Vermeiren Gemini User manual

VERMEIREN
Gemini
I N S T R U C T I O N M A N U A L

Instructions to the specialist dealer
This instruction manual is part and parcel of the product and must accompany every product sold.
Version: A, November 2011
All rights reserved, including translation.
No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without
written permission of the publisher, or processed, duplicated or distributed by using electronic systems.
© N.V. Vermeiren N.V. 2011

Gemini
2011-11
Page 1
Contents
Preface ......................................................................................................................................2
1 Productdescription......................................................................................................3
1.1 Intended Use................................................................................................................3
1.2 Technical specifications ..............................................................................................4
1.3 Components.................................................................................................................5
1.4 Accessories..................................................................................................................5
1.5 Explanation of symbols...............................................................................................6
1.6 Safety rules..................................................................................................................6
2 Use................................................................................................................................7
2.1 Carrying the wheelchair ..............................................................................................7
2.2 Mounting or removing the rear wheels.......................................................................7
2.3 Unfolding the wheelchair............................................................................................7
2.4 Operating the brakes....................................................................................................7
2.5 Wedge (B22)................................................................................................................8
2.6 Safety belts..................................................................................................................8
2.7 Transfer in and out the wheelchair..............................................................................9
2.8 Correct position in the wheelchair ..............................................................................9
2.9 Riding the wheelchair..................................................................................................9
2.10 Moving on slopes ........................................................................................................9
2.11 Negotiating steps or curbs.........................................................................................10
2.12 Fold up the wheelchair..............................................................................................11
2.13 Transport in the car....................................................................................................11
2.14 Transport in other vehicles........................................................................................12
3 Installation and adjustment.....................................................................................12
3.1 Tools..........................................................................................................................12
3.2 Manner of delivery....................................................................................................12
3.3 Adjusting the seat depth............................................................................................13
3.4 Footrest......................................................................................................................14
3.5 Backrest.....................................................................................................................16
3.6 Seat............................................................................................................................18
3.7 Tyre changing............................................................................................................20
4 Maintenance..............................................................................................................21
4.1 Regular Maintenance.................................................................................................21
4.2 Shipping and storage.................................................................................................22
4.3 Care ...........................................................................................................................22
4.4 Inspection..................................................................................................................23
4.5 Disinfection...............................................................................................................23
5 Guarantee..................................................................................................................25
6 Disposal......................................................................................................................25
7 Declaration of conformity........................................................................................25
8 Maintenance plan......................................................................................................26
9 Disinfection book ......................................................................................................26

Gemini
2011-11
Page 2
Preface
First of all we want to thank you for putting your trust in us by selecting one of our
wheelchairs.
The Vermeiren wheelchairs are the result of many years of research and experience. During
the development, special attention was given to the ease of use and the serviceability of the
wheelchair.
The expected lifetime of your wheelchair is strongly influenced by the care and maintenance
of the wheelchair.
This manual will help you get acquainted with the operation of your wheelchair.
Following the user instructions and the maintenance instructions are an essential part of the
warranty.
This manual reflects the latest product developments. Vermeiren has the right to introduce
changes without the obligation to adapt or replace previously delivered models.
For any further questions, please consult your specialist dealer.

Gemini
2011-11
Page 3
1 Productdescription
1.1 Intended Use
The wheelchair is intended for children with a disability or movement dysfunction through
brain damage.
The wheelchair is designed to transport 1 child.
The wheelchair is suited for indoor and outdoor use in combination with a supervisor.
The Gemini can be pushed by an attendant or the parent.
The modular aluminum construction allows to choose the optimal design in specific need to
your child. Together with a variety of colors for the frame will this chair ensure a physical and
mental happiness for your child.
When providing for individual requirements:
•body size and weight
•physical and psychological condition
•residential circumstances
•environment
should be taken into consideration.
Your wheelchair should only be used on surfaces where all four wheels are touching the
ground and where there is sufficient contact to propel the wheels equally.
You should practice for use on uneven surfaces (cobblestones, etc.), slopes, curves and to
get past obstacles (curbs, etc.).
The wheelchair should not be used as a ladder, nor is it a transport for heavy or hot objects.
When used on mats, carpeted floors or loose floor coverings, the floor covering can get
damaged.
Use only Vermeiren approved accessories.
The manufacturer is not liable for damage caused by the lack of or improper service or as a
result of not following instructions from this manual.
Compliance with the user and maintenance instructions are an essential part of the
guarantee conditions.

