SERVICEMANUAL - EN
REFRIGERATORS
BIOMEDICAL SOLUTIONS
models - R-90i- R-138i- R-427i

Vestfrost Solutions 3
EN
CONTENTS
ACCESS TO COMPONENTS � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Top panel � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Fan � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Sensors � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Engine room & electrical box � � � � � � � � � � � � � � � � � � � � � � � 9
Display - with integrated keyboard � � � � � � � � � � � � � � � � � � � 10
REPLACEMENT OF DOOR � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
COOLING SYSTEM � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
Change compressor � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
ELECTRICAL SYSTEM � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
Wire diagram R-90i � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
Wire diagram R-138i � � � � � � � � � � � � � � � � � � � � � � � � � � � 17
Wire diagram R-427i � � � � � � � � � � � � � � � � � � � � � � � � � � � 18
SPARE PARTS� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 20
Spare parts exploded view R-90i� � � � � � � � � � � � � � � � � � � � � 20
Spare parts list R-90i � � � � � � � � � � � � � � � � � � � � � � � � � � � 21
Spare parts exploded view R-90i Glass door � � � � � � � � � � � � � � 22
Spare parts list R-90i Glass door � � � � � � � � � � � � � � � � � � � � 23
Spare parts exploded view R-138i � � � � � � � � � � � � � � � � � � � � 24
Spare parts list R-138i � � � � � � � � � � � � � � � � � � � � � � � � � � 25
Spare parts exploded view R-138i Glass door � � � � � � � � � � � � � 26
Spare parts list R-138i Glass door � � � � � � � � � � � � � � � � � � � � 27
Spare parts exploded view R-427i � � � � � � � � � � � � � � � � � � � � 28
Spare parts list R-427i � � � � � � � � � � � � � � � � � � � � � � � � � � 29
Spare parts exploded view R-427i Glass door � � � � � � � � � � � � � 30
Spare parts list R-427i Glass door � � � � � � � � � � � � � � � � � � � � 31
LIST OF PARAMETERS � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 32
List of default parameters R-90i, R-138i, R-427i � � � � � � � � � � � � 32
List of LCP parameters R90-i, R-138i, R-427i � � � � � � � � � � � � � � 33
List of LCS parameters R-90i, R-138i, R-427i � � � � � � � � � � � � � � 34

4 Vestfrostsolutions.com EN
ATTENTION!
Before servicing or cleaning
the appliance, unplug the
appliance from the mains
or disconnect the electrical
power supply�
ATTENTION!
This service manual is in-
tended for use by persons
having electrical and me-
chanical training and a level
of knowledge of these sub-
jects generally considered
acceptable in the appliance
repair trade�The manufac-
turer cannot be responsible,
MAINTENANCE SCHEDULE
TASK SCHEDULE
Cleaning of interior Weekly
Cleaning of compressor compartment
(including condenser and compressor)
Monthly
Cleaning of sealing in the door Quarterly
Replacement of battery for back up Every third year
All below maintenance is recommended.
Please investigate the local legislation in your area.
nor assume any liability, for
injury or damage of any kind
arising from the use of this
manual�
ATTENTION!
Bare pcbs are sensitive to
ESD, so please take precau-
tions to ensure that tools,
persons and appliance is
equalised�
ATTENTION!
Compressor and tubes can be
hot, please allow the unit to
cool down before repairing�

Vestfrost Solutions 5
EN
Top panel
1. Loosen the screws see picture
2. Pull the top panel straight out and
place it on top of the unit.
3. Unplug the wires from connector
Note!
Be careful not to damage electric wires
and not to scratch the unit when placing
the top panel upside down.
1
2
ACCESS TO COMPONENTS
TASK SCHEDULE
Cleaning of interior Weekly
Cleaning of compressor compartment
(including condenser and compressor)
Monthly
Cleaning of sealing in the door Quarterly
Replacement of battery for back up Every third year

6 Vestfrostsolutions.com EN
Fan
The location and number of fans may
vary, but the procedure for access is
identical, except for the number of
screws to be removed.
To access the plate with fans, start by remov-
ing all shelves and any drawers.
R-138i
R-90i
R-427i

Vestfrost Solutions 7
EN
1. Remove the screws (4 in R-90i and
R-138i, 10 in R-427i)
2. Flip out the fan sheet and discon-
nect the fan
3. When replacing fan, fan grill must
also be replaced
4. Press together 4 fan grill fasteners
and push to release

8 Vestfrostsolutions.com EN
Sensors
1. Remove the screws, 4- 10 in ventila-
tor plate (4 in R-90i and R-138i, 10 in
R-427i) and 2 in air guide step plate.
A. TR3 Temperatur sensor
B. EVP Defrost sensor
C. TL1 Logging sensor
D. S1 Safety thermostat sensor
B
C
D
A

Vestfrost Solutions 9
EN
Engine room & electrical box
1. Remove 4 screws in the engine
room cover
2. For access to the electrical box
remove 2 screws
3. Slide out the electrical box

