Invacare TDX 4 Manual

Owner’s Operator and Maintenance Manual
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
TDX™ Wheelchairs
TDX 5, TDX 4, TDX 3,
TDX 3 SE
Wheelchair Base Only

REFERENCE DOCUMENTS
TDX™ Wheelchairs 2Part No 1143150
 WARNING
A QUALIFIED TECHNICIAN MUST PERFORM THE INITIAL SET UP
OF THIS WHEELCHAIR. ALSO, A QUALIFIED TECHNICIAN MUST
PERFORM ALL PROCEDURES IN THE SERVICE MANUAL.
WHEELCHAIR USERS: DO NOT SERVICE OR OPERATE THIS
EQUIPMENT WITHOUT FIRST READING AND UNDERSTANDING
(1) THE OWNER’S OPERATOR AND MAINTENANCE MANUAL
AND (2) THE SEATING SYSTEM’S MANUAL (IF APPLICABLE). IF
YOU ARE UNABLE TO UNDERSTAND THE WARNINGS,
CAUTIONS, AND INSTRUCTIONS, CONTACT INVACARE
TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR
OPERATE THIS EQUIPMENT OTHERWISE INJURY OR DAMAGE
MAY RESULT.
DEALERS AND QUALIFIED TECHNICIANS: DO NOT SERVICE OR
OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND
UNDERSTANDING (1) THE OWNER’S OPERATOR AND
MAINTENANCE MANUAL, (2) THE SERVICE MANUAL (IF
APPLICABLE) AND (3) THE SEATING SYSTEM’S MANUAL (IF
APPLICABLE). IF YOU ARE UNABLE TO UNDERSTAND THE
WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT
INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO
SERVICE OR OPERATE THIS EQUIPMENT OTHERWISE, INJURY
OR DAMAGE MAY RESULT.
REFERENCE DOCUMENTS
Refer to the table below for part numbers of additional documents which are referenced
in this manual.
MANUAL PART NUMBER
MK6i™Programming Guide 1141471
MK6i Service Manual 1143203
TDX Ba e Service Manual 1114819
Adju table ASBA, PTO+ and PTO Owner’ Manual 1143192
Formula™TRE Owner’ Manual 1122170
Invi ible Super Low™Tilt Owner’ Manual 1122132
NOTE: Updated versions of this manual are available on www.invacare.com.

TABLE OF CONTENTS
Part No 1143150 3TDX™ Wheelchairs
TABLE OF CONTENTS
REFERENCE DOCUMENTS ................................................................. 2
REGISTER YOUR PRODUCT................................................................ 4
SPECIAL NOTES ................................................................................ 7
LABEL LOCATIONS ........................................................................... 9
All Wheelchairs...........................................................................................................................................9
Wheelchairs without TRRO..................................................................................................................
Wheelchairs with TRRO ........................................................................................................................ 2
TYPICAL PRODUCT PARAMETERS .................................................. 13
TDX 5 ......................................................................................................................................................... 3
TDX 4 ......................................................................................................................................................... 4
TDX 3 ......................................................................................................................................................... 5
TDX 3 SE.................................................................................................................................................... 6
SECTION 1—GENERAL GUIDELINES ................................................. 17
Repair or Service Information ............................................................................................................... 7
Operation Information............................................................................................................................ 8
Tire Pressure ............................................................................................................................................. 9
Electrical .....................................................................................................................................................20
Batteries......................................................................................................................................................20
Rain Test.....................................................................................................................................................2
Weight Training ........................................................................................................................................2
Weight Limitation.....................................................................................................................................2
SECTION 2—SAFETY/HANDLING OF WHEELCHAIRS ......................... 22
Stability and Balance.................................................................................................................................22
Coping with Everyday Obstacles ..........................................................................................................23
A Note to Wheelchair Assistants ........................................................................................................24
Reaching, Leaning and Bending - Forward ..........................................................................................24
Reaching, Bending - Backward...............................................................................................................25
Pinch Points................................................................................................................................................25
Stairways.....................................................................................................................................................26
Transferring To and From Other Seats ..............................................................................................27
SECTION 3—EMI INFORMATION ..................................................... 28
SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING .................... 3
Safety Inspection Checklists...................................................................................................................30
Troubleshooting - Mechanical ..............................................................................................................32
Troubleshooting - Electrical...................................................................................................................33
Checking Battery Charge Level.............................................................................................................36
SECTION 5—WHEELCHAIR OPERATION ........................................... 37
Operating the Wheelchair......................................................................................................................37

