Vertiv NetSure 211 Series User manual

NetSure™ 211 SERIES
-48 VDC Battery Cabinet
Installation and User Manual (Section 6023), Revision L
Specification Number: 541434
Model Number: 211BC

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
2
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution has
been taken to ensure the accuracy and completeness of this document, Vertiv
assumes no responsibility and disclaims all liability for damages resulting from
use of this information or for any errors or omissions. Refer to other local
practices or building codes as applicable for the correct methods, tools, and
materials to be used in performing procedures not specifically described in
this document.
The products covered by this instruction manual are manufactured and/or
sold by Vertiv. This document is the property of Vertiv and contains
confidential and proprietary information owned by Vertiv. Any copying, use or
disclosure of it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of
the respective companies. Any questions regarding usage of trademark
names should be directed to the original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the
pertinent section of this manual to see if the issue can be resolved by following outlined
procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
3
TABLE OF CONTENTS
Admonishments Used in this Document............................................................4
Important Safety Instructions ..............................................................................5
Safety Admonishments Definitions......................................................................................................5
General Safety ...........................................................................................................................................................5
DC Voltages.................................................................................................................................................................5
Battery .............................................................................................................................................................................. 6
Personal Protective Equipment (PPE)..............................................................................................7
Hazardous Voltage...............................................................................................................................................7
Introduction ...............................................................................................................9
Description...................................................................................................................................................................9
Batteries..........................................................................................................................................................................9
Specifications ..........................................................................................................................................................10
Installation................................................................................................................10
Important Safety Instructions .................................................................................................................10
General Requirements....................................................................................................................................10
Mounting the Battery Cabinet................................................................................................................10
Relay Rack Method....................................................................................................................................................11
Wall Method......................................................................................................................................................................11
Connecting Battery Cabinet(s) to the Associated Power System.....................13
Installing Enersys SBS15 Batteries .....................................................................................................15
Installing Fiamm 12SLA12 Batteries...................................................................................................16
Installing EaglePicher HE-12V12.7FR Batteries...................................................................... 17
Installing Eaglepicher HE-12V7.7FR Batteries.........................................................................19
Installing Enersys NP18-12FR Batteries........................................................................................20
Securing the Batteries Using the Strap........................................................................................ 25
Typical Internal Wiring Layout...............................................................................................................27

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
4
ADMONISHMENTS USED IN THIS DOCUMENT
DANGER
! Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided. (ANSI, OSHA)
WARNING
! Warns of a potential hazard the reader may be exposed to that could
result in
death or serious injury if not avoided. This admonition is not used for situations that pose a
risk only to equipment, software, data, or service. (ANSI)
CAUTION
! Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided. (ANSI, OSHA) This admonition is not
used for situations that pose a risk only to equipment, data, or service, even if such use
appears to
be permitted in some of the applicable standards. (OSHA)
ALERT
! Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service. (ISO)
ALERT
! Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data loss, or service interruption. (ISO)
FIRE SAFETY
! Informs the reader of fire safety information, reminders, precautions,
or
policies, or of the locations of fire-fighting and fire-safety equipment. (ISO)
SAFETY
! Informs the reader of general safety information, reminders, precautions, or
policies not related to a particular source of hazard or to fire safety. (ISO, ANSI, OS
HA)

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
5
IMPORTANT SAFETY INSTRUCTIONS
Safety Admonishments Definitions
Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this
Document” on page 4.
General Safety
DANGER! YOU MUST FOLLOW APPROVED SAFETY PROCEDURES.
Performing the following procedures may expose you to hazards. These procedures should be
performed by qualified technicians familiar with the hazards associated with this type of equipment.
These hazards may include shock, energy, and/or burns. To avoid these hazards:
a) The tasks should be performed in the order indicated.
b) Remove watches, rings, and other metal objects.
c) Prior to contacting any uninsulated surface or termination, use a voltmeter to verify that no voltage
or the expected voltage is present. Check for voltage with both AC and DC voltmeters prior to
making contact.
d) Wear eye protection.
e) Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for
the work to be performed.
DC Voltages
DANGER! THIS SYSTEM CONTAINS BATTERIES
Although the DC voltage is not hazardously high, the battery can deliver large amounts of current.
Exercise extreme caution not to inadvertently contact or have any tool inadvertently contact a battery
terminal or exposed wire connected to a battery terminal. NEVER allow a metal object, such as a tool, to
contact more than one termination or battery terminal at a time, or to simultaneously contact a
termination or battery terminal and a grounded object. Even a momentary short circuit can cause
sparking, explosion, and injury.

