Veridian Healthcare 01-506 User manual

INSTRUCTION MANUAL • ENGLISH & ESPAÑOL
Automatic
Digital Blood Pressure
Wrist Monitor
Model 01-506

2– English
STOP!
PLEASE E SURE YOU HAVE ALL OF THE FOLLOWI G COMPO E TS BE-
FORE USI G YOUR DIGITAL BLOOD PRESSURE MO ITOR.
IF YOU ARE MISSI G A Y PARTS, I CLUDI G I SERTS OR I STRUCTIO
MA UALS, DO OT RETUR TO PLACE OF PURCHASE.
CO TACT CUSTOMER CARE AT 866-326-1313.
Digital Monitor 2 AAA Batteries Storage Case
Instruction Manual
Quick Start Guide
Blood Pressure Reading Tracking Log
AQ Information Sheet

English – 3
INDEX
Care and Safety Information......................................................................4-5
Introduction ..................................................................................................6
Monitor eatures ..........................................................................................7
Getting Started .............................................................................................8
Battery Installation and Replacement / AC Power..........................................9
Setting Date and Time ................................................................................10
Applying Your Blood Pressure Cuff ..............................................................11
Taking Your Blood Pressure Reading......................................................12-13
Interpreting your Results (IHB and Hypertension) ...................................14-15
Memory unction ..................................................................................16-17
Care and Maintenance................................................................................18
Device and Label Symbols..........................................................................19
Display Symbols .........................................................................................20
Troubleshooting/Error Codes .................................................................21-23
CC Statement ...........................................................................................24
Electromagnetic Compatibility ...............................................................25-28
Specifications.............................................................................................29
Warranty.....................................................................................................30
Instrucciones en Español.......................................................................31-60
Toll-Free Customer Care Help Line: 1-866-326-1313
Monday – Friday 8:30 a.m. – 4:30 p.m. CST
Manufactured for:
Veridian Healthcare
1175 La eside Drive
Gurnee, IL 60031
www.veridianhealthcare.com
Made in China
#93-1057 11/14
©2014 Veridian Healthcare, LLC

4– English
CARE & SAFET INFORMATION
ote: Read all instructions carefully before use. The following basic precautions are needed
when using an electrical product.
Caution: ailure to read and observe all precautions could result in personal injury or equipment
damage.
Improper care or use of your blood pressure monitor may result in injury, damage to the unit or
ineffective treatment. ollowing these instructions will ensure the blood pressure monitor’s
efficacy and long life.
General Cautions & Warnings
• Measurement results should be discussed with your physician or healthcare professional;
never self-diagnose or attempt treatment as this may be dangerous
• Intended for adult use only; this device is not approved for infant or child use
• Keep out of reach of children
• Do not use the unit if it has any damaged parts, if it has been submersed in water or dropped
• If any abnormality occurs, discontinue use until the unit has been examined and repaired
• Only use included attachments and parts; do not use attachments from other brands or
models as these may not be properly calibrated for use with this device and may result in
measurement error
• This monitor may not be appropriate for individuals with serious arrhythmias; consult with
your physician for proper monitor use and evaluation.
• Check the blood circulation of the user before measurement
• Do not share the cuff with an infected person.
• Do not disassemble the unit or attempt to repair it; substitution of a component different from
that supplied may result in measurement error and will void manufacturer warranty
• Always follow local regulations for proper disposal of the monitor, cuff and batteries

English – 5
CARE & SAFET INFORMATION
Operating Cautions & Warnings
• Prolonged over-inflation may cause congestion, swelling or bruising in some people
• Wait a minimum of 2 minutes between measurements (20-minutes is recommended);
excessive frequent measurements may restrict blood circulation
• Do not use this device while connected to any monitoring equipment on the same limb
• The application of the cuff over a wound or inflammation diseases
• Consult with your healthcare professional for guidance for use if you have any of the
following: intravascular shunt; mastectomy on the arm cooresponding to the measurement
side of the body
• If you experience any discomfort or an abnormality occurs, stop using the device
immediately; to stop the device during operation, press the POWER button and the cuff will
automatically deflate
• Operation outside of stated operating temperature may result in measurement error or device
malfunction; operation environment temperature is:
41o – 104o (5oC – 40oC)
Humidity ≤90% RH max
• Never use this unit while operating a vehicle or in the bathtub or shower
Storage Cautions & Warnings
• Storage outside of stated storage temperature may result in measurement error or device
malfunction; storage environment temperature is: -4o – 131o (-20oC – 55oC) Humidity ≤90%
• Keep the unit out of reach of small children
• Always keep the unit unplugged while not in use; remove the batteries if the unit will not be
used for an extended period of time
Cleaning Cautions & Warnings
• Never immerse the unit in water to clean as it may damage the unit
• ollow the ‘Cleaning and Maintenance’ portion of this manual for instruction on how to clean
and care for your monitor