TABLE OF CONTENTS
TDX™ Wheelchairs 4Part No 1143150
TABLE OF CONTENTS
SPJ+, MK6i SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators ....................39
MPJ+ Joystick Switches and Indicators ................................................................................................42
Preparing the Joystick for Use...............................................................................................................47
Repositioning the Joystick.......................................................................................................................48
SECTION 6—SEAT ........................................................................... 49
Tilting the Seat Assembly........................................................................................................................49
SECTION 7—BATTERIES .................................................................. 51
Warnings for Handling and Replacing Batteries ................................................................................5
Using the Proper Batteries.....................................................................................................................52
Removing/Installing the Batteries From/Into the Wheelchair........................................................53
Replacing Batteries ...................................................................................................................................58
Cleaning Battery Terminals....................................................................................................................6
SECTION 8—CHARGING BATTERIES ................................................ 62
When to Charge Batteries.....................................................................................................................62
Charging Batteries ....................................................................................................................................63
SECTION 9—MOTOR LOCKS/FORKS ................................................. 65
Disengaging/Engaging Motor Lock Levers...........................................................................................65
Adjusting Forks .........................................................................................................................................66
SECTION 1 —TRANSPORT READY PACKAGE (TRRO) ...................... 67
About Transport Ready Packages.........................................................................................................68
Compliance Information .........................................................................................................................68
Securing the Wheelchair to the Vehicle .............................................................................................69
Securing the Occupant............................................................................................................................7
GLOBAL LIMITED WARRANTY (EXCLUDING CANADA) ................... 75
CANADA LIMITED WARRANTY ...................................................... 76
REGISTER YOUR PRODUCT
The benefits of registering:
. Safeguard your investment.
2. Ensure long term maintenance and servicing of your purchase.
3. Receive updates with product information, maintenance tips, and industry news.
4. Invacare can contact you or your provider, if servicing is needed on your product.
5. It will enable Invacare to improve product designs based on your input and needs.
Register ONLINE at www.invacare.com
- or -
Complete and mail the form on the next page
Any registration information you submit will be used by Invacare Corporation only, and
protected as required by applicable laws and regulations.

Part No 1143150 5TDX™ Wheelchairs
Name_______________________________________________________________
Address _____________________________________________________________
City ___________________State/Province __________
Zip/Postal Code ________
Email ___________________________________Phone No. _________________
Invacare Model No. ______________________Serial No. __________________
Purchased From _________________________Date of Purchase:___________
1. Method of purchase: (check all that apply)
❏ Medicare ❏ Insurance ❏Medicaid ❏ Other __________________________
2. This product was purchased for use by: (check one)
❏ Self ❏ Parent ❏ Spouse ❏ Other
3. Product was purchased for use at:
❏ Home ❏ Facility ❏ Other
4. I purchased an Invacare product because:
❏ Price ❏ Features (list features) _________________________________________
5. Who referred you to Invacare products? (check all that apply)
❏Doctor ❏ Therapist ❏ Friend ❏Relative ❏Dealer/Provider ❏Other_________
❏ Advertisement (circle one): TV, Radio, Magazine, Newspaper ❏ No Referral_____
6. What additional features, if any, would you like to see on this product?
__________________________________________________________________________
7. Would you like information sent to you about Invacare products that may be available for a
particular medical condition? ❏Yes ❏No
If yes, please list any condition(s) here and we will send you information by email and/or mail about
any available Invacare products that may help treat, care for or manage such condition(s):
__________________________________________________________________________
8. Would you like to receive updated information via email or regular mail about the Invacare
home medical products sold by Invacare's dealers? ❏Yes ❏No
9. What would you like to see on the Invacare website?
__________________________________________________________________________
10. Would you like to be part of future online surveys for Invacare products? ❏ Yes ❏ No
11. User's Year of birth: ______________________________________________________
If at any time you wish not to receive future mailings from us, please contact us at Invacare Corporation,
CRM Department, 39400 Taylor Parkway, Elyria, OH 44035, or fax to 877-619-7996 and we will remove
you from our mailing list.
To find more information about our products, visit www.invacare.com.
PRODUCT REGISTRATION FORM
Register ONLINE at www.invacare.com - or -
Complete and mail this form
Cut Along Line
Fold
here
Fold
here

