Veris E50B1 User manual

Installation Guide
Power Monitoring
ZL0103-0C Page 1 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
TM
For use inaPollutionDegree 2or betterenvironmentonly.APollutionDegree 2environmentmust
controlconductivepollutionand thepossibility ofcondensation orhighhumidity.Considerthe
enclosure,the correct useof ventilation,thermalproperties ofthe equipment,and therelationship with
theenvironment. Installation category: CATIIor CATIII. Provide a disconnect device todisconnect the
meter from the supply source. Placethis device inclose proximity tothe equipmentand within easy
reach of theoperator,and mark itas thedisconnecting device.The disconnecting device shall meet the
relevantrequirements ofIEC60947-1and IEC 60947-3and shallbe suitable for the application. Inthe US
andCanada,disconnecting fuseholders canbe used.Provide overcurrentprotection anddisconecting
deviceforsupply conductors with approvedcurrent limiting devices suitable for protectingthe wiring.
If the equipment isused inamanner not specified bythe manufacturer,the protection provided bythe
devicemaybeimpaired.
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Follow safe electrical work practices. See NFPA 70E in the USA, or applicable local codes.
• This equipment must only be installed and serviced by qualified electrical personnel.
• Read, understand and follow the instructions before installing this product.
• Turn off all power supplying equipment before working on or inside the equipment.
• Product may use multiple voltage/power sources. Disconnect all sources of power
before servicing.
• Use a properly rated voltage sensing device to confirm power is off.
DO NOT DEPEND ON THIS PRODUCT FOR VOLTAGE INDICATION.
• Current transformer secondaries must be shorted or connected to a burden at all times.
• Products rated only for basic insulation must be installed on insulated conductors.
• Replace all doors, covers and protective devices before powering the equipment.
Failure to follow these instructions will result in death or serious injury.
A qualied person is one who has skills and knowledge related to the construction and
operation of this electrical equipment and installations, and has received safety
training to recognize and avoid the hazards involved. NEC2014 Article 100
No responsibility is assumed byVeris Industries for any consequences arising out of the
use of this material.
DANGER
NOTICE
• This product is not intended for life or safety applications.
• Do not install this product in hazardous or classied locations.
• The installer is responsible for conformance to all applicable codes.
• Mount this product inside a suitable re and electrical enclosure.
FCC PART 15 INFORMATION
NOTE: This equipment has been tested by the manufacturer and found to
comply with the limits for a class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
residential environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Modifications to this product without the express authorization of the
manufacturer nullify this statement.
WARNING
LOSS OF CONTROL
∙ Assure that the system will reach a safe state during and after a control path failure.
∙ Separate or redundant control paths must be provided for critical control functions.
∙ Test the eect of transmission delays or failures of communication links.1
∙ Each implementation of equipment using communication links must be individually
and thoroughly tested for proper operation before placing it in service.
Failure to follow these instructions may cause injury, death or equipment damage.
1For additional information about anticipated transmission delays or failures of the link, refer to
NEMA ICS 1.1 (latest edition). Safety Guidelins for the Application, Installation, and Maintenance
of Solid-State Control or its equivalent in your specic country, language, and/or location.
Control system design must consider the potential failure modes of control paths and, for
certain critical control functions, provide a means to acheive a safe state during and after a
path failure. Examples of critical control functions are emergency stop and over-travel stop.
Product Overview
The E50 DIN Rail Power Meter provides a solution for measuring energy data with a single device. Inputs include
Control Power, CT, and 3-phase voltage. The E50 supports multiple output options, including solid state relay
contacts, Modbus (with or without data logging), and pulse. The LCD screen on the faceplate allows instant output
viewing.
The meter is housed in a plastic enclosure suitable for installation on T35 DIN rail according to EN50022. The E50 can
be mounted with any orientation over the entire ambient temperature range, either on a DIN rail or in a panel. The
meter is not sensitive to CT orientation to reduce installation errors.
E50B1, E50C2, E50C3
Compact Power and Energy Meter
RoHS
Compliant
Product Identification
Model Description Output Data Logging
Pulse RS-485 Alarm
E50B1 Pulse Output Only •
(2 pulses)
E50C2 Modbus output, full data set • • •
E50C3 Modbus output, data logging • • • •
Specifications
MEASUREMENT ACCURACY
Real Power and Energy IEC 62053-22 Class 0.2S, ANSI C12.20 0.2%
Reactive Power and Energy IEC 62053-23 Class 2, 2%
Current 0.4% (+0.015% per °C deviation from 25°C) from 5% to 100% of
range; 0.8% (+0.015% per °C deviation from 25°C) from 1% to 5% of
range
Voltage 0.4% (+0.015% per °C deviation from 25°C) from 90VL- N to 600VACL- L
Sample Rate 2520 samples per second
Data Update Rate 1 sec
Type of Measurement True RMS up to the 21st harmonic 60 Hz; One to three phase AC
system
INPUT VOLTAGE CHARACTERISTICS
Measured AC Voltage Minimum 90VL- N (156VL- L ) for stated accuracy;
UL Maximum: 600VL- L (347VL- N )
CE Maximum: 300VL- N
Metering Over-Range +20%
Impedance 2.5 MΩL- N /5 MΩL- L
Frequency Range 45 to 65 Hz
INPUT CURRENT CHARACTERISTICS
CT Scaling Primary: Adjustable from 5 A to 32,000 A
Measurement Input Range 0 to 0.333 VAC or 0 to 1.0 VAC (+20% over-range), rated for use with
Class 1 voltage inputs
Impedance 10.6 kΩ(1/3 V mode) or 32.1 kΩ(1 V mode)