6– English
It s recommended that you first seek the adv ce and recommendat on of your phys c an or
healthcare profess onal when us ng home d agnost c dev ces, nclud ng blood pressure
mon tors.
Automatic Digital Blood Pressure Monitors use the oscillometric method to electronically measure
your blood pressure. The monitor detects your blood’s movement through the artery in your arm
and converts the movements into a digital reading. The oscillometric method does not require a
stethoscope, making the monitor ideal for home use.
Blood pressure readings determined with this device are equivalent to measurements obtained
by a trained healthcare professional using the cuff/stethoscope auscultation method, within the
limits prescribed by the American National Standard for Electronic or Automated
Sphygmomanometers.
Thank you for purchasing our Automatic Digital Blood Pressure Monitor. With proper care
and use, your monitor will provide you with many years of reliable readings.
Introduction
PLEASE READ THIS I STRUCTIO MA UAL
COMPLETELY BEFORE OPERATI G THIS U IT.

English – 7
Monitor Features
Digital Display
Wrist Cuff
MEMORY
Recall Button
POWER
Button (on/off)
Battery
Compartment
(underside)
Details of the display and interpretation of the symbols are included
throughout this manual.

8– English
Before Taking a Measurement
1. Your readings should only be interpreted by your physician or healthcare professional with
access to your individual medical history. Regular use of a home blood pressure monitor will
allow you to track and record your readings for discussion with your physician.
2. Conduct your measurement in a quiet place while seated in a relaxed position. Rest for 15
minutes before taking your reading. If an error occurs or you desire to take a second reading,
allow 15 minutes between readings for your blood vessels to return to normal.
3. Avoid smoking, eating, taking medication, alcohol, physical activity or any other stressful
activity for 30 minutes prior to taking a reading.
4. Always remove any jewelry or constrictive clothing that may interfere with the cuff
placement.
5. Keep yourself and the monitor still during measuring; do not talk during the reading.
6. It is recommended that you take your readings as the same time each day to better monitor
any indications in your results.
7. Record your daily measurement on the included chart or some other written document to
share with your physician.
Getting Started
Variations in Blood Pressure
Blood pressure is influenced by many factors and can change from moment to moment.
Normally, blood pressure is lowest during sleeping periods and rises during the day.

English – 9
This unit comes complete with 2 AAA batteries.
2
It is necessary to replace the batteries when the Low Battery symbol appears on the
display or when the display does not turn on after the POWER button is pressed.
Replacing Battery, Fig. 1
1. Press down and lift the cover.
2. Insert or replace 2 AAA batteries
into the battery compartment,
ensuring to match the indicated
polarity symbols. Always use new
batteries.
3. Replace the battery cover.
4. Dispose of batteries according to
local disposal and recycling
regulations.
It is recommended to remove the
batteries if the unit will not be used
for an extended period of time.
Battery installation and Replacement
Fig. 1

10 – English
Setting the Date and Time
1. When the unit is off, press and release both the POWER and M
(MEMORY) button at the same time. The month will begin to flash, Fig. 1.
2. Press the M(MEMORY) button to change until the desired number
appears. To scroll through the numbers quicker, hold down the M
(MEMORY) button as the numbers advance.
3. Press the POWER button to confirm the month entry.
4. Next, the date will blink. Repeat steps 2 and 3 to set the date, then
hours, then minutes.
5. After setting the minutes, the unit will automatically exit out of the
date/time setting mode.
When the monitor is off, the date and time will still appear at the top of the
screen.
The time is displayed in 24hr Military Time. This chart explains the time
conversion.
Fig. 1
Military Time = Regular Time
1:00 = 1am 7:00 = 7am 13:00 = 1pm 19:00 = 7pm
2:00 = 2am 8:00 = 8am 14:00 = 2pm 20:00 = 8pm
3:00 = 3am 9:00 = 9am 15:00 = 3pm 21:00 = 9pm
4:00 = 4am 10:00 = 10am 16:00 = 4pm 22:00 = 10pm
5:00 = 5am 11:00 = 11am 17:00 = 5pm 23:00 = 11pm
6:00 = 6am 12:00 = 12pm 18:00 = 6pm 24:00 = 12am
IT IS ECESSARY TO SET THE DATE A D TIME FOR THE MO ITOR EVERY TIME
BATTERIES ARE I ITIALLY I STALLED OR REPLACED.