TDX™ Wheelchairs 6Part No 1143150
Fold
here
Fold
here
Cut Along Line
Invacare Product Registration Form
Please Seal with
Tape Before Mailing

SPECIAL NOTES
Part No 1143150 7TDX™ Wheelchairs
SPECIAL NOTES
Signal words are used in this manual and apply to hazards or unsafe practices which
could result in personal injury or property damage. Refer to the table below for
definitions of the signal words.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO
CHANGE WITHOUT NOTICE.
WHEELCHAIR USER
As a manufacturer f wheelchairs, Invacare endeav rs t supply a wide variety f
wheelchairs t meet many needs f the end user. H wever, final selecti n f the
type f wheelchair t be used by an individual rests s lely with the user and his/her
healthcare pr fessi nal capable f making such a selecti n. Invacare highly
rec mmends w rking with a certified rehab techn l gy supplier and/ r a member
f NRRTS r RESNA.
WHEELCHAIR TIE-DOWN RESTRAINTS AND SEAT RESTRAINTS (TRRO OR
TRBKTS)
TRRO includes f ur fact ry-installed transp rt brackets and a wheelchair anch red
pelvic belt. TRRO has been crash-tested in acc rdance with ANSI/RESNA WC V l 1
Secti n 19 Fr ntal Impact Test requirements f r wheelchairs with a 168 lb crash
dummy, which c rresp nds t a pers n with a weight f 114 t 209 lbs.
TRBKTS includes f ur fact ry-installed wheelchair transp rt brackets. TRBKTS has
n t been crash-tested in acc rdance with WC 19. Use these transp rt brackets nly
t secure an un ccupied wheelchair during transp rt.
As f this date, the Department f Transp rtati n has n t appr ved any tie-d wn
systems f r transp rtati n f a user while in a wheelchair, in a m ving vehicle f any
type. It is Invacare’s p siti n that users f wheelchairs sh uld be transferred int
appr priate seating in vehicles f r transp rtati n and use be made f the restraints
made available by the aut industry. Invacare cann t and d es n t rec mmend any
wheelchair transp rtati n systems.
Refer t Transp rt Ready Package (TRRO) n page 67 f r m re inf rmati n ab ut
transp rting the wheelchair.
SIGNAL WORD MEANING
DANGER
Danger indicate an imminently hazardou ituation which, if not avoided,
will re ult in death or eriou injury.
WARNING
Warning indicate a potentially hazardou ituation which, if not avoided,
could re ult in death or eriou injury.
CAUTION
Caution indicate a potentially hazardou ituation which, if not avoided,
may re ult in property damage.