ZL0103-0C Page 2 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
CONTROL POWER
AC 5VA max.; 90V min.
UL Maximum: 600VL- L (347 VL- N )
CE Maximum: 300VL- N
DC* 3 W max.; UL and CE: 125 to 300VDC
Ride Through Time 100 msec at 120VAC
OUTPUT
Alarm Contacts (all models) N.C., static output (30VAC/DC, 100mA max. @ 25°C, derate 0.56mA
per °C above 25°C)
Real Energy Pulse Contacts
(all models) AND
Reactive Energy Pulse Contacts
(E50B1A only)
N.O., static output (30VAC/DC, 100mA max. @ 25°C, derate 0.56mA
per °C above 25°C)
RS-485 Port (E50CxA) 2-wire, 1200 to 38400 baud, Modbus RTU
MECHANICAL CHARACTERISTICS
Weight 0.62 lb (0.28 kg)
IP Degree of Protection
(IEC 60529)
IP40 front display; IP20 Meter
Display Characteristics Back-lit blue LCD
Terminal Block Screw Torque 0.37 to 0.44 ft-lb (0.5 to 0.6 N·m)
Terminal Block Wire Size 24 to 14 AWG (0.2 to 2.1 mm2)
Rail T35 (35mm) DIN Rail per EN50022
OPERATING CONDITIONS
Operating Temperature Range -30° to 70°C (-22° to 158°F)
Storage Temperature Range -40° to 85°C (-40° to 185°F)
Humidity Range <95% RH noncondensing
Altitude of Operation 3000 m
COMPLIANCE INFORMATION
US and Canada CAT III, Pollution degree 2;
for distribution systems up to 347VL- N /600VACL- L
CE CAT III, Pollution degree 2;
for distribution systems up to 300VL- N
Dielectric Withstand Per UL 508, EN61010
Conducted and Radiated
Emissions
FCC part 15 Class B, EN55011/EN61000 Class B (residential and light
industrial)
Conducted and Radiated
Immunity
EN61000 Class A (heavy industrial)
US and Canada (cULus) UL508 (open type device)/CSA 22.2 No. 14-05
Europe (CE) EN61010 -1
* External DC current limiting is required, see fuse recommendations.
Specifications (cont.)

ZL0103-0C Page 3 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Table of Contents Dimensions 4
Data Outputs 4
Product Diagram 5
Display Screen Diagram 5
Installation 6
Supported System Types 7
Wiring Symbols 7
Wiring 8
Control Power 9
Quick Setup Instructions 10
Solid State Output 11
User Interface Menu Abbreviations Dened 11
User Interface for Data Conguration 12
Alert/Reset Information 13
User Interface for Setup 14
RS-485 Communications (E50C3 Only) 16
Data Logging (E50C3 Only) 16
Modbus Point Map Overview 17
Standard Modbus Default Settings 17
Modbus Point Map Overview 18
Modbus Point Map 19
Troubleshooting 26
China RoHS Compliance Information (EFUPTable) 26

ZL0103-0C Page 4 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Dimensions
4.2”
(107mm)
3.6”
(91mm)
1.5”
(39mm)
2.3”
(59mm)
1.9”
(48mm)
1.8”
(45mm)
3.6“
(91 mm)
4.2“
(107 mm)
0.2“
(4 mm)
3.9“
(99 mm)
2.4“
(61 mm)
++
+
4.3“
(109 mm)
1.2“
(31 mm) 0.3“
(8 mm)
0.4“
(10 mm)
Bottom View (DIN Mount Option) Bottom View (Screw Mount Option)
Full Data Set (FDS):
Power (kW)
Energy (kWh)
Congurable for CT & PT ratios, system type, and passwords
Diagnostic alerts
Current: 3-phase average
Volts: 3-phase average
Current: by phase
Volts: by phase Line-Line and Line-Neutral
Power: Real, Reactive, and Apparent 3-phase total and per phase
Power Factor: 3-phase average and per phase
Frequency
Power Demand: Most Recent and Peak
Demand Conguration: Fixed, Rolling Block, and External Sync (Modbus only)
Data Logging (includes all FDS outputs, plus):
Real Time Clock: user congurable
10 user congurable log buers: each buer holds 5760 16-bit entries
(User congures which 10 data points are stored in these buers)
User congurable logging interval
(When congured for a 15 minute interval, each buer holds 60 days of data)
Continuous and SIngle Shot logging modes: user selectable
Auto write pause: read logs without disabling the meter’s data logging mode
Data Outputs

ZL0103-0C Page 5 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Product Diagram
* Two Output Options Available
Pulse (E50B1) RS-485 (E50Cx)
Display Screen
Diagram

 Tx
Rx
ERR
♥
Screen Name or Units
Diagnostic Alert
Logo
Numeric Data
Alive Indicator
RS-485 Equipped Units Only:
Transmit Data
Receive Data
Receive Data Error
LCD Screen: Buttons:
+
–
(Up)
Select
(Right)
Next
(Down)
Select
(Left)
Back
Alarm Energy


Two 5-character rows
of display text.
Top row alphanumeric;
Bottom row numeric only
CONTROL POWER
0.1A 50/60 Hz
A B C N 1 2
Alarm Energy
NC NO + - S
OUTPUT
Phase Loss Alarm Pulse
VA VB VC
Neutral
Earth
Control Power
Output varies by model *
UL: 90V L-N - 600V L-L CE: 90V L-N - 300V L-N
VOLTAGE INPUTS
CAT III 50/60 Hz
+
–
The red Alarm LED lights when
any of the 3 phase voltages
drop below the selected
threshold. The green Energy
LED lights momentarily each
time the Energy output pulse is
active.
(X2) A(X1) (X2) B(X1) (X2) C(X1)
IA IB IC
X2 X1 X2 X1 X2 X1
CT Inputs 1 or 0.333 VAC
+ - S
VARh
N.O. Contact
+ - S
RS-485
Modbus
Shield

ZL0103-0C Page 6 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Installation Disconnect power prior to installation.
Reinstall any covers that are displaced during the installation before powering the unit.
Mount the meter in an appropriate electrical enclosure near equipment to be monitored.
Do not install on the load side of a Variable Frequency Drive (VFD), aka Variable Speed Drive (VSD)
or Adjustable Frequency Drive (AFD).
The meter can be mounted in two ways: on standard 35 mm DIN rail or screw-mounted to the interior surface of the enclosure.
A. DIN Rail Mounting
1. Attach the mounting clips to the underside of the housing by sliding them into the slots from the inside. The stopping pegs
must face the housing, and the outside edge of the clip must be ush with the outside edge of the housing.
2. Snap the clips onto the DIN rail. See the diagram of the underside of the housing (below).
Clip flush with
outside edge
Snap onto
DIN rail
Insert clips from inside
3. To reduce horizontal shifting across the DIN rail, use two Veris AV02 end stop clips.
B. Screw Mounting
1. Attach the mounting clips to the underside of the housing by sliding them into the slots from the outside. The stopping pegs
must face the housing, and the screw hole must be exposed on the outside of the housing.
2. Use three #8 screws (not supplied) to mount the meter to the inside of the enclosure. See the diagram of the underside of the
housing (below).
Screw holes
exposed for
mounting
Insert clips from outside