Gemini
2011-11
Page 4
1.2 Technical specifications
Technical terms below are valid for the wheelchair in standard settings.
If other footrest or other accessories are used, the tabulated values will change.
Make
Vermeiren
Address
Vermeirenplei
n 1/15, B
-
2920 Kalmthout
Type
Manual wheelchair
Model
Gemini
Description
Gemini 32
Gemini 40
Gemini 45
Maximum occupant mass
35 kg 50 kg 60 kg
Effective seat width
320 mm 400 mm 450 mm
Overall width (depends on the model)
630 mm 690 mm 740 mm
Overall length (footrest open, back in
laying position)
1300 mm 1400 mm 1400 mm
Overall length (footrest closed, back in
seating position)
770 mm 980 mm 980 mm
Folded length
850 mm
without rear wheels:
800 mm
950 mm
without rear wheels:
900 mm
950 mm
without rear wheels:
900 mm
Folded width
610 mm
without rear wheels:
570 mm
670 mm
without rear wheels:
630 mm
720 mm
without rear wheels:
680 mm
Folded height
460 mm
without rear wheels:
350 mm
560 mm
without rear wheels:
460 mm
560 mm
without rear wheels:
460 mm
Total height (including push bar)
1180 mm 1230 mm 1230 mm
Total mass
± 13,5 kg ± 21 kg ± 25 kg
Mass of heaviest part
± 12,5 kg ± 20 kg ± 24 kg
Masses of parts that can be dismantled or
removed Rear wheels: 1 kg Rear wheels: 1 kg Rear wheels: 1 kg
Static stability downhill
10°(in standard configuration)
Static stability uphill
10°(in standard configuration)
Static stability sideways
10°(in standard configuration)
Obstacle climbing
40 mm (when seated correctly)
Seat plane angle
55° 25° 25°
Effective seat depth
280 - 340 mm 360 mm 420 mm
Seat surface height at front edge
500 mm 500 mm 500 mm
Backrest angle
45° 45° 45°
Backrest height
510 – 640 mm 630 – 750 mm 700 – 780 mm
Distance between footrest and seat
250 mm - 340 mm 390 – 450 mm 390 - 450 mm
Angle between seat and footrest
90°- 180° 90°- 180° 90°- 180°
Distance between armrest and seat
200 mm 200 mm 200 mm
Front location of armrest structure
360 - 370 mm 360 - 370 mm 360 - 370 mm
Handrim diameter
Not applicable
Horizontal location of axle (deflection)
230 mm 150 mm 150 mm
Minimum turning diameter
1100 mm 1200 mm
Diameter Krypton PU Rear wheels
310 x 50 (12” ½ x 2” ¼)
Tyre pressure, rear (driving) wheels (for air
tyres)
Max. 2,0 bar
Diameter Krypton PU steering wheels
200 mm x 50 mm

Gemini
2011-11
Page 5
Tyre pressure, steering wheels (for air
tyres)
Max. 2.5 bar
Change the direction of the seat
Yes No No
Storage and use temperature
+ 5 °C + 41 °C
Storage and use humidity
30% 70%
We reserve the right to introduce technical changes. Measuremen
t tolerance
±
1
5
m
m / 1,5 kg
/ °
Table 1: Technical specifications Gemini
The wheelchair complies to the requirements set up in:
ISO 7176-8: Requirements and test methods for static, impact and fatigue strengths.
1.3 Components
1.4 Accessories
The following accessories are available for the Gemini:
•Clamps
These clamps are made in a specific shape coated with foam making contact very
gentle. The clamps are connected to the frame of the side supports with special tube
locks. By letting the tubes of the clamps hinge, two possible positions become
available (high or low position).
•Foot belts
The feet of your child can easily be held into place by usage of the foot belts made
out of Velcro strips.
•Collapsible cover
The accessory enhances the comfort of the Gemini. Special holes in the frame of the
Gemini are made to fix the cover. It suffices to lock the ends of the cover into the
holes. Depending on the needs, the cover can open or closed.
•Table
•Barrier
We offer a wide range of interesting and useful additional elements for the Gemini, which will
increase the comfort and usefulness of the Gemini. Please refer to your local dealer for more
information on the available options.
1 = Push bar
2 = Headrest (upper part backrest)
3 = Backrest
4 = Arm supports
5 = Driving wheels (rear wheels)
6 = Frame
7 = Brakes
8 = Steering wheels (Front wheels)
9 = Seat
10 = Footrest
11 = Footplate
1
2
3
4
5
6
7
8
9
10
11