SPECIAL NOTES
TDX™ Wheelchairs 8Part No 1143150
 TRRO AND TRBKTS WARNINGS
Only use the transp rt brackets included with TRRO and TRBKTS f r the purp ses
described in this manual.
Battery supp rt brackets MUST be installed at all times. Otherwise, the wheelchair
will n t be WC/19 c mpliant. Refer t Rem ving/Installing the Batteries Fr m/Int
the Wheelchair n page 53.
 WARNING
Invacare pr ducts are specifically designed and manufactured f r use in c njuncti n
with Invacare access ries. Access ries designed by ther manufacturers have n t
been tested by Invacare and are n t rec mmended f r use with Invacare pr ducts.
The seat p siti ning strap is a p siti ning belt nly. It is n t designed f r use as a
safety device withstanding high stress l ads such as aut r aircraft safety belts. If
signs f wear appear, belt MUST be replaced immediately.
The drive behavi r initially experienced by the user may be different fr m ther
wheelchairs previ usly used. This p wer wheelchair has Invacare’s SureStep®
techn l gy, a feature that pr vides the wheelchair with ptimum tracti n and
stability when driving f rward ver transiti ns and thresh lds f up t 3-inches f r
TDX 5 and TDX 4 and 2-inches f r TDX 3. The f ll wing warnings apply specifically
t the Sure Step feature:
• DO NOT use n inclines greater than 9°.
• DO NOT use n inclines with wet, slippery, icy r ily surfaces. This may include
certain painted r therwise treated w d surfaces.
• DO NOT traverse d wn ramps at high speed. D ing s will reduce tracti n and
increase st pping distance.
• The end user’s weight can materially affect tracti n n sl ped surfaces. Great
care sh uld be taken when traversing such sl pes.
T determine and establish y ur particular safety limits, practice use f this pr duct
n vari us sl ping surfaces in the presence f a qualified healthcare pr vider bef re
attempting active use f this wheelchair. Other general warnings listed within this
d cument als apply.
Wheelchairs sh uld be examined during maintenance f r signs f c rr si n (water
exp sure, inc ntinence, etc.). Electrical c mp nents damaged by c rr si n sh uld
be replaced IMMEDIATELY.
Wheelchairs that are used by inc ntinent users and/ r are frequently exp sed t
water may require replacement f electrical c mp nents m re frequently.

LABEL LOCATIONS
Part No 1143150 9TDX™ Wheelchairs
LABEL LOCATIONS
All Wheelchairs
Serial Number Label is located on a
plate below the controller.
One of these
labels is on the
inside of battery
tray door,
depending on
battery type.

LABEL LOCATIONS
TDX™ Wheelchairs 0 Part No 1143150
P/N 1118367
Rev A - 3/03
DRIVE
PUSH
CAUTION
Ensure both clutches
are fully engaged
before driving chair
WARNING
USE this
battery
terminal
configuration
Positive
Terminal
Negative
Terminal
Positive
Terminal
Negative
Terminal
P/N 1114848 Rev A - 2/03
Cross Hole
DO NOT use
this battery
terminal
configuration
GP24 batteries with terminal configuration
(negative on the left and positive on the right)
as shown MUST be used. GP24 batteries that
have the reverse terminal configuration MUST
not be used. Terminals MUST have a cross
hole located as shown for proper battery
connection. See Owner's Manual, part number
1114809. These recommendations MUST be
followed otherwise injury and damage may
occur.
WARNING
USE this
battery
terminal
configuration
Positive
Terminal
Negative
Terminal
Positive
Terminal
Negative
Terminal
P/N 1114847 Rev A - 2/03
Cross Hole
DO NOT use
this battery
terminal
configuration
22NF batteries with terminal configuration
(positive on the left and negative on the right)
as shown MUST be used. 22NF batteries that
have the reverse terminal configuration MUST
not be used. Terminals MUST have a cross
hole located as shown for proper battery
connection. See Owner's Manual, part number
1114809. These recommendations MUST be
followed otherwise injury and damage may
occur.
One of these labels is on inside of battery tray door depending on battery type.
Located on each
2-pole motor

LABEL LOCATIONS
Part No 1143150 TDX™ Wheelchairs
Wheelchairs without TRRO
One of these labels will appear on the battery tray and the
battery wiring connector bracket, depending on battery type.
NOTE: Auto style seat
positioning strap shown. This
label is also on the airline style
seat positioning strap.

LABEL LOCATIONS
TDX™ Wheelchairs 2 Part No 1143150
Wheelchairs with TRRO
NOTE: Also on opposite side.
NOTE: Also on opposite side.