ZL0103-0C Page 7 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
The meter has a number of dierent possible system wiring congurations (see Wiring section). To congure the meter, set the
System Type via the User Interface or Modbus register 130 (if so equipped). The System Type tells the meter which of its current
and voltage inputs are valid, which are to be ignored, and if neutral is connected. Setting the correct System Type prevents
unwanted energy accumulation on unused inputs, selects the formula to calculate the Theoretical Maximum System Power,
and determines which phase loss algorithm is to be used. The phase loss algorithm is congured as a percent of the Line-to-Line
System Voltage (except when in System Type 10) and also calculates the expected Line to Neutral voltages for system types that
have Neutral (12 & 40).
Values that are not valid in a particular System Type display as “----” on the User Interface or as QNAN in the Modbus registers.
CTs Voltage Connections System Type Phase Loss Measurements Wiring
Diagram
Number
of wires
Qty ID Qty ID Type Modbus
Register 130
User Interface:
SETUP>S SYS
VLL VLN Balance Diagram
number
Single-Phase Wiring
2 1 A 2 A, N L-N 10 1L + 1n AN 1
2 1 A 2 A, B L-L 11 2L AB 2
3 2 A, B 3 A, B, N L-L with N 12 2L + 1n AB AN, BN AN-BN 3
Three-Phase Wiring
3 3 A, B, C 3 A, B, C Delta 31 3L AB, BC, CA AB-BC-CA 4
4 3 A, B, C 4 A, B, C, N Grounded
Wye
40 3L + 1n AB, BC, CA AN, BN, CN AN-BN-CN &
AB-BC-CA
5, 6
Supported System
Types
To avoid distortion, use parallel wires for control power and voltage inputs.
The following symbols are used in the wiring diagrams on the following pages.
Symbol Description
Voltage Disconnect Switch
Fuse (installer is responsible for ensuring compliance with local requirements. No
fuses are included with the meter.)
Earth ground
X2
X1 Current Transducer
Potential Transformer
Protection containing a voltage disconnect switch with a fuse or disconnect circuit
breaker. The protection device must be rated for the available short-circuit current at
the connection point.
CAUTION
RISK OF EQUIPMENT DAMAGE
• This product is designed only for use with 1V or 0.33V current
transducers (CTs).
• DO NOT USE CURRENT OUTPUT (e.g. 5A) CTs ON THIS PRODUCT.
• Failure to follow these instructions can result in overheating and
permanent equipment damage.
Wiring Symbols

ZL0103-0C Page 8 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
RISK OF ELECTRIC SHOCK OR PERMANENT EQUIPMENT DAMAGE
CT negative terminals are referenced to the meter’s neutral and may be at elevated voltages
· Do not contact meter terminals while the unit is connected
· Do not connect or short other circuits to the CT terminals
Failure to follow these instructions may cause injury, death or equipment damage.
WARNING
Wiring
N L1
X2
X1 White
Black
A
B
C
N
X1
X2
X1
X2
X1
X2
A
B
C
Diagram 1: 1-Phase Line-to-Neutral 2- Wire
System 1 CT
Diagram 2: 1-Phase Line-to-Line 2-Wire
System 1 CT
L1 L2
X2
X1
X2
X1
A
B
C
N
A
B
C
N
White
Black
White
Black
X1
X2
X1
X2
X1
X2
L1 L2
X2
X1
A
B
C
N
A
B
C
White
Black X1
X2
X1
X2
X1
X2
Diagram 3: 1-Phase Direct Voltage Connection 2 CT
L1 L2 L3
X2
X1
A
B
C
N
A
B
C
X2
X1
X2
X1
White
Black
White
Black
White
Black
X1
X2
X1
X2
X1
X2
Diagram 4: 3-Phase 3-Wire 3 CT no PT
Use System Type 11 (2L)
Use System Type 12 (2L + 1n) Use System Type 31 (3L)
Use System Type 10 (1L + 1n)
L1N L2 L3
X2
X1
A
B
C
N
A
B
C
X2
X1
X2
X1
White
Black
White
Black
White
Black
X1
X2
X1
X2
X1
X2
Diagram 5: 3-Phase 4-Wire Wye Direct Voltage Input
Connection 3 CT
Use System Type 40 (3L + 1n)
White
Black
White
Black
White
Black
L1N L2 L3
X2
X1
A
B
C
N
A
B
C
X2
X1
X2
X1
X1
X2
X1
X2
X1
X2
Diagram 6: 3-Phase 4-Wire Wye Connection 3 CT
3 PT
Use System Type 40 (3L + 1n)

ZL0103-0C Page 9 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Control Power
Direct Connect Control Power (DC Control Power)
L1N L2 L3 1 2G
L1N L2 L3
1 2G
L1
1 2G
L2 L3
Direct Connect Control Power (Line to Neutral)
Line to Neutral from 90 VAC to 347 VAC (UL) or 300 VAC (CE)
1 2G
Control Power Transformer (CPT) Connection
Direct Connect Control Power (Line to Line)
Line to Line from 90 VAC to 600 VAC (UL). In UL installations the
lines may be oating (such as a delta). If any lines are tied to an
earth (such as a corner grounded delta), see the Line to Neutral
installation limits. In CE compliant installations, the lines must
be neutral (earth) referenced at less than 300 VACL-N
The Control Power Transformer may be wired L-N or L-L. Output to
meet meter input requirements
DC Control Power from 125 VDC to 300 VDC
(UL and CE max.)
Fuse Recommendations
Keep the fuses close to the power source (obey local and national code requirements).
For selecting fuses and circuit breakers, use the following criteria:
• Select current interrupt capacity based on the installation category and fault current capability.
• Select over-current protection with a time delay.
• Select a voltage rating sucient for the input voltage applied.
• Provide overcurrent protection and disconnecting means to protect the wiring. For AC installations, use Veris AH02,
AH03, AH04, or equivalent. For DC installations, provide external circuit protection. Suggested: 0.5 A, time delay fuses.
• The earth connection (G) is required for electromagnetic compatibility (EMC) and is not a protective earth ground.