Gemini
2011-11
Page 6
1.5 Explanation of symbols
Maximum mass
Indoor and outdoor use
Down slope
Up slope
CE conformity
Not crash-tested
1.6 Safety rules
L To prevent injury and/or damage to your wheelchair, make sure that no objects
and/or body parts are caught in the driving wheels.
L The parking brakes should be applied before getting into and out the Gemini.
L When getting into and out the wheelchair, do not stand on the footplate. These
should be folded up beforehand.
L Investigate the effects of shifting the centre of gravity on the behavior of the wheelchair,
for example on up or down gradients, on laterally sloping ground, or when overcoming
obstacles. Obtain support from an attendant.
L If you want to pick up something (lying in front of, on the side, or to the rear of the
wheelchair), you should not lean too far out to avoid tipping over.
L When moving through doors, arches, etc. ensure that there is enough room at the sides
so that you do not get your hands or arms caught or crushed and that there is no
damage to the wheelchair.
L Only use your wheelchair according to regulations. For example, avoid uncontrolled
rolling against obstacles (steps, curbs, doorframes, etc) or dropping down from ledges.
The manufacturer cannot assume liability for damage caused by overloading, collision
or other improper use.
L Stairs may only be negotiated when aided by another person. If furnishings like drive-on,
ramps or lifts are available, use them.
L When moving on the public highway, you are subject to the rules of the road.
L When travelling outdoors, adapt your driving to weather and traffic conditions.
L When transporting the wheelchair, never pick it up by grasping movable parts (footrest,
rear wheels, etc.).
L To be better visible when driving in the dark, wear the brightest possible clothing or
clothes with reflectors, and check that the reflectors mounted on the sides and rear of
the wheelchair are clearly visible.
L Be careful when using possible causes of fire such as cigarettes since they may set the
seat and back covers alight.
L Never exceed the maximum load.
L Check the profile depth and the inflation pressure of the tyres.
L Only use a Gemini which has been adjusted to the weight and length of the child.
L The Gemini cannot be tipped too much backwards because the shift of the centre of
gravity may cause the Gemini to flip backwards.
L The person who operates the wheelchair must be aware of the responsibility of his
actions concerning the correct usage of the Gemini.

Gemini
2011-11
Page 7
2 Use
This chapter describes the everyday use. These instructions are for the user and the
specialist dealer.
The wheelchair is delivered fully assembled by your specialist dealer. The instructions
intended for the specialist dealer on how to set up the wheelchair are given in § 3.
2.1 Carrying the wheelchair
The best way to carry the wheelchair is to make use of the wheels and roll the wheelchair.
If this is not possible (e.g. when the rear wheels are taken off for transportation in a car),
firmly grasp the frame on the front and the grips. Do not use the footrest or the wheels to
grasp the wheelchair.
Also is it possible to fold the Gemini for a pretty easy transport.
2.2 Mounting or removing the rear wheels
L
LL
L CAUTION: Risk of injury – Check that the rear wheels are correct mounted with
the quick release axle (B80) before using the Gemini.
The fast and safe removal of the wheels is very convenient for transport in smaller cars.
By usage of the special axles B80, a fast removal is possible. Use your thumb to press the
button on the wheels to the inside. After that, the wheel can be removed.
For mounting the wheels again, the same procedure needs to be followed. Push the button
on the axle and slide the axle in the wheel to lock it into position.
Improper assembly or use of tyres other than ours voids any warranty claim.
2.3 Unfolding the wheelchair
L
LL
L CAUTION: Risk of clamping – Keep fingers away from moving parts of the
wheelchair.
1. Mount the rear wheels.
2. Unfold the full frame of the Gemini, by unfolding the tubes.
3. Fold the frame of the backrest backwards and place the headrest in a
comfortable position for the child.
4. Unfold the footrest.
2.4 Operating the brakes
L
LL
L WARNING: The brakes are not used to slow down the wheelchair during
movements – Use the brake only to prevent the wheelchair from unintended
movements.
L
LL
L WARNING: Good operation of the brakes is influenced by wear and
contamination of the tires (water, oil, mud, …) – Check the condition of the tires
before each use.
L
LL
L WARNING: The brakes are adjustable and can wear – Check the operation of the
brakes before each use.
L
LL
L CAUTION: Risk of unintended movement – Make sure the wheelchair is on a flat
horizontal surface before releasing the brakes. Never release both brakes
simultaneously.
The person who is pushing the Gemini is responsible for the correct usage of the brakes and
the usage of them on both wheels. The Gemini has been equipped with separate brakes for
each wheel.