TYPICAL PRODUCT PARAMETERS
Part No 1143150 3 TDX™ Wheelchairs
TYPICAL PRODUCT PARAMETERS
TDX 5
ADULT -
ADJUSTABLE
WIDTH
JUNIOR -
ADJUSTABLE
WIDTH
SEAT-TO-FLOOR
LOW:
MEDIUM:
TALL:
17 inche @ 5°
19 inche @ 5°
21 inche @ 5°
OVERALL WIDTH OF BASE: 25 inche without joy tick
OVERALL HEIGHT
LOW:
MEDIUM:
TALL:
with ASBA eat, 0° eat angle
33.25 inche
35.25 inche
37.25 inche
OVERALL LENGTH
WITH CENTER MOUNT FRONT RIGGING:
WITHOUT FRONT RIGGINGS:
42.9 inche @ 0°
35.25 inche
WEIGHT
WITHOUT GP24 BATTERIES:
WITH TWO GP24 BATTERIES:
WITH TRRO:
208 lb
310 lb
add 16 lb
MOTOR: TrueTrack HD Motor Package
DRIVE AXLE: Non-adju table
DRIVE WHEELS/TIRES: 14 x 3-inch Foam Filled or Pneumatic
CASTERS: 6 x 2-inch, Semi-pneumatic with Preci ion Sealed
Bearing
BATTERY REQUIREMENTS: U e MK p/n M24SLDG or p/n M22NFSLDG batterie
only.
ELECTRONICS: MK6i
CONTROLLER: MK6TT
JOYSTICK: MPJ+
SEAT TILT ANGLE ADJUSTMENT: Adju table (0° to 10°)
*WEIGHT LIMITATION: Up to 400 lb Up to 150 lb
NOTE: All dimensions are ± . 0 inches unless otherwise indicated.
*NOTE: Weight limitation is total weight (user weight plus any additional items that the user
may require [back pack, etc.]). Example: If weight limitation of the wheelchair is 300 lbs and
additional items equal 2 lbs, subtract 2 lbs from 300 lbs. This means the maximum weight
limitation of the user is 27 lbs.

TYPICAL PRODUCT PARAMETERS
TDX™ Wheelchairs 4 Part No 1143150
TDX 4
ADULT -
ADJUSTABLE WIDTH
SEAT-TO-FLOOR
LOW:
MEDIUM:
TALL:
17 inche @ 5°
19 inche @ 5°
21 inche @ 5°
OVERALL WIDTH OF BASE: 25.5 inche without joy tick
OVERALL HEIGHT
LOW:
MEDIUM:
TALL:
with ASBA eat, 0° eat angle
33.25 inche
35.25 inche
37.25 inche
OVERALL LENGTH
WITH CENTER MOUNT FRONT RIGGING:
WITHOUT FRONT RIGGINGS:
42.9 inche @ 0°
35.25 inche
WEIGHT
WITHOUT GP24 BATTERIES:
WITH TWO GP24 BATTERIES:
WITH TRRO:
150 lb
250 lb
add 16 lb
MOTOR: 4 Pole HD or True Track HD
DRIVE AXLE: Non-adju table
DRIVE WHEELS/TIRES: 14 x 3-inch Foam Filled
CASTERS: 6 x 2-inch, Semi-pneumatic with
Preci ion Sealed Bearing
BATTERY REQUIREMENTS: U e MK p/n M24SLDG only.
WHEELCHAIR UPHOLSTERY OPTIONS: Nylon
STANDARD ELECTRONICS: MK6i
CONTROLLER: MK690 (4 Pole HD) or MK6TT
(TrueTrack)
JOYSTICK: MPJ+
SEAT TILT ANGLE ADJUSTMENT: Adju table (0° to 10°)
WEIGHT LIMITATION
4 POLE HD OR TRUE TRACK: Up to 400 lb
NOTE: All dimensions are ± . 0 inches unless otherwise indicated.
*NOTE: Weight limitation is total weight (user weight plus any additional items that the user
may require [back pack, etc.]). Example: If weight limitation of the wheelchair is 300 lbs and
additional items equal 2 lbs, subtract 2 lbs from 300 lbs. This means the maximum weight
limitation of the user is 27 lbs.