ZL0103-0C Page 10 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Quick Setup
Instructions
These instructions assume the meter is set to factory defaults. If it has been previously congured, all optional values should be
checked.
1. Press the +
+or
–
button repeatedly until SETU P screen appears.
2. to the PASWD screen.
3. through the digits. Use the +
+or
–
buttons to select the password (the default is 00000). Exit the screen to the right.
4. Use the +
+or
–
buttons to select the parameter to congure.
5. If the unit has an RS-485 interface, the rst Setup screen is S COM (set communications).
a. to the ADDR screen and through the address digits. Use the +
+or
–
buttons to select the Modbus address.
b. to the BAUD screen. Use the +
+or
–
buttons to select the baud rate.
c. to the PAR screen. Use the +
+or
–
buttons to select the parity.
d. back to the S COM screen.
6.
–
to the S CT (Set Current Transducer) screen. If this unit does not have an RS-485 port, this will be the rst screen.
a. to the CT V screen. Use the +
+or
–
buttons to select the voltage mode Current Transducer output voltage.
b. to the CT SZ screen and through the digits. Use the +
+or
–
buttons to select the CT size in amps.
c. back to the S CT screen.
7.
–
to the S SYS (Set System) screen.
a. to the SYSTM screen. Use the +
+or
–
buttons to select the System Type (see wiring diagrams).
b. back to the S SYS screen.
8. (Optional)
–
to the S PT (Set Potential Transformer) screen. If PTs are not used, then skip this step.
a. to the RATIO screen and through the digits. Use the +
+or
–
buttons to select the Potential Transformer step down
ratio.
b. back to the S PT screen.
9.
–
to the S V (Set System Voltage) screen.
a. to the VLL (or VLN if system is 1L-1n) screen and through the digits. Use the +
+or
–
buttons to select the Line to Line
System Voltage.
b. back to the S V screen.
10. Use the to exit the setup screen and then SETUP.
11. Check that the wrench is not displayed on the LCD.
a. If the wrench is displayed, use the +
+or
–
buttons to nd the ALERT screen.
b. through the screens to see which alert is on.
For full setup instructions, see the conguration instructions on the following pages.

ZL0103-0C Page 11 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [e-mail] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Solid State Output The E50 have one normally open (N.O.) KY Form A output and one normally closed (N.C.) output.* One is dedicated to energy
(Wh), and the other to Alarm. The E50B1 also provides an additional N.O. reactive energy (VARh) contact. See the Setup section for
conguration information.
~
=
~
=
≤ 100 mA
≤ 100 mA
~
=
≤ 100 mA
Alarm Energy Output
+ – S
LOAD
LOAD
LOAD
Power Source
3-30 VDC
6-30 VAC
Power Source
3-30 VDC
6-30 VAC
Over-Current Protective
Device** (not supplied)
Power Source
3-30 VDC
6-30 VAC
E50B1 only
The solid state pulse outputs are rated for 30 VAC/DC nom.
Maximum load current is 100mA at 25°C. Derate 0.56 mA per °C above 25°C.
* While the relay used for the Phase Loss contact is Normally Closed (contacts are closed when the meter is not powered), closure indicates the presence of an
alarm; either loss of phase, when the meter is powered, or loss of power when the meter is not. The contacts are open when the meter is powered and no phase
loss alarm conditions are present
** Use an over-current protective device rated for the short circuit current at the connection point.
Main Menu
IEC IEEE Description
D D Demand
MAX M Maximum Demand
P W Present Real Power
QVAR Present Reactive Power
SVA Present Apparent Power
A A Amps
UAB, UBC, UAC VAB, VBC, VAC Voltage Line to Line
V VLN Voltage Line to Neutral
PF PF Power Factor
U VLL Voltage Line to Line
HZ HZ Frequency
KSh KVAh Accumulated Apparent
Energy
KQh KVARh Accumulated Reactive
Energy
KPh KWh Accumulated Real Energy
PLOSS PLOSS Phase Loss
LOWPF LOWPF Low Power Factor Error
Main Menu
IEC IEEE Description
F ERR F ERR Frequency Error
I OVR I OVR Over Current
V OVR V OVR Over Voltage
PULSE PULSE kWh Pulse Output Overrun
(conguration error)
_PHASE _PHASE Summary Data for 1, 2, or 3
active phases
ALERT ALERT Diagnostic Alert Status
INFO INFO Unit Information
MODEL MODEL Model Number
OS OS Operating System
RS RS Reset System
SN SN Serial Number
RESET RESET Reset Data
PASWD PASWD Enter Reset or Setup
Password
ENERG ENERG Reset Energy Accumulators
DEMND DEMND Reset Demand Maximums
User Interface (UI)
Menu Abbreviations
Defined
The user can set the display mode to either IEC or IEEE notation in the SETUP menu.