English – 11
Before applying your blood pressure cuff, be sure your wrist is within the
appropriate cuff range.
Wrist Circumference Range Suitable for:
5-1/2” – 7-5/8” (14 – 19.5 cm)
Reminder, it is important to avoid smoking, eating, taking medication,
alcohol consumption or physical activity 30 minutes prior to taking a
reading.
If for any reason you are unable to or should not use your left wrist, please
modify the instructions for cuff application to your right wrist. Your physician
can help you identify which wrist is best for you to take measurements from.
1. Remove any constrictive clothing or jewelry that may interfere with cuff
placement.
2. Be seated at a table or desk with your feet flat on the floor.
3. Hold your left arm in front of you with your palm facing upward and legs
uncrossed.
4. Apply the preformed cuff to your left wrist so that the digital display face
is positioned on the inside area of your wrist facing you, Fig. 1.
5. Adjust the cuff 1/4” - 1/2” from the edge of the head of the ulna bone, Fig.
2.
6. The cuff should fit comfortably, yet snugly around your wrist.
If you are not comfortable with applying your cuff, please seek the assistance
of another member of your household or work with your physician to practice
the cuff application. Incorrectly applied cuffs may result in inaccurate
readings.
Applying our Blood Pressure Cu
Fig. 1
Fig. 2
PROPER CUFF FIT A D PLACEME T IS CRITICAL I OBTAI I G ACCURATE BLOOD
PRESSURE MEASUREME TS. PLEASE READ THESE I STRUCTIO S CAREFULLY A D
CO SIDER CO SULTI G WITH YOUR PHYSICIA FOR FURTHER DIRECTIO .

12 – English
Taking our Blood Pressure Reading
Please read the preceding portions of this manual prior to taking
your first reading.
Reminder, it is important to avoid smoking, eating, taking
medication, alcohol consumption or physical activity 30 minutes
prior to taking a reading.
1. Rest your elbow on a solid surface with your palm facing
upward. Elevate your arm so that the cuff is at the same level
as your heart, Fig 1. Relax your left hand.
2. Press the POWER button to turn the unit on; the unit will run a
self-test, Fig. 2.
3. The unit will briefly display the last reading value for that memory
bank. If there is no previous measurement, the unit will display ‘0’
for all of the reading values, Fig. 3.
4. The cuff will automatically inflate to approximately 190mmHg or 40
mmHg higher than the last systolic pressure reading stored in
memory.
5. When the inflation has reached optimum level, the display will begin
to show the decreasing pressure while you feel the pressure of the
cuff decrease.
Fig. 1
Fig. 2
Fig. 3
OTE: You can stop the inflation or deflation process at any
time by pressing the POWER button.

English – 13
Fig. 6
6. When the measurement is complete, your blood pressure
measurement and pulse will display simultaneously on the screen,
ig 4. Both the systolic and diastolic readings will display at the
same time.
7. The Hypertension Indicator will indicate your reading range in the
left side of the display, ig 5. See page 16 for a chart interpreting
the Hypertension Indicator results.
8. If an irregular heartbeat was detected during the reading, the
Irregular Heartbeat Detector indicator will appear on the display, ig
6. See page 14 for more information on the Irregular Heartbeat
Detector feature.
9. The reading will automatically be stored in memory, up to 60
readings.
10. Select POWER to turn the unit off and conserve energy and
battery life. The unit will automatically shut-off and revert to
time/date mode after approximately 1 minute.
Taking our Blood Pressure Reading
Fig. 5
Fig. 4

14 – English
Interpreting our Results
Irregular Heartbeat Detection
An irregular heartbeat is defined as a heartbeat rhythm that is more than 25% slower or 25%
faster than the average measurement detected while the monitor is conducting the
measurement. When this device detects an irregular rhythm two or more times during the
reading, the IHB symbol will appear on the display screen.
This monitor will operate if the icon appears, but the results may be compromised, especially if
this symbol appears often. Please consult with your physician or trained healthcare professional
for further information regarding an irregular heartbeat and if this symbol appears frequently.
Pulse
Pulse
Blood
Pressure
Blood
Pressure
Normal Heartbeat
Irregular Heartbeat
Short
Beat
Long
Beat

English – 15
Interpreting our Results
Hypertension Indicator
This unit features our unique Hypertension Indicator. The World Health Organization has
established globally accepted standards for the assessment of high or low blood pressure.
This chart can help you identify where your blood pressure measurements fall according to WHO
classification standards. This chart should only be considered as a guideline; always consult with
your physician to interpret your individual results. Never adjust your medication(s) dosage, or
severely alter your diet or exercise routine without consulting with your physician.
The Hypertension
Indicator is
located on the left
side of the display
window
Stage 3 Hypertension
Systolic pressure: ≥180 mmHg
or
Diastolic pressure: ≥110 mmHg
Stage 2 Hypertension
Systolic pressure: ≥160-179 mmHg
or
Diastolic pressure: ≥100-109 mmHg
Stage 1 Hypertension
Systolic pressure: ≥140-159 mmHg
or
Diastolic pressure: ≥90-99 mmHg
High Normal
Systolic pressure: ≥130-139 mmHg
or
Diastolic pressure: ≥85-89 mmHg
Normal
Systolic pressure: ≥ 120-129 mmHg
or
Diastolic pressure: ≥ 80-84 mmHg
Optimal
Systolic pressure: <120 mmHg
or
Diastolic pressure: <80 mmHg