TYPICAL PRODUCT PARAMETERS
Part No 1143150 5 TDX™ Wheelchairs
TDX 3
ADULT -
ADJUSTABLE
WIDTH
JUNIOR -
ADJUSTABLE
WIDTH
SEAT-TO-FLOOR
LOW:
MEDIUM:
TALL:
17 inche @ 5°
19 inche @ 5°
21 inche @ 5°
OVERALL WIDTH OF BASE: 25 inche without joy tick
OVERALL HEIGHT
LOW:
MEDIUM:
TALL:
with ASBA eat, 0° eat angle
33.25 inche
35.25 inche
37.25 inche
OVERALL LENGTH
WITH CENTER MOUNT FRONT RIGGING:
WITHOUT FRONT RIGGINGS:
42.9 inche @ 0°
35.25 inche
WEIGHT
WITHOUT 22NF BATTERIES:
WITH TWO 22NF BATTERIES:
WITH TRRO:
150 lb
230 lb
add 16 lb
MOTOR: 4 Pole or True Track
DRIVE AXLE: Non-adju table
DRIVE WHEELS/TIRES: 14 x 3-inch Foam Filled (Standard)
CASTERS: 6 x 2-inch, Semi-pneumatic with Preci ion Sealed
Bearing
CASTER FORKS: Two ide fork (Standard), One ided fork (Optional)
BATTERY REQUIREMENTS: U e MK p/n M22NFSLDG batterie only (Standard).
STANDARD ELECTRONICS: MK6i
CONTROLLER: MK690 (4 Pole) or MK6TT (TrueTrack)
JOYSTICK: MPJ+
SEAT TILT ANGLE ADJUSTMENT: Adju table (0° to 10°)
WEIGHT LIMITATION
4 POLE OR TRUE TRACK: Up to 300 lb Up to 150 lb
NOTE: All dimensions are ± . 0 inches unless otherwise indicated.
*NOTE: Weight limitation is total weight (user weight plus any additional items that the user
may require [back pack, etc.]). Example: If weight limitation of the wheelchair is 300 lbs and
additional items equal 2 lbs, subtract 2 lbs from 300 lbs. This means the maximum weight
limitation of the user is 27 lbs.

TYPICAL PRODUCT PARAMETERS
TDX™ Wheelchairs 6 Part No 1143150
TDX 3 SE
ADULT -
ADJUSTABLE
WIDTH
JUNIOR -
ADJUSTABLE
WIDTH
SEAT-TO-FLOOR
LOW:
MEDIUM:
TALL:
17 inche @ 5°
19 inche @ 5°
21 inche @ 5°
OVERALL WIDTH OF BASE: 25 inche without joy tick
OVERALL HEIGHT
LOW:
MEDIUM:
TALL:
with ASBA eat, 0° eat angle
33.25 inche
35.25 inche
37.25 inche
OVERALL LENGTH
WITH CENTER MOUNT FRONT RIGGING:
WITHOUT FRONT RIGGINGS:
42.9 inche @ 0°
35.25 inche
WEIGHT
WITHOUT 22NF BATTERIES:
WITH TWO 22NF BATTERIES:
WITH TRRO:
150 lb
230 lb
add 16 lb
MOTOR: 4 Pole or True Track
DRIVE AXLE: Non-adju table
DRIVE WHEELS/TIRES: 12.5 x 2.25-inch Solid (Standard)
CASTERS: 6 x 2-inch, Semi-pneumatic with Preci ion Sealed
Bearing
CASTER FORKS: Two ide fork (Standard), One ided fork (Optional)
BATTERY REQUIREMENTS: U e MK p/n M22NFSLDG batterie only (Standard).
STANDARD ELECTRONICS: MK6i
CONTROLLER: MK690 (4 Pole) or MK6TT (TrueTrack)
JOYSTICK: SPJ+
SEAT TILT ANGLE ADJUSTMENT: Adju table (0° to 10°)
WEIGHT LIMITATION
4 POLE OR TRUE TRACK: Up to 300 lb Up to 150 lb
NOTE: All dimensions are ± . 0 inches unless otherwise indicated.
*NOTE: Weight limitation is total weight (user weight plus any additional items that the user
may require [back pack, etc.]). Example: If weight limitation of the wheelchair is 300 lbs and
additional items equal 2 lbs, subtract 2 lbs from 300 lbs. This means the maximum weight
limitation of the user is 27 lbs.