ZL0103-0C Page 12 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [e-mail] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
User Interface for
Data Configuration
* This screen is not available in units with rmware versions 1.018 or earlier. ** This screen is part of the Phase Summary Data in units with rmware versions 1.018 or earlier.
* * *
_PHAS
APHAS
BPHAS
CPHAS
3 A 3 VLL 3 VLN 3 KW
A A A VABA KW
1, 2, o
r 3 Phase
Summary D
ata
Phase A:
All Systems
Phase B:
2 & 3 Phase
Systems Only
Phase C:
3 Phase
Systems Only
A VLN
Volts Line-Line (U)
(Average of Active
Phases)
Amps (A)
(Average of
Active Phases)
Volts Line-Neutral (V)
(Average of Active
Phases)
Total Real
Power (P)
Power Factor
(Average of
Active Phases)
3 KVA
Total Apparent
Power (S)
B A B VBCB KWB VLN
C A C VACC KWC VLN
A KVA
B KVA
C KVA
A PF
3 PF
B PF
C PF
3KVAR
Total Reactive
Power (Q)
AKVAR
BKVAR
CKVAR
KVARhKVAh
Accumulated
Reactive Energy
(Qh)
Accumulated
Apparent Energy
(Sh)
DEMND D KW
Present
Real Power
Demand (P)
M KW MKVARM KVA
Maximum
Apparent Power
Demand (S)
Maximum
Reactive Power
Demand (Q)
Maximum
Real Power
Demand (P)
DKVAR
Present
Reactive Power
Demand (Q)
D KVA
Present
Apparent Power
Demand (S)
DEMND
Demand
>>> Scroll When Idle >>>
To:
SETUP
APHAS
BPHAS
CPHAS
A KWh
3 KWh
B KWh
C KWh
_PHAS
HZ
Frequency
Accumulated
Real Energy
ENRGY
To:
ALERT
Energy
Accumulators
and Co
unters
ENRGY
PULS1
Pulse Counter 1
(Wh if present)
PULS2
Pulse Counter 2
(VARh if present)
KWh
Accumulated
Real Energy
(Ph)
** ** ****

ZL0103-0C Page 13 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [e-mail] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Alert/Reset
Information
SETUP
ALERT
RESET
Back
Display “nOnE” if no alerts
To Setup
Setup
Meter
Reset
Data
Phase Loss
A B C
Low Power Factor
A B C
Frequency Out
of Range
A
Current
Out of Range
Voltage
Out of Range
A B C A B C
INFO MODEL OS SNRS
Serial
Number
Reset
System
Operating
System
ALERT
INFO
PLOSS
--------
A b C
LOWPF
--------
A b C
F ERR
--------
A
I OVR
--------
A b C
V OVR
--------
A b C
PASWD
--------
00000
PASWD
--------
00000
Model
Number
Energy Pulse Output:
Error = Overrun Error
ConF = Configuration Error
PULSE
--------
Error
ENERG
--------
rES
ResetEnergy
Accumulators to 0
Unit
Information
Alert Status
(check if
Wrench on
LCD)
RESET
Enter Reset
Password
Enter Setup
Password
To: ENRGY
To: DEMND
COUNT
--------
rES
Reset Pulse
Counters to 0
DEMND
--------
rES
Reset Demand
Maximums to Present
PASWD – Enter the Reset Password
(configured in the setup menu).
ENERG – Reset all Energy
Accumulators (Wh, VARh, VAh) to 0.
Press “+” or “-“ to Reset.
DEMND – Reset all Maximum
Demand (W, VAR, VA) to the present
Demand. Hit “+” or “-“ to Reset.
COUNT – Reset the pulse counters.
Press “+” or “-“ to Reset.
* This screen is not available in units with rmware versions 1.018 or earlier.
*

ZL0103-0C Page 14 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [e-mail] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
UI for Setup
Next
Next
From:
SETUP > PASWD
ADDR
--------
001
BAUD
--------
38400
19200
9600
4800
2400
1200
PAR
--------
nOnE
EvEn
Odd
Set Communications Parameters:
ADDR - Modbus Address: 1 – 247.
+ increments the selected (blinking) digit.
-selects the digit to the left.
BAUD - Baud Rate: 1200 – 38400 Baud
PAR - Parity: Odd, Even, None
+or –to step through the options.
Set Current Transducer:
CT V - CT Input Voltage: + or –to Select 1.0 or .33V.
CT SZ - CT Size: in Amps. Maximum is 32000 Amps.
Set System Configuration:
SYSTM: + or –to step through the following System Type options:
System Reg 130 CTs Description
3L-1n 40 3 Wye Three Phase: A, B, & C with Neutral (Default).
3L 31 3 Delta Three Phase: A, B & C; no Neutral
2L-1n 12 2 Single Split Phase: A & B with Neutral
2L 11 1 Single Phase: A & B; no Neutral
1L-1n 10 1 Single Phase: A to Neutral
System
Type
Current
Transformer
S SYS
Next
S CT
CT V
--------
1.0
.33
CT SZ
--------
100
SYSTM
--------
3L-1n
3L
2L-1n
2L
1L-1n
Back To SETUP
Back
Back
Back S COM
To Setup p. 2 “SPLOS”
Next
S PT
Set Potential Transfomer Ratio:
RATIO – Potential transformer step down is RATIO:1. Default is 1:1
(No PT installed). See Install for wiring diagrams. This value must be
set before the System Voltage (if used).
Potential
Transformer
RATIO
--------
001.00
Back
S V
Back
Sytem
Voltage Next
Set System Voltage:
V LL – The nominal Line to Line Voltage for the system. This is used
by the meter to calculate the theoretical maximum system power, and
as the reference voltage for setting the Phase Loss threshold.
Maximum is 32000 Volts. For system type 1+N (10), this is a Line to
Neutral Voltage, indicated by “V LN”. Note: the meter will reject settings
that are not within the meter’s operating range when divided by the PT
ratio.
V LL
--------
00600
S PWR
Back
Sytem
Voltage
MX KW
--------
103.92
Next
System Power:
MX KW – The theoretical Maximum System Power is calculated by the
meter from the System Voltage, CT size, and System Type. Power
Factor is assumed to be unity. The value of System Power is used to
determine which combinations of pulse weight and duration are valid
and will keep up with the maximum power the meter will see. This value
is read only.
Note: Bold is the Default.
To Setup p. 2 “SPASS”
RS-485
Output
† †
†
†
†
†
†
†
† When leaving this parameter screen using the right button ( ), the display will
briey indicate “SAvEd)” to conrm that any changes made have been accepted.

