Vermeiren Gemini 2 User manual

VERMEIREN
INSTALLATION MANUAL
Gemini 2

Gemini 2
2021-06
Contents
Installation manual
- 1 -
EN
NL
Contents
Preface........................................................................................................................2
1This product ..................................................................................................3
2Scope of delivery ..........................................................................................4
3Tools ..............................................................................................................4
4Assembly and adjustments .........................................................................5
4.1 Adjusting the wheelchair to the user ...............................................................6
4.1.1 Seat depth..........................................................................................6
4.1.2 Footrest length (seat width 40)...........................................................7
4.1.3 Foot supports (optional) .....................................................................7
4.1.4 Hip pelots ...........................................................................................8
4.2 Changing pneumatic tyres ..............................................................................8

Gemini 2
2021-06
Preface
Installation manual
- 2 -
EN
NL
Preface
To support you on the installation and repairs of this wheelchair, this manual is offered. Please
read it carefully. If you still have questions after reading this manual, do not hesitate to contact
Vermeiren.
The information in this manual applies to all wheelchairs in the following list:
•Gemini 2
Pictures of the product are used to clarify the instructions. Details of the shown product may
deviate from your product.
On our website http://www.vermeiren.com/ you will always find the most recent version of the
following information. Please consult this website regularly for possible updates.
Visually impaired people can download the electronic version of this manual and have it read out
by means of a text-to-speech software application.
Instruction manual
For user and specialist dealer
Installation instructions (Instructions for detail adjustments)
For specialist dealer
Torque table (maximum torques for bolts and nuts)
For specialist dealer
Service manual for wheelchairs
For specialist dealer
Drawings of (spare) parts
For specialist dealer

Gemini 2
2021-06
Contents
Installation manual
- 3 -
EN
NL
1 This product
1
2
3
4
5
6
7
8
9
10
11
Push bar
Backrests
Safety belt
Seat
Footrest
Footplate
Steering wheels (front wheels)
Driving wheels (rear wheels)
Brake
Frame
Location identification plate

Gemini 2
2021-06
Scope of delivery
Installation manual
- 4 -
EN
NL
2 Scope of delivery
The following items are part of the delivery.
•Frame including wheels, backrest and seat, footrest, central brake
•Tools
•Manual
•Accessories
Please note that the basic configuration may differ in different European countries. Contact your
specialist dealer.
3 Tools
To repair and adjust the wheelchair, the following tools are needed:
•Wrench set no. 10
•Allen keyset no. 4

Gemini 2
2021-06
Contents
Installation manual
- 5 -
EN
NL
4 Assembly and adjustments
Important remark
•Read the user manual of this wheelchair.
•Be aware of the technical details and limits of intended use; see the user manual.
•For more information, contact Vermeiren. See the website http://www.vermeiren.com/.
Risk of injuries or damage
•The wheelchair needs to be adjusted by a specialist dealer according to the instructions in this
manual.
•Any modification to the product will lapse the warranty and will cease the responsibility of
Vermeiren.
•Only use parts and tools described in this manual.
•Prevent bystanders from accessing the working area.
•While adjusting and operating the wheelchair, make sure no objects or body parts get caught
between moving parts.
•Only use the settings described in this manual.
•Make sure that the adjustment on left and right side of the wheelchair are the same.
•Deviation of the adjustment settings may influence the stability of the wheelchair with risk of
tilting and falling.
•Make sure all screws are firmly secured before riding the wheelchair. Adhere to the
tightening torques for screws according to the Torque table on our website.
CAUTION

Gemini 2
2021-06
Assembly and adjustments
Installation manual
- 6 -
EN
NL
4.1 Adjusting the wheelchair to the user
4.1.1 Seat depth
Seat width 32 1. Loosen the four bolts (1) on both
sides of the seating plate.
2. Slide the seating plate to the
front/back to the desired position
(60 mm range, stepless).
3. Tighten both screws.
Seat width 40 1. Loosen the four bolts (2) on both
sides of the seating plate.
2. Slide the seating plate to the
front/back to the desired position
(3 positions, steps of 25 mm).
3. Tighten both screws.
1
1
2
2