SECTION —GENERAL GUIDELINES
Part No 1143150 7 TDX™ Wheelchairs
SECTION 1—GENERAL GUIDELINES
 WARNING
SECTION 1 - GENERAL GUIDELINES c ntains imp rtant inf rmati n f r the safe
perati n and use f this pr duct. DO NOT use this pr duct r any available
pti nal equipment with ut first c mpletely reading and understanding these
instructi ns and any additi nal instructi nal material such as Owner’s Manuals,
Service Manuals r Instructi n Sheets supplied with this pr duct r pti nal
equipment. If y u are unable t understand the Warnings, Cauti ns r Instructi ns,
c ntact a healthcare pr fessi nal, dealer r technical pers nnel bef re attempting
t use this equipment - therwise, injury r damage may ccur.
Repair or Service nformation
Set-up of the Electronics Control Unit is to be performed only by a qualified technician.
he final adjustments of the controller may affect other activities of the wheelchair.
Damage to the equipment could occur if improperly set-up or adjusted.
Except for programming, DO NO service or adjust the wheelchair while occupied,
unless otherwise noted.
A pinch point exists between head tube cap and walking beam.
A pinch point exists between walking beam/head tube cap and telescoping tube when
DX is at the lowest seat to floor height.
Before adjusting, repairing or servicing the wheelchair, ALWAYS turn the wheelchair
power Off, otherwise, injury or damage may occur.
Invacare products are specifically designed and manufactured for use in conjunction with
Invacare accessories. Accessories designed by other manufacturers have not been tested
by Invacare and are not recommended for use with Invacare products.
ransport ready packages are not retrofittable to existing models and are not field
serviceable.
Battery support brackets MUS be installed at all times. Otherwise, the wheelchair will
not be WC/19 compliant. Refer to Removing/Installing the Batteries From/Into the
Wheelchair on page 53.
Wheelchairs should be examined during maintenance for signs of corrosion (water
exposure, incontinence, etc.). Electrical components damaged by corrosion should be
replaced IMMEDIA ELY.
Wheelchairs that are used by incontinent users and/or are frequently exposed to water
may require replacement of electrical components more frequently.

SECTION —GENERAL GUIDELINES
TDX™ Wheelchairs 8 Part No 1143150
Operation nformation
Performance adjustments should only be made by professionals of the healthcare field or
persons fully conversant with this process and the driver's capabilities. Incorrect settings
could cause injury to the driver, bystanders, damage to the wheelchair and to
surrounding property.
After the wheelchair has been set-up/adjusted, check to make sure that the wheelchair
performs to the specifications entered during the set-up procedure. If the wheelchair does
NO perform to specifications, turn the wheelchair Off immediately and reenter set-up
specifications. Repeat this section until the wheelchair performs to specifications.
DO NO leave the power button On when entering or exiting your wheelchair.
DO NO attempt to drive over curbs or obstacles greater than 3 inches for DX 5 and
DX 4 or greater than 2 inches for DX 3. Doing so may cause your wheelchair to turn
over and cause bodily harm or damage to the wheelchair. ALWAYS stop before climbing
an obstacle. Approach slowly until casters contact the obstacle. Apply power and the
action of the SureStep feature will lift the casters over the obstacle. Weight is transferred
to the drive wheels providing traction and motor strength to power the wheelchair over
the obstacle.
DO NO operate on roads, streets or highways.
DO NO climb, go up or down ramps or traverse slopes greater than 9°.
DO NO attempt to move up or down an incline with water, ice or oil film.
DO NO stand on the frame of the wheelchair.
DO determine and establish your particular safety limits by practicing bending, reaching
and transferring activities in the presence of a qualified healthcare professional before
attempting active use of the wheelchair.
DO NO attempt to reach objects if you have to move forward in your seat.
DO NO attempt to reach objects if you have to pick them up from the floor by reaching
between your knees.
DO NO lean over the top of the back upholstery to reach objects behind you, as this may
cause the wheelchair to tip over.
ALWAYS shift your weight in the direction you are turning. DO NO shift your weight
in the opposite direction of the turn. Shifting your weight in the opposite direction of the
turn may cause the inside drive wheel to lose traction and the wheelchair to tip over.
DO NO shift your weight or sitting position toward the direction you are reaching as the
wheelchair and/or seating system (if any) may tip over.
DO NO use an escalator to move a wheelchair between floors. Serious bodily injury may
occur.
DO NO use the footplates as a platform. When getting in or out of the wheelchair, make
sure that the footplates are in the upward position or swing footrests towards the outside
of the wheelchair.
NEVER leave an unoccupied wheelchair unattended on an incline.

