4
1
3
L3
L3
L2
L1
QF
PE
L2
L1
X1
2
4
1
3
L3
L3
PE
L2
L1
QF
PE
~400 V
50/60 Hz L2
L1
X1
2
4
1
3
L3
L3
5
4
TW1
TW2
TW1
TW2
L2
L1
QF
PE
~400 V
50/60 Hz
L2
L1
X1
2
7
1
3
L3
L3
5
4
6
V1
U1
W1
W2
PE
U2
V2
L1
L2
L3
8
9
TW2
TW1TW1
TW2
TW1
TW2
PE
PE
L
N
X1
1
2
3
N
L
QF
PE
~230 V
50/60 Hz
4
PE
L2
L1
QF
PE
~400 V
50/60 Hz L2
L1
X1
2
4
1
3
L3
L3
L2
L1
QF
PE
L2
L1
X1
2
4
1
3
L3
L3
PE
L2
L1
QF
PE
~400 V
50/60 Hz L2
L1
X1
2
4
1
3
L3
L3
5
4
TW1
TW2
TW1
TW2
L2
L1
QF
PE
~400 V
50/60 Hz
L2
L1
X1
2
7
1
3
L3
L3
5
4
6
V1
U1
W1
W2
PE
U2
V2
L1
L2
L3
8
9
TW2
TW1TW1
TW2
TW1
TW2
PE
PE
where X1 is a terminal block, QF is an automatic circuit breaker (not included into
thedelivery set).

18
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
N
L
QF
PE
~230 V
50 Hz L
N
X1
3
6
2
5
4
1
TK1
TK2
TK2
TK1
РЕ
1
2
TW1
TW2
TW1
TW2
L2
L1
QF
PE
~400
V
50 Hz
L2
L1
X1
4
9
3
5
L3
L3
7
6
8
U1
W2
W1
PE
U2
V2
L1
L2
L3
V1
РЕ
Wiring diagram of the fans VKPF, VKPFI with a single-phase motor to the alternating
current power supply
Wiring diagram of the fans VKPF, VKPFI with a three-phase motor to the alternating
current power supply
where X1 is a terminal block, QF is an automatic circuit breaker (not included into
thedelivery set).

19
Wiring diagram of the fans VKP 600x300 EC, VKPI 600x300 EC
Contact Connection
Cable 1 Cable 2
Colour
Black
Blue
Green/Yellow
White 1
White 2
Red
Yellow
Blue
Purpose / Function
Power supply 50/60 Hz, phase
Power supply 50/60 Hz, zero
Ground cable
Fault relay, normally closed
contact
Fault relay, COMMON
Voltage eciency +10 V
(no more 1.1 mA)
Control input 0-10 V / PWM
(total resistance 100 kohm)
Ground
Terminal Connection Purpose / Function
Ground cable
Net, L3
Net, L2
Net, L1
Alarm relay, normally-closed contact
Alarm relay, COMMON (2A, 250V, AC1)
Alarm relay, normally-open contact
Terminal Connection Purpose / Function
Master output 0-10V, max. 3 mA
GND (Ground)
Actual value input / control input
(total resistance 100 kohm)
External potentiometer supply, 10 V (+10 %)
max. 10 mA
External sensor supply, 20 V (+20 %)
max. 50 mA
Actual value input / control input
Actual value input / control input
GND (Ground)
interface RS485 for ebmBUS; RS B
interface RS485 for ebmBUS; RS A
interface RS485 for ebmBUS; RS B
Contact Connection
Cable 1 Cable 2
Colour
Black
Blue
Green/Yellow
White 1
White 2
Red
Yellow
Blue
Purpose / Function
Power supply 50/60 Hz, phase
Power supply 50/60 Hz, zero
Ground cable
Fault relay, normally closed
contact
Fault relay, COMMON
Voltage eciency +10 V
(no more 1.1 mA)
Control input 0-10 V / PWM
(total resistance 100 kohm)
Ground
Terminal Connection Purpose / Function
Ground cable
Net, L3
Net, L2
Net, L1
Alarm relay, normally-closed contact
Alarm relay, COMMON (2A, 250V, AC1)
Alarm relay, normally-open contact
Terminal Connection Purpose / Function
Master output 0-10V, max. 3 mA
GND (Ground)
Actual value input / control input
(total resistance 100 kohm)
External potentiometer supply, 10 V (+10 %)
max. 10 mA
External sensor supply, 20 V (+20 %)
max. 50 mA
Actual value input / control input
Actual value input / control input
GND (Ground)
interface RS485 for ebmBUS; RS B
interface RS485 for ebmBUS; RS A
interface RS485 for ebmBUS; RS B
Wiring diagram for the fans VKP 600x350 EC, VKPI 600x350 EC

20
VKP / VKPI / VKPF / VKPFI / VKP EC / VKPI EC
Wiring diagram for the fans VKP 700x400 EC, VKPI 700x400 EC
Terminal Connection Purpose / Function
Net, L3
Net, L2
Net, L1
Ground cable
Alarm relay , normally-closed contact
Alarm relay , COMMON (2A, 250 V, Ac1)
Alarm relay , normally-open contact
Terminal Connection Purpose / Function
Digital input 1 (electronics unblocking/blocking)
Unblocking: Pin is opened or set voltage 5…50 V
GND (Ground)
Analogue input of set values, 4-20 mA
(resistance 100 kohm), exclusively optionally
Ain1 I is used for connection
interface RS485 for ebmBUS; RS B
interface RS485 for ebmBUS; RS A
Analogue output 0-10 V max. 5mA, output of
actual rpm / actual motor speed control factor
Analogue input of actual values, 4-20 mA
(resistance 100 kohm), exclusively optionally
Ain2 U is used for connection
External sensor voltage, 20 V (+25% / - 10%)
max. 40 mA
Analogue input of actual values, 0-10 mA
(resistance 100 kohm), exclusively optionally
Ain2 I is used for connection
GND (Ground)
Digital input 3 (normal / reverse changeover). The pre-set
parameters of the integrated controller may be selected
through interface or digital input normal / reverse
normal: Pin is open or set voltage is 5…50 V
reverse: jumper to GND or set voltage < 1 V
Digital input 2 (changeover day/night)
Pre-set parameters may be selected through
interface or digital input normal / reverse
Day: Pin is open or set voltage 5…50 V
Night: jumper to GND or set voltage < 1 V
External potentiometer supply , 10 V (3%)±
max. 10 mA
GND or set voltage block < 1V
Analog input of set 0-10V (resistanse 10 kOm)
use Ain1 only as alternate input
Terminal Connection Purpose / Function Terminal Connection Purpose / Function
Ground cable
Net, L3
Net, L2
Net, L1
Alarm relay, normally-open contact
Alarm relay, COMMON (2A, 250 V, Ac1)
Alarm relay, normally-closed contact
Master output 0-10V, max. 3 mA
GND (Ground)
Actual value input / control input
(total resistance 100 kohm)
External potentiometer supply, 10 V
(+10 %) max. 10 mA
External sensor supply, 20V
(+20%) max. 50 mA
GND (Ground)
Actual value input / control input
Actual value input / control input
interface RS485 for ebmBUS; RS B
interface RS485 for ebmBUS; RS A
interface RS485 for ebmBUS; RS B
interface RS485 for ebmBUS; RS A
Wiring diagram for the fans VKP 800x500 EC, VKP 900x500 EC,
VKP 1000x500 EC, VKPI 800x500 EC, VKPI 900x500 EC, VKPI 1000x500 EC