Gemini 2
2021-06
Contents
Installation manual
- 7 -
EN
NL
4.1.2 Footrest length (seat width 40)
The footrest can be changed in 2 different lengths
(steps 35 mm: outer tube) and 4 different lengths
(steps of 25 mm: inner tube).
Adjustments are made as follows:
1. Loosen the screws (3) on both sides.
2. Move the footplate (4) up/down until the desired
length.
3. Retighten the two screws (3).
4. Make sure that the footplate is firmly fixated.
4.1.3 Foot supports (optional)
1. Place the foot supports (5) on the footplate (6).
2. Place the screw-nut connections (7) and tighten by hand.
3. Place the wingnuts (8) and tighten firmly.
3
3
4
8
5
8
32
40
5
6
6
7
7

Gemini 2
2021-06
Assembly and adjustments
Installation manual
- 8 -
EN
NL
4.1.4 Hip pelots
To adjust the width:
1. Loosen the two screws (9).
2. Move the hip pelot (10) outwards or inwards
until the desired width (range 18,8 mm,
stepless).
3. Retighten the two screws (9).
4. Check that the pelot (10) is well fixated.
5. Repeat for the other pelot.
4.2 Changing pneumatic tyres
Risk of injuries and damage
•Make sure all air is released from the tyre, before removing it.
•Make sure that no body parts, the inner tube nor any other objects are pinched between tyre
and rim.
•Make sure all screws are firmly secured by hand before driving with the wheelchair.
•Make sure that the pressure is correct, see the pressure indication on the tyres.
•Inflate the tyre using inflating equipment which complies to regulations and with a pressure
indication in “bar”.
•Only use replacement parts approved by Vermeiren.
To change the tyre or inner tube, proceed as follows:
1. Let all the air out of the inner tube.
2. Insert a tyre lever between de tyre and the rim.
3. Gently push the tyre lever downwards. This will pull the tyre over the edge of the rim.
4. Move the lever along the rim so the tyre pops out.
5. Carefully remove the tyre from the rim and remove the tube.
Before replacing the tyre, check the rim bed and the inside wall of the tyre for foreign matter and
clean these properly if necessary. Check the condition of the rim bed, especially around the
position of the air valve.
Please use only genuine original replacement parts. We do not accept any liability for damage
caused by non-genuine parts. Kindly contact your specialist dealer.
CAUTION
9
10
9
10

Gemini 2
2021-06
Contents
Installation manual
- 9 -
EN
NL
Place the rim belt in position over the air valve before inserting it into the rim. The
rim belt can now be pulled over easily. Check that all spoke heads are covered (a
rim belt is not required in the case of a plastic rim).
Push the tyre over the edge of the rim, starting behind the air valve. Inflate the tube
slightly until it is round, and place it inside the tyre.
If the tube fits inside the tyre without any folds (in case of folds: let out some air),
then the upper side of the tyre can be pressed lightly onto the rim with both hands,
starting at the air valve. Lightly push the air valve inwards and pull it out again to
make sure that the tyre is positioned properly in the region of the air valve.
Check all around on both sides that the tube is not pinched between the rim and the edge of the
tyre. Lightly push the air valve inwards and pull it out again to make sure that the tyre is positioned
properly in the region of the air valve.
To ensure that the wheel inflated correctly, admit only so much air initially that the tyre can still be
easily pushed inwards by using your thumbs. If the check-lines are equidistant from the edge of
the rim on both sides of the tyre, then the tyre is centred properly. If not - let out the air and position
the tyre afresh.
Now the tyre can be inflated to its full operating pressure (note the maximum!!) and the valve cap
should be replaced.

© Vermeiren Group 2021
Vermeiren GROUP
Vermeirenplein 1 / 15
2920 Kalmthout
BE
website: www.vermeiren.com
Instructions for specialist dealer
This instruction manual is part and parcel of the product and must accompany
every product sold.
All rights reserved, including translation.
No part of this manual may be reproduced in any form what so ever (print,
photocopy, microfilm or any other process) without written permission of the
publisher, or processed, duplicated or distributed by using electronic systems.
R.E.: Vermeiren GROUP, Vermeirenplein 1/15 - 2920 Kalmthout –Belgium
Installation manual - Gemini 2_EN_A5_2021-06_A
Basic UDI: 5415174 122103Gemini 2 9D
Version: A, 2021-06