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
6
Battery
Refer to the battery manufacturer documentation for specific battery safety instructions. The following are
general guidelines.
WARNING! Correct polarity must be observed when connecting battery leads.
WARNING! Special safety precautions are required for procedures involving handling, installing, and
servicing batteries. Observe all battery safety precautions in this manual and in the battery instruction
manual. These precautions should be followed implicitly at all times.
WARNING! A battery can present a risk of electrical shock and high short circuit current. Servicing of
batteries should be performed or supervised only by properly trained and qualified personnel
knowledgeable about batteries and the required precautions.
The following precautions should be observed when working on batteries:
•Follow the recommended PPE requirements per the SDS for the battery to be used.
•Batteries are an energy source that can produce high amounts of electrical current.
•Remove watches, rings, and other metal objects.
•Eye protection should be worn to prevent injury from accidental electrical arcs.
•Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for
the work to be performed. Ensure that wrenches with more than one working end have only one
end exposed.
•Do not lay tools or metal parts on top of batteries.
•Verify that no current will flow when the battery is connected or disconnected by opening battery
disconnects (if available) or adjusting the system to match battery voltage.
•Risk of explosion if battery is replaced with an incorrect type or if polarity is reversed.
Recommended to replace batteries with the same manufacturer and type, or equivalent.
•Dispose of used batteries according to the instructions provided with the batteries. Do not dispose
of batteries in a fire. They may explode.
•Batteries may generate explosive gases during normal operation. Systems containing batteries
should never be installed in an airtight room or space. Only install in a ventilated environment.
•Batteries may contain sulfuric acid. If battery acid enters your eye, immediately flush your eye with
running cold water for at least 15 minutes. Get medical attention immediately. If battery acid
contacts skin or clothing, wash immediately with soap and water.
•Do not open or mutilate batteries.
•ALWAYS FOLLOW THE BATTERY MANUFACTURER’S RECOMMENDATIONS AND SAFETY
INSTRUCTIONS.

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
7
ALERT! Performing maintenance and/or troubleshooting procedures may interrupt power to the loads,
if battery reserve is not sufficient.
Personal Protective Equipment (PPE)
DANGER! ARC FLASH AND SHOCK HAZARD.
Appropriate PPE and tools required when working on this equipment. An appropriate flash protection
boundary analysis should be done determine the “hazard/risk” category, and to select proper PPE.
This product is intended only for installation in a Restricted Access Location.
Only authorized and properly trained personnel should be allowed to install, inspect, operate, or maintain
the equipment.
Do not work on LIVE parts. If required to work or operate live parts, obtain appropriate Energized Work
Permits as required by the local authority, per NFPA 70E “Standard for Electrical Safety in the
Workplace”.
Hazardous Voltage
DANGER! HAZARD OF ELECTRICAL SHOCK.
More than one disconnect may be required to de-energize the system before servicing.

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
8
This page is intentionally blank.

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
9
INTRODUCTION
Description
The NetSure™ 211 Series -48 VDC battery cabinet can be mounted in a 19” or 23” relay rack or mounted to a
wall. The battery cabinet contains one (1) 40 A battery disconnect circuit breaker and provides alarm leads
attached to the common contacts of the breaker.
Battery cabinets may be daisy chained as shown in Figure 7to increase the reserve time. However, a maximum
system current of 30 amps should be maintained regardless of the number of interconnected cabinets.
Figure 1: NetSure™ 211 Series -48 VDC Battery Cabinet
Batteries
The battery cabinet is designed to hold the batteries listed in Table 1.
Table 1: Batteries
Battery
Manufacturer
Manufacturer
P/N
Vertiv Co.
P/N
Rated 8-Hr.
Capacity (Ah)
Weight (lbs.)
per Battery
Enersys SBS15 139091 14 12.50
Fiamm
12SLA12
139092
12
12.35
EaglePicher
HE-12V12.7FR
139093
11.6 *
9.70
EaglePicher HE-12V7.7FR 139094 6.9 6.40
Enersys
NP18-12FR
139774
16 *
13.60

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
10
Specifications
Environmental Ratings
•Operating Ambient Temperature Range: -40 °C to +65 °C.
•Storage Ambient Temperature Range: -40 °C to +85 °C.
•Humidity: This unit is capable of operating in an ambient relative humidity range of 0% to 95%,
non-condensing.
•Altitude: The maximum operating ambient temperature should be derated by 10 °C at an elevation of
10,000 feet above sea level. For elevations between 3,000 feet and 10,000 feet, derate the maximum
operating ambient temperature linearly.
Overall Dimensions
Battery cabinet dimensions are illustrated in Figure 2.
Figure 2: Battery Cabinet Dimensions
INSTALLATION
Important Safety Instructions
DANGER! Adhere to the “Important Safety Instructions” starting on page 5.
General Requirements
The installer should be familiar with the installation requirements and techniques to be used in securing the
battery cabinet to a relay rack or wall.
Mounting the Battery Cabinet
The battery cabinet is designed to mount on a wall or a standard 19” or 23” wide relay rack.
9.06”
6.94”
17.50”