10 Vestfrostsolutions.com EN
Display - with integrated keyboard
1. Tilt the appliance and release the
touch panel by pushing in the plast
lock and lifting up the panel simul-
tanously
2. Carefully demount the plug/wire
from the touch panels back side

Vestfrost Solutions 11
EN
Start by disassembling the Display with
integrated keyboard (see previous page)
Place the unit on its back (we recom-
mend 2 people)
To avoid damage, place some soft pad-
ding under the unit.
Remove foot
Remove base plate (2 screws)
REPLACEMENT OF DOOR

12 Vestfrostsolutions.com EN
Pull out the wire
Place the unit in an upright position
Loosen the 4 screws
Pull the top panel straight out and place
it on top of the unit.
1
2

Vestfrost Solutions 13
EN
Remove the handle by removing the 2
screws.
Remove top hinge by removing the 2
screws.
Change the door by lifting it up from the
bottom hinge.

14 Vestfrostsolutions.com EN
Follow the above steps in reverse order
and the door change is complete.

Vestfrost Solutions 15
EN
Change compressor
COOLING SYSTEM
Repairs to the cooling system may only
be carried out by trained professionals.
When changing the compressor, the
filter drier must also be replaced.
Is is important to cut out the filter drier,
as heating with solder flame will release
moisture inside the dry filter. This will
vaporize and drive moisture from filter
drier back into system.
The quantity and type of the refrigerant
used in your appliance is indicated on the
rating plate.
Do not make sharp bending angels on
the pipes.
The distance between the pipes must be
at least 12 millimetres.

16 Vestfrostsolutions.com EN
Wire diagram R-90i
WH WH
Wire diagram
1006641-04
RD BK
RD
BK
7090453
7010563 21pcs LED5050
7512001
OR
BK
WH
WH
WH
WH
BN
WH BN
BK VI
7510252
7090050
BK RD BK
RD BK RD
BK RD
7511507
7090352
7512042
YG YG
6510012 FMXA4C
7512005
7021063 Mermaid config 2
BK WH
YG
BK YG WH
7080029
WH
BK
BK BU BN WH
RD BK
YG
BK VI
7090466 PSU kit
BK OR
WH WH
WH BN
WH BN
7512008
7512009
7512006
6520047 CF02D01 freq.
7512013
BN
WH
7512007
7060046
BK RD
GN
3: COM
2: NO/NC
1: not used
7512004
BK WH
7080123 7080124
BK
WH
WH
BN
Screen
YE
GN
BN
WH
7512122
YE GN
YE
GN
YE
WH
YE
GN
7021043
WH
YE GN BN
7060262
ELECTRICAL SYSTEM

Vestfrost Solutions 17
EN
Wire diagram R-138i
WH WH
Wire diagram
1006646-04
RD BK
RD
BK
7090453
7010563 21pcs LED5050
7512001
OR
BK
WH
WH
WH
WH
BK VI
7510252
BK RD BK
RD BK RD
7511507
7512042
YG YG
6510012 FMXA4C
7512005
7021063 Mermaid config 2
BK WH
YG
BK YG WH
7080029
WH
BK
BK BU BN WH
RD BK
YG
BK VI
7090466 PSU kit
BK OR
7512008
7512009
7512006
6520047 CF02D01 freq.
7512013
BN
WH
7512007
7060046
BK RD
BK RD
2x 7090461
BK RD
3: COM
2: NO/NC
1: not used
7512004
BK WH
7080123 7080124
BK
WH
WH
BN
Screen
YE
GN
BN
WH
7512123
BN
WH BN
7090050
WH WH
WH BN
WH BN
GN
YE GN
YE
GN
YE
WH
YE
GN
7021043
WH
YE GN BN
7060262

18 Vestfrostsolutions.com EN
Wire diagram R-427i
WH WH
Wire diagram
1006660-05
RD BK
RD
BK
7090453
7010563 21pcs LED5050
7512096
OR
BK
WH
WH
WH
WH
BK VI
7510252
7090058
BK RD
7511510
7512098
YG YG
6510012 FMXA4C
7512005
7021063 Mermaid config 2
BK WH
YG
BK YG WH
7080029
WH
BK
BK BU BN WH
RD BK
YG
BK VI
7090466 PSU kit
BK OR
7512008
7512009
7512006
6520047 CF02D01 freq.
7512013
BN
WH
7512007
7060046
BK RD
BK RD
2x 7090461
BK RD
3: COM
2: NO/NC
1: not used
7512004
BK WH
7080123 7080124
BK
WH
WH
BN
Screen
YE
GN
BN
WH
7512124
BN
WH BN
WH WH
WH BN
WH BN
GN
YE GN
YE
GN
YE
WH
YE
GN
7021043
WH
YE GN BN
BK RD BK RD BK RD
7060262

20 Vestfrostsolutions.com EN
SPARE PARTS
Spare parts exploded view R-90i
