VERIS INDUSTRIES ™
environmental SenSorS inStallation GUiDe
Z205466-0E PAGE 1 ©2009 Veris Industries USA 800.354.8556 or +1(0)503.598.4564 / suppor[email protected] 10091
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
TI SerIeS TI SerIeS
NOTICE
• This product is not intended for life or safety applications.
• Do not install this product in hazardous or classified locations.
• Read and understand the instructions before installing
this product.
• Turn off all power supplying equipment before working on it.
• The installer is responsible for conformance to all applicable codes.
Product IdentIfIcatIon
Immersion Temperature Sensors
Installer’s Specifications
Wiring 22AWG; 2-wire:RTD Thermistor, 4-20mA; 3-wire: Voltage output models
Probe Stainless Steel
Test Pressure 200psi
Linitemp:
Input Power 5 to 30VDC
Output 1µA/°C or 10mV/°C
Operating Temperature -25° to 105°C (-13° to 221°F)
Accuracy Calibration Error: 1.5°C (35°F) typical; 2.5°C (37°F) max. at 25°C (77°F)*
Error over Temperature: 1.8°C typical (35°F); 3.0°C (34°F) max.
over 0° to 70°C (32° to 158°F) range
2.0°C (35°F) typical, 3.5°C (38°F) max.
over -25° to 105°C (-13° to 221°F) range
*Room temperature error documented on each unit.
quIck Install
Thread assembly into a pipe fitting.1.
Wire as shown (see Wiring section).2.
TIG
TIH
TID
Thermowell Sensor Type
T I
Immersion Probe
Length “L”
0 = None
1 = Add Thermowell
B = 100R Platinum, RTD
C = 1k Platinum, RTD
D = 10k T2, Thermistor
E = 2.2k, Thermistor
F = 3k, Thermistor
G = 10k CPC, Thermistor
H = 10k, T3, Thermistor
J = 10k Dale, Thermistor
K = 10k w/11k shunt,Thermistor
M = 20k NTC, Thermistor
N = 1800 ohm, Thermistor
P = 10mV/°C, Linitemp
R = 10k US, Thermistor
S = 10k 3A221, Thermistor
T = 100k, Thermistor
U = 20k “D”, Thermistor
A = 2 1/2" (64mm)
B = 4" (102mm)
C = 6" (152mm)
D = 8" (203mm)
E = 12” (305mm)
Cal Certificate
Enclosure
D = Duct
G = Service Entry Body
H = Threaded NPT Only
W = Water resistant
housing
Threads
Blank = NPT
A = BSPT
B = DIN 2999
Thermowell Sizing
Probe Length Thermowell Length
A (2 1/2") (64mm) 1 1/2” (38mm)
B (4") (102mm) 3” (76mm)
C (6") (152mm) 5” (127mm)
D (8") (203mm) 7” (178mm)
E (12”) (305mm) 11” (279mm)
0 = None
1 = 1 point Cal validation
2 = 2 point Cal validation
Options
TIW

VERIS INDUSTRIES ™
inStallation GUiDe
ti SerieS
Z205466-0E PAGE 2 ©2009 Veris Industries USA 800.354.8556 or +1(0)503.598.4564 / suppor[email protected] 10091
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
dImensIons
1.5"
(38 mm)
0.25"Dia.
(6.3 mm)
L
1/2" NPT
Standard
L
L
0.25" dia.
(6.3mm)
Overall: "L" + 2" (50.8mm)
0.375" dia.
(10mm)
Overall: "L" + 1.75" (45mm)
Immersion Probes
Thermowells
TIG Model
TIH Model
4"
(102 mm)
2.2"
(56 mm)
0.25" dia"
(6.3mm)
L
0.5" nom.
(13 mm)
TID Model
WIrIng
Thermistor
RTD Orange
Orange
Linitemp
BLUE COMMON/GND
ORANGE V+ (15V)
WHITE SIGNAL
NOTE: All linitemp units are standard 3-wire 10m V/C. For 1µ A/C (2-wire)
connect +15V (orange) and (white) signal wire. The (blue) wire is not
connected.
CONTROLLER
TEMP SENSOR
+15v
Analog IN
Common
ORANGE V+ (15V)
WHITE (SIGNAL)
BLUE (COMMON/GND)
3-Wire 10m V/C
2-Wire 1µ A/C
CONTROLLER
TEMP SENSOR
+15v
Analog IN
Common
ORANGE V+ (15V)
WHITE (SIGNAL)
BLUE (NO CONNECT)
4.5"
(114 mm)
2.8"
(71 mm)
0.25" dia"
(6.3mm)
L
1.5"
(38 mm)
1/2" NPT
Standard
TIW Model