Gemini
2011-11
Page 8
A brake with blocking clamps which will be pushed against the wheel when the pedal is
being pushed. By pushing on the upper pedal, the brake will be released.
A good performance of the breaks depends on the correct tyre pressure.
If the brakes have lost their effectiveness because of wear and tear and/or damage to the
tyres and inner tubes, we advise you to consult your specialist dealer to renovate the
system, since he has suitable tools and knowledge.
Improper maintenance or the use of unsuitable tools might cause damage and/or loss of
function.
2.5 Wedge (B22)
By default, a wedge, covered with textile, is mounted on the seating element. It will prevent
your child from sliding out of the Gemini. The wedge has been mounted by a screw (M6). It
can easily be adjusted by loosening/tightening the screw.
The usage of the wedge depends on the physical and mental condition of your child.
2.6 Safety belts
L
LL
L WARNING: Risk of injury – Make sure all the safety belts are locked into place
before driving the Gemini.
Every Gemini has been equipped with adjustable belt to the purpose of a correct and safe
seating position. These belts have an adjustable length and are mounted to the seating
frame. The ends are connected to each other by means of a central lock.
After applying the safety belts to your child, you need to hear an auditable clicking sound to
make sure the belts are locked into place. Push the buttons on the locks to release them
again. The belts can only be adjusted after the locks are into place.
Adjusting the safety belts
Adjusting the length of each belt is done individually by shortening or extending the length of
each belt by means of the buckles.

Gemini
2011-11
Page 9
The connection points of the belts on the plate of the back support can be located in different
positions depending on the size of your child. To do so, the shoulder belts need to go
through the oval openings in the back support and retightened again.
The correct procedure of adjusting the length of the safety belts and the power by
which they are drawn will influence the safety and driving comfort of your child.
In case of questions regarding the locking and safety systems, please refer to our dealers.
2.7 Transfer in and out the wheelchair
L
LL
L CAUTION: Risk of tipping over of the wheelchair – Do not stand on the footplate.
1. Position the wheelchair as close as possible to the chair, couch or bed to/from you wish to
transfer.
2. Check both brakes from the wheelchair are in the on position.
3. Fold the footplate upwards to prevent standing on them.
4. Transfer the child to/from the wheelchair.
2.8 Correct position in the wheelchair
Some recommendations for a comfortable use of the wheelchair:
•Position your backside as close as possible to the back rest.
•Make sure your upper legs are horizontal – If needed adjust the length of the footrest.
(see § 3.4.2)
2.9 Riding the wheelchair
L
LL
L WARNING: Risk of clamping – Be careful passing through restricted passages
(e.g. doors).
L
LL
L WARNING: Risk of burns – Be careful when driving in hot or cold environments
(sunshine, extreme cold, saunas, etc.) for a sufficient amount of time and when
touching - Surfaces can assume the environment temperatures.
1. Release the brakes.
2. Take the push bar.
3. Push the wheelchair by an attendant or parent.
The Gemini has been equipped with rubber pushing handles, which have been mounted, on
a adjustable clamp. This will make it easier for the person who pushes the Gemini and
remain a firm grip under different driving circumstances.
Setting the clamp
Simultaneously, push both buttons at the clamp and lock in the desired position. Releasing
the buttons will automatically lock the clamp in the desired position.
2.10 Moving on slopes
L
LL
L WARNING: Control your speed – Moving on slopes as slow as possible.
L
LL
L WARNING: Consider the capacities of your attendant – If your attendant does not
have enough force to control the wheelchair, put on the brakes.
L
LL
L WARNING: Risk of tipping over – Lean forward to move your centre of gravity
forward. To improve a better stability.