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
11
Relay Rack Method
Procedure
1. Refer to Figure 3and install the 19” or 23” relay rack mounting angles to the battery cabinet. Mounting
hardware is provided with the battery cabinet. Torque these connections to 46 in-lbs.
NOTE! There are three mounting locations for the mounting angles providing different projections in
front of the relay rack.
Figure 3: Installing Mounting Angles on the Battery Cabinet
2. Install battery retention strap through openings in rear of cabinet. Orient the buckle per Figure 28.
3. Secure the battery cabinet to the relay rack with the provided 12-24 x 1/2” hex head thread-forming
screws (six per side) (P/N 218710500) and #12 ground washers (three per side) (P/N 215640600).
Torque these connections to 35.0 in-lbs.
Wall Method
WARNING! Ensure the technique and hardware used in securing the battery cabinet can support the
total weight of the battery cabinet and the four (4) batteries. Refer to “Batteries” on page 9 for a battery
weight reference table. If being mounted to a stud wall, the cabinet must be fastened to the studs.
Failure to mount the cabinet correctly may result in serious personal injury or equipment damage.
Procedure
1. Ensure that connector, wires and bushing located at the back are moved to the side, as shown in Figure
4, before mounting the cabinet.
2. Install battery retention strap through openings in rear of cabinet. Orient the buckle per Figure 28.

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
12
Figure 4: Connectors and Wires Moved to the Side
3. Install the frame ground landing point adapter P/N 556872 to the left or right side of the battery cabinet,
as shown in Figure 5.
Figure 5: Installing P/N 556872 Frame Ground Landing Point Adapter
4. Mount the battery cabinet to a wall through the two 0.406” diameter holes on the back of the cabinet, as
shown in Figure 6. If mounting to a stud wall, secure the battery cabinet to the studs.
5. Ensure the technique and hardware used in securing the cabinet can support the total weight of the
cabinet and the batteries. Refer to “Batteries” on page 9 for a battery weight reference table.
Frame Grounding Point
(1/4-20 Studson 5/8” Centers)
(Torque to 75 in-lbs)
Attach Frame Ground Landing
Point Adapter to Cabinet
(Torque to 46 in-lbs)

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
13
Figure 6: Mounting the Battery Cabinet to a Wall
Connecting Battery Cabinet(s) to the Associated Power System
Battery Leads
Cables with connectors are provided on the associated power system and the battery cabinet to allow simple
interconnections between a battery cabinet and the associated power system and between battery cabinets.
The battery cabinet is designed to be daisy-chained together with additional battery cabinets. There is no limit
to the number of battery cabinets that can be connected together. However, a maximum system current of
30 A should be maintained regardless of the number of interconnected battery cabinets.
Procedure
NOTE! Refer to Figure 7 as this procedure is performed.
1. Connect the power system’s battery cable terminated in an Anderson connector to the first battery
cabinet’s battery cable terminated in a mating Anderson connector.
2. Connect the second battery cabinet’s battery cable terminated in an Anderson connector to the fixed
mating Anderson connector located on the first battery cabinet.
3. Repeat the above step if there are additional battery cabinets.
Customer-supplied
mounting hardware
WALL
Two 0.406”
mounting holes

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
14
Figure 7: Connecting Multiple Battery Cabinets
Battery Disconnect Circuit Breaker Alarm Leads
Procedure
1. Furnished with the battery cabinet are battery disconnect circuit breaker alarm lead assemblies. Refer
to the power system installation manual to use these alarm leads to connect the battery cabinet battery
disconnect circuit breaker alarm into the power system alarm circuits.
NOTE! Supplied with the battery cabinet is a yellow alarm lead assembly P/N 545696 and an orange
alarm lead assembly P/N 565513. P/N 545696 is always used. P/N 565513 is used only with power
systems containing a 1M831ANA Mini Controller (may be discarded if battery cabinet is used with other
systems).
POWER SHELF
BATTERY CABINET
MAIN
BATTERY CABINET
SUPPLEMENTAL
(OPTIONAL)
BATTERY CABINET
SUPPLEMENTAL
(OPTIONAL)