ZL0103-0C Page 15 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [e-mail] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
UI for Setup (cont.)
Next
Set Passwords:
SETUP - The Password to enter the SETUP menu.
RESET - The Password to enter the RESET menu.
RESET
--------
00000
SPASS
Setup
Passwords
SETUP
--------
00000
Back
Next
SDMND
INTRV
--------
6
5
4
3
2
1
Demand
SEC
--------
00900
Back
Set Demand Interval:
INTRV - The number of Sub-Intervals (1 to 6) in a
Demand Interval.Default is 1 (block demand).
SEC - Sub-Interval length in seconds. Default is
900 (15 minutes). Set to 0 for external sync-to-
comms (Modbus units only).
Next
S DIS
Display
Units
UNITS
--------
IEEE
IEC
Back
Set Display Units: +/- to switch between:
IEEE – VLL VLN W VAR VA Units.
IEC - U V P Q S Units.
To Setup p. 1 “S PWR”
Max
PPS
--------
1
2
5
10
20
50
Pulse
Output
Next
Set Pulse:
The System Type , CT size, PT Ratio, and System Voltage must
all be configured before setting the Pulse Energy. If any of these
parameters are changed, the meter will hunt for a new Pulse
Duration, but will not change the Pulse Energy. If it cannot find a
solution, the meter will display the wrench, show “ConF” in the
ALARM -> PULSE screen, and enable Energy pulse output
configuration error bit in the Modbus Diagnostic Alert Bitmap (if
equipped).
Wh/P - Set Pulse Energy: In Watt Hours (& VAR Hours, if
present) per Pulse. When moving down to a smaller energy, the
meter will not allow the selection if it cannot find a pulse duration
that will allow the pulse output to keep up with Theoretical
Maximum System Power (see S_PWR screen). When moving
up to a larger energy, the meter will jump to the first value where
it can find a valid solution.
mS/P – Minimum Pulse Duration Time: This read only value
is set by the meter to the slowest duration (in mS per closure)
that will keep up with the Theoretical Maximum System Power.
The open time is greater than or equal to the closure time. The
maximum Pulses Per Second (PPS) is shown in yellow.
mS/P
--------
500
250
100
50
25
10
SPULS
Back
Wh/P
--------
10000
1000
100
10
SPLOS
Back
IMBAL
--------
0.25
Next
VOLTS
--------
0.10
Set Phase Loss:
VOLTS - Phase Loss Voltage: The fraction of the system
voltage below which Phase Loss Alarm is on. For system
types with neutral, the Line to Neutral voltage is also
calculated and tested. If the System Voltage is 600 and the
fraction is set to 0.10, then the Phase Loss threshold will be
60 volts.
IMBAL - Phase Loss Imbalance: The fractional difference
in Line to Line voltages above which Phase Loss Alarm is
on. For system types with neutral, the Line to Neutral
voltages are also tested. For system types 1+N (10) and 2
(11) , imbalance is not tested.
Phase
Loss
Back To SETUP
To Setup page 1 “S CT”, “S COM”,
or “S BAC” depending on model
BDS
†
†
†
†
†
†
†
†
† When leaving this parameter screen using the right button ( ), the display will
briey indicate “SAvEd)” to conrm that any changes made have been accepted.

ZL0103-0C Page 16 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Daisy-chaining Devices to the Power Meter
The RS-485 slave port allows the power meter to be connected in a daisy chain with up to 63 2-wire devices.
–
+
S
120 Ω terminator on the rst and last
device of the daisy chain
Shield wire
Notes
• The terminal’s voltage and current ratings are compliant with the requirements of the EIA RS-485 communications
standard.
• The RS-485 transceivers are ¼ unit load or less.
• RS-485+ has a 47 k pull up to +5V, and RS-485- has a 47 k pull down to Shield (RS-485 signal ground).
• Wire the RS-485 bus as a daisy chain from device to device, without any stubs. Use 120  termination resistors at each
end of the bus (not included).
• Shield is not internally connected to Earth Ground.
• Connect Shield to Earth Ground somewhere on the RS-485 bus.
For all terminals:
• When tightening terminals, apply the correct torque: 0.37 to 0.44
ft·lb (0.5-0.6 N·m).
• Use 14-24 gauge (2.1-0.2 mm2) wire.
RS-485
Communications
(ECx only)
Red
Black
Gray
0.37–0.44 ft•lb
(0.5–0.6 N•m)
Use 14-24 gauge wire
Data Logging
(EC only)
The E50C3 includes a data logging feature that records 10 meter parameters, each in its own buer.
Configuration
Use register 150 to set the data logging time subinterval. Writing to the storage buer is triggered by the subinterval timer. The
default subinterval is 15 minutes (at a 15 minute interval setting, the buers hold 60 days of data). An external timer can be used
over Modbus by setting this register to 0.
Use register 159 to turn on data logging and select either Single Shot or Continuous mode. (default is data logging on, Continuous
mode). In Single Shot mode, the meter records data until the buer is full. When the buer is full, the meter stops recording
new readings. Data for this time period is kept, but newer energy information is lost. In Continuous mode, the meter continues
to record energy data as long as the meter is operating. The buer can only hold 5760 entries at one time, however, so when the
number of records exceeds 5760, the oldest entry is deleted to make room for the newest.
Registers 169-178 contain the pointers to 10 data storage buers. Each buer is user-congurable with the Modbus address of the
16-bit data output to be stored. 32-bit data, such as oating point data or 32-bit integer energy accumulators, require two buers.
However, the lower 16 bits of an integer energy accumulator can be stored in a single buer (optional).
When the E50C3 is rst installed, the buers contain QNAN data, with a value of 0x8000. This data is considered invalid. If the
buer is reset at any point, all entries in the buers are overwritten with this 0x8000 value, indicating that it is invalid. All invalid
data is overwritten as the meter lls the buer with new data entries.
Reading Data
Use register 158 to choose which buer to read. When this register value is set to 0, the meter is in data logging mode. Changing
this value from 0 to (1 through 10) switches the meter to reading mode and selects a buer to read. Data from the selected buer
appears in registers 8000 to 13760.

