VERSARE Quick-Wall Folding User manual

Assembly Instructions
Versare Solutions, LLC
3236 California St. NE • Minneapolis, MN 55418
1-855-457-1473 • [e-mail]
100045 REV CW
Quick-Wall Folding (Wheel A) Page 1
Quick-Wall Sliding (Wheel A) Page 6
Wall Bracket Set Page 13
Work Station (Wheel A) Page 10
Quick-Wall Folding (Wheel B) Page 4
Quick-Wall Sliding (Wheel B) Page 8
Work Station (Wheel B) Page 12

1
Quick-Wall Folding
Assembly Instructions
If wheels are desired, screw two wheels
onto each foot with one washer and one
nut per wheel. If not using wheels skip
to step 4.
1.
Hardware included:
Feet Screws
Bolts
Wheels
Washers Nuts
Button
Screws
++
++
+
+
2.
To attach wheel to panel, locate square nut in bottom track of outer panel and
slide to outer edge. Add three washers to wheel threading and screw into square
nut. Repeat for remaining wheels.

2
Remove two bolts from outside, bottom edge of each outer panel and one
screw from the side of each outer panel. Then attach foot base with bolts first,
screws second. Repeat for other side. Assemblly complete.
++
+
1st 2nd
Important:
All bolts & screws
must be reinserted in
feet brackets for
proper use.
+
3.
+
+
4.
If not using wheels, insert button head
screw down into foot end and secure
with two washers and a nut. Repeat for
other side of foot. Repeat for second
foot.

3
Remove two bolts from outside, bottom edge of each outer panel and one
screw from the side of each outer panel. Then attach foot base with bolts first,
screws second. Repeat for other side.
++
+
1st 2nd
Important:
All bolts & screws
must be reinserted in
feet brackets for
proper use.
+
5.
+
+
Assembly complete!
We hope you enjoy your new Quick-Wall Folding!
For questions regarding your Quick-Wall Folding please contact us at
1-855-457-1473 or
[e-mail]

4
Quick-Wall Folding
Assembly Instructions
Hardware included:
Feet (type B)
Screws
Bolts
Wheels
Washers Nuts
If wheels are desired, screw two wheels
onto each foot with one washer and one
nut per wheel. If not using wheels skip
to step 3.
1.
++
++
+
+
2.
To attach wheel to panel, locate square nut in bottom track of outer panel and
slide to outer edge. Add three washers to wheel threading and screw into square
nut. Repeat for remaining wheels.

Remove a bolt and two screws from outer panel. Then attach foot base with
bolt first, screws second. Repeat for other side.
+
++
++
1st 2nd
Important:
All bolts & screws
must be reinserted in
feet brackets for
proper use.
Assembly complete!
We hope you enjoy your new Quick-Wall Folding!
For questions regarding your Quick-Wall Folding please contact us at
1-855-457-1473 or
[e-mail]
5

6
Quick-Wall Sliding
Assembly Instructions
Hardware included:
Feet
Screws
Bolts
Wheels
Washers Nuts
Button
Screws
Screw two wheels onto each foot with
one washer and one nut per wheel.
1.
2.
To attach wheel to panel, locate square nut in bottom track of outer panel and
slide to outer edge. Add three washers to wheel threading and screw into square
nut. Repeat for remaining wheels.
+
+ +
+
++

7
Assembly complete!
We hope you enjoy your new Quick-Wall Sliding!
For questions regarding your Quick-Wall Sliding please contact us at
1-855-457-1473 or
[e-mail]
Remove two bolts from outside, bottom edge of each outer panel and one
screw from the side of each outer panel. Then attach foot base with bolts first,
screws second. Repeat for other side.
1 st 2
nd
Important:
All bolts & screws
must be reinserted in
feet brackets for
proper use.
3.
+
+

8
Quick-Wall Sliding
Assembly Instructions
Hardware included:
Feet (type B)
Screws
Bolts
Wheels
Washers Nuts
Screw two wheels onto each foot with
one washer and one nut per wheel.
1.
2.
To attach wheel to panel, locate square nut in bottom track of outer panel and
slide to outer edge. Add three washers to wheel threading and screw into square
nut. Repeat for remaining wheels.
+
+ +
+
++

9
Remove a bolt and two screws from outer panel. Then attach foot base with
bolt first, screws second. Repeat for other side.
+
++
+
1 st 2
nd
Important:
All bolts & screws
must be reinserted in
feet brackets for
proper use.
3.
+
+
Assembly complete!
We hope you enjoy your new Quick-Wall Sliding!
For questions regarding your Quick-Wall Sliding please contact us at
1-855-457-1473 or
[e-mail]

Work Station Screen
Assembly Instructions
10
Hardware included:
Feet
Screws
Bolts
Washers Nuts
Button
Screws
Insert button head screw down into foot
end and secure with two washers and a
nut. Repeat for other side of foot. Repeat
for second foot.
1.
Remove two bolts from
outside, bottom edge of
outer panel(s) and one
screw from the side of
outer panel(s). Then attach
foot base with bolts first,
screws second. Repeat for
other side.
1st
2nd
Important:
Bolts must be
reinserted for proper
use of feet base.
2.

Assembly complete!
We hope you enjoy your new Work Station!
For questions regarding your Work Station please contact us at
1-855-457-1473 or
[e-mail]
+
+
+
3.
11

Work Station Screen
Assembly Instructions
Remove two bolts. Then attach feet
base with bolts first, screws second.
Hardware included:
1.
Feet (type B) Screws Bolts
Assembly complete!
We hope you enjoy your new Work Station!
For questions regarding your Work Station please contact us at
1-855-457-1473 or
[e-mail]
12

13
Wall Mount Bracket Set
Assembly Instructions
Hardware included:
1.
Bolts ScrewsBrackets
Gently place partition on its side. Remove
any bolts from top and bottom of the
end of the panel.
2.
Once bolts are removed,
attach brackets to corners
with two bolts included
with bracket kit.

14
Helpful Tips:
* Use two people for installation. One to hold panels
flush to the wall and one to attach brackets to the wall.
4.
Use four screws per wall plate to
attach to wall.*
3.
Find and mark stud in wall to anchor wall
plates to. Lock wheels and carefully lift panels
into place next to wall.
Assembly complete!
For questions regarding your Wall Mount Bracket Set please contact us at
1-855-457-1473 or [e-mail]