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
15
Installing Enersys SBS15 Batteries
Procedure
1. Place the batteries inside the cabinet. Refer to Figure 8.
2. Insert a spacer between the batteries.
Figure 8: Placing Enersys SBS15 Batteries
3. Connect all four Enersys batteries using supplied wires (Part Number 541420) crimped with 12-10 AWG
ring lug on each end, as shown in Figure 9.
Figure 9: Connecting Enersys SBS15 Batteries
4. Attach the cabinet wires to + and - terminals. Refer to Figure 10.
Enersys SBS15
Batteries
Spacers
Supplied
quick
connect
lug
Supplied
quick
connect
lug
+ Wire - Wire
Supplied
cables

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
16
Figure 10: Connecting Enersys SBS15 Batteries to (+) and (-) Terminals
5. Refer to “Securing the Batteries Using the Strap” on page 25 for instructions on securing the batteries
using the buckle strap that is bundled along with the cabinet.
Installing Fiamm 12SLA12 Batteries
Procedure
1. Place the batteries inside the cabinet. Refer to Figure 11.
2. Insert a spacer between the batteries.
Figure 11: Placing Fiamm 12SLA12 Batteries
3. Connect all four Fiamm batteries using supplied wires (Part Number 541420) crimped with 12-10 AWG
ring lug on each end, as shown in Figure 12.
Enersys
SBS15
Batteries
+ Wire - Wire
Spacers
Fiamm 12SLA12
Batteries

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
17
Figure 12: Connecting Fiamm 12SLA12 Batteries
4. Attach the cabinet wires to + and - terminals. Refer to Figure 13.
Figure 13: Connecting Fiamm 12SLA12 Batteries to (+) and (-) Terminals
5. Refer to “Securing the Batteries Using the Strap” on page 25 for instructions on securing the batteries
using the buckle strap that is bundled along with the cabinet.
Installing EaglePicher HE-12V12.7FR Batteries
Procedure
1. Place the batteries inside the cabinet. Refer to Figure 14.
2. Break each spacer at its score line and insert between the batteries.
+ Wire
- Wire
Supplied
cables
Supplied
quick
connect
lug
Supplied
quick
connect
lug
Fiamm
12SLA12
Batteries
+ Wire - Wire

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
18
Figure 14: Placing EaglePicher 12V12.7FR Batteries
3. Connect all four EaglePicher batteries using supplied wires (Part Number 541424) crimped with 12-10
AWG Faston receptacle on each end, as shown in Figure 15.
Figure 15: Connecting EaglePicher 12V12.7FR Batteries
4. Attach the cabinet wires to + and - terminals. Refer to Figure 16.
Spacers
EaglePicher
HE-12V12.7FR
Batteries
Supplied
cables
+Wire
- Wire

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
19
Figure 16: Connecting EaglePicher HE-12V12.7FR Batteries to (+) and (-) Terminals
5. Refer to “Securing the Batteries Using the Strap” on page 25 for instructions on securing the batteries
using the buckle strap that is bundled along with the cabinet.
Installing Eaglepicher HE-12V7.7FR Batteries
Procedure
1. Place the batteries inside the cabinet. Refer to Figure 17.
2. Break each spacer at its score line and insert between the batteries.
Figure 17: Placing EaglePicher 12V7.7FR Batteries
3. Connect all four EaglePicher batteries using wires (Part Number 541424) crimped with 12-10 AWG
Faston receptacle on each end, as shown in Figure 18.
EaglePicher
HE-12V12.7FR
Batteries
+ Wire
- Wire
EaglePicher
HE-12V7.7FR
Batteries
Spacers

Vertiv™ NetSure™ 211 SERIES -48 VDC Battery Cabinet Installation & User Manual (Section 6023)|Rev. L
20
Figure 18: Connecting EaglePicher 12V7.7FR Batteries
4. Attach the cabinet wires to + and - terminals. Refer to Figure 19.
Figure 19: Connecting EaglePicher 12V7.7FR Batteries to (+) and (-) Terminals
5. Refer to “Securing the Batteries Using the Strap” on page 25 for instructions on securing the batteries
using the buckle strap that is bundled along with the cabinet.
Installing Enersys NP18-12FR Batteries
A parts kit (P/N 545427), which is purchased in addition to the cabinet includes the following pieces:
•(1) Long rear spacer
•(8) Fast-on terminals
•(3) Fast-on lugged cables
•Mounting hardware
Supplied
cables
+ Wire
- Wire
Supplied
cables
EaglePicher
HE-12V7.7FR
Batteries
+ Wire - Wire
