Service manual
Service manual
FUNCTION wine cooler
FUNCTION wine cooler
Version A – November 2005

2
1. Access to evaporator, ventilator and heating element
2. Location of top and bottom sensor and sensor for frost
protection thermostat
3. Access to hinge with adjustable foot, lock and control panel.
4. Dismounting of control panel ”Remote control”.
5. Dismounting of cover for terminal box in engine room
Location of frost protection thermostat
6. Door magnet switches off the light when the door is opening
7. Location of type plate and description of data on type plate
8. Resistance values of temperature sensor
9. Replacement of bottom sensor
10. Reversible door
11. Replacement of light bulb/light fitting
Service manual FUNCTION wine cooler

2
1. Access to evaporator, ventilator and heating element.
1. Pull front plate from evaporator clips
Clips
2. Dismount 2 screws in front of the box
3. Dismount 2 screws at the bottom of the box

16-01-20064
3
1. Ventilator box 2. Heating element mounted with 4 screws
1. Access to evaporator, ventilator and heating element.
Back side, ventilator shield mounted with 4 screws Back side of heating element

4
Top sensor
Top sensor mounted in retainer
Sensor for frost protection thermostat and bottom sensor
Lead-in from engine room. Must be isolated!
Sensor for frost protection
thermostat fitted in container Bottom
sensor
fitted
in retainer
2. Location of top and bottom sensor and sensor for frost
protection thermostat

16-01-20066
1. Tip outwards with straight slot screwdriver
2. Remove cover from the column
3. Unscrew catch for lock
4. Take up catch and remove cylinder
5. Unscrew 2 cross slot screws
6. Dismount 4mm Allen screws
and remove the column.
Hereafter, the base plate can be
dismounted from the cabinet.
3. Access to hinge with adjustable foot, lock and control panel

6
1. Unscrew screws in control panel
2. Hereafter, the control panel can be pulled free from the base plate
Back side of operating panel.
The control panel consists of:
Remote control
ETC1H, thermostat
ON/OFF print
If this (control panel)
is defect, it is recommended that the
entire unit is replaced!
4. Dismounting of control panel “Remote control”

16-01-20068
1. Place a straight slot screwdriver
in the cover
2. Hereafter, pull cover backwards
Location of frost protection thermostat.
Frost protection thermostat
”Black” lead from control panel comes from the front along and under the
bottom and plug fitted in terminal box.
Terminal box
5. Dismounting of cover for terminal box in engine room.
Location of frost protection thermostat

8
The magnet is placed under the door
Magnet in retainer fastened with
clips up under the door
Magnet
Retainer
Micro switch (light)
On/off light switch
The light will be switched off all the time if
the light switch is positioned at off
6. Door magnet switches off the light when the door is opening
On/off switch
If the ventilator is operating when the door is being opened, this is switched off.

16-01-200610
Placed in the right side of the inner container
Model.
Serienummer.
Produktnummer.
Kølemiddel– fyldemængde.
9
7. Location of type plate and description of date on type plate
Model Serial number
Product number Cooling agent – filling quantity

10
The sensors are the same and the resistance values are as follows:
Temperature Resistance
30°C 4.029ohm
25°C 5.000 ohm
20°C 6.246 ohm
15°C 7.855 ohm
10°C 9.951 ohm
5°C 12.696 ohm
0°C 16.330 ohm
-15°C 36.503 ohm
-18°C 43.329 ohm
-20°C 48.614 ohm
-25°C 65.335 ohm
-30°C 88.765 ohm
8. Resistance values of temperature sensor

11
Defect sensor is cut app. 100 mm from the box
New sensor is fitted and assembled with
Scotchlok UY2 connector!
Scotchlok UY2 connector.
Sensor kit ”service” FUNTION.
Spare part number0-A97038764 consists of.:
1 x 0-7038764 Sensor 3.0m
2 x 0-7038676 Scotchlok UY2 connector.
9. Replacement of bottom sensor

12
1. Lay the appliance on
its back and loosen the
upper hinge.
2. Remove the upper
hinge. 3. Rotate the glass door
through 180˚. (On FZ 295
W, pull the handle to loosen
it on the inside from beneath
the sealing strip)
4. Carefully remove the
covers on the side of the
plinth using a flat-headed
screwdriver.
5. Pull up the hinge pin…
…and fit it on the opposite
side
6. Unscrew the lock pin
using a flat-headed
screwdriver
7. When the lock pin has
been loosened completely,
pull it up together with the
lock cylinder and refit on
opposite side
8. Click the covers into place
on the plinth sides on the
opposite side
9. Fit the door onto the
bottom pin, fit the top hinge
and tighten securely
10. After reversing the door, it is important to check that the sealing strip provides a tight seal all the way round. If it does not, carefully heat the strip all the way
round using a hair dryer. Then ease the strip outwards slightly so that it forms a tight seal against the cabinet. Be careful not to heat the strip so much that it melts.
The door can be changed from right-hinged to left-hinged and vice versa as follows:
10. Reversible door

13
Push lightly, and the glass can be removed from the fitting
Light fitting
Fitting can be dismounted by unscrewing
the screws
PL-S 11 watt tube Phillips.
Pull out PL-S tube
11. Replacement of light bulb/light fitting