ZL0103-0C Page 17 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [e-mail] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Data Logging
(EC only,
cont.)
Read/Write Collision
If the demand sub-interval timeout occurs while the user is reading a page (register 158 ≠ 0), the log data will be held in RAM
until the next demand subinterval. At that time, both the saved data from the previous cycle and the new data will be written to
the log, whether the page register has been set back to 0 or not. Error bits in the Log Status Register (160) track these conditions.
Subsequent log writes will proceed normally. Provided the log read is concluded in less time than the demand sub-interval, this
mechanism handles the occasional collision and prevents the user from reading data as the buer is being updated.
The Log Status Register has additional error ag bits that indicate whether logging has been reset or interrupted (power cycle,
etc.) during the previous demand sub-interval, and whether the Real-Time Clock has been changed (re-initialized to default date/
time due to a power-cycle or modied via Modbus commands).
Setting Value Modbus
Register
Setup Password 00000 
Reset Password 00000 
System Type 40 (3 + N) Wye 130
CT Primary Ratio (if CTs are not included) 100A 131
CT Secondary Ratio 1V 132
PT Ratio 1:1 (none) 133
System Voltage 600 V L-L 134
Max. Theoretical Power
(Analog Output: full scale (20mA or 5V))
104 kW 135
Display Mode 1 (IEEE) 137
Phase Loss 10% of SystemVoltage (60V), 25% Phase to Phase Imbalance 142, 143
Pulse Energy 1 (kWh/pulse) 144
Demand: number of sub-intervals per interval 1 (block mode) 149
Demand: sub-interval length 900 sec (15 min) 150
Modbus Address 001 
Modbus Baud Rate 19200 baud 
Modbus Parity None 
Log Read Page 0 158
Logging Conguration Register 0 159
Log Register Pointer 1 1 (Real Energy MSR) 169
Log Register Pointer 2 2 (Real Energy LSR) 170
Log Register Pointer 3 29 (Reactive Energy MSR) 171
Log Register Pointer 4 30 (Reactive Energy LSR) 172
Log Register Pointer 5 37 (Real Demand) 173
Log Register Pointer 6 38 (Reactive Demand) 174
Log Register Pointer 7 39 (Apparent Demand) 175
Log Register Pointer 8 155 (Month/Day) 176
Log Register Pointer 9 156 (Year/Hour) 177
Log Register Pointer 10 157 (Minutes/Seconds) 178
Standard Modbus
Default Settings

ZL0103-0C Page 18 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Modbus Point Map
Overview
The E50C2 Full Data Set (FDS) features data outputs such as demand calculations, per phase VA and VAR, and VAh VARh
accumulators. The E50C3 data logging model adds conguration registers 155-178 and buer reading at registers 8000-13760. For
security reasons, conguration and resets on all E50 models are protected by a user congurable passcode. The meter supports
variable CTs and PTs, allowing a much wider range of operation from 90V x 5A up to 32000V x 32000A. To promote this, the meter
permits variable scaling of the 16-bit integer registers via the scale registers. The 32-bit oating point registers do not need to be
scaled.
Integer registers begin at 001 (0x001). Floats at 257 (0x101). Conguration registers at 129 (0x081). Values not supported in a
particular System Type conguration will report QNAN (0x8000 in Integer Registers, 0x7FC00000 in Floating Point Registers).
Supported Modbus Commands
Note: ID String information varies from model to model. Text shown here is an example.
Command Description
0x03 Read Holding Registers
0x04 Read Input Registers
0x06 Preset Single Register
0x10 Preset Multiple Registers
0x11
Report ID
Return string:
byte0: address
byte1: 0x11
byte2: #bytes following w/out crc
byte3: ID byte = 247
byte4: status = 0xFF if the operating system is used; status = 0x00 if the reset system is used
bytes5+: ID string =“Veris Industries E50xx Power Meter Full Data Set” or“Veris Industries E50xx Power Meter - RESET
SYSTEM RUNNING RSVersion x.xxx”last 2 bytes: CRC
0x2B
Read Device Identication, BASIC implementation (0x00, 0x01 and 0x02 data), Conformity Level 1.
Object values:
0x01:“Veris Industries”
0x02:“ E50xx”
0x03:“Vxx.yyy”, where xx.yyy is the OS version number (reformatted version of the Modbus register #7001, (Firmware
Version, Operating System).
If register #7001 == 12345, then the 0x03 data would be“V12.345”).
Legend
The following table lists the addresses assigned to each data point. For oating point format variables, each data point appears
twice because two 16-bit addresses are required to hold a 32-bit oat value.
R/W R=read only; R/W=read from either int or oat formats, write only to integer format.
NV Value is stored in non-volatile memory.The value will still be available if the meter experiences a power loss and reset.
Format
UInt Unsigned 16-bit integer.
SInt Signed 16-bit integer.
ULong Unsigned 32-bit integer; Upper 16-bits (MSR) in lowest-numbered / rst listed register (001/002 = MSR/LSR).
Float 32-bit oating point; Upper 16-bits (MSR) in lowest-numbered / rst listed register (257/258 = MSR/LSR). Encoding
is per IEEE standard 754 single precision.
Units Lists the physical units that a register holds.
Scale Factor Some Integer values must be multiplied by a constant scale factor (typically a fraction), to be read correctly.This is done to allow
integer numbers to represent fractional numbers.
Range Denes the limit of the values that a register can contain.