Gemini
2011-11
Page 10
1. If available on the wheelchair, wear the safety belt.
2. Do not attempt moving on too high slopes. The maximum slope angles (upwards and
downwards) are mentioned in table 1.
3. Lean forward to move your centre of gravity forward.
4. Push the wheelchair up or down the slopes.
2.11 Negotiating steps or curbs
2.11.1 Getting down steps or curbs
Riding down curbs can be done moving forwards. Make sure that the footrest do not touch
the ground.
1. Ask the attendant/parent to tip the wheelchair slightly backwards.
2. Get past the curbs while moving on the rear wheels.
3. Put the wheelchair back on the four wheels.
2.11.2 Moving up steps or curbs
Moving up steps or curbs with attendant as follows:
1. Prevent the footrest from touching the curbs.
2. Ask the attendant to tip the wheelchair backwards, just enough to move the front
wheels over the curbs.
3. Lean backwards to move your centre of gravity above the rear wheel.
4. Place the front wheels on the curbs.
5. Roll rear wheels of the wheelchair over the curb.
Higher curbs are negotiated backwards:
1. Turn the wheelchair to have the rear wheels facing the curbs.
2. Lean backwards and move your centre of gravity above the rear wheels.
3. Ask the attendant to pull the wheelchair on the curbs.
4. Take back the normal position in the wheelchair.
2.11.3 Taking of stairs
Taking of stairs while you staying in the wheelchair shall be according following rules:
L
LL
L WARNING: Risk of tipping over – Taking of stairs shall always with 2 attendants.
L
LL
L WARNING: Risk of injury – Lifting the wheelchair while the patient is seated in
the wheelchair is forbidden! Always keep the rear wheels on the ground/stairs.
L
LL
L WARNING: Risk of injury – Wear suitable safety belt systems while being
transported (information obtainable from your specialist dealer).
L
LL
L WARNING: Risk of injury or damages – No persons or objects should be below
the wheelchair while being transported.
1. Remove the accessories.
2. One attendant tip the wheelchair slightly backwards.
3. The second attendant take the front of the frame.
4. Stay calm, avoid sudden movements and keep your arms inside the wheelchair.
5. Take the steps on the rear wheels of the wheelchair.
6. Mounting the accessories back after taking the stair.

Gemini
2011-11
Page 11
2.11.4 Using ramps
L
LL
L WARNING: Risk of injury – Do not exceed the maximum load of the ramps.
L
LL
L WARNING: Risk of injury - Choose the correct ramps so there cannot be caused
any injury or damage. We do not accept any liability for injury or damage caused
by an improper choice of ramps.
L
LL
L WARNING: Risk of injury - Be sure that the wheel height is high enough to get
over the free height of the ramps. The wheelchair frame may not touch the
ramps.
L
LL
L WARNING: Risk of injury - Use a restraining safety belt to secure yourself in your
wheelchair.
L
LL
L WARNING: Risk of tipping over - Put the adjustment functions (seat--horizontal,
back--vertical, ...) that the wheelchair has the best stability.
If you are considering the installation of ramps to overcome obstacles, kindly note the
following: Never go up or down ramps without the aid of a helper.
2.12 Fold up the wheelchair
L
LL
L CAUTION: Chance of pinching – Do not place fingers between the components
of the wheelchair.
1. Follow the instructions regarding the folding of the footplate and if needed remove or
shorten the undercarriage of the footrest.
2. Fold the frame of the backrest into the direction of the seat (as far as possible) and
shorten the headrest if needed.
3. At the same time, pull both sliders upwards. Due to the folding of the tube, the full
frame of the Gemini folds.
4. Remove the rear wheels.
2.13 Transport in the car
L
LL
L DANGER: Risk of injury – The wheelchair is not suited for use as a seat in a
motor vehicle.
L
LL
L WARNING: Risk of injury – See that the wheelchair is attached properly. So you
can avoid injury from the passengers during collision or sudden braking.
L
LL
L WARNING: Risk of injury – Use for attaching the wheelchair and passenger
NEVER the same seatbelt.
Never use your wheelchair as a seat in an automobile or other vehicle. The wheelchair shall
be marked with following symbol.
To transport the wheelchair in the car use following steps:
1. Remove accessories.
2. Store accessories safely.
3. Fold up the footrest.
4. If possible, fold the wheelchair and remove the rear wheels.
5. Place the wheelchair in the luggage place.
6. If the wheelchair and the passenger compartment is NOT separated, attach the
frame of the wheelchair securely to the vehicle. You can use the available safety
belts in the vehicle.