SECTION —GENERAL GUIDELINES
Part No 1143150 9 TDX™ Wheelchairs
DO NO attempt to stop a moving wheelchair with the wheel locks. Wheel locks are not
brakes.
DO NO attempt to lift the wheelchair by any removable (detachable) parts. Lifting by
means of any removable (detachable) parts of the wheelchair may result in injury to the
user or damage to the wheelchair.
DO NO overtighten hardware attaching to the frame. his could cause damage to the
frame tubing.
ALWAYS keep hands and fingers clear of moving parts to avoid injury.
ALWAYS wear your seat positioning strap. he seat positioning strap is a positioning belt
only. It is not designed for use as a safety device withstanding high stress loads such as
auto or aircraft safety belts. If signs of wear appear, belt MUS be replaced immediately.
ALWAYS turn the wheelchair power Off and engage the motor locks/clutches to prevent
the wheels from moving before attempting to transfer in or out of the wheelchair. Also
make sure every precaution is taken to reduce the gap distance. Align both casters parallel
with the object you are transferring onto.
DO NO use with a broken or missing joystick knob.
DO NO use if joystick does not spring back to the neutral position or becomes sticky or
sluggish.
DO NO use if joystick boot is torn or damaged.
ALWAYS check foam grips for looseness before using the wheelchair. If loose, contact a
qualified technician for instructions.
ALWAYS engage both wheel locks and reduce the gap distance before transferring to and
from the wheelchair. urn all casters parallel to the object you are transferring onto.
Avoid storing or using the wheelchair near open flame or combustible products. Serious
injury or damage to property may result.
DO NO engage or disengage the motor locks until the power is in the Off position.
Wheelchairs with TRRO or TRBKTS Only
Only use the transport brackets included with RRO and RBK S for the purposes
described in this manual.
Tire Pressure
DO NO use your wheelchair unless it has the proper tire pressure (P.S.I.). DO NO
overinflate the tires. Failure to follow these recommendations may cause the tire to
explode and cause bodily harm. he recommended tire pressure is listed on the side wall
of the tire.

SECTION —GENERAL GUIDELINES
TDX™ Wheelchairs 20 Part No 1143150
Electrical
Grounding Instructions
DO NO , under any circumstances, cut or remove the round grounding prong from any
plug used with or for Invacare products. Some devices are equipped with three-prong
(grounding) plugs for protection against possible shock hazards. Where a two-prong wall
receptacle is encountered, it is the personal responsibility and obligation of the customer
to contact a qualified electrician and have the two-prong receptacle replaced with a
properly grounded three-prong wall receptacle in accordance with the National Electrical
Code. If you must use an extension cord, use only a three-wire extension cord having the
same or higher electrical rating as the device being connected. In addition, Invacare has
placed RED/ORANGE warning tags on some equipment. DO NO remove these tags.
Batteries
he warranty and performance specifications contained in this manual are based on the
use of deep cycle gel cell batteries. Invacare strongly recommends their use as the power
source for this unit.
Carefully read battery/battery charger information prior to installing, servicing or
operating your wheelchair.
Charging Batteries
 DANGER
When using an extensi n c rd, use nly a three wire extensi n c rd having at least
16 AWG (American Wire Gauge) wire and the same r higher electrical rating as
the device being c nnected. Use f impr per extensi n c rd c uld result in risk f
fire and electric sh ck. Three pr ng t tw pr ng adapters sh uld n t be used. Use
f three pr ng adapters can result in impr per gr unding and present a sh ck haz-
ard t the user.
NEVER attempt to recharge the batteries by attaching cables directly to the battery
terminals.
DO NO attempt to recharge the batteries and operate the wheelchair at the same time.
DO NO operate wheelchair with extension cord attached to the AC cable.
DO NO attempt to recharge the batteries when the wheelchair has been exposed to any
type of moisture.
DO NO attempt to recharge the batteries when the wheelchair is outside.
DO NO sit in the wheelchair while charging the batteries.
READ and CAREFULLY follow the manufacturer’s instructions for each charger
(supplied or purchased). If charging instructions are not supplied, consult a qualified
technician for proper procedures.
Ensure the pins of the extension cord plug are the same number, size, and shape as those
on the charger.