ZL0103-0C Page 19 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [e-mail] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
Modbus Point Map
E50C2 FDS
E50C3 Log
E50xx REG.
R/W NV Format Units Scale Range Description
Integer Data
• • 001 R NV ULong kWh E0-0xFFFF Real Energy Consumption (MSR) Clear via reset register
• • 002 0-0xFFFF Real Energy Consumption (LSR)
• • 003 R UInt kW W 0-32767 Total Instantaneous Real Power (3 Phase Total)
• • 004 R UInt kVAR W 0-32767 Total Instantaneous Reactive Power (3 PhaseTotal)
• • 005 R UInt kVA W 0-32767 Total Instantaneous Apparent Power (3 Phase Total)
• • 006 R UInt Ratio 0.0001 0-10000 Total Power Factor (Total KW /Total KVA)
• • 007 R UInt Volt V 0-32767 Voltage, L-L, Average of 3 Phases
• • 008 R UInt Volt V 0-32767 Voltage, L-N, Average of 3 Phases
• • 009 R UInt Amp I 0-32767 Current, Average of 3 Phases
• • 010 R UInt kW W 0-32767 Real Power, Phase A
• • 011 R UInt kW W 0-32767 Real Power, Phase B
• • 012 R UInt kW W 0-32767 Real Power, Phase C
• • 013 R UInt Ratio 0.0001 0-10000 Power Factor, Phase A
• • 014 R UInt Ratio 0.0001 0-10000 Power Factor, Phase B
• • 015 R UInt Ratio 0.0001 0-10000 Power Factor, Phase C
• • 016 R UInt Volt V 0-32767 Voltage, Phase A-B
• • 017 R UInt Volt V 0-32767 Voltage, Phase B-C
• • 018 R UInt Volt V 0-32767 Voltage, Phase A-C
• • 019 R UInt Volt V 0-32767 Voltage, Phase A-N
• • 020 R UInt Volt V 0-32767 Voltage, Phase B-N
• • 021 R UInt Volt V 0-32767 Voltage, Phase C-N
• • 022 R UInt Amp I 0-32767 Current, Instantaneous, Phase A
• • 023 R UInt Amp I 0-32767 Current, Instantaneous, Phase B
• • 024 R UInt Amp I 0-32767 Current, Instantaneous, Phase C
• • 025 R UInt Reserved; returns 0x8000 (QNAN)
• • 026 R UInt Hz 0.01 4500-6500 Frequency (derived from Phase A)
• • 027 R NV ULong KVAh E0-0xFFFF Apparent Energy Consumption (MSR) Clear via reset register
• • 028 0-0xFFFF Apparent Energy Consumption (LSR)
• • 029 R NV ULong KVARh E0-0xFFFF Reactive Energy Consumption (MSR) Clear via reset register
• • 030 0-0xFFFF Reactive Energy Consumption (LSR)
• • 031 R UInt kVA W 0-32767 Apparent Power, Phase A
• • 032 R UInt kVA W 0-32767 Apparent Power, Phase B
• • 033 R UInt kVA W 0-32767 Apparent Power, Phase C
• • 034 R UInt kVAR W 0-32767 Reactive Power, Phase A
• • 035 R UInt kVAR W 0-32767 Reactive Power, Phase B
• • 036 R UInt kVAR W 0-32767 Reactive Power, Phase C
• • 037 R UInt kW W 0-32767 Total Real Power Present Demand
• • 038 R UInt kVAR W 0-32767 Total Reactive Power Present Demand
• • 039 R UInt kVA W 0-32767 Total Apparent Power Present Demand
• • 040 R NV UInt kW W 0-32767 Total Real Power Max Demand
• • 041 R NV UInt kVAR W 0-32767 Total Reactive Power Max Demand
• • 042 R NV UInt kVA W 0-32767 Total Apparent Power Max Demand

ZL0103-0C Page 20 of 26 ©2014 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 09141
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
EB, EC, EC TM
E50C2 FDS
E50C3 Log
E50xx REG.
R/W NV Format Units Scale Range Description
• • 043* R NV ULong 0-0xFFFF Pulse Counter 1 (Real Energy) MSR Contact Closure Counters. Valid for
both Pulse inputs and outputs. E50xx
counts are shown in (). See register
144 (Energy per Pulse) for the Wh per
pulse count. Clear via register 129.
Inputs are user dened.
• • 044* LSR
• • 045*
R NV ULong 0-0xFFFF Pulse Counter 2 (Reactive Energy)
MSR
• • 046* LSR
• • 047* R NV ULong kWh E 0-0xFFFF Real Energy Consumption
Phase A
MSR
Clear via reset register
• • 048* LSR
• • 049* R NV ULong kWh E 0-0xFFFF Real Energy Consumption
Phase B
MSR
• • 050* LSR
• • 051* R NV ULong kWh E 0-0xFFFF Real Energy Consumption
Phase C
MSR
• • 052* LSR
Conguration
• • 129 R/W UInt N/A
Command Register:
- Write 30078 (0x757E) to clear all Energy Accumulators to 0.
- Write 21211 (0x52DB) to begin new Demand Sub-Interval calculation cycle.Takes eect at the end of the next
1 second calculation cycle.Write no more frequently than every 10 seconds.
- Write 21212 (0x52DC) to reset Max Demand values to Present DemandValues.Takes eect at the end of the
next 1 second calculation cycle. Write no more frequently than every 10 seconds.
- Write 16640 (0x4100) to Reset Logging (E50C3 only).
- Write 16498 (0x4072) to Clear Pulse Counters to 0.
- Read always returns 0.
• • 130 R/W NV UInt
10,
11,
12,
31,
40
Single Phase: A + N
System Type
(See Manual. Note: only the indicated
phases are monitored for Phase Loss)
Single Phase: A + B
Single Split Phase: A + B + N
3 phase ∆, A + B + C, no N
3 phase Y, A + B + C + N
• • 131 R/W NV UInt Amps 1-32000 CT Ratio – Primary
Current Inputs
• • 132 R/W NV UInt 1, 3 CT Ratio – Secondary Interface (1 or 1/3 V, may not be user
congurable)
• • 133 R/W NV UInt 100 0.01-320.00 PT Ratio: The meter scales this value by 100 (i.e. entering 200 yields a potential transformer ratio of 2:1).The
default is 100 (1.00:1), which is with no PT attached. Set this value before setting the system voltage (below)
• • 134 R/W NV UInt 82-32000
SystemVoltage: This voltage is line to line, except for system type 10 which is line to neutral.The meter uses
this value to calculate the full scale power for the analog outputs and pulse conguration (below), and as full
scale for phase loss (register 142).The meter will refuse voltages that are outside the range of 82-660 volts
when divided by the PT Ratio (above).
• • 135 R NV UInt kW W 1-32767
Theoretical Maximum System Power:This read-only value is the theoretical max. power the meter can expect to
see on a service. This value is 100% of scale on the analog output (0-5VDC or 4-20mA), if equipped. The meter
recalculates this value if the user changes the CT size, system type, or system voltage.This integer value has
the same scale as other integer power registers (see register 140 for power scaling).
• • 136 R UInt Reserved, always returns 0
• • 137 R/W NV UInt 0,1 Display Units: 0 = IEC (U,V, P, Q, S), 1 = IEEE (default:VLL, VLN, W, VAR,VA)
Modbus Point Map (cont.)
