Vestax PMC-05ProD User manual

(b) C.F. FINE CONTROL
PROFESSIONAL MIXING CONTROLLER
FUNCTIONS
The replacement crossfader unit for PMC-05ProD is
"CF-X".
"CF-05PRO","CF-PCV" cannot be substituted in this
mixer.
OWNER'S MANUAL
Vestax Corporation
1-18-6 Wakabayashi, Setagaya-ku, Tokyo 154-0023 Japan
Phone [phone] Fax [phone]
Web : www.vestax.jp
Vestax (Europe) Ltd.
Unit 5 Riverwey Industrial Park Alton Hampshire GU34 2QL England, U.K.
Phone [phone] Fax [phone]
Web : www.vestax.co.uk
Vestax Technical Center of America
8489 W. Third Street Ste. 1044 Los Angleles, CA 90048
Phone [phone] Fax [phone]
TOP PANEL
CURVE PATTERN SWITCH (a) selects the crossfader
curve pattern.
Setting the C.F. FINE CONTROL to minimum, the
crossfader curve is most sharp,moving the control
clockwise,towards max,gradually reduces the
sharpness of the curve (b).
Thank you for purchasing the VESTAX PMC-05ProD. Please read this owner's manual carefully before you start to
use in order to understand fully how it to operate your new mixer.
CONGRATULATIONS!
FEATURES
The new Vestax Digital Fader System consists of coils and a permanent magnet.There is no contact between
these parts.Therefore,neither the element or magnet gets degraded or damaged even after hard usage.
Unlike an optical type fader,the digital fader system does not get effected even by liquid spills or dusts.
Control of the fader curve by a complete digital signal system, enabling creation of sharp edges in the curve
pattern.