16 – English
Recalling Measurements in Memory
You can recall up to 60 total measurements in memory. Using the
included blood pressure log, these readings can be shared with your
physician or trained healthcare professional.
1. Press and release the M(MEMORY) button. The unit will briefly
show how many readings are stored within the bank, ig. 1.
2. The display will next show the average of the last 3 readings. A
flashing A will appear on the display, the hypertension indicator bar
will also flash ig 2.
3. Press the M(MEMORY) button to begin scrolling through the saved
measurements. The measurement number and hypertension bar
indicator will flash, ig 3. After scrolling through all the readings,
the unit will automatically turn off.
4. When the number of readings exceeds 60, the oldest data will be
replaced with the new
Memory Function
Fig. 1
Fig. 2
Fig. 3

English – 17
Memory Function
Fig. 4
Clearing Measurements from Memory
1. Press and release the M(MEMORY) button. The unit will display
how many measurements are stored within the bank.
2. Press the M(MEMORY) button to confirm the bank to erase. Each
memory bank must be cleared separately.
3. Press and hold down the M(MEMORY) button until two horizontal
lines flash, indicating that all measurements have been erased,
Fig. 4.

18 – English
Proper care and maintenance of your blood pressure monitor will help ensure long life for the
product; improper use of the monitor may void the included warranty.
Monitor Care and Maintenance
• Do not use any liquids on the monitor; use a soft, dry cloth to clean the monitor as needed
• Storage outside of stated storage temperature may result in measurement error or device
malfunction; storage environment temperature is: -4° – 131° (-20°C – 55°C); humidity:
≤90% RH
• Do not store in direct sunlight
• Always keep the unit unplugged while not in use; remove the batteries if the unit will not be
used for an extended period of time
• Do not attempt to disassemble your monitor; disassembling your monitor may void the
manufacturers warranty
• Do not subject the monitor to strong shocks; take care not to drop the monitor
• With proper care, the monitor will maintain performance for a minimum of 10,000
measurements or three years
• No component of this device can be maintained by the user; the circuit diagrams, component
part lists, descriptions, calibration instruction or other information which will assist the user's
appropriately qualified technical personnel to repair those parts of equipment which are
designated repairable can be supplied.
• It is recommended that monitor performance be reviewed every two years or after service or
repair; please contact your service provider or call customer care
Cuff Care and Maintenance
• The cuff should not be submerged or washed in a washing machine, but may be spot cleaned
with a mild-detergent as needed
• Clean the cuff thoroughly after every 200 uses or more frequently as needed
• Never attempt to iron or dry the cuff; if the cuff becomes wet, allow the cuff to air dry completely
before use or storage
• To disinfect the cuff, wipe the inside (skin contact side) of the cuff using a cloth lightly moistened
with 70% - 90% ethyl rubbing alcohol and allow to air dry; it is suggested to disinfect the cuff
frequently when used in clinical sittings or if the cuff is contaminated in any way
• With proper care, the cuff will maintain performance for a minimum of 1000 measurements
Care and Maintenance

English – 19
Display Symbols
Read This Manual—All included manuals should be read prior to first use
Warning—Symbol indicates a warning, prohibition or mandatory action that mitigates a
risk that is not necessarily obvious to the device operator
Typ e B Applied Parts—Indicates that a part of this unit comes in contact with the patient
in order to carry out it’s intended function; in the case of this device the cuff is the Type B
Applied Part
Environment Protection—dispose of this product properly; consult with your local recycling
ordinances for proper recycling and disposal
Keep Dry—This device should be kept dry; never submerge the unit or cuff. Consult with
the Care and Maintenance section of this manual for information on cleaning your monitor

2012

2012
Symbol Mean ng

20 – English
Display Symbols
Symbol Mean ng
Systolic Blood Pressure—The ‘to ’ blood ressure result
Diastolic Blood Pressure—The ‘bottom’ blood ressure result
Milligrams of Mercury—Unit of blood ressure measurement for this device
Pulse Rate—Pulse rate er minute during the measurement
Low Battery—Battery is low and should be re laced
Down Arrow—The cuff is not ro erly wra ed or has too much air left in it;
arrow will cease flashing when the unit is ready for measurement
U Arrow—A measurement error has occurred and the measurement should be
attem ted again
Irregular Heartbeat Icon—An irregular heartbeat was detected during the
measurement
Memory Reading—Reading on dis lay is a reading from a memory bank
Average—The dis lay shows the average of the last three measurements in
memory
Error– An error has occurred during the measurement