Gemini
2011-11
Page 12
2.14 Transport in other vehicles
Examples of other vehicles are airplanes, buses, ships, trams, trains etc. You should ask the
service officials about travelling safely with your wheelchair to your intended destinations
and about the applicable requirements.
The wheelchair can be transported in an airplane. The wheelchairs shall be checked at the
desk. Announce the wheelchair on time by the concern airline before departure. Do not use
the wheelchair as a seat in an airplane or other vehicles, the wheelchair must be stored in
the luggage place.
To transport the wheelchair in an airplane note the following requirements:
1. Dimensions and weight of the wheelchair
The allowable weight and dimensions of the wheelchair depends on the type of the
airplane.
2. Damage on the wheelchair
It is possible that the wheelchair could be damaged because the wheelchair will be
stored in a narrow area with the suitcases and other goods.
To prevent damage on the wheelchair:
•Remove the accessories.
•Fold the footrest upwards and fold up the wheelchair.
•Check that the adjustment levers are positioned inwards.
Before travelling contact the concern airline about their requirements for transporting
the wheelchair in an airplane or other vehicle.
3 Installation and adjustment
The instructions in this chapter are for the specialist dealer.
The Vermeiren wheelchairs Gemini has been designed entirely for your comfort.
To find a service facility or specialist dealer near you, contact the nearest Vermeiren facility.
A list of Vermeiren facilities can be found on the last page.
L
LL
L WARNING: Risk of unsafe settings - Use only the settings described in this
manual.
L
LL
L WARNING: Variation of allowed adjustments can still change the stability of your
wheelchair (tilt back or sideways).
3.1 Tools
To set up the wheelchair the following tools are needed.
•Wrench set n°10 to n°19
•Allen key set n°4 to n°5
•Screwdriver Phillips head
For the Gemini 40 and 45 you do not need tools.
3.2 Manner of delivery
The Vermeiren Gemini shall be delivered with:
•1 frame structure
•rear wheels mounted on a fast-lock system (B80) and front wheels
•footrests with adjustable inclination and length
•back (inclinable with adjustable height
•removable seat with adjustable inclination and depth

Gemini
2011-11
Page 13
•parking brakes
•side support (L03)
•wedge (B22)
•head cushion
•safety belts
•tools
•manual
•accessories (optional)
•air pump (with pneumatic tyres only)
Before use check if everything is included and that no products are damaged (example by
transport, ...).
When delivered, your product has been set to be used in proper conditions. Only the length
of the footrest, the ideal inclination of the backrest and seat need to be adjusted to your own
specifications (follow the instructions in this manual).
3.3 Adjusting the seat depth
The function (not available on Gemini 40 and Gemini 45) to alter the depth of the seat can
be used after loosening the bolts (M6) on the seating plate (The needed tools are included in
the package) and sliding the full segment into the desired position. The range of the
adjustment is about 60 mm, which, in combination with the range of other adjustments of the
Gemini, allows a wide variety of adjustments.

Gemini
2011-11
Page 14
3.4 Footrest
L
LL
L WARNING: Risk of injury – Check that the footrest is securely locked in
place before use.
L
LL
L WARNING: Risk of injury – Check the screw connections are secured before
using the footrest.
L
LL
L WARNING: Risk of injury, stability – Check the position of the adjustment knobs
every time to prevent that they would be in a position that would endanger the
user.
L
LL
L WARNING: Risk of injury, stability – Never stand on the footrest.
L
LL
L CAUTION: Risk of clamping – Keep objects and people away from the footrest
swing range.
The foot support of the Gemini consists out of:
1. A foldable footplate
2. Undercarriage with blocking pins
3. Hinged upperparts with regulating strips
Fig. 1: Footrest standard Gemini
The foot support segment is connected to the seat module through a plate, which acts as a
depth regulator for the seat. This design allows your child to put its legs in any desired
position.
3.4.1 Positions of the footplate
By default the footplate is in a horizontal position.
With the emphasis on transport and rehabilitation and getting out of the Gemini, the footplate
must be turned into the direction of the undercarriage of the foot support.
The footplate has been equipped with limiters at the rear and the sides to prevent
uncontrollable sliding of the feet. As additional security, foot belts (B19) have been
implemented.
3.4.2 Adjusting the length of the footrest
Gemini (Fig. 1):
Due to the super design of the Gemini, the footrest can be set into 4 different lengths: 250 –
280 – 310 - 340 mm (steps: 30 mm).
Adjust them as follows:
•Retract both blocking pins.
•Adjust the undercarriage of the foot support into the desired position.
•Block the undercarriage again with the blocking pins

Gemini
2011-11
Page 15
Gemini 40 and 45 (Fig. 2):
The design of Gemini 40 and 45 provides a gradual change in the length of the footrest.
The footrest of the Gemini 40 and 45 can be changed in 3 different lengths:
390 - 420 - 450 mm (steps: 30 mm)
Adjustments are made as follows:
• Pull the two locking pins .
• Move the footplate up- or downwards until the desired length.
• Retighten the two locking pins again.
Fig. 2 Footrest Gemini 40 and 45
3.4.3 Adjusting the inclination of the footrest
Gemini (Fig. 1):
The adjustment of the inclination of the foot support to a range of 60°, in combination with
other adjustments, will increase the possible positions of the Gemini.
Adjust them as follows:
•Turn both adjustment knobs from the regulator strips loose.
•Adjust to optimal inclination for the footrest.
•Retighten both adjustment knobs again.
Gemini 40 and 45 (Fig. 2):
Changing the angle of the footrest can be in the range of 60 °. To raise the footrest to the
top, pull on the upper frame , for the chosen location. The footrest shall be automatically
locked in position.
Lowering the footrest should be performed as follows:
• Pull the lever upwards.
• Determine the location of the upper frame .
• Release the lever which locks automatically.
For a correct adjustment of the footrest, turn to your specialist dealer who will support you
with professional advice and technical support.
In case the disorder of your child makes the correct adjustment of the footrest difficult, turn to
your specialist dealer who will find a suitable and proper solution.

Gemini
2011-11
Page 16
3.5 Backrest
L
LL
L WARNING: Risk of injury – Check the backrest is well fixated.
The Gemini has been equipped with a back with adjustable inclination and adjustable height.
In combination with the adjustable seat and footrest will the Gemini provide optimal settings
for your child.
Depending on individual needs, two types of side supports (L03) can be mounted and will
increase the comfort and safety of its users.
3.5.1 Adjusting the inclination of the back
Gemini:
In the back part of the metal frame is a slider located that can be locked with the adjustment
handle M6. The release of this handle will ensure a seaming less transition from folded-
position (easy for transport) to a laying-position. The laying-position has been secured with
limiters.
The frame needs to be locked again, by means of adjusting handle M6, after adjusting the
position of the back.
Gemini 40 and 45:
On the rear of the backrest frame is a rod and blocked fixing pin .
1. Pull the pin to change the angle of the backrest.
2. Pull or push on the backrest until the desired angle (6 different positions in steps of
8,5 mm). The maximum angle is when the rod hits the blocking pin .
There is an extra hole (hole 7), that prevents that the backrest will be lift back in
the vertical position when the backrest is folded to the seat.
3. Release the pin .
4. Check that the backrest is well fixated.

Gemini
2011-11
Page 17
3.5.2 Adjusting the height of the back
L
LL
L WARNING: Risk of injury – Check the all connections and bolts are secured
before using the Gemini.
L
LL
L WARNING: Risk of tipping over – Do not place more weight on the back
(example: a backpack or shopping bag). This will cause overweight at the back
and may cause the Gemini to tip backwards, which can cause injuries to the user
of the Gemini! Adding additional elements to the Gemini is only allowed after
careful consideration and in collaboration with one of our retailers.
1. Loosen the two butterfly nuts on the back of the backrest.
2. Move the upper part (headrest) of the backrest upwards or downwards until the
desired backrest height (510 - 640 mm for Gemini, 630 - 750 mm for Gemini 40 and
700 - 780 for Gemini 45).
3. Retighten the two screws and wing nuts firmly by hand.
On the board of backrest are 2 pairs of holes for the safety belts. This is an additional
adjustment depending on the personal needs of each user.

Gemini
2011-11
Page 18
3.6 Seat
3.6.1 Rotating the seat
L
LL
L WARNING: Risk of tipping over – Be aware that you change the stability of your
wheelchair because the center of gravity shall changed.
The construction of the Gemini (not available on Gemini 40 and Gemini 45) makes it very
easy to adjust the inclination of the seat angle and the depth of the seat. Also a full
conversion of the orientation of the seating parts towards the person who is pushing the
Gemini has been made very easy and fast to accomplish.
3.6.2 Adjusting the inclination of the seat
Gemini:
Releasing the 2 adjustment bars at the bottom allows the full module to turn in a range of
55°.
